F9CSMFMM-1Wireless LAN Radio

Schlumberger Sema

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 14, 2002
Application Purpose: Original Equipment
Date of Application: Nov 14, 2002
Equipment Note: Wireless LAN Radio
Frequency Range: 917.58000000 - 917.58000000
Company: Schlumberger Sema
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

SENTINEL™ Meter Technical Reference Guide Release 2.0 D r a f t iiSENTINEL Meter Technical Reference Guide Proprietary Rights Notice This manual is an unpublished work and contains the trade secrets and confidential infor- mation of SchlumbergerSema Inc., which are not to be divulged to third parties and may not be reproduced or transmitted in whole or part, in any form or by any means, electronic or mechanical for any purpose, without the express written permission of SchlumbergerSema Inc. All rights to designs or inventions disclosed herein, including the right to manufacture, are reserved to SchlumbergerSema Inc. The information contained in this document is subject to change without notice. Schlum- bergerSema reserves the right to change the product specifications at any time without incurring any obligations. Trademarks Used in This Manual SENTINEL is a trademark of SchlumbergerSema Inc. PC-PRO+ is a registered trademark of SchlumbergerSema Inc. SITESCAN is a trademark of SchlumbergerSema Inc. VECTRON is a registered trademark of SchlumbergerSema Inc. Windows is a trademark of Microsoft Corporation. SENTINEL™ Meter Technical Reference Guide C&I-SEN-0007.1-04.03 Part Number: 7002-CCC SchlumbergerSema Energy & Utilities 313-B North Highway 11 West Union, SC 29696 Tel: (864) 638-8300 Fax: (864) 638-4950 Copyright© 2002 SchlumbergerSema Inc. All rights reserved. D r a f t SENTINEL Meter Technical Reference Guideiii Compliance With FCC Regulations FCC Part 68, Class B Registration This equipment complies with Part 68 of the FCC Rules. The label affixed to this equipment contains, among other information, the FCC Registration Number and Ringer Equivalence Number (REN) for this equipment. Upon request, you must provide this information to your telephone company. The REN is useful to determine the quantity of devices you can connect to your telephone line and still have all of those devices ring when your telephone number is called. In most, but not all areas, the sum of the RENs of all devices connected to one line should not exceed five (5.0). To determine the number of devices your can connect to your line in your calling area—as determined by the REN—contact your local telephone company. The following jacks must be ordered from the telephone company to interconnect this prod- uct with the public communication network: RJ31. If your telephone equipment causes harm to the telephone network, the Telephone Com- pany can discontinue your service temporarily. If possible, they will notify you in advance. If advance notice is not practical, you will be notified as soon as possible. You will be informed of your right to file a complaint with the FCC. Your telephone company can make changes in its facilities, equipment, operations, or proce- dures that could affect the proper function of your equipment. If they do, you will be noti- fied in advance. You will then have an opportunity to maintain uninterrupted telephone service. If you have trouble with this equipment, please contact us at the address below for informa- tion on obtaining service or repairs. The telephone company may ask that you disconnect this equipment from the network until the problem has been corrected or until you are sure that the equipment is not malfunctioning. This product is not field-repairable; however, the maintenance section of this manual described troubleshooting steps that you can take in the even of equipment problems.This equipment can not be used on coin service lines provided by the telephone company. Connections to party lines are subject to state tariffs. Contact your local telephone com- pany if you plan to use this equipment on party lines. The installation of this product does not require any connections or changes to the internal wiring of other registered terminal equipment. FCC Part 15, Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These rules are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential/ commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1Re-orient or relocate the receiving antenna. 2Increase the separation between the equipment and the receiver. 3Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. D r a f t ivSENTINEL Meter Technical Reference Guide 4Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) The device may not cause harmful interference, and (2) this device must accept any interference received, including the inter- ference that may cause undesired operation. This equipment complies with the FCC RF radiation requirements for controlled environ- ments. To maintain compliance with these requirements, the antenna and any radiating ele- ments should be installed to ensure that a minimum separation distance of 20cm is maintained from the general population. FCC Part 15, Subpart C When equipped with a radio transmitter option, this equipment has been tested and found to comply with the limits for an intentional radiator, pursuant to Part 15, Subpart C of the FCC Rules. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause interference to radio communications.…

Text truncated - open the document above for the full version.

