IWD4871048710 & 48722 Signal Boosters

USERS MANUAL For 48710 and 48722 Bi-Directional Amplifiers 200 Pondview Drive, Meriden, CT 06450 877 737-9675, Fax 203 821-3852, www.rfsamericas.com C C o o p p y y r r i i g g h h t t 1 1 9 9 9 9 3 3 - - R R a a d d i i o o F F r r e e q q u u e e n n c c y y S S y y s s t t e e m m s s - - A A l l l l r r i i g g h h t t s s r r e e s s e e r r v v e e d d . . Disclaimer All information and statements contained herein are accurate to the best of the knowledge of Radio Frequency Systems, but Radio Frequency Systems does not make any warranty with respect thereto, including without limitation any results which may be obtained from the products described herein or the infringement by such products of any proprietary rights of any persons. Use or application of such information or statements is at the user’s sole risk, without any liability on the part of Radio Frequency Systems. Nothing herein shall be construed as license of or recommendation for use which infringes upon any proprietary rights of any person. Product material and specifications are subject to change without notice. All sales of the products described herein are subject to Radio Frequency Systems’s standard terms of sale and the specific terms of any particular sale. USER’S MANUAL SERIES 48750 RF REPEATER AMPLIFIERS iDwg 602300003500/Rev.1 TABLE OF CONTENTS General Statements---------------------------------------------------------------------------------- -------- 1 M M P P E E S S t t a a t t e e m m e e n n t t - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 1 F F i i e e l l d d A A l l i i g g n n m m e e n n t t S S t t a a t t e e m m e e n n t t - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 2 F F C C C C a a n n d d D D O O C C C C e e r r t t i i f f i i c c a a t t i i o o n n - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 2 Product Overview ----------------------------------------------------------------------------------- -------- 3 Theory of Operation ----------------------------------------------------------------------- 3 Block Diagram------------------------------------------------------------------------- 3 Electrical and Mechanical Specifications ----------------------------------------------- 4 Outline of Face Plate------------------------------------------------------------------ 4 Intermod, Output Power and AGC ------------------------------------------------------ 5 Table 1. Typical Output Power------------------------------------------------------ 5 AGC Shut Down --------------------------------------------------------------------------- 6 Manual Gain Control ---------------------------------------------------------------------- 6 AC/DC Power ------------------------------------------------------------------------------ 6 Installation -------------------------------------------------------------------------------------------- -------- 7 Antenna Isolation -------------------------------------------------------------------------- 8 Troubleshooting, Repair, and Warranty ------------------------------------------------------- -------- 8 Periodic Maintenance-------------------------------------------------------------------- 10 Service ------------------------------------------------------------------------------------- 10 Warranty----------------------------------------------------------------------------------- 10 USER’S MANUAL SERIES 48750 RF REPEATER iiDwg 602300003500/Rev.1 G G E E N N E E R R A A L L S S T T A A T T E E M M E E N N T T S S T T h h a a n n k k y y o o u u f f o o r r s s e e l l e e c c t t i i n n g g t t h h i i s s R R F F S S p p r r o o d d u u c c t t . . W W e e a a r r e e c c o o n n f f i i d d e e n n t t t t h h a a t t y y o o u u w w i i l l l l f f i i n n d d t t h h i i s s p p r r o o d d u u c c t t i i n n p p r r o o p p e e r r w w o o r r k k i i n n g g o o r r d d e e r r , , m m e e e e t t i i n n g g a a l l l l s s t t a a t t e e d d s s p p e e c c i i f f i i c c a a t t i i o o n n s s . . I I f f n n o o t t , , p p l l e e a a s s e e c c o o n n t t a a c c t t c c u u s s t t o o m m e e r r s s e e r r v v i i c c e e i i m m m m e e d d i i a a t t e e l l y y 8 8 0 0 0 0 3 3 2 2 1 1 - - 4 4 7 7 0 0 0 0 a a n n d d w w e e w w i i l l l l r r e e s s o o l l v v e e t t h h e e s s i i t t u u a a t t i i o o n n w w i i t t h h o o u u t t h h e e s s i i t t a a t t i i o o n n . . P P l l e e a a s s e e t t a a k k e e t t h h e e t t i i m m e e t t o o r r e e a a d d t t h h r r o o u u g g h h t t h h i i s s c c o o n n s s i i s s e e m m a a n n u u a a l l . . A A f f u u l l l l u u n n d d e e r r s s t t a a n n d d i i n n g g o o f f t t h h e e w w a a y y t t h h i i s s p p r r o o d d u u c c t t o o p p e e r r a a t t e e s s w w i i l l l l s s u u p p p p o o r r t t o o p p t t i i m m a a l l p p e e r r f f o o r r m m a a n n c c e e a a n n d d p p r r e e v v e e n n t t a a c c c c i i d d e e n n t t a a l l d d a a m m a a g g e e n n o o t t c c o o v v e e r r e e d d b b y y t t h h e e s s t t a a t t e e d d w w a a r r r r a a n n t t y y . . N N i i n n e e t t y y p p e e r r c c e e n n t t o o f f i i n n s s t t a a l l l l a a t t i i o o n n s s h h a a v v e e n n o o p p r r o o b b l l e e m m s s a a t t a a l l l l , , i i t t ’ ’ s s…

