  1. Home/
  2. Intermec Technologies Corporation/
  3. EHADHIB

EHADHIBDHIB

Intermec Technologies Corporation
DHIB - FCC ID EHADHIB - Intermec Technologies Corporation
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 10, 2006
Application Purpose
Original Equipment
Date of Application
Sep 10, 2006
Equipment Note
DHIB
Frequency Range
2402.00000000 - 2480.00000000
Company
Intermec Technologies Corporation
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗
↗

Cover Letter(s)

↗
↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Document Number: 632194 Rev: A Page 1 of 4 DHIB Compliance Insert For Users in the United States and Canada For Users Outside of the United States or Canada Caution: This marking indicates that the user should read all included documentation before use. This product conforms to the following approvals. The users of this product are cautioned to use accessories and peripherals approved by Intermec Technologies Corporation. The use of accessories other than those recommended, or changes to this product that are not approved by Intermec Technologies Corporation, may void the compliance of this product and may result in the loss of the user’s authority to operate the equipment. Class B Compliant Products FCC Digital Emissions Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the radio or television receiving antenna. • Increase the separation between the computer equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the radio or television receiver is connected. • Consult the dealer or an experienced radio television technician for help. Canadian Digital Apparatus Compliance This Class B digital apparatus meets all requirements of the Canadian Interference- Causing Equipment Regulations. Document Number: 632194 Rev: A Page 2 of 4 Caution: The battery pack used in this device may ignite, create a chemical burn hazard, explode, or release toxic materials if mistreated. Do not incinerate, disassemble, or heat above 100°C (212°F). Charge only with Intermec Models AC14, AD10, AD11, AD12 or AV6. Do not short circuit; may cause burns. Keep away from children. Use only Intermec battery pack Model AB8 or AB9. Use of incorrect battery pack may present a risk of fire or explosion. Promptly dispose of used battery pack according to the instructions. Battery Recycling Information This product contains or uses a lithium ion (Li-ion) main battery. When the battery reaches the end of its useful life, the spent battery should be disposed of by a qualified recycler or hazardous materials handler. Do not mix this battery with the solid waste stream. Contact your Intermec Technologies Service Center for recycling or disposal information. Note: In the U.S.A., the EPA does not consider spent Li-ion batteries as hazardous waste. Caution: For Power Supply use Intermec Model (list model number(s) here). No user-serviceable parts. Laser and Imager Compliance and Precaution (Rest of World) This product complies with the following standards for LED safety: IEC 60825-1 / EN 60825-1 - Class 1 LED Product Important Radio Information For Users in the United States and Canada Place this supplement in your manual. This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that can cause undesired operation. Caution: Changes or modifications not expressly approved by Intermec could void the user’s authority to operate this equipment Document Number: 632194 Rev: A Page 3 of 4 For Users Outside the United States and Canada Intermec Technologies Corporation declares that this module is in compliance with the essential requirements and other relevant provisions of R&TTE Directive (1999/5/EC). The transmitter module’s output power is 646 mW. The products using this module are intended for business and industrial environments. They should not be used in residential environments and by children. This product is marked with this logo and uses radio frequency bands that are not harmonized throughout the European Community. The following table indicates the areas of intended use of the equipment and any known restrictions. Country of License Intended Use Yes No Required Restrictions Details Austria X Belgium X Cyprus X Czech Republic X Denmark X Estonia X Finland X France X X Outdoor frequency operation restricted to 2446.5 MHz to 2483.5 MHz Germany X Greece X Hungary X Ireland X Italy X Lithuania X Latvia X Luxembourg X Malta X The Netherlands X Poland X Portugal X Slovakia X Slovenia X Spain X Sweden X United Kingdom X Document Number: 632194 Rev: A Page 4 of 4 Country of License Intended Use Yes No Required Restrictions Details Other non-EU: Iceland X Liechtenstein X Norway X Switzerland X

