HN22011B-22011B Radio in 700C

Intermec Technologies Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 28, 2003
Application Purpose: Original Equipment
Date of Application: Mar 15, 2003
Equipment Note: 2011B Radio in 700C
Frequency Range: 2412.00000000 - 2462.00000000
Company: Intermec Technologies Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Exhibit L: User Manual - Part 1 of 2 FCC ID: HN22011B-2 P/N 072719-002 Important Radio Information! Contents For Users in the United States and Canada ...................................................................................................................................2 For 700C-802.11b Configuration...................................................................................................................................2 For ABTM3 (Bluetooth-Compatible Wireless Module by Socket Communications) Configuration ...............................2 For MC45 (Wireless WAN, GSM/GPRS) Configuration ...............................................................................................3 For SB555 (Wireless WAN, CDMA/1x) Configuration..................................................................................................3 For Users Outside of the United States and Canada ......................................................................................................................4 For 700C-802.11b Configuration...................................................................................................................................4 For ABTM3 (Bluetooth-Compatible Wireless Module by Socket Communications) Configuration ...............................5 For MC45 (Wireless WAN, GSM/GPRS) Configuration ...............................................................................................6 Pour les utilisateurs en dehors du Canada et des Etat-unis .............................................................................................................7 Pour la configuration 700C-802.11b ..............................................................................................................................7 Pour la configuration ABTM3 (Module sans fil compatible avec la norme Bluetooth de Socket Communications) .........8 Pour la configuration MC45...........................................................................................................................................8 Für Benutzer außerhalb von Kanada und den Vereinigten Staaten ................................................................................................9 700C-802.11b ................................................................................................................................................................9 ABTM3 (Bluetooth-kompatibles Funkmodul von Socket Communications) ................................................................10 MC45 ..........................................................................................................................................................................10 Per gli utenti al di fuori del Canada o degli Stati Uniti ................................................................................................................11 Per la configurazione di 700C-802.11b.........................................................................................................................11 Per la configurazione di ABTM3 (modulo wireless Bluetooth-compatibile della Socket Communications)....................11 Per la configurazione di MC45 .....................................................................................................................................12 Para Usuarios Fuera de Canada o de los Estados Unidos .............................................................................................................12 Para configuração do 700C-802.11b.............................................................................................................................12 Para configuração do ABTM3 (Módulo sem fio compatível com Bluetooth da Socket Communications) .....................13 Para configuração do MC45 .........................................................................................................................................14 Para Usuários Fora do Canadá ou dos Estados Unidos ................................................................................................................14 Para la configuración de 700C-802.11b ........................................................................................................................14 Para la configuración de ABTM3 (Módulo inalámbrico compatible con Bluetooth de Socket Communications) ..........15 Para la configuración de MC45.....................................................................................................................................16 2 For Users in the United States and Canada Place this supplement in your manual. For 700C-802.11b Configuration This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that can cause undesired operation. Federal Communications Commission Compliance FCC Digital Emissions Compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the radio or television receiving antenna. • Increase the separation between the computer equipment and receiver. • Connect …

Text truncated - open the document above for the full version.

