EZZ61170AChannelized Signal Booster

YOU'RE HEARD, LOUD AND CLEAR. 8625 Industrial Parkway, Angola, NY 14006 Tel: 716-549-4700 Fax: 716-549-4772 [email protected] www.bird-technologies.com Installation and Operation Manual for the SBIII Channelized Signal Booster Model 611-70A Manual Part Number 7-9469 Warranty This warranty applies for one year from shipping date. TX RX Systems Inc. warrants its products to be free from defect in material and workmanship at the time of shipment. Our obligation under warranty is limited to replacement or repair, at our option, of any such products that shall have been defective at the time of manufacture. TX RX Systems Inc. reserves the right to replace with merchandise of equal performance although not identical in every way to that originally sold. TX RX Systems Inc. is not liable for dam- age caused by lightning or other natural disasters. No product will be accepted for repair or replacement without our prior written approval. The purchaser must prepay all shipping charges on returned products. TX RX Systems Inc. shall in no event be liable for consequential damages, installation costs or expense of any nature resulting from the purchase or use of products, whether or not they are used in accordance with instructions. This warranty is in lieu of all other warranties, either expressed or implied, including any implied warranty or merchantability of fitness. No repre- sentative is authorized to assume for TX RX Systems Inc. any other liability or warranty than set forth above in con- nection with our products or services. TERMS AND CONDITIONS OF SALE PRICES AND TERMS: Prices are FOB seller’s plant in Angola, NY domestic packaging only, and are subject to change without notice. Fed- eral, State and local sales or excise taxes are not included in prices. When Net 30 terms are applicable, payment is due within 30 days of invoice date. All orders are subject to a $100.00 net minimum. QUOTATIONS: Only written quotations are valid. ACCEPTANCE OF ORDERS: Acceptance of orders is valid only when so acknowledged in writing by the seller. SHIPPING: Unless otherwise agreed at the time the order is placed, seller reserves the right to make partial shipments for which payment shall be made in accordance with seller’s stated terms. Shipments are made with transportation charges col- lect unless otherwise specified by the buyer. Seller’s best judgement will be used in routing, except that buyer’s routing is used where practicable. The seller is not responsible for selection of most economical or timeliest routing. CLAIMS: All claims for damage or loss in transit must be made promptly by the buyer against the carrier. All claims for shortages must be made within 30 days after date of shipment of material from the seller’s plant. SPECIFICATION CHANGES OR MODIFICATIONS: All designs and specifications of seller’s products are subject to change without notice provided the changes or modifi- cations do not affect performance. RETURN MATERIAL: Product or material may be returned for credit only after written authorization from the seller, as to which seller shall have sole discretion. In the event of such authorization, credit given shall not exceed 80 percent of the original pur- chase. In no case will Seller authorize return of material more than 90 days after shipment from Seller’s plant. Credit for returned material is issued by the Seller only to the original purchaser. ORDER CANCELLATION OR ALTERATION: Cancellation or alteration of acknowledged orders by the buyer will be accepted only on terms that protect the seller against loss. NON WARRANTY REPAIRS AND RETURN WORK: Consult seller’s plant for pricing. Buyer must prepay all transportation charges to seller’s plant. Standard shipping pol- icy set forth above shall apply with respect to return shipment from TX RX Systems Inc. to buyer. DISCLAIMER Product part numbering in photographs and drawings is accurate at time of printing. Part number labels on TX RX products supersede part numbers given within this manual. Information is subject to change without notice. Bird Technologies Group TX RX Systems Inc. Symbols Commonly Used WARNING ESD Electrostatic Discharge Hot Surface Electrical Shock Hazard Important Information CAUTION or ATTENTION High Voltage Heavy Lifting Bird Technologies GroupTX RX Systems Inc. NOTE Manual Part Number 7-9469 Copyright © 2010 TX RX Systems, Inc. First Printing: March 2009 Version NumberVersion Date 103/30/09 1.106/10/09 1.207/31/09 1.3 (RD)07/31/09 1.4 (RD)10/23/09 1.5 (RD)10/28/09 1.6 (RD)11/18/09 1.702/08/10 Contact Information Changes to this Manual Bird Technologies GroupTX RX Systems Inc. Sales Support at 716-217-3113 Customer Service at 716-217-3144 Technical Publications at 716-549-4700 extension 5019 We have made every effort to ensure this manual is accurate. If you discover any errors, or if you have suggestions for improving this manual, please send your comments to our Angola, New York facility to the attention of the Technical Publications Department. This manual may be periodically updated. When inquiring about updates to this manual refer to the manual part number and revision number on the revision page following the front cover. Table of Contents Manual 7-9469-1.7 02/08/10 Table of Contents Overview............................................................................................................... 1 Down / Up Conversion......................................................................................... 1 Unpacking ............................................................................................................ 2 Installation............................................................................................................ 2 Location ............................................................................................................. 2 Installing the Booster .......................................................................................... 2 Connections..........…