Users Manual

CN3 Mobile Computer User's Manual iiPRELIMINARY - CN3 Mobile Computer User’s Manual Intermec Technologies Corporation Worldwide HeadquartersCedar Rapids Technical Communications 6001 36th Ave.W. 550 Second Street SE Everett, WA 98203Cedar Rapids, IA 52401 U.S.A.U.S.A. www.intermec.com The information contained herein is provided solely for the purpose of allowing customers to operate and ser- vice Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2006 by Intermec Technologies Corporation. All rights reserved. The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser, Durath- erm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under license), Intellitag, Intellitag Gen2, JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan, Smart Mobile Computing, TE 2000, Trakker Antares, and Vista Powered are either trademarks or registered trade- marks of Intermec Technologies Corporation. There are U.S. and foreign patents as well as U.S. and foreign patent applications pending. Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and/or other countries. Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. Contents CN3 Mobile Computer User’s Manual - PRELIMINARYiii Contents Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Global Services and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix Who Should Read this Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x Patent Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi 1 Using the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Introducing the CN3 Mobile Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Learning Software Build Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Resetting Your CN3 Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Scanning Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Scanning with the 2D Area Imager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Using the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Charging and Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Maximizing Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Checking the Battery Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Adjusting the Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Enabling the Beeper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Disabling the Beeper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Intermec Settings Applet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Using the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Using the Color-Coded Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Capitalizing All Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using the Power (I/O) Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Software Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 SmartSystems Foundation Console (www.intermec.com/SmartSystems) . . . . . . . 13 Intermec Resource Kits (www.intermec.com/IDL) . . . . . . . . . . . . . . . . . . . . . . . . 13 Using the Speakers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Using the Status LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Using the Storage Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Setting the Vibrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Wireless Network Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Contents ivPRELIMINARY - CN3 Mobile Computer User’s Manual Accessories for the CN3 Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Physical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Users Manual

CN3 Mobile Computer User’s Manual - PRELIMINARY69 3 Configuring the Computer There are multiple ways to get an application to your CN3 Mobile Com- puter; like there are multiple ways to package the application for delivery. Note: Desktop icons and settings applet icons are shown to the left. Any place that Start is mentioned, tap the following Windows icon in the top, left corner of your CN3 desktop. Chapter 3 — Configuring the Computer 70PRELIMINARY - CN3 Mobile Computer User’s Manual Developing Applications for the Computer CN3Computers run applications programmed in Microsoft Visual Studios 2005. Use this chapter to understand what you need to develop a new application for the CN3 Computer. To develop applications for your CN3 Computer, use the Resource Kits in the Intermec Developer Library (IDL). Download the IDL from the Inter- mec web site at www.intermec.com/idl. Contact your Intermec representa- tive for more information. You need the following hardware and software components to use the resource kits: • Pentium desktop, 400 MHz or higher • Windows 2000 (Service Pack 2 or later) or Windows XP (Home, Profes- sional, or Server) • For native and managed development, Microsoft Visual Studio 2005 • 128 MB RAM (196 MB recommended) • 360 MB hard drive space for minimum installation (720 MB for com- plete) • CD-ROM drive compatible with multimedia desktop specification • VGA or higher-resolution monitor (Super VGA recommended) • Microsoft Mouse or compatible pointing device Packaging Applications for the CN3 Computer Use any of these methods to package applications for installation: • You could package an application as a cabinet (CAB) file. Recommended • For simple applications, the application itself may be the file to deliver. • It could be a directory structure that contains the application, supporting files like ActiveX controls, DLLs, images, sound files, and data files. Consider any of these when choosing a storage location for applications: • In the basic CN3 Computer, there are two built-in storage options: the Object Store and the Flash File Store. The Object Store is a Disk on Chip (DOC) Flash that looks like a disk. The Flash File Store is an area of storage which is embedded in a section of the system’s FLASH mem- ory. This storage area is not erased during a clean-boot. • If the optional Secure Digital storage card is in the system, then consider this card the primary location for placing an applications install files. This storage card creates the “\Storage Card” folder. Note: Microsoft eMbedded Visual C++ 4.0 may be used, but some features are not available. Chapter 3 — Configuring the Computer CN3 Mobile Computer User’s Manual - PRELIMINARY71 • Use the small nonvolatile Flash File Store region to hold CAB files that rebuild the system at clean-boot or install applications from a CAB file into the Flash File Store so they are “ready-to-run” when a clean-boot is performed. Since the FLASH in the system has a limited number of write cycles, do not use the Flash File Store for excessive writing pur- poses; however, reading is okay. Installing Applications on the Computer Any of these options can move items to locations on your CN3 Computer: Microsoft ActiveSync (page 71), Secure Digital storage cards (page 72), Wavelink Avalanche (page 72), or SmartSystems™ Console (page 73). Using Microsoft ActiveSync You can use Microsoft ActiveSync to establish a connection between your desktop and the CN3 Computer. Microsoft ActiveSync transfers files, syn- chronizes files, remote debugging, and other device management activities. See Chapter 2, “Windows Mobile” for information about the Microsoft ActiveSync application as provided by Microsoft Corporation. This can be a USB Microsoft ActiveSync connection. Files can be copied using Windows Explorer on a desktop or a laptop computer. This is usually good when updating few CN3 Computers. These instructions assume that Microsoft ActiveSync was installed onto your desktop and is up and running. If not, go to Chapter 2, “Windows Mobile” for an URL from which to download the latest application. 1Connect your CN3 Computer to your desktop using a USB cable. You may have to detach, then reattach the cable to “wake” the connection. 2Wait for a “Connected” message to appear in the Microsoft ActiveSync application to signal a connection to the CN3 Computer. If necessary, select File > Get Connected to initiate a connection or detach, then reat- tach the USB cable. 3Click Explore to access the “\Mobile Device” folder on your unit. Chapter 3 — Configuring the Computer 72PRELIMINARY - CN3 Mobile Computer User’s Manual 4From your desktop, select Start > Windows Explorer, then browse the “C:\Intermec\CN3 Mgmt Tools\CabFiles” path for any CAB files needed for your CN3 Computer. Select the appropriate file, right-click the file for a pop-up menu, then select Copy. 5Within the “\My Windows Mobile-Based Device” directory, go to the directory where you want the files located on the CN3 Computer, do a right-click for a pop-up menu, then select Paste. 6When all of the files are pasted, perform a clean-boot on the CN3 Com- puter. When the computer reboots, wait for the LED on the top left of your keypad to stop blinking. Tap Start > Programs > Windows Explorer to locate the newly copied executable files, then tap these files to activate their utilities. Using a Storage Card If you have a mini-Secure Digital (SD) storage card for your CN3 Com- puter, this is the best place for you to installation applications. 1If you are using a Secure Digital card reader, suspend the CN3 Com- puter, remove its mini-SD storage card, insert it in a mini-SD adapter card, then place it in the reader. For help, see “Using the Storage Card” on page 16. 2Copy your application file to the mini-SD card. If you are using Microsoft ActiveSync to copy the files to the mini-SD card, place the application in the “\Storage Card” folder on the CN3 Computer. 3If using a Secure Digital card re…

