HN2SB555-2SB555 Radio in 700C

Intermec Technologies Corporation

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Sep 04, 2003
Application Purpose: Original Equipment
Date of Application: Mar 14, 2003
Equipment Note: SB555 Radio in 700C
Frequency Range: 1850.00000000 - 1910.00000000
Company: Intermec Technologies Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Exhibit L: User Manual - Part 1 of 2 FCC ID: HN2SB555-2 P/N 072719-002 Important Radio Information! Contents For Users in the United States and Canada ...................................................................................................................................2 For 700C-802.11b Configuration...................................................................................................................................2 For ABTM3 (Bluetooth-Compatible Wireless Module by Socket Communications) Configuration ...............................2 For MC45 (Wireless WAN, GSM/GPRS) Configuration ...............................................................................................3 For SB555 (Wireless WAN, CDMA/1x) Configuration..................................................................................................3 For Users Outside of the United States and Canada ......................................................................................................................4 For 700C-802.11b Configuration...................................................................................................................................4 For ABTM3 (Bluetooth-Compatible Wireless Module by Socket Communications) Configuration ...............................5 For MC45 (Wireless WAN, GSM/GPRS) Configuration ...............................................................................................6 Pour les utilisateurs en dehors du Canada et des Etat-unis .............................................................................................................7 Pour la configuration 700C-802.11b ..............................................................................................................................7 Pour la configuration ABTM3 (Module sans fil compatible avec la norme Bluetooth de Socket Communications) .........8 Pour la configuration MC45...........................................................................................................................................8 Für Benutzer außerhalb von Kanada und den Vereinigten Staaten ................................................................................................9 700C-802.11b ................................................................................................................................................................9 ABTM3 (Bluetooth-kompatibles Funkmodul von Socket Communications) ................................................................10 MC45 ..........................................................................................................................................................................10 Per gli utenti al di fuori del Canada o degli Stati Uniti ................................................................................................................11 Per la configurazione di 700C-802.11b.........................................................................................................................11 Per la configurazione di ABTM3 (modulo wireless Bluetooth-compatibile della Socket Communications)....................11 Per la configurazione di MC45 .....................................................................................................................................12 Para Usuarios Fuera de Canada o de los Estados Unidos .............................................................................................................12 Para configuração do 700C-802.11b.............................................................................................................................12 Para configuração do ABTM3 (Módulo sem fio compatível com Bluetooth da Socket Communications) .....................13 Para configuração do MC45 .........................................................................................................................................14 Para Usuários Fora do Canadá ou dos Estados Unidos ................................................................................................................14 Para la configuración de 700C-802.11b ........................................................................................................................14 Para la configuración de ABTM3 (Módulo inalámbrico compatible con Bluetooth de Socket Communications) ..........15 Para la configuración de MC45.....................................................................................................................................16 2 For Users in the United States and Canada Place this supplement in your manual. For 700C-802.11b Configuration This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that can cause undesired operation. Federal Communications Commission Compliance FCC Digital Emissions Compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the radio or television receiving antenna. • Increase the separation between the computer equipment and receiver. • Connect …

Text truncated - open the document above for the full version.

