EW4C95Bluetooth HCI module

Page 1 of 4 WML-C95_User_Manual User Manual MITSUMI Bluetooth HCI Module MODEL WML-C95 The purpose of this manual is to explain correct way how to integrate module WML-C95 to the end product. It includes procedures that shall assist you to avoid unforeseen problems. This manual presents information that shows how module and OEM product, where module integrated, complies with regulations in certain regions. Any modifications, not expressly approved by the manufacturer could void the authority to operate in these regions. Content 1. General 2. Product Information 3. Federal Communications Commission Interference Statement 4. Industry Canada Statement 1. General This MITSUMI Bluetooth HCI Module, model WML-C95 has to be installed and used in accordance with the technical description/installation instructions provided by the manufacturer. For detail information concerning type approval of this module, please contact the authorized local distributor or manufacturer. The system may only be implemented in the configuration that was authorized. Note that any changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. 2. Product Information WML-C95 is a Bluetooth HCI Module. The specification is shown in the following. Power Supply VBAT:DC 2.97V to 3.63V (3.3V Typ) VIO:DC 1.7V to 1.98V (1.8V Typ) or 2.97V to 3.63V (3.3V Typ) Bluetooth Version Bluetooth V4.0 BDR/EDR+LE Carrier Frequency 2.402GHz to 2.480GHz Output Power 0 dBm (Class 2) Hopping 1600hops/sec Modulation Method GFSK, PI/4-DQPSK, 8DPSK Data rate GFSK: 1Mbps , PI/4-DQPSK: 2Mbps , 8DPSK: 3Mbps Host interface UART, PCM (I2C) Page 2 of 4 WML-C95_User_Manual 3. Federal Communications Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Page 3 of 4 WML-C95_User_Manual End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: EW4C95”. The grantee's FCC ID can be used only when all FCC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. 4. Industry Canada statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésira…

Text truncated - open the document above for the full version.

2- 11-2, Tsurumaki, Tama-shi, TOKYO, 206-8567 JAPAN TEL: +81-42-310-5822 FAX: +81-42-310-5598 Date: 2015-04 -20 FCC ID: EW4C95 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ----------------------------------- Name: Masashi Tsuchida Title : Section Manager Tel +81-42-310-5822 Fax: +81-42-310-5598 E-mail: [email protected]

2-11-2, Tsurumaki, Tama-shi, TOKYO, 206-8567 JAPAN TEL: +81-42-310-5822 FAX: +81-42-310-5598 Date: 2015-04-20 FCC ID: EW4C95 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ----------------------------------- Name: Masashi Tsuchida Title : Section Manager Te l +81-42-310-5822 Fax: +81-42-310-5598 E-mail: [email protected]

2- 11-2, Tsurumaki, Tama-shi, TOKYO, 206-8567 JAPAN TEL: +81-42-310-5822 FAX: +81-42-310-5598 Date: 2015-04-20 FCC ID: EW4C95 AUTHORIZATION LETTER To whom it may concern: We, the undersigned, hereby authorize Andrea Hsia/Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Andrea Hsia/Specialist of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------- Name: Masashi Tsuchida Title : Section Manager Tel +81-42-310-5822 Fax: +81-42-310-5598 E-mail: [email protected]

2- 11-2, Tsurumaki, Tama-shi, TOKYO, 206-8567 JAPAN TEL: +81-42-310-5822 FAX: +81-42-310-5598 FCC ID: EW4C95 Report No.: RF150409C03 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch April 20, 2015 Dear Application Examiner, Mitsumi Electric Co., Ltd. Bluetooth HCI module, FCC ID:EW4C95 would like to have your authorization as a modular approval specific to the mobile RF exposure condition. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “ The modular transmitter must have its own RF shielding.” The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip BCM20713A1KUBXG. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is BCM20713A1KUBXG. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “ The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a USB extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “ The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 2- 11-2, Tsurumaki, Tama-shi, TOKYO, 206-8567 JAPAN TEL: +81-42-310-5822 FAX: +81-42-310-5598 FCC ID: EW4C95 Report No.: RF150409C03 7. “ The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “ The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, ----------------------------------- Name: Masashi Tsuchida Title : Section Manager Te l +81-42-310-5822 Fax: +81-42-310-5598 E-mail: [email protected]

WML-C95 Overall Appearance Photos Top ViewBottom View Left ViewRight View Front ViewBack View

WML-C95 Internal Photos

Report No.: SA150409C03 Page No. 1 / 5 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150409C03 FCC ID: EW4C95 Test Model: WML-C95 Received Date: Apr. 09, 2015 Test Date: Apr. 10 ~ 16, 2015 Issued Date: Apr. 20, 2015 Applicant: Mitsumi Electric Co., Ltd. Address: 2-11-2, Tsurumaki, Tama-shi, Tokyo, 206-8567 Japan Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA150409C03 Page No. 2 / 5 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits For Maximum Permissible Exposure (MPE) ............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result Of Maximum Conducted Power .......................................................................... 5 Report No.: SA150409C03 Page No. 3 / 5 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150409C03 Original release. Apr. 20, 2015 Report No.: SA150409C03 Page No. 4 / 5 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Bluetooth HCI module Brand: Mitsumi Test Model: WML-C95 Sample Status: Engineering sample Applicant: Mitsumi Electric Co., Ltd. Test Date: Apr. 10 ~ 16, 2015 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date:Apr. 20, 2015 Pettie Chen / Senior Specialist Approved by : , Date:Apr. 20, 2015 Ken Liu / Senior Manager Report No.: SA150409C03 Page No. 5 / 5 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 3 Calculation Result Of Maximum Conducted Power Max Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Bluetooth EDR 2.60 -5.68 20 0.00010 1 Bluetooth LE -0.65 -5.68 20 0.00005 1 --- END ---

Report No.: RF150409C03 Page No. 1 / 45 Report Format Version: 6.1.1 FCC Test Report Report No.: RF150409C03 FCC ID: EW4C95 Test Model: WML-C95 Received Date: Apr. 09, 2015 Test Date: Apr. 10 ~ 16, 2015 Issued Date: Apr. 20, 2015 Applicant: Mitsumi Electric Co., Ltd. Address: 2-11-2, Tsurumaki, Tama-shi, Tokyo, 206-8567 Japan Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150409C03 Page No. 2 / 45 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Description of Support Units .............................................................................................................. 11 3.3.1 Configuration of System under Test ................................................................................................... 11 3.4 General Description of Applied Standards ........................................................................................ 12 4 Test Types and Results ...................................................................................................................... 13 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 13 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 13 4.1.2 Test Instruments ................................................................................................................................ 14 4.1.3 Test Procedures ................................................................................................................................. 15 4.1.4 Deviation from Test Standard ............................................................................................................ 15 4.1.5 Test Set Up ........................................................................................................................................ 16 4.1.6 EUT Operating Conditions ................................................................................................................. 16 4.1.7 Test Results ....................................................................................................................................... 17 4.2 Conducted Emission Measurement .................................................................................................. 24 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 24 4.2.2 Test Instruments ................................................................................................................................ 24 4.2.3 Test Procedures ................................................................................................................................. 25 4.2.4 Deviation From Test Standard ........................................................................................................... 25 4.2.5 Test Setup ...............................................................................…
