EW4DRTW127NFC Module

User Manual NFC Module MODEL DRT-W127 The purpose of this manual is to explain correct way how to integrate module DRT-W127 to the end product. It includes procedures that shall assist you to avoid unforeseen problems. This manual presents information that shows how module and OEM product, where module integrated, complies with regulations in certain regions. Any modifications, not expressly approved by the manufacturer could void the authority to operate in these regions. The NFC Module, model DRT-W127 has to be installed and used in accordance with the technical description/installation instructions provided by the manufacturer. For detail information concerning type approval of this module (e.g. where this module is already pre-approved) please contact the authorized local distributor or the manufacturer. The system may only be implemented in the configuration that was authorized. Note that any changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Regulatory Information Operational Information Wireless Interoperability The end product integrating this module is designed to be interoperable with any NFC Card Reader/Writer product that is based on ISO18092, ISO14443A/B and JIS X 6319-4 for Contactless integrated circuit card technology and to comply with the following standards. ･ISO/IEC 18092 Near Field Communication – Interface and Protocol ･ISO/IEC 14443A/B 13.56MHz Contactless integrated circuit card - Proximity card ･JIS X 6319-4 13.56MHz Contactless integrated circuit card-Proximity card Safety The end product integrating this module, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by this device, however, is less than the electromagnetic energy emitted by other wireless devices such as mobile phones. The end product integrating this module operates within the guidelines found in radio frequency safety standards and recommendations. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situations or environments, the use of the end product integrating this module may be restricted by the proprietor of the building or responsible representatives of the applicable organization. Examples of such situations include the following: ･Using the end product integrating this module onboard airplanes, or ･Using the end product integrating this module in any other environment where the risk of interference with other devices or services is perceived or identified as being harmful. If uncertain of the policy that applies to the use of wireless devices in a specific organization or environment (an airplane, for example), ask for authorization to use the end product integrated into this module before turning it on. USA-Federal Communications Commission (FCC) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Labeling MITSUMI NFC Card Reader/Writer MODULE DRT-W127 labeled as below. FCC ID: EW4DRTW127 The label with FCC ID is to be placed on the module. If FCC ID is not visible when the module is installed into the system, “Contains FCC ID: EW4DRTW127” shall be placed on the outside of final host system. Caution: Exposure to Radio Frequency Radiation. This device must not be co-located or operating in conjunction with any other antenna or transmitter. Instructions to OEM Integrators A User manual provided to the end user must indicate the operating requirements and conditions that must be observed to ensure compliance with the above-mentioned FCC RF Exposure guideline. If this module is intended for use in a portable device, integrators are responsible for separate evaluation and/or approval to satisfy FCC RF Exposure requirements. Only the antenna (Type: PCB Loop antenna) used during testing can be used with this module. Canada-Industry Canada (IC) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Labeling MITSUMI NFC Card Reader/Writer MODULE DRT-W127 labeled as below. IC: 4250A-DRTW127 The label with IC No. is to be placed on the module. If IC No. is not visible when the module is installed into the system, “Contains IC: 4250A-DRTW127” shall be placed on the outside of final host system. The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met. Caution: Exposure to Radio Frequency Radiation. This device must not be co-located or operating in conjunction with any other antenna or transmitter. Instructions to OEM Integrators A User manual provided to the end user must indicate the operating requirements and conditions that must be observed to ensure compliance with the above-mentioned IC RF Exposure guideline. If this module is intended for use in a portable device, integrators are responsible for separate evalua…

Text truncated - open the document above for the full version.

Applicant/Grantee Mitsumi Electric Co., Ltd. FCC ID: EW4DRTW127 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The device is equipped with Metal shielding to cover RF section. Refer to external photos Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. All inputs to the device are buffered through logic U1 inputs. Refer to Schematic Diagram. Y 3 The modular transmitter must have its own power supply regulation. The device is equipped with Internal 1.8VDC regulator. Refer to Block diagram. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The device employs a unique antenna connector. Refer to External Photos. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially The device was tested outside of the Laptop PC for full modular approval. Refer to setup photos. Y available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. The proposed FCC ID label format is to be placed on the module. If FCC ID is not visible when the module is installed into the system, “Contains FCC ID: EW4DRTW127” shall be placed on the outside of final host system. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to “User’s Guide” Exhibit Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The device complies with RF exposure compliance requirement Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.

