IFHAURORA9X2.4GHz RADIO CONTROL SYSTEM

AURORA 9X 2.4GHz Radio Control System USER MANUAL Hitec RCD KOREA INC. Introducing the AURORA 9X Congratulations and welcome to the R/C world! You now own a basic, but unusually versatile and powerful, 5-Channel beginner’s RC transmitter. The AURORA 9X is all the radio you need to fly the most of 5-Channel fixed-wings aircraft models. Standard features include servo-reversing for all channels, trim adjustments on all control channels, ATV (Adjustable Travel Volume) on Aileron (CH.1) and Elevator (CH.2). The AURORA 9X features: Pre-mixed Flight Control Functions: The AURORA 9X computer automatically mixes rudder and elevator outputs to control a V-tail or mixes aileron and elevator outputs to create elevons for tail-less flying wings, eliminating the need for on-board mixing systems. Trim Adjustment Function: This computerized radio allows you to easily tune and coordinate the control surfaces (such as keeping a rudder centered or two ailerons-each on their own servo-moving the same amount) without having to physically re-adjust linkages. Buddy-Box Function: For those learning to fly, the transmitter has a "buddy-box" capability so that you can use the optional trainer cord to connect your AURORA 9X to another Hitec transmitter (Master)*. This function allows one transmitter to be used by an instructor as the primary flight control while the other is controlled by the student pilot. *Note: AURORA 9X only can be used as a Pupil (Slave) transmitter. If you are new to Computerized RC Transmitters If AURORA 9X is your first radio control transmitter, you're probably feeling a bit overwhelmd. However, if you take little time to read this manual and follow the programming steps as you watch your model's control surfaces respond, handling the AURORA 9X will soon become quite comfortable. So stick with it. Learning the programming basics won't take any longer or require any more brain power than it takes to do the average crossword or Sudoku puzzle. You'll discover that the rewards for mastering this simple radio are well worth the effort. TIP: Throughout the manual you will see our "Tip Sheet" notes. These highlight specific function details we didn't want you to miss within the body of the manual. Check these out; they can make programming the Optic Sport easier. Hitec AFHSS 2.4GHz Technology Most of Hitec’s 2.4GHz product uses AFHSS (Advanced Frequency Hopping Spread Spectrum) technology which gives you highly stable one-way and telemetric signals for ensure safe flight of your model aircrafts. Equipment Mounting When you mount each servo, use the supplied rubber grommets and insert an eyelet up through the bottom. Be sure not to over tighten the screws. If any portion of the servo case directly contacts the fuselage or the servo rails, the rubber grommets will not be able to attenuate vibration, which can lead to mechanical wear and possible servo failure. Servo Throw Once you have installed the servos, operate each one over its full travel and check that the pushrod and output arms do not bind or collide with each other, even at extreme trim settings. Check to see that each control linkage does not require undue force to move (if you hear a servo buzzing when there is no transmitter control motion, most likely there is too much friction in the control or pushrod). Even though the servo will tolerate loads like this, they will drain the battery pack much more rapidly Receiver Installation and Setup Note: Vibration and Water The receiver contains precision electronic parts. Be sure to avoid vibration, shock, and temperature extremes. For protection, wrap the receiver in the provided "Flight Preserver" foam rubber, or use some other vibration-absorbing materials. If you are flying near bodies of water, it's also a good idea to protect the receiver by placing it in a plastic bag and securing the open end of the bag with a rubber band before wrapping it with foam. If you accidentally get moisture inside the receiver, you may experience intermittent operation or a crash. Switch Harness Installation When you are ready to install the receiver's switch harness, remove the switch cover and use it as a template to cut screw holes and a rectangular hole slightly larger than the full stroke of the switch. Choose a switch location on the opposite side of the fuselage from the engine exhaust, and choose a location where it can't be inadvertently turned on or off during handling or storage. Install the switch so that it moves without restriction and "snaps" from ON to OFF and vice versa. Charging the AURORA 9X Ni-MH Batteries Connect the transmitter charging cord into the charging socket (on the rear of the case, left side) and airborne Ni-MH batteries to the receiver connector on the charger. Connect the receiver battery to the charging cord. Plug the charger into a wall socket. The charger's LEDs should light, indicating charging current is flowing. The batteries should be left on charge for about 15 hours. Try to charge the batteries with the charger supplied with your system exclusively. The use of a fast-charger may damage the batteries by overheating and dramatically reduce their lifetime. NOTE: If you need to remove or replace the transmitter battery, do not pull on its wires to remove it. Instead, gently pull on the connector's plastic housing where it plugs in to the transmitter. The battery must be removed to charge it properly with a "peak" charger. Operating With A Trainer Cord An optional training cord is available from your dealer. The cord may be used to help a beginning pilot learn to f ly easily by allowing a second transmitter, operated by an experienced instructor, to be connected to this system. The instructor may override the beginning pilot at any time to Bring the model back under safe control. For training To use the trainer cord: Set up both the student's and instructor's transmitters to have identical trim and control motions. If the instructor's transmitter is on a different frequ…