Users Manual

Exhibit L: User Manual - Part 2 of 2 FCC ID: HN2SB555-2 Scanner SupportChapter —6 182700 Series Color Mobile Computer User’s Manual Code 128 Enumerations typedef enum tagCode128Decoding { ITC_CODE128_NOTACTIVE = 0, // Default ITC_CODE128_ACTIVE = 1, ITC_CODE128_NO_CHANGE = 255 } ITC_CODE128_DECODING; typedef enum tagEan128Identifier { ITC_EAN128_ID_REMOVE, ITC_EAN128_ID_INCLUDE, // Default ITC_EAN128_ID_NO_CHANGE = 255 } ITC_EAN128_IDENTIFIER; typedef enum tagCode128Cip128 { ITC_CODE128_CIP128_NOTACTIVE = 0, // Default ITC_CODE128_CIP128_ACTIVE = 1, ITC_CODE128_CIP128_NO_CHANGE = 255 } ITC_CODE128_CIP128; #define ITC_CODE128_FNC1_NO_CHANGE 255. This definition can be used when the Code128 FNC1 does not require any change. #define ITC_BC_LENGTH_NO_CHANGE 255. This definition can be used when the bar code length does not require any change. The table below shows what to be expected for EAN 128 labels for various symbology identifier transmit configurations and EAN 128 Identifier op- tions. SetupApplication’s Expected Result EAN 128 ]C1 IDSymbology ID optionEAN 128 LabelOther Labels 1Include ]C1Disabled<data><data> 2Remove]C1Disabled<data><data> 3Include ]C1AIM ID Transmitted]C1<data>]XY<data> 4Remove]C1AIDIDTransmitted]C1<data>]XY<data> 5Include ]C1Custom ID TransmittedZ]C1<data>Z<data> 6Remove]C1Custom ID TransmittedZ<data>Z<data> where “X” is the symbology identifier, “Y” is the modifiercharacter, and “Z” is the 1-byte symbology identifier. 6 Scanner Support—Chapter 183700 Series Color Mobile Computer User’s Manual IS9CConfig::GetI2of5 This function retrieves the current settings of Interleaved 2 of 5. Syntax HRESULTIS9CConfig::GetI2of5(ITC_INTERLEAVED2OF5_DECODING* peDecode, ITC_INTERLEAVED2OF5_CHECK_DIGIT*peCheck, ITC_BARCODE_LENGTH_ID*peLengthId, BYTErbgLengthBuff[], DWORD*pdwNumBytes); Parameters peDecode[out] Pointer to the ITC_INTERLEAVED2OF5_DECODING location to receive the decoding for Interleaved 2 of 5 symbology. peCheck[out] Pointer to the ITC_INTERLEAVED2OF5_CHECK_DIGIT location to receive the check digit. peLengthId[out] Pointer to the ITC_BARCODE_LENGTH_ID location to receive an indicator of either ITC_BARCODE_LENGTH or ITC_BARCODE_FIXED_LENGTH. rgbLengthBuff[out,size_is(3)] An array of bytes to receives 1 byte of data for ITC_BARCODE_LENGTH or 3 bytes of data for ITC_BARCODE_FIXED_LENGTH. pdwNumBytes[out] Pointer to the DWORD location to receive a number indicating number of bytes in rbgLengthBuff[]: 1 byte for ITC_BARCODE_LENGTH or 3 bytes for ITC_BARCODE_FIXED_LENGTH. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Scanner SupportChapter —6 184700 Series Color Mobile Computer User’s Manual IS9CConfig::SetI2of5 This function updates the Interleaved 2 of 5 settings with new values. Syntax HRESULTIS9CConfig::SetI2of5(ITC_INTERLEAVED2OF5_DECODING eDecode, ITC_INTERLEAVED2OF5_CHECK_DIGITeCheck, ITC_BARCODE_LENGTH_IDeLengthId, BYTErgbLengthBuff[], DWORD dwNumBytes); Parameters eDecode[in] Identifies the decoding for Interleaved 2 of 5 symbology. eCheck[in] Identifies the check digit. eLengthId[in] Use ITC_BARCODE_LENGTH_NO_CHANGE to indicate no change for bar code length. Use ITC_BARCODE_LENGTH for any length and minimum length, and setrgbLengthBuff[0]to a valid length value. Use ITC_BARCODE_FIXED_LENGTH to compose 1 or 2 or 3 fixed lengths, and set 3 bytes: rgbLengthBuff[0],rgbLengthBuff[1], rgbLengthBuff[2]with valid values. rgbLengthBuff[in,size_is(dwNumBytes)] Contains bar code lengths wheneLengthId= Use ITC_BARCODE_LENGTH or Use ITC_BARCODE_FIXED_LENGTH. dwNumBytes[in] Number of bytes inrbgLengthBuff[]. For S9C, this value is 1 wheneLengthId= ITC_BARCODE_LENGTH or 3 wheneLengthId = ITC_BARCODE_FIXED_LENGTH. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Interleaved 2 of 5 Default Settings ParameterDefaultValid Range DecodingNot ActiveITC_INTERLEAVED2OF5_DECODING Check DigitNot UsedITC_INTERLEAVED2OF5_CHECK_DIGIT Bar Code LengthMinimum Length = 60x00`0xFE ITC_BC_LENGTH_NO_CHANGE 6 Scanner Support—Chapter 185700 Series Color Mobile Computer User’s Manual Interleaved 2 of 5 Enumerations typedef enum tagInterleaved2of5Decoding { ITC_INTERLEAVED2OF5_NOTACTIVE = 0, // Default ITC_INTERLEAVED2OF5_ACTIVE = 1, ITC_INTERLEAVED2OF5_NO_CHANGE = 255 } ITC_INTERLEAVED2OF5_DECODING; typedef enum tagInterleaved2of5CheckDigit { ITC_INTERLEAVED2OF5_CHECK_NOTUSED, // Default ITC_INTERLEAVED2OF5_CHECK_MOD10_XMIT, ITC_INTERLEAVED2OF5_CHECK_MOD10_NOTXMIT, ITC_INTERLEAVED2OF5_CHECK_FRENCH_CIP_XMIT, ITC_INTERLEAVED2OF5_CHECK_FRENCH_CIP_NOTXMIT, ITC_INTERLEAVED2OF5_CHECK_NO_CHANGE = 255 } ITC_INTERLEAVED2OF5_CHECK_DIGIT; typedef enum tagBarcodeLengthId { ITC_BARCODE_LENGTH = 0, ITC_BARCODE_FIXED_LENGTH, ITC_BARCODE_LENGTH_NO_CHANGE = 255 } ITC_BARCODE_LENGTH_ID; IS9CConfig::GetMatrix2of5 This function retrieves the current settings of Matrix 2 of 5. Syntax HRESULTIS9CConfig::GetMatrix2of5(ITC_MATRIX2OF5_DECODING* peDecode, DWORD*pdwLength); Parameters peDecode[out] Pointer to the ITC_MATRIX2OF5_DECODING location to receive the decoding for Matrix 2 of 5 symbology. pdwLength[out] Pointer to the DWORD location to receive a value for the bar code length. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Scanner SupportChapter —6 186700 Series Color Mobile Computer User’s Manual IS9CConfig::SetMatrix2of5 This function updates the Matrix 2 of 5 settings with new values. Syntax HRESULTIS9CConfig::SetMatrix2of5(ITC_MATRIX2OF5_DECODING eDecode, DWORDdwLength); Parameters eDecode[in] Identifies the decoding for Matrix 2 of 5 symbology. dwLength[in] Identifies the bar code length. Return Values HRESULT that indicates success or failure. Remarks None. See Also None. Matrix 2 of 5 Default Settings ParameterDefaultValid Range DecodingNot ActiveITC_MATRIX2OF5_DECODING Bar Code LengthMinimum Length = 60x00`0xFE ITC_BC_LENGTH_NO_CHANGE Matrix 2 of 5 Enumerations typedef enum tagMatrix2of5Decoding { IT…