Text truncated - open the document above for the full version.

January 11, 2010 Nemko Canada Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 Models: 611-70A Letter of Understanding – FCC Rules 1. CFR47-90.219 - I have read and fully understand the contents of 90.219 and TX RX works with our customers to fully comply with these rules. 2. Frequency Listing – We also understand that this equipment as certified for Part 90 can only be used on authorized frequencies within the 450-512 MHz band and that it is a violation of FCC rules if the device is operated on unauthorized frequencies. Dated this 11th Day of January 20 10 By: Ronald J. Jakubowski Signature Printed Title: Chief Engineer-RF Systems On behalf of : TX RX Systems Telephone: 440-539-1196

TX RX Systems 30303 Aurora Rd Solon, OH 44139 Phone: (440) 248-1200 / (866) 695-4569 [Toll Free] Fax: (440) 248-9593 November 12, 2009 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent FCC On our behalf, I appoint Nemko USA, Inc. at 802 N Kealy Avenue, Lewisville TX 75057 to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. We also authorize Nemko USA, Inc. to certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides (company name and address). Dated this 12th Day of November 20 09 Agency agreement expiration date: December 31, 2010 By: Ronald J. Jakubowski Signature Printed Title: Chief Engineer-RF Systems On behalf of : TX RX Systems, Inc. Telephone: 440-539-1196 TX RX Systems 30303 Aurora Rd Solon, OH 44139 Phone: (440) 248-1200 / (866) 695-4569 [Toll Free] Fax: (440) 248-9593

TX RX Systems 30303 Aurora Rd Solon, OH 44139 Phone: (440) 248-1200 / (866) 695-4569 [Toll Free] Fax: (440) 248-9593 November 12, 2009 Nemko Canada Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 FCC ID: EZZ61170A Product Name: Channelized Signal Booster Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s rules, we hereby request that the following documents be held confidential: • Technical/Operational Description • Schematics • Block diagram These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 12th Day of November 20 09 By: Ronald J. Jakubowski Signature Printed Title: Chief Engineer-RF Systems On behalf of : TX RX Systems, Inc. Telephone: 440-539-1196

Channelized Signal Booster (Model 611-70A) - External Photos Channel Module 3-22322 or 3-23231or 3-23232 Front View Channel Module 3-22322 or 3-23231 or 3-23232 Rear View Channelized Signal Booster (Model 611-70A) - External Photos Channel Module 3-22322 or 3-23231 or 3-23232 right side view. Channel Module 3-22322 or 3-23231 or 3-23232 Left Side View. Channelized Signal Booster (Model 611-70A) - External Photos Combline Filter Assembly 3-9774 rear view. Combline Filter Assembly 3-9774 front view. Channelized Signal Booster (Model 611-70A) - External Photos Combline Filter Assembly 3-9774 right side view. Combline Filter Assembly 3-9774 left side view. Channelized Signal Booster (Model 611-70A) - External Photos Low Pass Filter Assembly 8-23026 front view. Low Pass Filter Assembly 8-23026 side view. Channelized Signal Booster (Model 611-70A) - External Photos Active Combiner Assembly 3-22318 top view. Active Combiner Assembly 3-22318 bottom view. Channelized Signal Booster (Model 611-70A) - External Photos Active Combiner Assembly 3-22318 front view. Active Combiner Assembly 3-22318 back view. Channelized Signal Booster (Model 611-70A) - External Photos UHF Distribution Amplifier Assembly 3-22340 bottom view. UHF Distribution Amplifier Assembly 3-22340 top view. Channelized Signal Booster (Model 611-70A) - External Photos UHF Distribution Amplifier Assembly 3-22340 front view. UHF Distribution Amplifier Assembly 3-22340 rear view. Channelized Signal Booster (Model 611-70A) - External Photos Hybrid Combiner 3-18317-1 top view. Hybrid Combiner 3-18317-1 bottom view.