Text truncated - open the document above for the full version.

Hitec RCD Inc. 12115 Paine Street, Poway, CA 92064, USA Date: June 26, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA To whom it may concern: I, the undersigned, hereby authorize Technical Manager Issac Jin of MOVON CORPORATION and hereafter referred to as MOVON CORPORATION , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these m atters. Any and all acts carried out by Technical Manager Issac Jin of MOVON CORPORATION on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MOVON CORPORATION as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Hitec RCD Inc. 12115 Paine Street, Poway, CA 92064, USA e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Tony Ohm / Service Dept. Manager Hitec RCD Inc. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Hitec RCD Inc. 12115 Paine Street, Poway, CA 92064, USA August 19, 2013 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Cover letter Model name : AURORA 9X MPE evaluationl Gentlemen: The end-user should use this AURORA 9X from 30cm antenna separation distance. Sincerely Yours, Tony Ohm / Service Dept. Manager Hitec RCD Inc.

Hitec RCD Inc. 12115 Paine Street, Poway, CA 92064, USA Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: IFHAURORA9X To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operation Description Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, Tony Ohm / Service Dept. Manager Hitec RCD Inc.

External photos of EUT Front view of EUT Rear view of EUT Top view of EUT Bottom view of EUT Side view of EUT

16.8 27.9 3.5 Label Location

Internal photos of EUT Antenna view of RF Module Top view of Main PCB Bottom view of Main PCB Top view of LCD Bottom view of LCD Top view of SUB PCB-1 Bottom view of SUB PCB-1 Top view of SUB PCB-2 Bottom view of SUB PCB-2