Users Manual

Exhibit L: User Manual - Part 2 of 2 FCC ID: HN22011B-2 Scanner SupportChapter —6 182700 Series Color Mobile Computer User’s Manual Code 128 Enumerations typedef enum tagCode128Decoding { ITC_CODE128_NOTACTIVE = 0, // Default ITC_CODE128_ACTIVE = 1, ITC_CODE128_NO_CHANGE = 255 } ITC_CODE128_DECODING; typedef enum tagEan128Identifier { ITC_EAN128_ID_REMOVE, ITC_EAN128_ID_INCLUDE, // Default ITC_EAN128_ID_NO_CHANGE = 255 } ITC_EAN128_IDENTIFIER; typedef enum tagCode128Cip128 { ITC_CODE128_CIP128_NOTACTIVE = 0, // Default ITC_CODE128_CIP128_ACTIVE = 1, ITC_CODE128_CIP128_NO_CHANGE = 255 } ITC_CODE128_CIP128; #define ITC_CODE128_FNC1_NO_CHANGE 255. This definition can be used when the Code128 FNC1 does not require any change. #define ITC_BC_LENGTH_NO_CHANGE 255. This definition can be used when the bar code length does not require any change. The table below shows what to be expected for EAN 128 labels for various symbology identifier transmit configurations and EAN 128 Identifier op- tions. SetupApplication’s Expected Result EAN 128 ]C1 IDSymbology ID optionEAN 128 LabelOther Labels 1Include ]C1Disabled<data><data> 2Remove]C1Disabled<data><data> 3Include ]C1AIM ID Transmitted]C1<data>]XY<data> 4Remove]C1AIDIDTransmitted]C1<data>]XY<data> 5Include ]C1Custom ID TransmittedZ]C1<data>Z<data> 6Remove]C1Custom ID TransmittedZ<data>Z<data> where “X” is the symbology identifier, “Y” is the modifiercharacter, and “Z” is the 1-byte symbology identifier. 6 Scanner Support—Chapter 183700 Series Color Mobile Computer User’s Manual IS9CConfig::GetI2of5 This function retrieves the current settings of Interleaved 2 of 5. Syntax HRESULTIS9CConfig::GetI2of5(ITC_INTERLEAVED2OF5_DECODING* peDecode, ITC_INTERLEAVED2OF5_CHECK_DIGIT*peCheck, ITC_BARCODE_LENGTH_ID*peLengthId, BYTErbgLengthBuff[], DWORD*pdwNumBytes); Parameters peDecode[out] Pointer to the ITC_INTERLEAVED2OF5_DECODING location to receive the decoding for Interleaved 2 of 5 symbology. peCheck[out] Pointer to the ITC_INTERLEAVED2OF5_CHECK_DIGIT location to receive the check digit. peLengthId[out] Pointer to the ITC_BARCODE_LENGTH_ID location to receive an indicator of either ITC_BARCODE_LENGTH or ITC_BARCODE_FIXED_LENGTH. rgbLengthBuff[out,size_is(3)] An array of bytes to receives 1 byte of data for ITC_BARCODE_LENGTH or 3 bytes of data for ITC_BARCODE_FIXED_LENGTH. pdwNumBytes[out] Pointer to the DWORD location to receive a number indicating number of bytes in rbgLengthBuff[]: 1 byte for ITC_BARCODE_LENGTH or 3 bytes for ITC_BARCODE_FIXED_LENGTH. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Scanner SupportChapter —6 184700 Series Color Mobile Computer User’s Manual IS9CConfig::SetI2of5 This function updates the Interleaved 2 of 5 settings with new values. Syntax HRESULTIS9CConfig::SetI2of5(ITC_INTERLEAVED2OF5_DECODING eDecode, ITC_INTERLEAVED2OF5_CHECK_DIGITeCheck, ITC_BARCODE_LENGTH_IDeLengthId, BYTErgbLengthBuff[], DWORD dwNumBytes); Parameters eDecode[in] Identifies the decoding for Interleaved 2 of 5 symbology. eCheck[in] Identifies the check digit. eLengthId[in] Use ITC_BARCODE_LENGTH_NO_CHANGE to indicate no change for bar code length. Use ITC_BARCODE_LENGTH for any length and minimum length, and setrgbLengthBuff[0]to a valid length value. Use ITC_BARCODE_FIXED_LENGTH to compose 1 or 2 or 3 fixed lengths, and set 3 bytes: rgbLengthBuff[0],rgbLengthBuff[1], rgbLengthBuff[2]with valid values. rgbLengthBuff[in,size_is(dwNumBytes)] Contains bar code lengths wheneLengthId= Use ITC_BARCODE_LENGTH or Use ITC_BARCODE_FIXED_LENGTH. dwNumBytes[in] Number of bytes inrbgLengthBuff[]. For S9C, this value is 1 wheneLengthId= ITC_BARCODE_LENGTH or 3 wheneLengthId = ITC_BARCODE_FIXED_LENGTH. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Interleaved 2 of 5 Default Settings ParameterDefaultValid Range DecodingNot ActiveITC_INTERLEAVED2OF5_DECODING Check DigitNot UsedITC_INTERLEAVED2OF5_CHECK_DIGIT Bar Code LengthMinimum Length = 60x00`0xFE ITC_BC_LENGTH_NO_CHANGE 6 Scanner Support—Chapter 185700 Series Color Mobile Computer User’s Manual Interleaved 2 of 5 Enumerations typedef enum tagInterleaved2of5Decoding { ITC_INTERLEAVED2OF5_NOTACTIVE = 0, // Default ITC_INTERLEAVED2OF5_ACTIVE = 1, ITC_INTERLEAVED2OF5_NO_CHANGE = 255 } ITC_INTERLEAVED2OF5_DECODING; typedef enum tagInterleaved2of5CheckDigit { ITC_INTERLEAVED2OF5_CHECK_NOTUSED, // Default ITC_INTERLEAVED2OF5_CHECK_MOD10_XMIT, ITC_INTERLEAVED2OF5_CHECK_MOD10_NOTXMIT, ITC_INTERLEAVED2OF5_CHECK_FRENCH_CIP_XMIT, ITC_INTERLEAVED2OF5_CHECK_FRENCH_CIP_NOTXMIT, ITC_INTERLEAVED2OF5_CHECK_NO_CHANGE = 255 } ITC_INTERLEAVED2OF5_CHECK_DIGIT; typedef enum tagBarcodeLengthId { ITC_BARCODE_LENGTH = 0, ITC_BARCODE_FIXED_LENGTH, ITC_BARCODE_LENGTH_NO_CHANGE = 255 } ITC_BARCODE_LENGTH_ID; IS9CConfig::GetMatrix2of5 This function retrieves the current settings of Matrix 2 of 5. Syntax HRESULTIS9CConfig::GetMatrix2of5(ITC_MATRIX2OF5_DECODING* peDecode, DWORD*pdwLength); Parameters peDecode[out] Pointer to the ITC_MATRIX2OF5_DECODING location to receive the decoding for Matrix 2 of 5 symbology. pdwLength[out] Pointer to the DWORD location to receive a value for the bar code length. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Scanner SupportChapter —6 186700 Series Color Mobile Computer User’s Manual IS9CConfig::SetMatrix2of5 This function updates the Matrix 2 of 5 settings with new values. Syntax HRESULTIS9CConfig::SetMatrix2of5(ITC_MATRIX2OF5_DECODING eDecode, DWORDdwLength); Parameters eDecode[in] Identifies the decoding for Matrix 2 of 5 symbology. dwLength[in] Identifies the bar code length. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Matrix 2 of 5 Default Settings ParameterDefaultValid Range DecodingNot ActiveITC_MATRIX2OF5_DECODING Bar Code LengthMinimum Length = 60x00`0xFE ITC_BC_LENGTH_NO_CHANGE Matrix 2 of 5 Enumerations typedef enum tagMatrix2of5Decoding { IT…