Text truncated - open the document above for the full version.

Attestation Statements

Exhibit T: Attestation Letter from Applicant FCC ID: HN2SB555-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com December 13, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: HN2SB555-2 To whom it may concern, Intermec Technologies Corp. hereby declares that the CDMA transceiver module SB555 used in our 700C handheld terminal product (FCC ID: HN2SB555-2) is the same transceiver module as Sierra Wireless’ CDMA module approved under FCC ID: N7NSB555. No hardware or software modifications have been made to the module for its integration into our terminal. Please feel free to contact me, if you have any questions. Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer

Attestation Statements

Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com May 27, 2003 To Whom It May Concern: This letter is to confirm that the 2.4 GHz DSSS transceiver used in our Model 700C (HN22011B and HN22011B-2) is the same transceiver module as the one certified by Intel Corp. (H9PLA4137P). No hardware or software modifications are made to the module for its integration into our Model 700C. The radio module was declared to have a conducted output power of 19.5 dBm in the original FCC test report. This power level was used in our original FCC grant application (HN22011B) as well as in the original SAR report (Celltech Labs 100202-284HN2). However, the testing performed by the original manufacturer Symbol Technologies was performed on early prototype units. We have never received a transceiver module with output power more than 17.2 dBm. In fact the vast majority of our radio modules have an output power around 16 dBm. To verify the output power 26 radios were taken from stock between May 12 and May 16 and their conducted output powers measured on low (1), medium (7) and high (11) channels with CW test output as well as worst case transmit (highest data rate, package transmission) modes. Only one of the 26 radios had an output power of 17.01 dBm at the low channel (CW). That same radio had an output power of 16.84 dBm and 16.42 dBm on the medium and high channels. All of the rest of the radios had conducted output powers ranging between 14 dBm and 16.7 dBm. During the retesting of the product with the collocated transmitters (HN22011B-2), conducted output power was measured at 17.0 dBm. This level was declared in the SAR test report (Celltech Labs 010303-327HN2). Therefore 17 dBm represents the worst case output power for our 802.11b radio in all configurations of our Model 700C. If you have any questions regarding these products, please feel free to contact our local representative or our Safety and Compliance Group in Everett, WA USA at +1 425 356 1765. Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer Intermec Technologies Corp.