CHIEF R&D DESIGN Daesik Hwang Jihyun Kim Hyunjung Kim Date June. 23. 09. SAE HAN ANTENNA CO.,LTD Specification for Approval Part name : WF-24Rx Antenna Part No : HTR24-002 TECHNICAL DATA SHEET Page 2 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna NO Description Material 1 Tube PVC / Black 2 Coaxial Cable PVC, Teflon, Cu, Plated Wire 3 Ground Plane BsBM 4 Connector S hell, Contact terminal : Phosphor Bronze, Insulator : PBT Series 5 Bushing PVC / Black SPECIFICATION DRAWING TECHNICAL DATA SHEET Page 3 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna Table of Contents ELECTRICAL CHARACTERISTICS MECHANICAL CHARACTERISTICS 1 General 1.1 Product description 1.2 Product Name 1.3 Units and Definitions 1.4 Conditions 2 ELECTRICAL PROPERTIES 2.1 Frequency Band 2.2 Impedance 2.3 VSWR 2.4 Gain 3 MECHANICAL PROPERTIES 3.1 Drop 3.2 Flexure 4 ENVIRONMENTAL RESISTANCE PROPERTIES 4.1 Temperature 4.2 Humidity 4.3 Vibration TECHNICAL DATA SHEET Page 4 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna ELECTRICAL CHARACTERISTICS . Center Frequency ................................................................ 2450 MHz . Frequency Range ................................................................. 2400~2500 MHz . Nominal Impedance ............................................................. 50 Ω . VSWR.................................................................................... Less Than 2.0:1 . Type ..................................................................................... 1/2 wave dipole . Gain Peak Gain ........................................................................... 0 dBi . Radiation Pattern ................................................................... Omni Directional -3dB Beam width : . Horizontal Plane .................................................................... 360̊̊̊̊̊̋̊̊̊ ̊ . Vertical Plane ........................................................................ 85±10 ̊ . Polarization :........................................................................... Vertical . Maximum input power ........................................................... 3 W TECHNICAL DATA SHEET Page 5 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna MECHANICAL CHARACTERISTICS Sleeve Material .......................................................... Shrinkable Tube / black Weight : ............................................................................... 4 g Connector type : ................................................................ U.FL Male (Micro Connector) Temperature : .................................................................... -40 / +85°C Drop Test ............................................................................. 1m / 10 Times Humidity ............................................................................... +30°C&95% RH 24Hours Vibration .............................................................................. Frequency 3-500-3Hz(1cycle) Sweep rate 5 db / octave Amplitude 1.12G-rms Acceleration 1.5g Overall Length of Antenna .................................................. 233 mm +/- 2mm TECHNICAL DATA SHEET Page 6 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna 1. GENERAL 1.1 Product description This antenna is to account for the measurement setup and results of 2.4GHz Type Dipole Antenna. 1.2 Product Number Saehan Antenna Product Name. : WF-24Rx Antenna 1.3 Units and Definitions V.S.W.R ................................ Voltage Standing Wave Ratio dBi ........................................ Antenna gain in dB relative to a isotropic antenna g ........................................... Acceleration of gravity(about 9.8 m/sec 2) RH.......................................... Relative Humidity Dimensions .......................... mm 1.4 Test Conditions Unless otherwise stated all temperature tolerance are ± 3°C and all RH tolerance are ± 5 percentage units Unless otherwise stated all values are valid at +20 °C and 50% RH 2. ELECTRICAL PROPERTIES 2.1 Frequency Band ..................................................... 2400 ~ 2500 MHz 2.2 Impedance ............................................................... Nominal Value : 50Ω 2.3 V S W R 2.3.1 Maximum Values ......................................... Less than 2.0 : 1 2.3.2 Measuring Method A 50ohms coaxial cable is connected to the antenna connector. In the other end the coaxial cable is connected to a network analyzer. The analyzer calibrated so that the reference plane is at the end the coaxial cable connected to the antenna ⁲ TECHNICAL DATA SHEET Page 7 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna FrequencyV.S.W.RRemarks 2.40GHz1.34 2.45GHz1.19 2.50GHz1.17 Figure 1. Network Analyzer Measuring V S W R Figure 2. V. S. W. R Testing TECHNICAL DATA SHEET Page 8 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna Chamber Size16(L)m X 11(W)m X 9.5(H)m Frequency Range 400MHz – 60GHz (Far Field) Quiet Zon 1.2m X 1.2 m @ 1GHz TypeRectangular 2.4 Gain 2.4.1 Measuring Method The connection is done according to figure. Radiation patters are measured at the lowest. middle and highest frequency for frequency band. The measurement performed so as to minimize Measurement frequency: 2400,2450,2500MHz the influence of the cables. Calibration for absolute measurements is done with a reference antenna. which is in turn calibrated by a certified calibration company Figure 3 Anechoic Chamber Measuring TECHNICAL DATA SHEET Page 9 of 13 DIRECT FEED 1/2 WAVE DIPOLE FOR QUALIFICATION SaeHan Part Name WF-24Rx Series : Antenna FrequencyGain(Max)Remarks 2.40GHz0.37dBi 2.45GHz0.71dBi 2.50GHz0.68dBi ⁲ Gain (H-plane) Figure 4 Anechoic Chamber Measuring (H-plane) TECHNICAL DATA SHEET …

Text truncated - open the document above for the full version.