1601, SAKAI, ATSUGI-SHI, KANAGAWA, 243-8533 JAPAN TEL: +81-46-230-3420 FAX: +81-46-230-3500 Date: July 23, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: EW4DRTW127 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In addition to above mentioned documents, pursuant to Public Notice DA 04-1705 of the commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we are requesting the commission to grant short-term confidentiality request on the following attachments for 180 days: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Masashi Tsuchida Mitsumi Electric Co., Ltd.

External Photos Model: DRT-W127

DRT-W127 ID LABEL DRT-W127 ID LABELDRT-W127 ID LABEL LABEL LOCATION : BOTTOM OF EUT 20 9.5

Inte Mode ernal Pho el: DRT-W otos W127

FCC CFR47 PART 15 SUBPART C INDUSTRY CANADA RSS-210 ISSUE 8 CERTIFICATION TEST REPORT FOR NFC MODULE MODEL NUMBER: DRT-W127 FCC ID: EW4DRTW127 IC: 4250A-DRTW127 REPORT NUMBER: 12J14452-1, REVISION A ISSUE DATE: JULY 25, 2012 Prepared for MITSUMI ELECTRIC CO., LTD. 1601, SAKAI, ASUGI-SHI, KANAGAWA, 243-8533 JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES (UL CCS) 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 12J14452-1A DATE: JULY 25, 2012 FCC ID: EW4DRTW127 IC: 4250A-DRTW127 Page 2 of 50 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701F 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. Revision History Rev. Issue Date Revisions Revised By - 07/23/12 Initial Issue A 07/25/12 Revised Section 11 T. Chan REPORT NO: 12J14452-1A DATE: JULY 25, 2012 FCC ID: EW4DRTW127 IC: 4250A-DRTW127 Page 3 of 50 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701F 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY .......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY .................................................................................... 6 4.1. MEASURING INSTRUMENT CALIBRATION ................................................................. 6 4.2. SAMPLE CALCULATION ................................................................................................ 6 4.3. MEASUREMENT UNCERTAINTY .................................................................................. 6 5. EQUIPMENT UNDER TEST ................................................................................................... 7 5.1. DESCRIPTION OF EUT .................................................................................................. 7 5.2. MAXIMUM OUTPUT POWER ......................................................................................... 7 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ................................................................. 8 5.4. SOFTWARE AND FIRMWARE ....................................................................................... 8 5.5. WORST-CASE CONFIGURATION AND MODE ............................................................ 8 5.6. DESCRIPTION OF TEST SETUP ................................................................................... 9 6. TEST AND MEASUREMENT EQUIPMENT ........................................................................ 11 7. RADIATED EMISSION TEST RESULTS ............................................................................. 12 7.1. LIMITS AND PROCEDURE ........................................................................................... 12 7.2. FUNDAMENTAL AND SPURIOUS EMISSIONS (0.15 – 30 MHz) ............................... 14 7.2.1. TAG A...................................................................................................................... 14 7.2.2. TAG B...................................................................................................................... 15 7.2.3. TAG F ...................................................................................................................... 16 7.3. BAND EDGE MEASUREMENT ..................................................................................... 17 7.3.1. TAG A...................................................................................................................... 17 7.3.1. TAG B...................................................................................................................... 21 7.4. TX/RX SPURIOUS EMISSION 30 TO 1000 MHz ......................................................... 25 8. AC MAINS LINE CONDUCTED EMISSIONS ...................................................................... 28 8.1. EUT WITHOUT ANTENNA ............................................................................................ 29 8.2. EUT WITH ANTENNA .................................................................................................... 32 9. FREQUENCY STABILITY .................................................................................................... 35 10. 99% BANDWIDTH ............................................................................................................. 37 11. MAXIMUM PERMISSIBLE EXPOSURE .......................................................................... 39 12. SETUP PHOTOS ............................................................................................................... 42 REPORT NO: 12J14452-1A DATE: JULY 25, 2012 FCC ID: EW4DRTW127 IC: 4250A-DRTW127 Page 4 of 50 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701F 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. 12.1. FUNDAMENTAL FIELD (WORST-CASE ORIENTATION INVESTIGATION) .......... 42 12.2. RADIATED EMISSION BELOW 30 MHz ................................................................... 45 12.3. RADIATED EMISSION ABOVE 30 MHz ................................................................... 46 12.4. FREQUENCY TOLERANCE OVER EXTREME CONDITIONS ................................ 48 12.5. AC MAINS LINE CONDUCTED EMISSION .............................................................. 49 REPORT NO: 12J14452-1A DATE: JULY 25, 2012 FCC ID: EW4DRTW127 IC: 4250A-DRTW127 Page 5 of 50 COMP…
