IMK-HRFPC2Symphony Home RF PC Card Adapter

i Copyright © 2001 Proxim, Inc., Sunnyvale, CA. All rights reserved. Covered by one or more of the following U.S. patents: 5,412,687; 5,844,900; 5,875,179; 5,913,174; 6,006,090; and 5,231,634. This manual and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Proxim, Incorporated. Trademarks Symphony, Symphony-HRF, the Symphony logo, Symphony Composer, Symphony Conductor, Symphony Maestro, and Proxim are trademarks of Proxim, Inc. All other trademarks are the property of their respective owners. Limited Warranty, Disclaimer, Limitation Of Liability For a period of one (1) year from the date of purchase by the retail customer, Proxim warrants the Symphony HomeRF product(s) against defects in materi- als and workmanship. If a product is found defective during the warranty period, Proxim will repair or replace the product with the same or a similar model, which may be a reconditioned unit, without charge for parts or labor. Any replaced or repaired product will have either a ninety (90) day warranty, under the conditions described herein, or the remainder of the initial one (1) year war- ranty, whichever is longer. Proxim also warrants the media containing the Symphony software against fail- ure for a period of ninety (90) days. Proxim will not honor this warranty if there has been any attempt to tamper with or remove the product’s external foil label. This warranty does not cover and Proxim will not be liable for any damage or failure caused by misuse, abuse, acts of God, accidents, or other causes beyond Proxim’s control, or claim by any entity other than the original purchaser. Symphony HomeRF Adapters User’s Manual Part # 7360.xxxx Rev. A ii In no event shall Proxim, Inc. be responsible or liable for any damages arising: ❑ From the use of the product; ❑ From the loss of use, revenue or profit of the product; or ❑ As a result of any event, circumstance, action, or abuse beyond the control of Proxim, Inc. Whether such damages be direct, indirect, consequential, special, or otherwise and whether such damages are incurred by the person to whom this warranty extends or a third party. Proxim does not warrant that the functions contained in the products will meet your requirements or that the operation of the Symphony HomeRF product(s) will be uninterrupted or error free. Warranty Return Policy If you have a problem with your Symphony HomeRF product, please call Symphony Technical Support at (408) 731-2780. Symphony Technical Support will assist with resolving any technical difficulties you may have with your Symphony product. If a Symphony technical representative determines that a product is defective and the product is still in warranty, you will be assigned a Return Material Authorization (RMA) number to authorize its return for repair or replacement. Dated proof of purchase may be required. Package the product appropriately for safe shipment, mark the RMA number on the outside of the package, and ship the package at your expense. Proxim recommends that you insure the package during shipment. For support of software media, please refer to the Symphony Web site at http://www.proxim.com/symphony/. iii Contents 1. Introduction .............................................................. 1 Product Description ...............................................................................2 Symphony HomeRF Hardware Products ........................................2 Software Products ...........................................................................2 The Product Package ..............................................................................3 System Requirements .............................................................................4 Network Requirements ..........................................................................4 Note to Customers Who Have a Symphony HomeRF Base Station .....5 Interoperability Between Symphony Products ......................................5 2. Wireless Networking for the Home & Small Office 7 What Is Wireless Networking? ..............................................................7 Supported Configurations ......................................................................8 Wireless Network Sharing a Modem ..............................................8 Wireless Network Communicating With An Ethernet Network ....9 Peer-to-Peer Wireless Network ....................................................10 3. Installation .............................................................. 11 Pre-installation Considerations ............................................................11 Note to Customers Using a Laptop Without a CD-ROM Drive ...11 Installation Procedure ..........................................................................12 4. Symphony Composer Installation Wizard ............ 15 Important Note to PPPoE Users ...................................................16 Important Note to Users in Transparent Bridging Mode ..............16 Composer Features ...............................................................................16 Assign a Security Code .................................................................16 Choose a Network Configuration .................................................17 Assign a Computer Name .............................................................18 Create a Virtual Modem ...............................................................18 Select Drives and Printers to Share ..............................................18 Configure Switcher Prompt at Boot-up ........................................19 Register Symphony Products ........................................................19 iv 5. Symphony Maestro Configuration Tool ............... 21 Conductor Management and Configuration Fea…

Text truncated - open the document above for the full version.