Attestation Statements

Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com May 28, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Stan Lyles SUBJECT: Intermec Technologies Corporation FCC ID: HN22011B-2 731 Confirmation No.: EA496964 Correspondence Reference No.: 25158 Dear Stan, On behalf of Intermec Technologies Corporation is our response to question 3 of your e-mail dated May 08, 2003 requesting additional information for the subject application. 1. We confirm that the WLAN was operating correctly during the co-located transmit tests with the CDMA modem. The fact that the WLAN transmitter shows no effect on the SAR plots for co-located transmit with the CDMA modem can most likely be attributed to the following: a. The gain of the external single-band PCS CDMA antenna is 4 dBi and the gain of the external dual-band CDMA antenna is 3 dBi, whereas the gain of the internal WLAN antenna is -2 dBi. b. The output power of the CDMA modem is 23.5 dBm, whereas the output power of the WLAN is 17.0 dBm. c. In the ear-held position the distance from external CDMA antenna to EUT surface touching the phantom ear section is 1.5 cm, whereas the distance from the internal WLAN antenna to EUT surface touching the phantom ear section is 3.5 cm. d. For body-worn right side position, the external CDMA antenna is closer to the planar phantom than the WLAN antenna. If you have any further questions or comments concerning the above, please contact the undersigned. Sincerely, Jonathan Hughes General Manager Celltech Labs Inc. Cc: Intermec Technologies Corp.

Attestation Statements

Intel Corporation 2300 Corporate Center Drive CJ1 Thousand oaks, CA 91320 June 16, 2003 Intermec Technologies Corporation 6001 36th Avenue West Everett, WA 98203-1264 RE: CF Card Output Power To Whom It May Concern: The factory (Solectron, Malyasia) tunes the Intel PRO/Wireless 2011B CF Cards to obtain the best spectral mask possible in order to comply with the IEEE standards, which is 17dBM +/- 1.0dB. Tuning the card higher will saturate the PA and the signal degregates, not complying with IEEE requirements. . Regards, Jim Baer Manager, Global Compliance Engineering

Cover Letter(s)

Exhibit A: Agent Authorization Letter FCC ID: HN2SB555-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com November 8, 2002 To Whom It May Concern: Intermec Technologies, Corp., the undersigned, hereby authorizes Northwest EMC, Inc., to act on our behalf, as our agent, in the following matters related to the FCC and Industry Canada approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Northwest EMC, Inc. within the scope of this authorization shall have the same affect as our own. This authorization shall expire 12 months from original date. If you have any questions, regarding this application, please feel free to contact me (phone: 425 356 1765, fax: 425 348 2633, email: [email protected]). Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer Intermec Technologies Corp.

Cover Letter(s)

Exhibit B: Cover Letter From Agent FCC ID: HN2SB555-2 NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 March 13, 2003 Dear Application Examiner: On behalf of Intermec Corporation, Northwest EMC Inc is submitting this application for the certification of Intermec’s SB555 radio, FCC ID: HN2SB555-2. It is a dual-band wireless modem that supports both the 800 MHz and 1900 MHz PCS bands. It operates from 824 – 849 MHz and from 1850 – 1910 MHz, with a peak output power of 224 mW. This RF module will only be used in the applicant’s 700C hand held terminal as a portable transmitter. The EUT can be configured with one of two different antennas. The EUT will be co-located with two other radios: FCC ID:HN22011B-2 (802.11(b) radio), and FCC ID:HN2ABTM3-3 (Bluetooth radio). Any two of the three radios can transmit simultaneously. All three radios cannot transmit simultaneously. Each radio transmits through its own antenna. The Northwest EMC technical report and associated spurious emissions data are supplied in support of the two antennas and simultaneous transmission of the co-located radios. The RF exposure exhibit (SAR Reports) also addresses the exposure conditions of the co-located radios. Sierra Wireless Inc. was previously granted certification for this same radio module (FCC ID: N7NSB555). The applicant is not seeking to modify or alter the Sierra Wireless grant in any way. Intermec Corporation was previously granted certfication for this same radio in the 700C (FCC ID: HN2SB555) for mobile use only. This application is for a change in exposure condition to portable use. The technical reports and exhibits demonstrate compliance with FCC rules 47 CFR 22H and 47 CFR 24E. To facilitate the review process, an index of exhibits has been provided. Your efforts in reviewing this application are greatly appreciated. Best regards, Greg Kiemel, Director of Engineering Northwest EMC, Inc.

