F2Q4NE980TPMKeyboard

WARNING S S P P E E C C I I F F I I C C A A T T I I O O N N S S O O F F N N E E T T M M E E D D I I A A K K E E Y Y B B O O A A R R D D S S C C O O R R P P I I U U S S 9 9 8 8 0 0 T T P P / / 9 9 8 8 0 0 T T P P M M P P L L U U S S JUN 03,1999 9F,#75,Sec, 1 Hsin Tai Wu Rd. Hsichih, Taipei Hsien, Taiwan, R.O.C (Far East World Center-Bldg.A) TEL(886-2)2698-2566 FAX(886-2)2698-3133 Scorpius 980tP /980TPM plus SCORPIUS SPECIFICATIONS 2 Note : This equipment has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference to radio communications however , there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on , the user is encouraged to try to correct the interference by one or more of the following measures: £ªReorient or relocate the receiving antenna. £ªIncrease the separation between the equipment and receiver. £ªConnect the equipment into an outlet on a circuit different from that to which the receiver in connected. £ªConsult the dealer or an experienced radio / TV technician for technician for help. Notice: Changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operaton is Subject to the following two conditions : (1) this device may not cause Harmful interference, and (2) this device must accept any interference Received, including interference that may cause undesired operaton. WARNING Scorpius 980tP /980TPM plus SCORPIUS SPECIFICATIONS 3 ¢πSCOPE The purpose of this specification is to define the generic operational, Environmental, electrical and mechanical characteristics of the “ Scorpius 980TP / 980TPM “ rubber mechanical keyswitch keyboard. ¢∫ GENERAL Description The Scorpius 980TP / 980TPM keyboard has an enhanced slim design and can work with any IBM PC AT & PS/2 compatible computer. Utilizing the latest in rubber mechanical key switch technology, the Scorpius 980TP / 980TPM plus offers durability and style that will enhance any system for years to come. 23 Extra rubber buttons let keyboard link more closer with PC, touch one button to make some functions work immediately. 10 of 23 buttons can be programmed by end-users. 3 ACPI Keys added for easy using under Windows 98. The trackball is 400 dot per inch (DPI) or 0.015 mm/count opto- mechanical mouse A built in micro processor, Uses multiple rotary optical encoders and a rubber coated ball to detect Mouse movements . count signals are sent to the host computer where They are translated into motion of the display screen cursor. Multiple Interface protocols are provided as follows. Trackball with three Buttons A powerful 3-button Trackball built-in for convenient operation. Scorpius 980tP /980TPM plus SCORPIUS SPECIFICATIONS 4 Features £ªEasily “plug and play” and compatible with IBM PC which supports PS/2 ports and Com Port £ªFeaturing with 20 hot key to quickly access Internet browser and multimedia applications £ª10 of the 20 hot keys are programmable which can be re-defined by user’s command after installing the included software £ªMultimedia functions support five DVD players: ATI, Creative, Realmagic, Win DVD and Power DVD £ªSupport three Windowsσ 98 ACPI keys £ªBuilt-in trackball with scroll-in-mouse program activate Scrolling and Zoom functions £ªSleek style with detachable ergonomic wrist pad £ª Adjustable tilt mechanism. £ª High quality rubber membrane key switches. £ª Permanently attached coiled cord. £ª Tactile key stroke. £ª N-key –roll- over. £ª 20,000,000 lift cycles per switch. Appearance / Durability This keyboard is to be used in home and office environments. Therefore, the quality of appearance and touch are of great importance. Because of the environmental severity of home and office place, longevity, durability and resistance to contamination are also of major concern. Good engineering design practices shall be followed throughout, both mechanically and electrically. Scorpius 980tP /980TPM plus SCORPIUS SPECIFICATIONS 5 Package Contents S-980TP • Keyboard ( with 2 PS/2 ports ) • Wrist-support attachment • CD-ROM driver ( for software installation ) • User Manual S-980TPM• Keyboard ( Y –cable with 2 PS/2 ports ; a Serial-adapter) • Wrist-Support attachment • CD-ROM driver ( for software installation ) • User,s Manual Definitions The term “keyboard” when used in this document defines a PC board with 104 /105 /109 key switches, 3 ACPI keys and 20 rubber buttons for Scorpius 980TP / 980TPM which is fully assembled and housed in an enclosure with an interconnecting cable. The complete assembly shall be tested and ready for use when plugged into a host device. Scorpius 980tP /980TPM plus SCORPIUS SPECIFICATIONS 6 ¢ª ENVIRONMENTAL SPECIFICATIONS Temperature Operating The operating temperature range shall be from 0¢J to 50¢J(32 o F to 122 o F). There shall be An operational temperature test of a single cycle, ambient, cold, hot, ambient, With a minimum of a 15 minute dwell (pause) for every 15¢J increment of change. The rate of temperature change shall not exceed 20¢J per hour. The keyboard will operate normally throughout the cycle requiring no operator Intervention or corrective actions, except to cause normal movement. Non-Operating The non-operating temperature range shall be from-10¢J to 60¢J(14 o F to 140 o F). There Shall be a thermal shock test of five(5) cycles from-15 ¢J to 55¢J holding for 30 minutes at each extreme. The rate of temperature change shall not exceed 25¢J pe…

Text truncated - open the document above for the full version.