REPORT NO: 01U0850-1 FCC ID: IMK-HRFPC2 DATE: 06/15/01 PAGE NO: 38 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. COMPLIANCE CERTIFICATION SERVICES, INC. DOCUMENT NO:CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. ATTACHMENT 4 REQUEST FOR CONFIDENTIALITY LETTER

From: Jeff Liew [[email protected]] Sent: Wednesday, July 18, 2001 5:58 PM To: 'Mike Kuo' Subject: RE: PROXIM, INC., FCC ID:IMK-HRFPC2, Assessment no:AN01T1407 Hi Mike, The peak output power readings for low, mid, and high channel are 72.4mW (18.60dBm), 73.3mW (18.65dBm), and 72.3mW (18.59dBm) respectively. Attached are the plots you have requested for questions 1, 3, 4, and 5. <<timeofoccupancy.bmp>> <<openairhopchannel.bmp>> <<homerfhopchannel.bmp>> <<lowchbw.bmp>> <<highchbw.bmp>> Thanks you for your patience. Please don't hesitate to contact me if you have any further questions. Best regards, ____________________________________________ Jeff Liew RF Design Engineer Proxim, Inc. 510 DeGuigne Drive Sunnyvale, CA 94085 voice: 408-731-2734 fax: 408-731-3672 mailto:[email protected] http://www.proxim.com/ -----Original Message----- From: Mike Kuo [mailto:[email protected]] Sent: Wednesday, July 18, 2001 6:18 PM To: 'Jeff Liew' Subject: RE: PROXIM, INC., FCC ID:IMK-HRFPC2, Assessment no:AN01T1407 Dear Jeff: Please provide three peak output readings. Low, middle and high channel. Best Regards Mike Kuo -----Original Message----- From: Jeff Liew [mailto:[email protected]] Sent: Wednesday, July 18, 2001 5:32 PM To: 'Mike Kuo' Subject: RE: PROXIM, INC., FCC ID:IMK-HRFPC2, Assessment no:AN01T1407 Hi Mike, I just finished making the plots for FCC ID:IMK-HRFPC2, Assessment no: AN01T1407. I will be scanning them into jpeg files and emailing them to you in a moment. As we discussed earlier regarding question 2 (conducted peak output power), I made a peak power measurement with our HP Peak Power Meter (HP 8900D) with the UUT in hopping mode and recorded 73.3mW peak power or 18.6dBm. This compares very well with the lab data we got at your facility, which was also 18.6dBm. Please let me know if you have any further questions regarding this submittal. I will be working on FCC ID:IMK-HRFUSB2 next. Best regards, ____________________________________________ Jeff Liew RF Design Engineer Proxim, Inc. 510 DeGuigne Drive Sunnyvale, CA 94085 voice: 408-731-2734 fax: 408-731-3672 mailto:[email protected] http://www.proxim.com/ -----Original Message----- From: Mike Kuo [mailto:[email protected]] Sent: Wednesday, July 18, 2001 1:40 PM To: 'Jeff Liew' Cc: Chuck Cowden; Steve Cheng Subject: FW: PROXIM, INC., FCC ID:IMK-HRFPC2, Assessment no:AN01T1407 -----Original Message----- From: CERTADM Sent: Wednesday, July 18, 2001 1:37 PM To: Steve Cheng Cc: Mike Kuo Subject: PROXIM, INC., FCC ID:IMK-HRFPC2, Assessment no:AN01T1407 Notice_content ------------- Question #1: 20dB bandwidth : In accordance to FCC public notice DA-00-705, when measuring 20dB bandwidth, RBW shall use 1% of 20dB bandwidth. The 20dB bandwidth with high data rate is 4.68MHz, the RBW shall not be less than 46.8KHz. However, RBW of 30kHz was used. Please submit new test data for low channel with high data rate, high channle with high data rate. Question #2: Conducted peak output power: In accordance to FCC public notice DA-00-705, RBW shall be greater than 20dB bandwidth of emission being measured. The 3MHz RBW was used to measure the conducted peak output power which is less than 20dB BW (4.68MHz).In addition, the span shall be approx. 5 times of 20dB BW. 5MHz span was used which is less than 5 times of 20dB BW. When redo the tests, please make sure the hopping is enable. Question #3:Time of Occupancy ( Dwell Time): In FCC public notice, 1 MHz RBW shall be used. However, 300kHz was used during the tests. Please submit new measurement data to comply such requirements. Question #4:There are two modes of operation: Open-air and Home-RF modes. The number of hopping frequencies during these two modes are different. Only 75 hopping frequenies spectrum plot was submitted, please submit spectrum plot to demenstarte number of hopping channels for Home-RF mode. Question #5: Number of hopping frequencies: In accordance to FCC public notice, the span shall be the frequency band of operation, RBW shall not be less than 1% of the span. RBW 100kHz was used with 100MHz span. Please submit new spectrum plot to comply this requirement. Best Regards Mike Kuo / TCB Certifier The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