Text truncated - open the document above for the full version.

Attestation Statements

Exhibit R: Applicant Attestation Letter FCC ID: HN22011B-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2663 fax www.intermec.com October 1, 2002 Northwest EMC Labs 22975 NW Evergreen Pkwy Ste 400 Hillsboro, OR 97124 Dear Sir or Madam, Intermec Technologies Corporation hereby declares that our 700C product (FCC ID: HN22011B-2) uses the same transceiver as Symbol's WLAN Compact Flash radio module (FCC ID: H9PLA4137P). No hardware or software modifications have been made to the module for its integration into our Pen Tablet Computer. Therefore all test data and technical exhibits in Symbol's original FCC grant application are applicable to our product as well. Please feel free to contact me, if you have any questions. Sincerely, Cheryl D. White Compliance Engineer Intermec Technologies Corp.

Cover Letter(s)

Exhibit A: Agent Authorization Letter FCC ID: HN22011B-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com November 8, 2002 To Whom It May Concern: Intermec Technologies, Corp., the undersigned, hereby authorizes Northwest EMC, Inc., to act on our behalf, as our agent, in the following matters related to the FCC and Industry Canada approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Northwest EMC, Inc. within the scope of this authorization shall have the same affect as our own. This authorization shall expire 12 months from original date. If you have any questions, regarding this application, please feel free to contact me (phone: 425 356 1765, fax: 425 348 2633, email: [email protected]). Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer Intermec Technologies Corp.