Channelized Signal Booster (Model 611-70A) - External Photos Hybrid Combiner 3-18317-1 front view. Hybrid Combiner 3-18317-1 rear view. Channelized Signal Booster (Model 611-70A) - External Photos Power Amplifier 8-23291 top view. Power Amplifier 8-23291 bottom view. Channelized Signal Booster (Model 611-70A) - External Photos Power Amplifier 8-23291 front view. Power Amplifier 8-23291 rear view. Channelized Signal Booster (Model 611-70A) - External Photos 6-Way Power Divider 3-16676 top view. 6-Way Power Divider 3-16676 bottom view. Channelized Signal Booster (Model 611-70A) - External Photos 6-Way Power Divider 3-16676 front view. 6-Way Power Divider 3-16676 rear view. Channelized Signal Booster (Model 611-70A) - External Photos Power & Control, POD Assembly 3-22686 Channelized Signal Booster (Model 611-70A) - External Photos Power Supply 8-22688 top view. Power Supply 8-22688 bottom view. Channelized Signal Booster (Model 611-70A) - External Photos Power Supply 8-22688 front view. Power Supply 8-22688 rear view. Channelized Signal Booster (Model 611-70A) - External Photos Complete System - Front View Channelized Signal Booster (Model 611-70A) - External Photos Complete System Left Side View Channelized Signal Booster (Model 611-70A) - External Photos Complete System Rear View Channelized Signal Booster (Model 611-70A) - External Photos Complete System Right Side View

Channelized Signal Booster (Model 611-70A) - Label Location 5.906 5.906 1.5 .144 Label Location on rear of module cabinet.

Channelized Signal Booster (Model 611-70A) - Label Sample FCC and IC label sample.

Channelized Signal Booster (Model 611-70A)- Internal Photos Channel Module - Digital Board 3-22310 top view. Channel Module - Digital Board 3-22310 bottom view. Channelized Signal Booster (Model 611-70A) - Internal Photos Channel Module - LO Board 3-22312 top view. Channel Module - LO Board 3-22312 bottom view. Channelized Signal Booster (Model 611-70A)- Internal Photos Channel Module - Up Converter Board (3-22302 or 3-22304 or 3-22306) top view. Note: The difference between the three up-converter boards is that the part number for filter FL2 will change as per the table below. The pinout and foot print is the same for each different filter. Circuit BoardPart# of FL2 3-223028-22287 3-223048-22305 3-223068-22307 Channel Module - Up Converter Board (3-22302 or 3-22304 or 3-22306) under RF shield view. Channel Module - Up Converter Board (3-22302 or 3-22304 or 3-22306) bottom view. Channelized Signal Booster (Model 611-70A) - Internal Photos Channel Module - Down Converter Board 3-22308 top view. Channel Module - Down Converter Board 3-22308 under RF shield view. Channel Module - Down Converter Board 3-22308 bottom view. Channelized Signal Booster (Model 611-70A)- Internal Photos Channel Module - Interface Board 3-22315 top view. Channel Module - LED Board 3-22295 bottom view. Channel Module - Interface Board 3-22315 bottom view. Channel Module - LED Board 3-22295 top view. Channelized Signal Booster (Model 611-70A) - Internal Photos Channel Module with boards installed and cover removed. NOTE: LED Board (3-22295) under front cover. NOTE: Interface Board (3-22315) under rear cover.