Text truncated - open the document above for the full version.

Cover Letter(s)

August 24, 2006 To Who It May Concern: Intermec Technologies Corporation, the undersigned, hereby authorizes Northwest EMC, Inc., to act on our behalf, as our agent, in the following matters related to the FCC and Industry Canada approval of our products: report submittal, related correspondence, the signing of all documents related to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Northwest EMC, Inc. within the scope of this authorization shall have the same affect as our own. This authorization shall expire 12 months from original date. If you have any questions regarding this application, please feel free to contact me via phone at 425- 267-2928, via fax at 425-348-2633 or via email at [email protected]. Sincerely, Cheryl D. White Compliance Engineer Intermec Technologies Corporation Safety & Compliance 6001 36 th Avenue West Everett, Washington 98203 United States tel 425 267 2928 fax 425 348 2633

Cover Letter(s)

NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 August 30, 2006 Dear Application Examiner: On behalf of Intermec Technologies Corporation, Northwest EMC Inc is submitting this application for the original certification of Intermec's combination radio module, FCC ID: EHADHIB. The radio, M/N: DHIB, operates in the 2400-2483.5MHz band as a Bluetooth radio and an 802.11(b)/(g) radio. The radio is seeking full modular approval and was tested in a stand-alone configuration. The radio utilizes a single type of antenna, one for the Bluetooth portion of the radio and one for the 802.11(b)/(g) portion of the radio. Intermec Technologies Corporation has provided antenna gain information over the 2400MHz frequency band. For final use, the antenna will be internal to the device it is installed in, thus satisfying the requirements of 47 CFR 15.203. The technical reports and exhibits demonstrate compliance of the Bluetooth portion of the radio with FCC rules 47 CFR 15.247 as a hybrid transmitter. For reference, please see the third example (highlighted) in the attached FCC interpretation. The reports and exhibits also demonstrate compliance of the 802.11(b)/(g) portion of the radio with FCC rules 47 CFR 15.247. Your efforts in reviewing this application are greatly appreciated. Best regards, Northwest EMC, Inc. Company: Subject:Digital Transmission system 20021209- 001  Remarks: Keyword:BlueTooth FH HS Rule Parts:15.247 City: State: Country: INQUIRY: I have an inquiry about FCC15.247 (f). In this section, it is stated as follows; The digital modulation operation of the hybrid system, with the frequency hopping turned off, shall comply with the power density requirements of paragraph (d) of this section. Should we apply to the above requirement even Bluetooth equipment ? RESPONSE: A bluetooth device may apply under the rules in 15.247 as either a Digital transmission system, a Frequency hopping system or a Hybrid system whichever provides an advantage to the grantee as long as all the requirements are met. Please note the following regarding the requirements for Hybrids and clarification of spread spectrum systems with regard to the recent changes to the spread spectrum rules. Prior to the recent changes to the spread spectrum rules, there were two major types of spread spectrum systems. They were direct sequence and frequency hopping spread spectrum ("FHSS") systems. These two distinct systems were required to comply with separate rule requirements. The new rules, however, allow manufacturers more flexibility and are not as limiting. The new rules provide more flexibility for manufacturers by eliminating the requirement to employ direct sequence modulation techniques along with its associated requirement to comply with a minimum processing gain. Instead, manufacturers now may employ wideband digital modulation under the new rules for Digital Transmissions Systems ("DTS"). It is possible for a device to be designed to operate as a DTS, as a FHSS system, or using a combination of these two modulation types. Because of this, we have received several requests for interpretations by manufacturers that wish to produce transmission systems that employ both frequency hopping (or channel changing) techniques using digitally modulated channels. We believe that such systems fall under three possible combinations of standards, depending on the exact methods of modulation. First example: We will allow a manufacturer of a combination DTS and FHSS system to demonstrate compliance with the rules required for DTS operation or for FHSS operation. There is no need to demonstrate compliance with both the FHSS standards and the DTS standards. Second example: Systems may employ two mutually exclusive operational modes. One mode would be as a FHSS system and the other would be as a DTS. For example, a device may be operated as a FHSS system while transmitting data and as a DTS while in the acquisition mode. When operating in this manner, the device must fully comply with the rules for a FHSS system when operating in that mode and as a DTS when operating in that mode. The two types of operation must be distinct so that each mode of operation can be distinguished and separately demonstrated to comply with the pertinent standards. Third example: The third method of authorizing a combination system is as a hybrid system under the provisions described in Section 15.247(f) of the rules. Prior to the new rules on DTS operation, a hybrid system consisted of a transmission system that employed a combination of both direct sequence and frequency hopping techniques. Such systems were required to show compliance with a 17 dB processing gain. This is no longer required since the processing gain requirement has been replaced by the DTS regulations. A hybrid system uses both digital modulation and frequency hopping techniques at the same time on the same carrier. This is similar to the combination DTS/FHSS system described above in the first example but the system is subject to slightly different standards. As indicated in Section 15.247(f), a hybrid system must comply with the power density standard of 8 dBm in any 3 kHz band when the frequency hopping function is turned off. The transmission also must comply with a 0.4 second/channel maximum dwell time when the hopping function is turned on. There is no requirement for this type of hybrid system to comply with the 500 kHz minimum bandwidth normally associated with a DTS transmission; and, there is no minimum number of hopping channels associated with this type of hybrid system. However, the hopping function must be a true hopping system, as described in Section 15.247(a)(1). The specific requirements in Section 15.247(a)(1) are: 1) A minimum channel separation. 2) Pseudorandom hop sequence. 3) Equal use of each frequency. 4) Receiver matching bandwidth and Synchronization. The additional requirements in Section 15.247 for a hybrid transmitter include the…

Text truncated - open the document above for the full version.

