HOLCL990Cordless Phone Base

&DOOHU,'&DOO:DLWLQJ,' &RUGOHVV7HOHSKRQH 2ZQHU∑V0DQXDO SuperManual.book Page 1 Thursday, August 19, 1999 12:50 PM Copyright © 1999 by CIDCO Incorporated. All rights reserved. Part No. 103567.01 Rev. A No part of this publication may be reproduced, copied, transcribed, stored in a retrieval system, or translated into any language in any form, by any means, without the prior written permission of CIDCO Incorpo- rated. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. How- ever, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tele- vision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measurements: qReorient or relocate the receiving antenna. qIncrease the separation between the equipment and receiver. qConnect the equipment into an outlet on a circuit different from that to which the receiver is connected. qConsult the dealer or an experienced radio/TV technician for help. Caution ! Changes or modification to this device not expressly approved by CIDCO Incorporated could void the user’s authority to operate this equipment. SuperManual.book Page 2 Thursday, August 19, 1999 12:50 PM i TABLE OF CONTENTS o INTRODUCTION 1 Checking the Contents....................................................................................... 1 Basic Features ........................................................................................................ 1 o DESCRIPTION OF TELEPHONES 2 CL940 ........................................................................................................................ 2 CL980 ........................................................................................................................ 3 CL990 ........................................................................................................................ 3 Telephone Functions .......................................................................................... 4 Lights ............................................................................................................... 4 Keys .................................................................................................................. 4 o INSTALLING YOUR PHONE 6 Choose a Location for the Base Unit ............................................................. 6 Plug in the Adapter.............................................................................................. 6 Install the Line Cord............................................................................................. 6 Install Battery ......................................................................................................... 7 o PERSONALIZING YOUR PHONE 8 Enter Setup Mode ................................................................................................ 8 Select Your Language......................................................................................... 9 Enter Your Voice Mail Access Number ......................................................... 9 Set your Area Code Information ..................................................................... 9 Adding Other Local Area Codes ..................................................................... 9 Select Dialing Method ...................................................................................... 10 Select Ring Sound .............................................................................................. 10 New Call Light ..................................................................................................... 10 Answer on Pickup .............................................................................................. 10 o USING YOUR PHONE 11 Answering Calls................................................................................................... 11 Dialing .................................................................................................................... 11 Pre-Dialing ............................................................................................................ 11 Speed Dialing....................................................................................................... 11 Dialing from Caller ID Records.............................................................. 11 Dialing from Directory Records ............................................................ 11 Redialing ....................................................................................................... 12 Storing Numbers in your Phone for Speed Dialing....................... 12 Using Speedial ............................................................................................ 12 Reprogramming Network Service Keys for One Touch Dialing ........ 12 Adjusting the Volume....................................................................................... 13 Using the Speakerphone ................................................................................. 13 Using the Intercom ............................................................................................ 13 To use the intercom from the handset.............................................. 13 SuperManual.book Page i Thursday, August 19, 1999 12:50 PM ii To use the intercom from the base..................................................... 14 Using HOLD ....................................................................…

Text truncated - open the document above for the full version.

CIDCO, INC. XXXXXX-01 Rev. A XX/XX/99 CIDCO MODEL CL990 Complies with Part 68 of FCC Rules FCC Registration Number: HOLTHA-25800-W9-E 24755-MT-E REN: 0.1B Jack Type: RJ-11C HAC Made in Thailand This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. FCCID: HOLCL990 /GAYLE/UL-FCC/CIDCO01/CL990CR