Channelized Signal Booster (Model 611-70A)- Internal Photos Control Board for Channel Modules 3-22297 top view. Control Board for Channel Modules 3-22297 bottom view. Channelized Signal Booster (Model 611-70A) - Internal Photos Active Combiner 3-22318 circuit board (3-22319) top view. Active Combiner 3-22318 circuit board (3-22319) bottom view. Channelized Signal Booster (Model 611-70A)- Internal Photos UHF Distribution Amplifier 3-22340 circuit board (3-22341) top view. UHF Distribution Amplifier 3-22340 circuit board (3-22341) bottom view. Channelized Signal Booster (Model 611-70A) - Internal Photos Hybrid Combiner 3-18317-1 Circuit Board top view. Hybrid Combiner 3-18317-1 Circuit Board bottom view. Hybrid Combiner 3-18317-1 with Circuit Board installed in chassis. Channelized Signal Booster (Model 611-70A)- Internal Photos 6-Way Power Divider 3-16676 Circuit Board top view. 6-Way Power Divider 3-16676 Circuit Board bottom view. 6-Way Power Divider 3-16676 with circuit board installed in chassis. Channelized Signal Booster (Model 611-70A) - Internal Photos Power Amplifier 8-23291 non-component side view. Power Amplifier 8-23291 component side view.