Cover Letter(s)

Exhibit B: Cover Letter From Agent FCC ID: HN22011B-2 NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 March 13, 2003 Dear Application Examiner: On behalf of Intermec Corporation, Northwest EMC Inc is submitting this application for the certification of Intermec’s 2011B radio, FCC ID: HN22011B-2. It is a 89 mW 802.11(b) radio that will only be used in the the applicant’s 700C hand held terminal as a portable transmitter. The EUT (FCC ID: HN22011B-2) can be configured with one of two different antennas; an external or an internal antenna. The EUT will be co-located with two other radios: FCC ID:HN2SB555-2 (CDMA radio), and FCC ID:HN2ABTM3-3 (Bluetooth radio). Any two of the three radios can transmit simultaneously. All three radios cannot transmit simultaneously. Each radio transmits through its own antenna. The CDMA radio only uses external antennas, so when the EUT is co-located with the CDMA radio, it only uses its internal antenna. The Northwest EMC technical report and associated spurious emissions data are supplied in support of the simultaneous transmission of the co- located radios. The RF exposure exhibit (SAR Reports) also addresses the exposure conditions of the co-located radios. The technical reports and exhibits demonstrate compliance with FCC rules 47 CFR 15.247. Your efforts in reviewing this application are greatly appreciated. Best regards, Greg Kiemel, Director of Engineering Northwest EMC, Inc.

Cover Letter(s)

Exhibit C: Request for Confidentiality Letter FCC ID: HN22011B-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.348.2600 tel 425.355.9551 fax www.intermec.com December 23, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: HN22011B-2 To whom it may concern, We hereby respectfully request that under the provision of 47 CFR 0.459, the documents listed below and attached with this application for certification under FCC ID: HN22011B-2 be provided with confidential status. • Schematics • Frequency Block Diagram • Operational Description Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer

External Photos

Exhibit E: External Photos FCC ID: HN22011B-2 Bottom Of 802.11(b) Radio Top of 802.11(b) Radio

ID Label/Location Info

Exhibit D: FCC ID Label & Location on Radio FCC ID: HN22011B-2

ID Label/Location Info

072775B SIZECAGE CODEDRAWING NUMBER SCALE 1/1SHEET 17 33825 CAD DB. REF - 072775_D_017 6001 36TH AVENUE WEST EVERETT, WA 98203-9280 REVISIONS DESCRIPTIONECN INITIAL DRAWING CREATION REV 01 RELEASED AT REV AA ADDED 760 CDMA CONFIGS & SHEET 17 TO DRAWINGD DATEAPPROVED ARTMASTER REV D 760 WITH: CDMA (FCC), FCC (704) 802.11b RADIO, AND BLUETOOTH RADIO CONFIGURATION 760XXXC1XXXX4704 OR CONFIGURATION 760XXXC2XXXX4704 Tested To Comply With FCC Standards FOR HOME OR OFFICE USE 12V 1,5A Made in Singapore I.T .E. 729T MODEL: 700C MFD: XXXXXXXXX 2002 SN: xxxxxxxxxxx XXXXXXXX4323232XXX CN: 760XXXC1XXXX4704 OR 760XXXC2XXXX4704 FCC ID: HN2SB555 FCC ID: HN22011BB CONTAINS TX FCC ID: HN2ABTM3-2 N309 SCALE 1/1:

ID Label/Location Info

Internal Photos

Exhibit F: Internal Photos FCC ID: HN22011B-2 Bottom of Radio, Shield Removed Top of Radio, Shield Removed

Parts List/Tune Up Info

Exhibit I: Antenna Description FCC ID: HN22011B-2 700C Antennas: Antenna Type Gain Manufacturer Part Number External Tuned Dipole 1.3 dBi Mobilemark 805-606 Internal Folded monopole -2 dBi (avg.) SeaRay 805-608 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com October 1, 2002 To Whom It May Concern: Intermec complies with the unique connector requirement of FCC Part 15.203 by using a custom made reverse gender SMA connector. This custom made antenna connector is not available off-the-shelf to consumers. If you have any questions regarding this product, please feel free to contact me (phone: 425 348 2600 ext 6214, fax: 425 348 2633, email: [email protected]). Sincerely, Cheryl D. White Compliance Engineer Intermec Technologies Corp.