External Photos

ID Label/Location Info

PRODUCT LABELING Actual size of label is 0.95 Inches by 0.35 Inches and will be placed on the top side of the product. FCC ID: F9CSMFMM-1 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS. (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Internal Photos

Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 1 FCC Part 15 Subpart C Direct Sequence Spread Spectrum Transmitter Certification Test Report Appendix C Internal Photos Manufacturer: SchlumbergerSema, Inc. Model: Enigma FCC ID: F9CSMFMM-1 ACS Report Number: 02-0118-15C Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 2 Figure C1: Outer Cover Removed Exposing Face Plate with Antenna Antenna Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 3 Figure B2: Face Plate Removed Exposing Topside of RF Board Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 4 Figure B3: Face Plate and RF Board Removed Exposing Top Side of Power Supply Board Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 5 Figure B4: Back Side of Face Plate with Antenna Antenna Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 6 Figure B5: Top Side of RF Board Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 7 Figure B6: Bottom Side of RF Board Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 8 Figure B7: Topside of Power Supply Board Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 9 Figure B8: Back Side of Power Supply Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 10 Figure B9: Top Side of Display Board Model: Enigma Advanced Compliance Solutions FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Page 11 Figure B10: Back Side of Display Board

RF Exposure Info

FCC Compliance Statement General Information: Applicant: Schlumberger ACS Project: 02-0118 FCC ID: F9CSMFMM-1 Device Category: Mobile Device Environment: General Population/Uncontrolled Exposure Technical Information: Antenna Type: Integrated Patch Antenna Gain: 2 dBi Transmitter Conducted Power: 24dBm System EIRP: 407mW Operating Configuration: Wall Mounted Exposure Conditions: Usually greater than 20cm from the population MPE Calculation The minimum separation distance is calculated as follows: E(V/m) = xPxG30 Power Density: P d =(mW/cm 2 ) = d MPE Distance MPE Calculator for 900MHz Mobile Equipment Limits for General Population/Uncontrolled Exposure* Transmit Freq. Radio Power Antenna Gain Sytem EIRP MPE Limit MPE Distance (MHz) (dBm) (dBi) (mW) (mW/cm2)(cm) 900 24 2.1 407.38 0.60 4.41 Installation Guidelines The installation manual will contain the following text advising how to install the equipment to maintain compliance with the FCC RF exposure requirements: “This equipment complies with the FCC RF radiation requirements for uncontrolled environments. To maintain compliance with these requirements, the antenna and any radiating elements should be installed to ensure that a minimum separation distance of 20cm is maintained from the general population” Conclusion This device complies with the MPE requirements by providing adequate separation between the device and any radiating structure and the general population. E 2 3770

