IVS1800TIMTWSecurity/Remote Control Transmitter

FCC ID: IVS1800TIMTW Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, TOUCHTRONICS. INC., hereby request confidentiality for the block diagram, schematic and product description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Sincerely, Gordon L. Helm Technical Lab Manager Narte Certified Engineer, # EMC-002401-NE Tel. 269 313-2433 / Fax 269 429-9016 Email: [email protected]

Printed copies must be verified against electronic master before use. T ouch Tr onics , I nc ™ 57315 Nagy Drive www.touchtroni cs.com Phone: (574) 294-2570 Drawn By: D. Evans Date: 2005-12-15 Elkhart, IN 46517 touchtronics@touc htronics.com FAX: (574) 293-1611 Approved By: R. Mathia Date: 2005-12-20 Approved By: Date: Title: Label, PowerTouch 1000 Series Transmitters Size: B Drawing: LBL11404 Rev: A Proprietary Information These drawings and specifications are the property of TouchTronics, Inc. And shall not be reproduced, copied, disclosed to others, or used as the basis for the manufacture or sale of apparatus or devices without permission. Scale: None Filename: LBL11404_A.doc Sheet: 1 of 1 Label Size: 1” x 0.75” Label Stock: LBL10471-5 (white polyester) Ribbon Stock: LBL10472-3 (black) ECO #: Rev: Description: Drawn: Date: App’d: Date: --- A Initial release. DWE 2005-12-15 RCM 2005-12-20 LBL11404-10 1800-TIM-TW4 IVS1800TIMTW 6265A-18TIMTW Label, PowerTouch 1800-TIM-TW4 Transmitter LBL11404-9 1000-TX6S IVS1800EQLTX 6265A-18EQLTX Label, PowerTouch 1000-TX6S Transmitter LBL11404-8 1000-TX4S IVS1800EQLTX 6265A-18EQLTX Label, PowerTouch 1000-TX4S Transmitter LBL11404-7 1000-TX2S IVS1800EQLTX 6265A-18EQLTX Label, PowerTouch 1000-TX2S Transmitter LBL11404-6 1800-EQL-TX6S IVS1800EQLTX 6265A-18EQLTX Label, PowerTouch 1800-EQL-TX6S Transmitter LBL11404-5 1800-EQL-TX4S IVS1800EQLTX 6265A-18EQLTX Label, PowerTouch 1800-EQL-TX4S Transmitter LBL11404-4 1800-EQL-TX2S IVS1800EQLTX 6265A-18EQLTX Label, PowerTouch 1800-EQL-TX2S Transmitter LBL11404-3 1000-TF6 IVS1000TF 6265A-1000TF Label, PowerTouch 1000-TF6 Transmitter LBL11404-2 1000-TF4 IVS1000TF 6265A-1000TF Label, PowerTouch 1000-TF4 Transmitter LBL11404-1 1000-TF2 IVS1000TF 6265A-1000TF Label, PowerTouch 1000-TF2 Transmitter Part Number <Model> Field <FCC_ID#> Field <IC_ID#> Field Description Note : 1. Replace <Model>, <FCC_ID#>, and <IC_ID#> text fields on label with values shown in part number table.

Test report #0500814B FCC 15.231 for 1800-TIM-TW4 FCC ID: IVS1800TIMTW Tested Sep 21, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 0500814BF.doc EXHIBIT E: Page 1 of 16 EXHIBIT E: REPORT OF MEASUREMENTS [2.1033(B6)] Test Report for FCC ID: IVS1800TIMTW FCC Part 2.1031, Part 15 Subpart C(15.231b) Report #0500814B Issued 1/17/06 433.92MHZ POWERTOUCH 1800-TIM-TW4 TRANSMITTER Prepared for: TOUCHTRONICS. INC.. 57315 Nagy Drive Elkhart, IN 46517 Test Date(s): Sep 21, 2005 Data recorded by Gordon L. Helm, NCE This report prepared by: Gordon L. Helm, NCE Technical Manager/Test Engineer, AHD Test report #0500814B FCC 15.231 for 1800-TIM-TW4 FCC ID: IVS1800TIMTW Tested Sep 21, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 0500814B.doc EXHIBIT E: Page 2 of 16 TABLE OF CONTENTS EXHIBIT E: Report of Measurements [2.1033(b6)] .....................................................................................1 TABLE OF CONTENTS.........................................................................................................................2 Statements Concerning this Report.......................................................................................................3 Manufacturer/Applicant [2.1033(b1)] ....................................................................................................4 Measurement/Test Site Facility & Equipment........................................................................................4 Test Site1 [2.948, 2.1033(b6)] ....................................................................................................4 Measurement Equipment Used [2.947(d), 15.231(b)] ..................................................................4 Environment...........................................................................................................................................4 Summary of Results: .............................................................................................................................6 Changes made to achieve compliance..........................................................................................6 EUT Description ............................................................................................................................................7 EUT Pictures..........................................................................................................................................7 Tested Configuration /Setup: .................................................................................................................8 Support Equipment & Cabling .......................................................................................................8 Setup Diagram ...............................................................................................................................8 Standards Applied to Test: ..................................................................................................................10 Equipment Configuration .....................................................................................................................10 Test Methodology: ...............................................................................................................................10 FORMULAS AND SAMPLE CALCULATIONS: ...........................................................................12 Test Data .............................................................................................................................................13 Radiated Field Strength Measurements: [15.231(b), 15.205] ....................................................13 Occupied Bandwidth [15.231(c)]..................................................................................................13 Radiated Field Strength Measurements: [15.205, 15.231(b)] ....................................................14 Out of Band Emissions [15.231(b)]..............................................................................................15 Test report #0500814B FCC 15.231 for 1800-TIM-TW4 FCC ID: IVS1800TIMTW Tested Sep 21, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 0500814B.doc EXHIBIT E: Page 3 of 16 Statements Concerning this Report NVLAP Accreditation: NVLAP Lab Code 200129-0 The scope of AHD accreditation is the conducted emissions, radiated emissions test methods of: IEC/CISPR 22: Limits and methods measurement of radio disturbance characteristics of information technology equipment. FCC Method – 47 CFT Part 15 – Digital Devices. AS/NZS 3548: Electromagnetic Interference – Limits and Methods of Measurement of Information Technology Equipment. IEC61000-4-2 and Amend.1: ElectroStatic Discharge Immunity IEC61000-4-5: Surge Immunity Test Data: This test report contains data covered by the NVLAP accreditation.. Test Traceability: The calibration of all measuring and test equipment and the measured data using this equipment are traceable to the National Institute for Standards and Technology (NIST). Limitations on results: The test results contained in this report relate only to the Item(s) tested. Any electrical or mechanical modification made to the test item subsequent to the test date shall invalidate the data presented in this report. Any electrical or mechanical modification made to the test item subsequent to this test date shall require an evaluation to verify continued compliance. Limitations on copying: This report shall not be reproduced, except in full, without the written approval of AHD. Limitations of the report: This report shall not be used to claim product endorsement by NVLAP, FCC, or any agency of the US Government. Statement of Test Results Uncertainty: Following the guidelines of NAMAS publication NIS81 and NIST Technical Note 1297, the Measurement Uncertainty at a 95% confidence level is determined to be: ± 1.4 dB Retention of Records: 1) For equipment verified to co…