Photo # 1 Front View (Model No. SCORPIUS 980TPM plus) Photo # 2 Front View (Model No. SCORPIUS 980TP Plus) Photo # 3 Rear View Photo # 4 Unit Partially Disassembled Photo # 5 Unit Partially Disassembled Photo # 6 Unit Partially Disassembled Photo # 7 Unit Partially Disassembled Photo # 8 Unit Partially Disassembled Photo # 9 Unit Partially Disassembled

1. Product Labeling 1-1. FCC ID label 1-2 Location of Label on EUT

NEUTRON EMC LAB. FCC ID: F2Q4NE980TPM 1/21 MEASUREMENT/TECHNICAL REPORT APPLICTNT: QTRONIX CPRPORATION MODEL NO.: SCORPIUS 980TP plus, SCORPIUS 980TPM plus FCC ID: F2Q4NE980TPM This report concerns ( check one ) : Original Grant ̧ Class II Change Equipment type: Keyboard Deferred grant requested per 47CFR 0.457(d)(1)(ii)? Yes No ̧ If yes, defer until: (date) We, the undersigned, agree to notify the Commission by (date) / / of the intended date of announce ment of the product so that the grant can be issued on that date. Transiyion Rules Request per 15.37? Yes No ̧ If no, assumed Part 15, Subpart B for unintentional radiator the new 47 CFR (10-1-90 Edition) provision. Report Prepared by Testing House : Neutron Engineering Inc. for Company : Name QTRONIX CORPORATION Address 9F, #75, Sec, 1 Hsin Tai Wu Rd. Hsichih, Taipei Hsien, Taiwan, R. O. C. Applicant Signature °G Alan Hsu / Electronic Chief NEUTRON EMC LAB. FCC ID: F2Q4NE980TPM 2/21 CERTIFICATION We hereby certify that: The test data , data evaluation , test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) /CISPR22(1996) and the energy emitted by the sample EUT tested as described in this report is in compliance with CLASS B conducted and radiated emission limits of FCC Rules Part 15 , Subpart B/CISPR22(1996). NEUTRON ENGINEERING INC. 20, Alley 50, Lane 119, Dong Hwu Rd., P.O. Box 6-158, Nei Hwu, Taipei, Taiwan TEL °G(02) 2646-5426 FAX°G(02) 2646-6815 Prepared by: Sherry Kuo Reviewed by: Andy Chiu Approved by: George Yao Issued Date : Dec. 9, 1999 Report No. : NEI-FCCB-99201 Company Stamp: NEUTRON EMC LAB. FCC ID: F2Q4NE980TPM 3/21 Table of Contents 1. General Information...................................................................................................................... 1-1 Product Description................................................................................................................4 1-2 Related Submittal(s)/Grant(s)..................................................................................................4 1-3 Tested System Details.............................................................................................................5 1-4 Test Methodology...................................................................................................................6 1-5 Test Facility............................................................................................................................6 2. System Test Configuration............................................................................................................ 2-1 Justification.............................................................................................................................7 2-2 EUT Exercise Software...........................................................................................................7 2-3 Special Accessories.................................................................................................................8 2-4 Equipment Modifications.........................................................................................................8 2-5 Configuration of Tested System...............................................................................................9 Figure 2-1 Configuration of Tested System....................................................................................11 3. Conducted and Radiated Measurement Photos............................................................................ Figure 3-1.Conducted Measurement Photos...................................................................................12 Figure 3-2 Radiated Measurement Photos......................................................................................14 4. Conducted Emission Datas............................................................................................................16 5. Radiated Emission Datas .............................................................................................................. 5-1 Reaiated Emission Data...........................................................................................................18 5-2 Field Strength Calculation.......................................................................................................20 5-3 Correction Factor Table VS Frequency....................................................................................21 NEUTRON EMC LAB. FCC ID: F2Q4NE980TPM 4/21 1. GENERAL INFORMATION 1-1. Product Description The QTRONIX CORPORATION Model: SCORPIUS 980TP plus, SCORPIUS 980TPM plus (referred to as the EUT in this report) has an enhanced slim design and can work with any IBM PC AT&PS/2 compatible computer. The summarized feature of EUT are described as following: l Easily “plug and play” and compatible with IBM PC which supports PS/2 ports and Com port. l Featuring with 20 hot key to quick access Internet browser and multimedia applications. l 10 of the 20 hot keys are programmable which can be re-defined by user’s command after installing the included software. l Multimedia functions support five DVD players: ATI, Creative, Realmagic, Win DVD and Power DVD l Support three Windows ... 98 ACPI keys l Built-in trackball with scroll-in-mouse program activate Scrolling and Zoom functions. l Sleek style with detachable ergonomic wrist pad l Adjustable tilt mechanism. l High quality rubber membrane key switches. l Permanently attached coiled cord. l Tactile key stroke. l N-key-roll-over. l 20,000,000 lift cycles per switch. A more detailed and/or technical description of EUT is attached in User’s Manual. 1-2. Related Submittal(s) / Grant (s) 1-2-1.Models Covered Models Covered in this test report submitted for FCC ID filing are model SCORPIUS 980TP plus and SCORPIUS 980TPM plus 1-2-2.Models Difference Model: SCORPIUS 980TPM plus is identical to Model: SCORPIUS 980TP…