RF Exposure Info

Exhibit N: SAR Test Report Cover Letters FCC ID: HN22011B-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com February 28, 2003 To Whom It May Concern: This letter is to is to explain the justification of the different configurations used in SAR testing of our Model 700C Mobile Computer with a Bluetooth, 802.11b and CDMA transmitters. Model 700C is a handheld computer intended for industrial and business customers with data collection, inventory tracking etc. needs. The product can contain any combination of the three transmitters listed above. The transmitters have all been granted FCC approval as a mobile application. With our new application we would like to obtain approval for portable uses of the product, which covers use of body worn accessories such as belt clip and holster, and a cell phone – like application with the CDMA transmitter, where an integrated speaker and microphone on the back of the product allow it to be used as a phone (although the product’s size limits this application to infrequent uses). Three separate SAR reports based on tests performed by Celltech Labs have been submitted with our grant application. These reports cover: 1) The Bluetooth transmitter alone 2) The 802.11b transmitter alone 3) The CDMA transmitter in both bands along with the 802.11b transmitter As can be seen in the Bluetooth and 802.11b test reports, both transmitters register very low SAR levels (~ 1% of the limit). Despite that fact, the effect of the 802.11b transmitter when it is co-located with the CDMA transmitter was tested as shown in the third report. While the CDMA transmitter was tested transmitting in various channels, the 802.11b transmitter was tested in the middle channel only due to its low SAR reading in the prior test (test report 2). The Bluetooth transmitter’s effect when it is co-located with the CDMA transmitter was not tested mainly due to its very low output power and very low SAR readings. Also, the Bluetooth transmitter does not operate when the CDMA transmitter is used in cell phone mode. The Bluetooth transmitter uses a lossy integrated antenna, which was used during its standalone SAR testing (test report 1). The 802.11b transmitter can use an internal and an external antenna alternatively, when the CDMA transmitter is not present. Both antenna configurations were tested during the standalone SAR test (test report 2). The CDMA transmitter only uses the external antenna, and when it and 802.11b transmitter are both present, the 802.11b transmitter uses only the internal antenna. Those antennas were used in the combined SAR test (test report 3). The belt clip and the holster accessories were not used during the SAR tests, since those are purely plastic and their presence would have only added to the distance. So, the SAR measurements reflect the absolute worst case scenario. The speaker and microphone for the cell phone application are internal to the product, and head model tests were performed (test report 3). If you have any questions, please feel free to contact our Safety and Compliance Group in Everett, WA USA at +1 425 356 1765. Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer Intermec Technologies Corp. Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com March 3, 2003 To Whom It May Concern: Celltech Labs Inc. performed three separate SAR measurements on behalf of Intermec Corporation Model 700C handheld data terminal with Bluetooth, 802.11b, and dual-band CDMA transmitters. The Bluetooth and 802.11b transmitters were tested individually in separate platforms; the Bluetooth with integrated antenna and the 802.11b with internal and external antenna configurations. The dual-band CDMA transmitter utilized an external antenna only, and was tested for single transmit and co-located simultaneous transmit with the 802.11b transmitter. The dual-band CDMA and 802.11b transmitters were not tested for co-located simultaneous transmit with the Bluetooth transmitter due to the low power of the Bluetooth (10mW). Subsequently, three SAR test reports were issued with the following serial numbers: Bluetooth: 080701-143EHA 802.11b: 100202-284HN2 CDMA: 010303-327HN2 Please do not hesitate to contact me if you have any further questions or comments. Sincerely, Jon Hughes General Manager Celltech Labs Inc.