Cover Letter(s)

Exhibit C: Request for Confidentiality Letter FCC ID: HN2SB555-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.348.2600 tel 425.355.9551 fax www.intermec.com December 23, 2002 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: HN2SB555-2 To whom it may concern, We hereby respectfully request that under the provision of 47 CFR 0.459, the documents listed below and attached with this application for certification under FCC ID: HN2SB555-2 be provided with confidential status. • Schematics • Frequency Block Diagram • Operational Description • Tune-up Procedure • Bill of Materials Any exhibit / information for which we have requested confidentiality, but which may not be accorded such treatment by the FCC, should be returned to us. The documents listed above contain trade secrets that are treated as confidential by us. Substantial competitive harm to us could result should they be made available to the public. Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer

Cover Letter(s)

Exhibit P: SAR Test Report Cover Letters FCC ID: HN2SB555-2 Intermec Technologies Corporation 6001 36 th Avenue West Everett, WA 98203-9280 425.356.1765 tel 425.348.2633 fax www.intermec.com February 28, 2003 To Whom It May Concern: This letter is to is to explain the justification of the different configurations used in SAR testing of our Model 700C Mobile Computer with a Bluetooth, 802.11b and CDMA transmitters. Model 700C is a handheld computer intended for industrial and business customers with data collection, inventory tracking etc. needs. The product can contain any combination of the three transmitters listed above. The transmitters have all been granted FCC approval as a mobile application. With our new application we would like to obtain approval for portable uses of the product, which covers use of body worn accessories such as belt clip and holster, and a cell phone – like application with the CDMA transmitter, where an integrated speaker and microphone on the back of the product allow it to be used as a phone (although the product’s size limits this application to infrequent uses). Three separate SAR reports based on tests performed by Celltech Labs have been submitted with our grant application. These reports cover: 1) The Bluetooth transmitter alone 2) The 802.11b transmitter alone 3) The CDMA transmitter in both bands along with the 802.11b transmitter As can be seen in the Bluetooth and 802.11b test reports, both transmitters register very low SAR levels (~ 1% of the limit). Despite that fact, the effect of the 802.11b transmitter when it is co-located with the CDMA transmitter was tested as shown in the third report. While the CDMA transmitter was tested transmitting in various channels, the 802.11b transmitter was tested in the middle channel only due to its low SAR reading in the prior test (test report 2). The Bluetooth transmitter’s effect when it is co-located with the CDMA transmitter was not tested mainly due to its very low output power and very low SAR readings. Also, the Bluetooth transmitter does not operate when the CDMA transmitter is used in cell phone mode. The Bluetooth transmitter uses a lossy integrated antenna, which was used during its standalone SAR testing (test report 1). The 802.11b transmitter can use an internal and an external antenna alternatively, when the CDMA transmitter is not present. Both antenna configurations were tested during the standalone SAR test (test report 2). The CDMA transmitter only uses the external antenna, and when it and 802.11b transmitter are both present, the 802.11b transmitter uses only the internal antenna. Those antennas were used in the combined SAR test (test report 3). The belt clip and the holster accessories were not used during the SAR tests, since those are purely plastic and their presence would have only added to the distance. So, the SAR measurements reflect the absolute worst case scenario. The speaker and microphone for the cell phone application are internal to the product, and head model tests were performed (test report 3). If you have any questions, please feel free to contact our Safety and Compliance Group in Everett, WA USA at +1 425 356 1765. Sincerely, Carl K. Turk, MSEE Sr. EMC Engineer Intermec Technologies Corp. Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com March 3, 2003 To Whom It May Concern: Celltech Labs Inc. performed three separate SAR measurements on behalf of Intermec Corporation Model 700C handheld data terminal with Bluetooth, 802.11b, and dual-band CDMA transmitters. The Bluetooth and 802.11b transmitters were tested individually in separate platforms; the Bluetooth with integrated antenna and the 802.11b with internal and external antenna configurations. The dual-band CDMA transmitter utilized an external antenna only, and was tested for single transmit and co-located simultaneous transmit with the 802.11b transmitter. The dual-band CDMA and 802.11b transmitters were not tested for co-located simultaneous transmit with the Bluetooth transmitter due to the low power of the Bluetooth (10mW). Subsequently, three SAR test reports were issued with the following serial numbers: Bluetooth: 080701-143EHA 802.11b: 100202-284HN2 CDMA: 010303-327HN2 Please do not hesitate to contact me if you have any further questions or comments. Sincerely, Jon Hughes General Manager Celltech Labs Inc.