Channelized Signal Booster (Model 611-70A)Parts List (page 1 of 14) 611-70A Channelized Signal Booster PART NUMBERQTYDESCRIPTION 1-226821SUPPORT BRACKET, RIGHT OPEN RACK 19" 1-226831SUPPORT BRACKET, LEFT OPEN RACK 19" 3-97741COMBLINE PRESELECT 406-490MHZ 3-18317-11ISOLATOR COMBINER 5-WAY 8-230261FILTER, LOW PASS 600MHZ 8-60822010-32 x 1-2 SS THMS 1-223572FRONT PANEL, MODULE DUMMY SLOT 1-227002COVER, TOP & BOTTOM 1-227011COVER, BACK 1-227122FAN GUARD 1-227252COVER, SIDE 3-223223DSP CHANNEL MODULE ASSY, 450-470 MHz 3-23231DSP CHANNEL MODULE ASSY 470-491 MHZ 3-23232DSP CHANNEL MODULE ASSY 491-512 MHZ 3-223521CB MODULE, CAGE ASSY 3-223761POD ASSY, ACTIVE COMBINER PA 3-223802SUB ASSY, SPLITTER & DISTRIBUTION AMP 3-226841REAR FRAME ASSY CHANNELIZED BOOSTER 3-226861POD ASSY, POWER AND CONTROL 5A2125-81Terminal Block, Feed-thru, 8 position 5A2790-1218Collar, Screw pozidrive M2.5 x 12.3 5A2790-134Screw, TORX countersunk M2.5 x 7.3 5A2790-204Sleeve 8-1613526-32 x 3-8" PHILLIPS PHMSBLACK ZINC 8-221556M5 BELLEVILLE WASHER SS SERRATED BOTH SIDES 8-2225748-32 x .750 SHCS 8-2236414#6 BELLEVILLE WASHER SERRATED BOTH SIDES STEEL BLACK FINISH 8-223658M4 BELLEVILLE WASHER SERRATED BOTH SIDES STEEL BLACK FINISH 8-223698M4 x 0.7 x 10 MM SHCS, STEEL BLACK OXIDE 8-22370966-32 x .312 FHMS,UNDERCUTHEAD, PHILLIPS SS 8-22668610-32 x .375 SHCS, STEEL BLACK OXIDE 8-22669126-32 x .312 SHCS, STEEL BLACK OXIDE 8-226892CABLE ASSY, RJ45 JACK & PLUG 8-226911POWER ENTRY MODULE 8-226941JFA TAB HOUSING CONTACT 8-226951JFA CONNECTOR TAB HOUSING, PANEL MOUNT 8-227073CONN SMB FML , JACK BULKHEAD, RG-316 8-2270910CONNECTOR, TNC FEMALE BULKHEAD, RG-316 8-227112CONNECTOR, RJ-45 PANEL MOUNT, JACK 8-5872131-318 BNC FML BLKHD FOR RG-188 TR 8-60178#8-32 SS KEP NUT (TITELOK) 8-60234NO. 8 SS FLAT WASHER 8-615424-40 X 5-16 SS PHMS PHILLIPS LIGHT NYLON PATCH 8-619848-32 x 1/2 SS SOCKET HD CAP SCREW 3-4085 UHF Resonator Assembly for 3-9774 PA RT N U M B E RQTYDESCRIPTION 1-31701CAPACITIVE TUN SLEEVE, UHF INTERDIGITAL 1-31711RESONATOR COMP SECTION UHF COMBLINE 1-43751RESONATOR BODY, UHF COMBLINE FILTER 3-9774 Combline Preselector 406-490 MHz PA RT N U M B E RQTYDESCRIPTION 1-00828CONTACT FINGER SECTION 1-8" DIA TUN ROD 1-1228124-40 SILVER PLATED BRASS HEX NUT 1-15857CONTACT FINGER SECTION 1-4" TUNE RODS 1-32007TUNING ROD 2" VN CAVITY 1-4" DIA BR ROD 1-56914NUT BAR (FOR UHF COMBLINE) 1-56982END COVER UHF COMBLINE PRESELECTORS 1-64088TUNING ROD, 1-8"DIA x 3" LONG BR SIL PLT 611-70A Channelized Signal Booster PA RT N U M B E RQTYDESCRIPTION Channelized Signal Booster (Model 611-70A)Parts List (page 2 of 14) 1-97201CHASSIS LAYOUT UHF COMB LINE 2- 4 MHZ W-DUAL NTCH 3-40858RESONATOR ASSY, UHF COMBLINE 8-58862CONN N FML FLANG BLKHD SILVER W-GOLD PIN 8-600224-40 x 3-8 SS BHMS LIGHT NYLON PAT C H 8-60107SHAFTLOCK,1-4"W-HEX NUT,.255"+.002,-.000 8-60128SHAFTLOCK 1-8" NICKEL PLATED 8-60248NO.10 SS FLAT WASHER, MS 8-6024 8-61351210-32 x 1-2 SS PHILLIPS THMS LIGHT NYLON PATCH 8-6173810-32 X 5-8 SS TRIMMED HHMS not