RF Exposure Info

Exhibit O: CDMA SAR Report - Part 1 of 3 FCC ID: HN22011B-2 Test Report S/N: 010303-327HN2 Test Date(s): February 05-07, 2003 FCC/IC SAR Evaluation © 2003 Celltech Labs Inc.1 of 26 DECLARATION OF COMPLIANCE SAR EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone:250-448-7047 Fax:250-448-7046 e-mail:[email protected] web site:www.celltechlabs.com Applicant Information INTERMEC TECHNOLOGIES CORPORATION 6001 36 th Avenue West Everett, WA 98203 Rule Part(s):FCC 47 CFR §2.1093; IC RSS-102 Issue 1 (Provisional) Test Procedure(s):FCC OET Bulletin 65, Supplement C (Edition 01-01) FCC ID: HN2SB555 Model(s):700C Equipment Type:Handheld Voice/Data Terminal with Dual-Band CDMA Modem, DSSS Wireless LAN Card, & Bluetooth Module (802.11a) Device Classification(s):FCC Part 15 Digital Transmission System (DTS) FCC Part 24 Licensed Portable Transmitter Held to Ear (PCE) Modulation(s):Direct Sequence Spread Spectrum (DSSS), PCS CDMA, Cellular CDMA Tx Frequency Range(s):2412 - 2462 MHz (DSSS) 1851.25 - 1908.75 MHz (PCS CDMA) 824.70 - 848.31 MHz (Cellular CDMA) Conducted Power Tested:17.0 dBm (DSSS) 23.5 dBm (PCS CDMA) 23.5 dBm (Cellular CDMA) Antenna Type(s):Internal Patch (DSSS) External Stubby (Single-Band PCS CDMA P/N: 805-606-004) External Stubby (Dual-Band CDMA P/N: 805-606-002) Battery Type(s):7.2V Lithium-Ion (P/N: 318-013-001) Max. SAR Measured:1.47 W/kg (Head) / 1.00 W/kg (Body) Celltech Labs Inc. declares under its sole responsibility that this device was found to be in compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C, Edition 01-01 and Industry Canada RSS- 102 Issue 1 (Provisional) for the General Population / Uncontrolled Exposure environment. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Russell W. Pipe Senior Compliance Technologist Celltech Labs Inc. Test Report S/N: 010303-327HN2 Test Date(s): February 05-07, 2003 FCC/IC SAR Evaluation © 2003 Celltech Labs Inc.2 of 26 TABLE OF CONTENTS 1.0INTRODUCTION..................................................................... 3 2.0DESCRIPTION OF EUT............................................................ 3 3.0SAR MEASUREMENT SYSTEM ............................................... 4 4.0MEASUREMENT SUMMARY..................................................... 5-7 5.0DETAILS OF SAR EVALUATION............................................... 8-10 6.0EVALUATION PROCEDURES................................................... 11 7.0SAR LIMITS........................................................................... 11 8.0EVALUATION FLOW CHART................................................... 12 9.0SYSTEM PERFORMANCE CHECK............................................ 13 10.0EQUIVALENT TISSUES........................................................... 14 11.0SYSTEM SPECIFICATIONS...................................................... 15 12.0SAM PHANTOM...................................................................... 16 13.0DEVICE HOLDER.................................................................... 16 14.0PROBE SPECIFICATION......................................................... 16 15.0TEST EQUIPMENT LIST........................................................... 17 16.0MEASUREMENT UNCERTAINTIES............................................ 18 17.0REFERENCES........................................................................ 19 APPENDIX A - SAR MEASUREMENT DATA............................................. 20 APPENDIX B - SYSTEM CHECK DATA.................................................... 21 APPENDIX C - SYSTEM VALIDATION..................................................... 22 APPENDIX D - PROBE CALIBRATION.................................................... 23 APPENDIX E - MEASURED FLUID DIELECTRIC PARAMETERS................ 24 APPENDIX F - SAM PHANTOM CERTIFICATE OF CONFORMITY.............. 25 APPENDIX G - SAR TEST SETUP & EUT PHOTOGRAPHS........................ 26 Test Report S/N: 010303-327HN2 Test Date(s): February 05-07, 2003 FCC/IC SAR Evaluation © 2003 Celltech Labs Inc.Intermec Technologies Corporation FCC ID: HN2SB555 (Model: 700C)3 of 26 Handheld Voice/Data Terminal with Dual-Band CDMA Modem & DSSS WLAN Card 1.0 INTRODUCTION This measurement report demonstrates that the Intermec Technologies Corporation Model: 700C Handheld Voice/Data Terminal with Dual-Band CDMA Modem & DSSS WLAN Card FCC ID: HN2SB555 complies with the RF exposure requirements specified in FCC 47 CFR §2.1093 (see reference [1]), and Health Canada’s Safety Code 6 (see refe…