Cover Letter(s)

NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 August 30, 2006 Dear Application Examiner: Intermec’s Model DHIB, FCC ID: EHADHIB is seeking full modular approval. The radio meets the requirements for modular approval as detailed in FCC Public Notice DA00-1407. Compliance to each of the requirements is described below: 1. “The modular transmitter must have its own RF shielding.” The radio portion of the module is contained in its own RF shielding. The shielding is installed at the factory. Please see the Internal Photos and External Photos exhibit. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs to insure compliance with Part 15 requirements under conditions of excessive data rates or over-modulation. Please see the Schematics exhibit. 3. “The modular transmitter must have its own power supply regulation.” The EUT has its own power supply regulation to insure compliance with Part 15 requirements regardless of the quality or level of external DC supplying the module from the host unit. Please see Schematics exhibit. 4. “The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c).” The EUT meets the FCC antenna requirements. Please see Antenna information exhibit and internal photos exhibit. 5. “The modular transmitter must be tested in a stand-alone configuration.” The EUT was tested in a stand-alone configuration. The module was greater than 10 cm from the host device. Please see test setup photos exhibit and technical report exhibit. 6. “The modular transmitter must be labeled with its own FCC ID number.” The EUT is labeled with its own FCC ID number. Please see FCC ID label & location exhibit. Since the FCC ID number will not be visible when the module is installed in a host device, another label with the FCC ID will be applied to the exterior of the host device. 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance will be given in all future host device User Manuals. Additionally, Intermec Technologies Corporation has provided a Compliance Insert regarding the radio that will be included in all future User Manuals. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. Please see RF Exposure Exhibit. Please contact me if you have additional questions. Your attention to this matter is greatly appreciated. Best regards, Northwest EMC, Inc.

Cover Letter(s)

6001 36 th Avenue West Everett, Washington 98203 United States tel 425.267.2928 fax 425.355.9551 24-August 2006 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Direct Sequence Spread Spectrum, Frequency Hopping Spread Spectrum Transceiver Certification To whom it may concern, Application: Intermec Technologies Corporation, 550 Second Street SE, Cedar Rapids, Iowa 52401-2029 herein submits for Certification of a Direct Sequence Spread Spectrum , Frequency Hopping Spread Spectrum Transceiver FCC ID: EHADHIB. Intermec is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Intermec requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Intermec trade secrets and confidential information that Intermec does not customarily release to the public and which is ot herwise not generally available to the public. Confidentiality is requested for the following exhibits: • Theory of Operation • Schematics • Frequency Block Diagram Description: This equipment is an 802.11b/g + Bluetooth DSSS, FHSS combination radio module, which operates in the 2400-2483.5 MHz band. Limited modular approval is requested since the radio design allows use in multiple hosts of various configurations. Contact Information: Please contact me by telephone at (319) 369-3865 or by e-mail ([email protected]) if there are questions or additional information needed concerning this filing. Cheryl D. White Regulatory Compliance Engineer Intermec Technologies Corporation

Cover Letter(s)

Northwest EMC TCB Compliance Opinion Rev. 9/15/03 ITRM0128 Information about the Applicant Company Name Intermec Technologies Corporation Grantee Dave Fry Address 550 Second St. SE City, State, Zip Cedar Rapids, IA 52401-2023 Job Number ITRM0128 Model DHIB FCC ID EHADHIB Agent Northwest EMC, Inc. Approval Type Original Equipment Class DTS Digital Transmission System Rule Part 15.247DSSS Industry Canada Information Model DHIB Industry Canada ID 1223A-DHIB Rule Part RSS210 Overview Northwest EMC Inc is submitting this application for the original certification of Intermec's combination radio module, FCC ID: EHADHIB. The radio, M/N: DHIB, operates in the 2400- 2483.5MHz band as a Bluetooth radio and an 802.11(b)/(g) radio. The radio is seeking full modular approval and was tested in a stand-alone configuration. The radio utilizes a single antenna for the Bluetooth portion of the radio and for the 802.11(b)/(g) portion of the radio. Intermec Technologies Corporation has provided antenna gain information over the 2400MHz frequency band. For final use, the antenna will be internal to the device it is installed in, thus satisfying the requirements of 47 CFR 15.203. The technical reports and exhibits demonstrate compliance of the Bluetooth portio…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Brian Rudick(VP & GC, Honeywell Scanning & Mobility)
[email protected]803-835-8769Fax: 803-835-8700

Test Firm

Northwest EMC, Inc.Greg Kiemel
[email protected]503-844-4066Fax: 503-844-3826

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.40 GHz - 2.48 GHz1.63 mW
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Modular Approval. Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