indented LIGHT NYLON PATCH 8-6305166-32 x 1-2" SS HHMS,INDENTED LIGHT NYLON PATCH 8-72220.2916COPPER STRIP .020" x .250" WIDE SIL PLTD 8-73592TEFLON WASHER, .132 ID x .375 OD x .062 8-743984-40 x 5-16 SS PHILLIPS BINDING HD MS LIGHT NYLON PATCH 3-18317-1 Isolator Combiner 5-Way PART NUMBERQTYDESCRIPTION 1-169111COVER FOR 5-WAY INTEGRATED ISO-COMBINER 1-169721HEATSINK 5-WAY ISO-COMBINER 1-17205-12COVER, SIDE FOR PWR DVDRSTYPE I 1-17544-11CHASSIS 5W INTEGRATED ISO- CMBNR RADITEK 4-166731CKT BD, COUPLING STRIP -7dB COUPLER 4-175451CIRCUIT BD 5W INTEGRATED ISO- CBNR RADITE 8-168436CONN TNC PRESS-IN DELTA #1220- 000-Q911-3 8-173785ISOLATOR DROP-IN 30W 460-486 MHz 8-5328420 WATT, 50 OHM FLANGED TERMINATION 8-5665_A0HEAT SINK COMPOUND, WAKEFIELD#120-8(8oz) 8-60801010-32 x 1-2 SS SHCS LIGHT NYLON PAT C H 8-6833_A33 db HYBRID COUPLER ANAREN #XC0450L-03 3-9774 Combline Preselector 406-490 MHz PART NUMBERQTYDESCRIPTION 8-7438564-40 x 1-4 SS BHMS PHILLIPS LIGHT NYLON PATCH 8-7440164-40 x 3-8 SS PHILLIPS BINDING HD MS LIGHT NYLON PATCH 8-7441204-40 x 1-2 SS PHILLIPS BINDING HD MS LIGHT NYLON PATCH 3-22295 PCBA, LED Channel Module PA RT N U M B E RQTYDESCRIPTION 4-222961PCB, LED Channel Module 5A2410-2G10Pin, Receptacle 6A1495-44LED, SMT Standard, Green 6A1495-92LED, SMT, BiColor, Red/Green, 1210 6A304-1650-F8Resistor,Chip 165 1% 0603 50V 1/ 10W Thick Film 6A405-104- KR1H 2Capacitor, Ceramic Chip 0.1uF 10% 0603 50V X7R 3-22297 PCBA, Control Board PA RT N U M B E RQTYDESCRIPTION 4-222981PCB, Bare Control Board Channel Booster 5-1723-81Connector,Header,Shrouded2x12 (24 pin) .100 x .100 5A2045-31Terminal, Block, Sub-min 3 pin 5A2319-11Connector, BNC(f) PCB Right Angle Jack 5A2458-2V-1001Connector, Header Friction Lock 2 position Vertical 5A2482-14Connector, SMB, PCB Mount 5A2538-111Connector, Sub-D Right Angle female 9 pin 5A2631-11Connector USB Type B 4 Pin 5A2691-21IC, Ethernet Module, w/ Encryption 5A2694-32Connector, RJ-45 Vertical 6A1008-45Diode, Schottky BAT54S series 6A1009-21Diode, Schottky Barrier SERIES MBRS 6A1493-11LED, SMD Pilot Light 6A1715-13Transistor, MOSFET-N 6A2075-31IC,Inverter, Triple Gate High Speed 6A2159-11IC EPROM, Flash SPI 1Mb 6A2162-101IC, Microcontroller 8-bit 6A2312-11IC, RS232 Line Driver/ Receiver 6A2357-11IC, Bus Extended, I2C 6A2908-11IC Dual USB Port TVS 8-TSSOP 6A2930-11IC, Buffer Clock, PCI-X,142Mhz 3-18317-1 Isolator Combiner 5-Way PA RT N U M B E RQTYDESCRIPTION Channelized Signal Booster (Model 611-70A)Parts List (page 3 of 14) 6A304-0R0-J3Resistor,Chip 0 5% 0603 50V 1/10W Thick Film 6A304-0R0-J3Resistor,Chip 0 5% 0603 50V 1/10W Thick Film 6A304-1003-F2Resistor,Chip 100K 1% 0603 50V 1/ 10W Thick Film 6A304-1501-F1Resistor,Chip 1.50K 1% 0603 50V 1/ 10W Thick Film 6A304-1622-F1Resistor,Chip 16.2K 1% 0603 50V 1/ 10W Thick Film 6A304-1651-F1Resistor,Chip 1.65K 1% 0603 50V 1/ 10W Thick Film 6A304-2151-F1Resistor,Chip 2.15K 1% 0603 50V 1/ 10W Thick Film 6A304-33R2-F6Resistor,Chip 33.2 1% 0603 50V 1/ 10W Thick Film 6A304-4321-F4…