MOVON CORPORATION Report Number:MOV-13-RF-I022 Page : (1) of (61) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. FCC Part 15 Subpart B&C §15.247 RSS-210 ISSUE No. :8 Test Report Equipment Under Test 2.4GHz Radio Control System Model Name AURORA 9X Applicant Hitec RCD Inc. FCC ID IFHAURORA9X IC 3420A-AURORA9X Manufacturer Hitec RCD PHILIPPINES, INC. Date of Test(s) 2013. 08.05 ~ 2013. 08. 14 Date of Issue 2013. 08. 16 In the configuration tested, the EUT complied with the standards specified above. Issue to Issue by Hitec RCD Inc. 12115 Paine Street, Poway, CA 92064, USA Tel.: 858-748-6948 Fax: 858-748-1767 MOVON CORPORATION 194-1, Geumeo-ri, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 449-812 Tel.: +82-31-338-8837 Fax: +82-31-338-8847 MOVON CORPORATION Report Number:MOV-13-RF-I022 Page : (2) of (61) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Revision history RevisionDate of issue DescriptionRevised by -- August 16, 2013 Initial -- MOVON CORPORATION Report Number:MOV-13-RF-I022 Page : (3) of (61) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. Table of contents 1.ATTESTATION OF TEST RESULTS ............................................................................. 4 2.EUT DESCRIPTION ........................................................................................................ 5 3.INFORMATION ABOUT THE FHSS CHARACTERISTICS ............................................ 6 4.MEASUREMENT EQUIPMENT ...................................................................................... 7 5.TRANSMITTER RADIATED SPURIOUS EMISSIONS AND CONDUCTED SPURIOUS EMISSIONS .................................................................................................................. 8  6.CONDUCTED POWER LINE TEST .............................................................................. 29 7.RECEIVER RADIATED SPURIOUS EMISSIONS ........................................................ 32 8.20໒ BANDWIDTH MEASUREMENT & 99 % BANDWIDTH MEASUREMENT ........ 36 9.MAXIMUM PEAK OUTPUT POWER MEASUREMENT ............................................... 44 10.HOPPING CHANNEL SEPARATION ......................................................................... 49 11.NUMBER OF HOPPING FREQUENCY ...................................................................... 51 12.TIME OF OCCUPANCY(DWELL TIME) ..................................................................... 53 13.ANTENNA REQUIREMENT ....................................................................................... 57 14.RF EXPOSURE EVALUATION .................................................................................. 58 15.TEST SETUP PHOTO OF EUT .................................................................................. 60 MOVON CORPORATION Report Number:MOV-13-RF-I022 Page : (5) of (61) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 2. EUT Description Kind of product 2.4GHz Radio Control System Model Name AURORA 9X Serial Number N/A Power supply DC 7.2 V Frequency range(SLT) 2 406໬ ~ 2 474 ໬ , 2 480 ໬ Frequency range(Opti-mini) 2 405.6໬ ~ 2 471.6໬ Modulation technique AFHSS(GFSK) Number of channels 110(Opti-mini), 70(SLT) Antenna gain 0.71໒i (Max.) TEST SITE REGISTRATION NUMBER FCC(670686) , IC(6432B-1) 2.1. Declarations by the manufacturer SLT channel band operates in 2 406 to 2 474 and 2 480 ໬ 2 480໬ is used paring channel So. Test channel is Below Opti-mini Channel Freq(໬) LOW 2 405.6 MID 2 441.0 HIGH 2 471.6 SLT Channel Freq(໬) LOW 2 406 MID 2 440 HIGH 2 474 HIGH-1 2 480 2.2. Details of modification None MOVON CORPORATION Report Number:MOV-13-RF-I022 Page : (6) of (61) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. 3. Information about the FHSS characteristics 3.1. Pseudorandom frequency hopping sequence The product operates in 2 405.6 to 2 471.6 ໬ Band AURORA 9X is 2.4GHz R/C Transceiver. AURORA 9X has the 111 channels but when this product operates, gets only 21 channels among the 111 channels and then it would begin to be hop at random among 21 channels that channels spacing are over 1໬. The 21 channels are real hopping channels and whenever turn on the product, always try to get new 21 channels. The reason why get new 21 channels is to get the good receive sensitivity channels. Example of a 21 hopping sequence in data mode: 40,21,44,23,42,53,46,55,48,33,52,35,50,65,54ˎ Also, operates in 2 406 to 2 474 and 2 480 ໬ with SLT channel band. AURORA 9X in SLT channel band is 2.4GHz R/C Transceiver. AURORA 9X in SLT channel band has the 70 channels but when this product operates, gets only 16 channels among the 70 channels and then it would begin to be hop at random among 16 channels that channels spacing are over 1໬. The 16 channels are real hopping channels and whenever turn on the product, always try to get new 16 channels. The reason why get new 16 channels is to get the good receive sensitivity channels. Example of a 16 hopping sequence in data mode: 40,21,44,23,42,53,46,55,48,33,52,35,50,65,54ˎ 3.2 Equal Hopping Frequency Use 2.4Ghz system in Radio Control industry has no compatibility in different manufactures. Also each manufactures has their own protocol. 3.3 System Receiver Input Bandwidth The input ba…

Text truncated - open the document above for the full version.

Test setup photo of EUT A. Setup photo of EUT Photo of radiated spurious emission at below 30 ㎒ Photo of radiated spurious emission at 30 ㎒ ~ 1 000 ㎒ Photo of radiated spurious emission at above 1 000 ㎒ Photo of Conducted emission at below 30 ㎒
