S S C C O O R R P P I I U U S S 9 9 8 8 0 0 T T U U P P L L U U S S K K E E Y Y B B O O A A R R D D S S P P E E C C I I F F I I C C A A T T I I O O N N S S JUN 03, 1999 9F,#75,Sec, 1 Hsin Tai Wu Rd. Hsichih, Taipei Hsien, Taiwan, R.O.C (Far East World Center-Bldg.A) TEL: (886-2)2698-2566 FAX: (886-2)2698-3133 Scorpius 980Tu plus Keyboard SPECIFICATIONS 2 WARNING Note : This equipment has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and , if not installed and used in accordance with the instructions, may cause harmful interference to radio communications however , there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on , the user is encouraged to try to correct the interference by one or more of the following measures: £ªReorient or relocate the receiving antenna. £ªIncrease the separation between the equipment and receiver. £ªConnect the equipment into an outlet on a circuit different from that to which the receiver in connected. £ªConsult the dealer or an experienced radio / TV technician for technician for help. Notice: Changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conditions : (1) this device may not cause Harmful interference, and (2) this device must accept any interference Received, including interference that may cause undesired operation. Scorpius 980Tu plus Keyboard SPECIFICATIONS 3 ¢πSCOPE The purpose of this specification is to define the generic operational, Environmental, electrical and mechanical characteristics of the “ Scorpius 980TU Plus“ rubber mechanical keyswitch keyboard. ¢∫ GENERAL Description The Scorpius 980TU keyboard has an enhanced slim design and can work with any USB compatible computer. Utilizing the latest in rubber mechanical key switch technology, the Scorpius 980TU plus offers durability and style that will enhance any system for years to come. 23 Extra rubber buttons let keyboard link more closer with PC, touch one button to make some functions work immediately. 10of 23 buttons can be programmed by end-users. 3 ACPI Keys added for easy using under Windows 98. The trackball is 400 dot per inch (DPI) or 0.015 mm/count opto- mechanical mouse A built in micro processor, Uses multiple rotary optical encoders and a rubber coated ball to detect Mouse movements . count signals are sent to the host computer where They are translated into motion of the display screen cursor. Multiple Interface protocols are provided as follows. Trackball with three Buttons A powerful 3-button Trackball built-in for convenient operation. Features £ªEasily “plug and play” and compatible with IBM PC which supports USB ports £ªFeaturing with 20 hot key to quickly access Internet browser and multimedia applications £ª10 of the 20 hot keys are programmable which can be re-defined by user’s command after installing the included software Scorpius 980Tu plus Keyboard SPECIFICATIONS 4 £ªMultimedia functions support five DVD players: ATI, Creative, Realmagic, Win DVD and Power DVD £ªSupport three Windowsσ 98 ACPI keys £ªBuilt-in trackball with scroll-in-mouse program activate Scrolling and Zoom functions £ªSleek style with detachable ergonomic wrist pad £ªAdjustable tilt mechanism. £ªHigh quality rubber membrane key switches. £ªPermanently attached coiled cord. £ªTactile key stroke. £ªN-key –roll- over. £ª20,000,000 lift cycles per switch. Appearance / Durability This keyboard is to be used in home and office environments . Therefore, the quality of appearance and touch are of great importance. Because of the environmental severity of home and office place, longevity, durability and resistance to contamination are also of major concern. Good engineering design practices shall be followed throughout, both mechanically and electrically. Package Contents • SCORPIUS 980T Plus Keyboard ( with 2USB port) • Wrist-support attachment • CD-ROM driver ( for software installation ) • User Manual Definitions The term “keyboard” when used in this document defines a PC board with 104 /105 /109 key switches 3 ACPI keys and 20 rubber buttons for Scorpius 980TU Plus which is fully assembled and housed in an enclosure with an interconnecting cable. The complete assembly shall be tested and ready for use when plugged into a host device. Scorpius 980Tu plus Keyboard SPECIFICATIONS 5 ¢ª ENVIRONMENTAL SPECIFICATIONS Temperature Operating The operating temperature range shall be from 0¢J to 50¢J(32 o F to 122 o F). There shall be an operational temperature test of a single cycle, ambient, cold, hot, ambient, With a minimum of a 15 minute dwell (pause) for every 15¢J increment of change. The rate of temperature change shall not exceed 20¢J per hour. The keyboard will operate normally throughout the cycle requiring no operator Intervention or corrective actions, except to cause normal movement. Non-Operating The non-operating temperature range shall be from-10¢J to 60¢J(14 o F to 140 o F). There Shall be a thermal shock test of five(5) cycles from-15¢J to 55¢J holding for 30 minutes at each extreme. The rate of temperature change shall not exceed 25¢J per hour. Normal keyboard operation will be verified before and after the thermal shock text. Humidity Operating The operating relative humidity range shall be from10% to 85% non condensing ambient temperature. Non-Operating The non-operating relative humidity range shall be from 10% to 95% non- Condensing. The keyboard shall withstand an environment varying between …

Text truncated - open the document above for the full version.

SCORPIUS 980TU plus KEYBOARD QK 2104 IC KEYBOARD CONNECT LED DISPLAY LED DISPLAY MOUSE 6MHZ CRYSTAL SCORPIUS 980TU plus MOUSE 8452 IC QK 2104 IC X AXIS Y AXIS KEY BUTTON 6MHZ CRYSTAL

1. Product Labeling 1-1. FCC ID label 1-2 Location of Label on EUT