REPORT NO: 01U0850-1 FCC ID: IMK-HRFPC2 DATE: 06/15/01 PAGE NO: 39 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. COMPLIANCE CERTIFICATION SERVICES, INC. DOCUMENT NO:CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. ATTACHMENT 5 EUT TECHNICAL DESCRIPTON

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF FCC ID: IMK-HRFPC2 PC CARD WIRELESS LAN ADAPTER MODEL NO: PROXIM 4440 SYMPHONY HOME RF PC CARD REPORT NO: 01U0850-1 TEST DATE: JUNE 19, 2001 Prepared for PROXIM, INC. 510 DEGUIGNE DRIVE SUNNYVALE, CA 94085, U.S.A. Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 01U0850-1 FCC ID: IMK-HRFPC2 DATE: 06/15/01 PAGE NO: 1 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. COMPLIANCE CERTIFICATION SERVICES, INC. DOCUMENT NO:CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE.......................................................................................3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT).........................................................4 3. ANTENNA CONNECTION.......................................................................................................4 4. PSEUDORANDOM HOPPING SEQUENCE............................................................................4 5. CHANNEL USAGE ..................................................................................................................4 6. THEORY OF OPERATION......................................................................................................4 7. THE COORDINATION OF FREQUENCY HOPPING SYSTEM.............................................4 8. RECEIVER TECHNICAL INFORMATION............................................................................4 9. TEST LOCATION.....................................................................................................................4 10. SUPPORT EQUIPMENT...........................................................................................................6 11. TEST REQUIRED AND TEST RESULTS................................................................................7 Radiated Emissions (Restricted Bands of Operation)..................................................................................7 Test Requirement: 15.205......................................................................................................................7 Radiated Emissions..................................................................................................................................9 Test Requirement: 15.209....................................................................................................................11 AC Line Conducted Emissions................................................................................................................13 Test Requirement: 15.207....................................................................................................................13 Conducted Emission...............................................................................................................................15 Test Requirement: 15.247(c)................................................................................................................15 BAND-EDGE........................................................................................................................................17 Test Requirement: 15.247(c)................................................................................................................17 20dB Bandwidth for FHSS......................................................................................................................22 Test Requirement: 15.247(a)(1)(ii).......................................................................................................22 RF Power Output...................................................................................................................................23 Test Requirement: 15.247(b)(1)..........................................................................................................25 RF EXPOSURE REQUIREMENT..........................................................................................................27 Test Requirement: 15.247(b)(4)..........................................................................................................27 Minimum Number of Hopping Channel...................................................................................................28 Test Requirement: 15.247(a)1(ii).........................................................................................................28 Hop Channel Separation.........................................................................................................................30 Test Requirement: 15.247(a)(1)(ii).......................................................................................................30 Average Time of Channel Occupancy......................................................................................................32 Test Requirement: 15.247(a)1 (ii)........................................................................................................32 REPORT NO: 01U0850-1 FCC ID: IMK-HRFPC2 DATE: 06/15/01 PAGE NO: 2 This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. COMPLIANCE CERTIFICATION SERVICES, INC. DOCUMENT NO:CCSUP4025B 561 F. Monterey, Rd. Route 2 Morgan Hill, CA. TEL: (408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 12. ATTACHMENTS....................................................................................................................31 ATTACHMENT 1.....................................................…

Text truncated - open the document above for the full version.