FCC ID: HOLCL990 August 31, 1999 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention:Applications Examiner Reference:FCC ID: HOLCL990 CIDCO Model CL990 Cordless Telephone Base Unit Dear Examiner: The following equipment authorization application is presented on behalf of CIDCO , Inc. for the certification of their Model CL990 Cordless Telephone Base unit. Enclosed, please find complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR, Part 15, Subpart C for an Intentional Radiator. The manufacturer seeks authorization under the FCC ID: HOLCL990. We look forward to an expeditious review of the report presented and a granting of the certification for CIDCO , Inc. If you have any questions or we can be of assistance, in this matter, please call us at (410) 354-3300. Best regards, Chris Harvey EMC Laboratory Director, MET Laboratories, Inc. Enclosures FCC ID: HOLCL990 August 24, 1999 - 2 - EM IU9561B MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 ENGINEERING TEST REPORT in support of the Application for Grant of Equipment Authorization EQUIPMENT: Model CL990 Cordless Telephone Base Unit FCC IDENTIFIER:HOLCL990 SPECIFICATION:15.247(a) thru (e); 15.209(a). Manufacturer:CIDCO , Inc. 220 Cochrane Circle Morgan Hill, CA 95037 TESTING DATE(S):21 and 23 July 1999 MANUFACTURER'S REPRESENTATIVE: Mr. Can Nguyen ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. ______________________ Alvin Ilarina Test Engineer, MET Laboratories, Inc. FCC ID: HOLCL990 August 24, 1999 - 3 - EM IU9561B MODIFICATIONS STATEMENT I ATTEST: that the product will be manufactured with all modifications for Part 15 compliance as submitted in this report. Modifications made during testing appear below: 1. No modifications were made to the EUT. 1.0 INTRODUCTION The following test report is presented on behalf of the Applicant , as verification of the compliance of the CIDCO Direct Sequence, Spread-Spectrum Telephone Base unit, Model: CL990. 2.0 TEST SITE All testing was conducted at MET Laboratories, Inc., 33439 Western Avenue, Union City, CA 94587. A complete site description is on file with the FCC Laboratory Division as 31040/SIT/MET. 3.0 TEST EQUIPMENT USED ManufacturerEquipment Calibration DueCal. Interval Hewlett Packard8593EM Spectrum Analyzer12/1/99annual EMCOXwing Antenna 11454/1/00annual EMCOActive Rod Antenna2/15/00annual EMCODouble Ridge Horn 31152/4/00annual EMCOLISN 3825/29/29/99annual SchaffnerBiconilog Antenna4/30/00annual 4.0 TEST CONFIGURATION The CIDCO Cordless Telephone Base model CL990 , was configured with the Model: CL9HS Handset in accordance with the manufacturer's instructions and operated in a manner representative of the typical usage of the equipment. During testing of the EUT, the Base unit Model # CL990 was manipulated within the confines of typical usage to maximize each emission. FCC ID: HOLCL990 August 24, 1999 - 4 - EM IU9561B Equipment:Base Station (900MHz Cordless Telephone) Model #:CL990 Serial #:not provided FCC ID:HOLCL990 Equipment:Handset (900MHz cordless Telephone) Model #:CL9HS Serial #:not provided FCC ID:HOLCL9HS 6.0 TEST TYPE(S) 6.1As required by §15.247(b) of CFR 47, output power measurements radiated measurements were performed to verify compliance with the conducted limit. 6.2As required by §15.247(a)(2) of CFR 47, 6 dB bandwidth measurements were performed 6.3 As required by §15.247(e) of CFR 47, processing gain Measurements were not performed. Data is provided instead, by the spread spectrum chipset manufacturer 6.4As required by §15.247(c)(1 )& (c)(2) of CFR 47, out of band emissions measurements were performed. 6.5As required by §15.247(d) of CFR 47, power density measurements were performed 6.6As required by §15.107 of CFR 47, Line Conducted Emission measurements were performed 7.0 EUT CONFIGURATION INFORMATION Special Note: 6.7As required by §15.214 of CFR 47, Security code requirments were met based on the nature of the technology used. The EUT uses Direct Sequence, Spread Spectrum Technology which provides adequate security for any unintended receivers of the intended signal. FCC ID: HOLCL990 August 24, 1999 - 5 - EM IU9561B Photograph(s) of Radiated Emissions Test Configuration CIDCO Model CL990 Cordless Telephone FCC ID: HOLCL990 August 24, 1999 - 6 - EM IU9561B Photograph(s) of Line Conducted Emissions Test Configuration CIDCO Model CL990 Cordless Telephone Base FCC ID: HOLCL990 August 24, 1999 - 7 - EM IU9561B SUBJECT:Peak Output PowerMET REPORT:EMIU9561B 15.247(b)MFG:CIDCO FCC Part 15, Subpart CTESTED BY:Alvin Ilarina Intentional RadiatorTEST DATE(S):23 July 1999 EUT:CIDCO MODEL:CL990 (Telephone Base unit ) TECHNICAL SPECIFICATION:15.247(b) CARRIER POWER:Peak Output power was calculated through the following means: The raw reading from the analyzer was added to the cable loss and antenna factor (for the specific frequency of measurement). The final E-field strength limit is derived from the conversion of the power limit specified in FCC Part. 15.247(b) to V/m , considering a 50S system. Please see the attached plots Handset/FreqWorst caseDist (m)Cbl/HPF/CPreCorrTotal Total Base (MHz)Raw+ACFonamplevel(V/m)watts ReadingLoss(dB)(dBμV/m) (dBuV/m)(dB) Base904.17112.563.02.7*n/a115.260.5790.101 * - Cable losses only. No High-pass filter (i.e. insertion loss) factors, etc., associated with measurement. The Model CL990 system results for the Base are provided as the highest level of the system. (Across…

Text truncated - open the document above for the full version.

FCC ID: HOLCL990 The following Data is for the Peak to Average requirements of FCC 15.35(b). EMIU9561B CL990 Base FreqPolRawAntCbldd corrCorrLimitsComment s (dBuV)(dB/m)(dB)(m)(m)(dBuV) (dBuV) 1820 H34.624.93.151-9.5453.11115.08 Peak Mea s 1820 V37.7253.151-9.5456.31115.08 Peak Meas 1820 H29.724.93.151-9.5448.2195.08Average M 1820 V31.2253.151-9.5449.8195.08 Average M 2960 H33.0230.44.21-9.5458.08115.08 Peak Mea s 2960 V34.5630.44.21-9.5459.62115.08 Peak Meas 2960 H32.130.44.21-9.5457.1695.08Average M 2960 V32.0830.44.21-9.5457.1495.08 Average M 4470 H15.73371-9.5446.16115.08 Peak 4470 V15.6933.771-9.5445.76115.08 Peak 4470 H15.73371-9.5446.1695.08 Average 4470 V15.6933.771-9.5445.7695.08 Average 10000 H24.338.310.11-9.5463.16115.08 Peak 10000 V24.238.210.11-9.5462.96115.08 Peak 10000 H24.338.310.11-9.5463.1695.08 Average 10000 V24.238.210.11-9.5462.9695.08 Average The above limit is based on the fundamental measurement below: EMIU9561BCL990 Base FreqPolRawAntCbldCorrLimitsComments MHz(dBuV)(dB/m)(dB)(m)(dBuV)(dBuV) 904.42 V88.8623.452.770115.08131 RBW=3 MHz, VBW = 3 MHz New spurious limit for non-restricted band measurements: 115.08 - 20dB = 95.08 dBuV The operating frequency range for this device, from center of lowest channel to the center of the highest channel is: Channel 1 904.2 MHz Channel 20 925.8 MHz
