TCB RF Exposure Review Procedure Statement FCC ID:IMK-HRFGW2 Transmitter Category Device Type Product Category Approval and Review Procedures Used Specific Procedures: V FHSS Wireless LAN Base Station Part 15 Mobile Transmitter Section F SP(1),(3),(5),(7),(8), and (9) Grant Conditions – The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna ortransmitter. End-users and installers must be provided with antenna installation instructions and transmitteroperating conditions for satisfying RF exposure compliance. SP1 Max. conducted power measured as stated in page 25 of test report measured withpower meter. Use integral antenna. No source based average consideration forFHSS device. SP3 RF Exposure Warning Statement can be found in page 55 of user manual. 20cmseparation distance has been mentioned. SP5 Frequency range: 2402 – 2480 MHz. SP7 Use integral antenna. No antenna installation is needed by the end-user. SP8 No antenna installation is required. SP9 Grant conditions have been verified by TCB and applicable to this product. Reviewed by Mike KuoCompliance Certification ServicesSept. 14, 2001

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT TEST REPORT FOR ETHERNET WIRELESS LAN BASE STATION FCC ID: IMK-HRFGW2 MODEL NO: PROXIM 4940 SYMPHONY HOME RF BASE STATION REPORT NO: 01U0930-1 TEST DATE: AUGUST 20, 2001 Prepared for PROXIM, INC. 510 DE GUIGNE DRIVE SUNNYVALE, CA 94085, U.S.A. Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 01U0930-1 FCC ID: IMK-HRFGW2 DATE: 08/20/01 EUT: ETHERNET WIRELESS LAN BASE STATION Page 2 of 46 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. DOCUMENT NO: CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE.......................................................................................4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT).........................................................5 3. ANTENNA CONNECTION.......................................................................................................5 4. PSEUDORANDOM HOPPING SEQUENCE............................................................................5 5. CHANNEL USAGE ..................................................................................................................5 6. THEORY OF OPERATION......................................................................................................5 7. THE COORDINATION OF FREQUENCY HOPPING SYSTEM.............................................5 8. RECEIVER TECHNICAL INFORMATION............................................................................5 9. TEST LOCATION.....................................................................................................................6 10. SUPPORT EQUIPMENT...........................................................................................................7 11. TEST REQUIRED AND TEST RESULTS................................................................................8 Radiated Emissions (Restricted Bands of Operations).................................................................................8 Test Requirement: 15.205......................................................................................................................8 Radiated Emissions................................................................................................................................10 Test Requirement: 15.209....................................................................................................................11 AC Line Conducted Emissions................................................................................................................13 Test Requirement: 15.207....................................................................................................................13 Conducted Emission...............................................................................................................................15 Test Requirement: 15.247(c)................................................................................................................15 BAND-EDGE........................................................................................................................................17 Test Requirement: 15.247(c)................................................................................................................17 20dB Bandwidth for FHSS......................................................................................................................20 Test Requirement: 15.247(a)(1)(ii).......................................................................................................20 RF Power Output...................................................................................................................................28 Test Requirement: 15.247(b)(1)..........................................................................................................25 RF EXPOSURE REQUIREMENT..........................................................................................................29 Test Requirement: 15.247(b)(4)..........................................................................................................26 Minimum Number of Hopping Channel...................................................................................................27 Test Requirement: 15.247(a)1(ii).........................................................................................................27 Hop Channel Separation.........................................................................................................................29 Test Requirement: 15.247(a)(1)(ii).......................................................................................................29 Average Time of Channel Occupancy......................................................................................................31 Test Requirement: 15.247(a)1 (ii)........................................................................................................31 REPORT NO: 01U0930-1 FCC ID: IMK-HRFGW2 DATE: 08/20/01 EUT: ETHERNET WIRELESS LAN BASE STATION Page 3 of 46 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. DOCUMENT NO: CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 12. ATTACHMENTS....................................................................................................................37 ATTACHMENT 1......................…

Text truncated - open the document above for the full version.

12-Sep-01 Re: Proxim IMK-HRFGW2 High rate channel occupancy Number of high rate channels used: Refer to attached plot (Proxim HR chans.pdf) showing 15 channels spaced 5 MHz apart. Time of occupancy for high rate channel: Refer to attached plot (Proxim HR occ.pdf) showing a single packet being transmitted. The time of occupancy is not greater than 16 ms. Average time of channel occupancy: CFR 47 Paragraph 15.247 (a)(1)(iii) reads in part "The average time of occupancy on any one channel shall not be greater than 0.4 seconds within the time period required to hop through all channels." The high rate channel hop pattern is linked to the low rate hop pattern, which cycles every 1.5 seconds. There are 15 high rate channels, and the hop duration is 20 ms. In one cycle, high rate channels are then used: (1.5 sec / 1 cycle) * (1 cycle / 15 HR channel) * (1 channel occupancy / 20 ms) = 5 channel occupancy / HR channel The hop duration is 20 ms, but only 16 ms of that is used for transmission: (5 chan occupancy / HR channel) * (16 ms / chan occupancy) = 80 ms / HR channel This is less than the 400 ms allowed.

REPORT NO: 01U0930-1 FCC ID: IMK-HRFGW2 DATE: 08/20/01 EUT: ETHERNET WIRELESS LAN BASESTATION Page 46 of 46 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. DOCUMENT NO: CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. ATTACHMENT 9 SET-UP PHOTOS