Cover Letter(s)

FCC ID: HN2SB555-2 Exhibit A Agent Authorization Letter Exhibit B Cover Letter From Agent Exhibit C Request for Confidentiality Letter Exhibit D FCC ID Label & Location on Radio Exhibit E External Photos Exhibit F Internal Photos Exhibit G Frequency Block Diagram Exhibit H Operational Description Exhibit I Antenna Description Exhibit J Technical Report Exhibit K Schematics Exhibit L User Manual Exhibit M Bill of Materials Exhibit N Test Setup Photos Exhibit O Tune-up Procedure Exhibit P SAR Test Report Cover Letters Exhibit Q CDMA SAR Report Exhibit R 802.11(b) SAR Report Exhibit S Bluetooth SAR Report Exhibit T Attestation Letter from Applicant

External Photos

Exhibit E: External Photos FCC ID: HN2SB555-2

ID Label/Location Info

Exhibit D: FCC ID Label & Location on Radio FCC ID: HN2SB555-2

ID Label/Location Info

072775B SIZECAGE CODEDRAWING NUMBER SCALE 1/1SHEET 17 33825 CAD DB. REF - 072775_D_017 6001 36TH AVENUE WEST EVERETT, WA 98203-9280 REVISIONS DESCRIPTIONECN INITIAL DRAWING CREATION REV 01 RELEASED AT REV AA ADDED 760 CDMA CONFIGS & SHEET 17 TO DRAWINGD DATEAPPROVED ARTMASTER REV D 760 WITH: CDMA (FCC), FCC (704) 802.11b RADIO, AND BLUETOOTH RADIO CONFIGURATION 760XXXC1XXXX4704 OR CONFIGURATION 760XXXC2XXXX4704 Tested To Comply With FCC Standards FOR HOME OR OFFICE USE 12V 1,5A Made in Singapore I.T .E. 729T MODEL: 700C MFD: XXXXXXXXX 2002 SN: xxxxxxxxxxx XXXXXXXX4323232XXX CN: 760XXXC1XXXX4704 OR 760XXXC2XXXX4704 FCC ID: HN2SB555 FCC ID: HN22011BB CONTAINS TX FCC ID: HN2ABTM3-2 N309 SCALE 1/1:

ID Label/Location Info

Internal Photos

Exhibit F: Internal Photos FCC ID: HN2SB555-2

Parts List/Tune Up Info

Exhibit I: Antenna Description FCC ID: HN2SB555-2 REVISION HISTORY Rev.File No.Description of ChangeDateApproved AC3233Release4/22/02D V BC3332¶1.0 Blue was yellow; ¶5.2 Was TBS; ¶5.3 Was TBS; ¶5.4 Was TBS; ¶6.2 Was6/10/02J S fractional wave; ¶6.3 -30º to +60ºC was TBS; ¶8.0 Blue was yellow; ¶9.0 Was TBS CC3463Add -004 part; Revise ¶1.0, ¶5.2, ¶5.3 & ¶6.2; ¶7.2 Was not specified; ¶8.0 Add 10/31/02J S length & -004 status; ¶9.0 Redrawn, L was 2.23, add 0.34, add 0.19 & add 0.09 (typ) DC3534¶5.2 3dBi & 4dBi were TBS; ¶5.3 3.0:1 was TBS; ¶8.0 1.10 was .90, & add white12/16/02J S REVISION LEVEL DDC SHEET NUMBER 1234567891011121…

Text truncated - open the document above for the full version.