Test Report

FCC Part 15 Subpart C Direct Sequence Spread Spectrum Transmitter Certification Test Report Manufacturer: SchlumbergerSema, Inc. Model: ENIGMA RF MODULE WITH SENTINEL METER FCC ID: F9CSMFMM-1 Rules Section: 15.247(Modular Approval) Test Begin Date: July 25, 2002 Test End Date: September 16, 2002 Report Issue Date: October 14, 2002 ACS Report Number: 02-0118-15C Test Result: PASS Prepared by: R. Sam Wismer Engineering Manager Table of Contents 1.0 General 3 1.1 Introduction 3 1.2 Product Description 3 1.2.1 General 3 1.2.2 Intended Use 3 1.2.3 Technical Specifications 3 1.2.4 Antennas 3 2.0 Location of Test Facility 4 2.1 Description of Test Facility 4 2.1.2 Open Area Test Site 4 2.1.2 Conducted Emissions Test Site 5 3.0 Applicable Standards and References 6 4.0 List of Test Equipment 6 5.0 Support Equipment 7 6.0 EUT Setup Block Diagram 8 7.0 Summary of Tests 8 7.1 Section 15.203 - Antenna Requirement 9 7.2 Section 15.207 - Power Line Conducted Emissions 9 7.3 Section 15.209 - Radiated Emissions 11 7.4 Section 15.247(b)(1) – Peak Output Power 13 7.5 Section 15.247(a)(2) – 6 dB Bandwidth 15 7.6 Section 15.247(d) – Power Spectral Density 15 7.7 Section 15.247(c) - Spurious Emissions 15 7.7.1 RF Conducted Spurious Emissions 15 7.7.2 Radiated Spurious Emissions(Restricted Bands) 17 7.6.2.1 Duty Cycle Correction Factor 17 7.6.2.2 Test Results 18 8.0 RF EXPOSURE - Section 15.247(b)(4) 18 9.0 CONCLUSION 19 Appendix A - Radiated Spurious Emissions Appendix B – External Photographs Appendix C – Internal Photographs Model: Enigma RF Module with Sentinel Meter FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Advanced Compliance Solutions Page 3 1.0 GENERAL 1.1 Introduction The purpose of this report is to demonstrate compliance with Part 15, Subpart C of the FCC’s Code of Federal Regulations. 1.2 Product Description 1.2.1 General The Equipment Under Test (EUT), is the Model Enigma RF Module with the Sentinel Meter manufactured by SchlumbergerSema, Inc. Located at the following address: SchlumbergerSema, Inc. 313-B North Highway 11 West Union, South Carolina 29696 Detailed photographs of the EUT are filed separately with this filing. 1.2.2 Intended Use The EUT is intended to transmit power usage to a data collection point via a Direct Sequence Spread Spectrum RF link. The power meters are fixed devices typically installed outdoors on the sides of buildings, or otherwise greater than 2 meters from nearby persons. 1.2.3 Technical Specifications Table 1.2.3-1: Specifications Frequency Band 902-928 Number of Channels 1 Channel Bandwidth 1.0 MHz Nominal Channel Spacing N/A Output power 23.66dBm nominal Antenna Type Dipole Antenna Gain 2dBi Antenna Connector Type Permanently Attached to PCB 1.2.4 Antennas The antenna is a tuned dipole on a printed circuit board that is located on the faceplate of the SENTINEL meter. Table 1.2.4-1 below gives the antennas that will be employed with the Enigma RF Module with the Sentinel Meter. Photographs are submitted separately as appendix B with this filing. Table 1.2.4-1: Antennas Mfg. Mfg. Antenna Gain Connector System EIRP Model No. Type (dBi) Type (dBm) Schlumberger Proprietary Dipole 2 Soldered to Board 26 Model: Enigma RF Module with Sentinel Meter FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Advanced Compliance Solutions Page 4 2.0 LOCATION OF TEST FACILTY All testing was performed by qualified ACS personnel located at the following address: ACS, Inc. 5015 B.U. Bowman Drive Buford, GA 30518 2.1 DESCRIPTION OF TEST FACILITY Radiated and conducted emissions were conducted at an ACS facility specifically prepared for this testing. Both sites have been fully described and submitted to, and accepted by the FCC and Industry Canada. FCC registration number 89450 and Industry Canada Lab Code IC 4175 have been assigned in recognition of the sites. Both sites are also in conformance with publication CISPR16. 2.1.1 Open Area Test Site The open area test site consists of a 40’ x 66’ concrete pad covered with a perforated electro-plated galvanized sheet metal. The perforations in the sheet metal are 1/8” holes that are staggered every 3/16”. The individual sheets are placed to overlap each other by 1/4” and are riveted together to provide a continuous seam. Rivets are spaced every 3” in a 3 x 20 meter perimeter around the antenna mast and EUT area. Rivets in the remaining area are spaced as necessary to properly secure the ground plane and maintain the electrical continuity. The entire ground plane extends 12’ beyond the turntable edge and 16’ beyond the antenna mast when set to a 10 meter measurement distance. The ground plane is grounded via 4 - 8’ copper ground rods, each installed at a corner of the ground plane and bound to the ground plane using 3/4" stainless steel braided cable. The turntable is an all aluminum 10’ flush mounted table installed in an all aluminum frame. The table is remotely operated from inside the control room located 40’ from the range. The turntable is electrically bonded to the surrounding ground plane via steel fingers installed on the edge of the turn table. The steel fingers make constant contact with the ground plane during operation. Adjacent to the turntable is a 7’ x 7’ square and 4’ deep concrete pit used for support equipment if necessary. The pit is equipped with 5 - 4” PVC chases from the pit to the control room that allow for cabling to the EUT if necessary. The underside of the turntable can be accessed from the pit so cables can be supplied to the EUT from the pit. The pit is covered with 2 sheets of 1/4" diamond style re- enforced steel sheets. The sheets are painted to match the perforated steel ground plane, however the underside edges have been masked off to maintain the electrical continuity of the ground plane. All reflecting objects are located outside of the ellipse defined in ANSI C63.4. Model: Enigma RF Module with Sentinel Meter FCC ID: F9CSMFMM-1 ACS Report: 02-0118-15C Advanced Compliance Solutions Page 5 A diagram of the Open …

Text truncated - open the document above for the full version.

Test Report

Contact Information

Applicant

Lee Littlejohn(Compliance Engineer)

[email protected]864-638-4761Fax: 864-638-4900

Test Firm

Advanced Compliance Solutions, Inc.Sam Wismer

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	917.58 MHz - 917.58 MHz	232.00 mW

Confidentiality

Long Term

Grant Notes

The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