Text truncated - open the document above for the full version.

Nemko Canada Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 Product Name: Channelized Signal Booster This letter is to clarify that there is no tuning procedure available to the end-user for this product. All tuning is conducted and sealed at the factory. By: Ronald J. Jakubowski Signature Printed Title: Chief Engineer-RF Systems On behalf of : TX RX Systems, Inc. Telephone: 440-539-1196 November 24, 2009 FCC ID: EZZ61170A Dated 24th Day of November 2009 Agency agreement expiration date: July 31, 2010

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Maximum peak eirp:39.00(dBm) Maximum peak eirp:7943.282347(mW) Antenna gain(maximum):0(dBi) Maximum antenna gain:1(numeric) Time Averaging:100(%) Prediction distance:100(cm) Prediction frequency:450(MHz) MPE limit for uncontrolled exposure at prediction frequency:0.300(mW/cm^2) Power density at prediction frequency:0.063211(mW/cm^2) Margin of compliance:-6.8(dB) This equates to:0.632106325W/m^2 2 4R PG S π =

Nemko Canada Inc. 303 River Road, Ottawa, Ontario K1V 1H2 T 1 613 737 9680 F 1 613 737 9691TF 1 800 563 6336 Nemko Test Report: 137975-1R1TRFWL Applicant: Bird Technologies - TX RX Systems 30303 Aurora Road Solon, United States OH 44139 Apparatus: Channelized Signal Booster FCC ID: EZZ61170A In Accordance With: FCC Part 90, Boosters Private Land Mobile Radio Services Authorized By: Kevin Ma, Wireless/EMC Specialist Date: February 19, 2010 Total Number of Pages: 86 Email [email protected] Web www.nemko.com Nemko Canada Inc. Report Number: 137975-1R1TRFWL Specification: FCC Part 90 TABLE OF CONTENTS Section 1 : Report Summary......................................................................................................................3 Section 2 : Equipment Under Test.............................................................................................................4 2.1 Identification of Equipment Under Test (EUT)..........................................................................................4 2.2 Accessories.................................................................................................................................................4 2.3 EUT Description.........................................................................................................................................4 2.4 Technical Specifications of the EUT..........................................................................................................5 2.5 EUT Modulations.......................................................................................................................................5 2.6 EUT Setup diagram....................................................................................................................................6 2.7 Operation of the EUT during testing..........................................................................................................6 2.8 Modifications incorporated in the EUT ......................................................................................................6 Section 3 : Test Conditions.........................................................................................................................7 3.1 Specifications.............................................................................................................................................7 3.2 Deviations From Laboratory Test Procedures ............................................................................................7 3.3 Test Environment.......................................................................................................................................7 3.4 Measurement Uncertainty...........................................................................................................................7 3.5 Test Equipment...........................................................................................................................................8 Section 4 : Results Summary.....................................................................................................................9 4.1 FCC Part 90 : Test Results.........................................................................................................................9 Appendix A : Test Results........................................................................................................................10 Clause 90.205 Output Power ...............................................................................................................................10 Clause 90.210 Conducted Spurious Emissions....................................................................................................18 Clause 90.210 Radiated Spurious Emissions.......................................................................................................60 Clause 90.213 Frequency Stability......................................................................................................................61 Clause 2-11-04/EAB/RF Occupied Bandwidth...................................................................................................62 Clause 2-11-04/EAB/RF Out of Band Rejection.................................................................................................80 Appendix B : Setup Photographs............................................................................................................85 Appendix C : Block Diagram of Test Setups..........................................................................................86 Page 2 of 86 SECTION 1 : REPORT SUMMARY Nemko Canada Inc. Report Number: 137975-1R1TRFWL Specification: FCC Part 90 Section 1 : Report Summary These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 90. Conducted measurements were performed in accordance with ANSI TIA-603-B-2002. Radiated tests were conducted is accordance with ANSI C63.4-2003. The assessment summary is as follows: Apparatus Assessed: Channelized Signal Booster Specification: FCC Part 90 Compliance Status: Complies Exclusions: None Non-compliances: None Report Release History: R1 – Product description updated Test Location: Nemko Canada Inc. 303 River Road Ottawa, Ontario K1V 1H2 Registration Number: 176392 (3 m Semi-Anechoic Chamber) Tests Performed By: Andrey Adelberg, EMC/Wireless Specialist Test Dates: April 23–24 and November 3–4, 2009 Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for …