Text truncated - open the document above for the full version.

I W D 487 10

FCC ID: IWD48710 ITEM 12EQUIPMENT SPECIFICATIONS Frequency Range (MHz) Rated RF power output in watts Frequency tolerance Emission Designator Microprocessor Model number 806 - 8241N/AF3EN/A 851 - 8691N/AF3EN/A 896 – 9021N/AF3EN/A 935 - 9411N/AF3EN/A 806 - 8240.5N/ADXWN/A 851 - 8690.5N/ADXWN/A 896 – 9020.5N/ADXWN/A 935 - 9410.5N/ADXWN/A 806 - 8240.5N/AD7WN/A 851 - 8690.5N/AD7WN/A 896 – 9020.5N/AD7WN/A 935 - 9410.5N/AD7WN/A

200 Pondview Drive, Meriden, CT 06450 • (877) 737-9675 • Fax (203) 821-3852 • www.rfsworld.com Bi-Directional Amplifiers 800/900 SMR ƒ Replace 48510-N and 48522-N ƒ High Reliability/No Maintenance ƒ Ultrahigh Dynamic Range ƒ Fast and Easy Set Up ƒ Field Repairable The 48710 and 48722 are Signal Boosters designed to improve SMR band radio coverage in RF isolated areas. Industry leading fan-less cooling technique results in a MTBF of better then 10 years. AGC circuitry automatically prevents interference from strong signals or oscillation. No tuning and no maintenance required. Set up is fast and easy with the performance monitor (no computer required). Modular components and auto- balance control circuitry make field repair a snap. Additional band limit filtering can be incorporated into these models for custom requirements. Ordering Information: 48710 800 SMR band Class B Signal Booster 48722 900 SMR band Class B Signal Booster All models include a performance monitor and 10 ft extension cable. PM700-10 Monitor with 10 ft cable PMX-30 30 ft extension cable SPECIFICATIONS Downlink Uplink 48710 Frequency, MHz 851-869 806-824 48722 Frequency, MHz 935-941 896-901 Gain, no Attenuation, 80 dB 80 dB Gain Flatness, Typ. ±1.0 dB ± 1.0 dB Manual Attenuator Range 15 dB 15 dB Output Limiter Range, automatic* 20 dB 20 dB Noise Figure, Typ.** 2.0 dB 2.0 dB Composite Power, Typ.* +30 dBm +30 dBm iDEN, CDMA Typ. +27 dBm +27 dBm * AGC circuitry monitors the output power and reduces the gain to prevent overdrive or oscillation. * No attenuation and room temperature Impedance 50 Ohms VSWR, input, both ports 1.5 Propagation Delay, worse case at band edge < 1.0 microsecond Power, 110-240 VAC auto ranging 1.5 A @ 120 VAC Operating Temperature, ambient -30 to +50° C Connectors, RF N Female Size L X W X D,wall mount, 40 lbs 13.5 X 18.0 X 7.3 (34.3 x 45.7 x 18.5 cm) Similar to Nema 3R Diagnostics: Power and Fault LEDs plus 15 pin diagnostics port. Alarms for all active component modules plus overdrive and over temperature Output DCV for AGC level and Output detectors, Uplink and Downlink, and Remote Shutdown Hand held performance monitor provides LED indications from the diagnostics port. FCC ID: Pending IC CANADA: Pending

IWD48710 Technical Description T T h h e e 4 4 8 8 7 7 1 1 0 0 s s e e r r i i e e s s s s i i g g n n a a l l b b o o o o s s t t e e r r s s a a r r e e d d e e s s i i g g n n e e d d t t o o e e n n h h a a n n c c e e r r a a d d i i o o c c o o m m m m u u n n i i c c a a t t i i o o n n s s i i n n b b u u i i l l d d i i n n g g s s , , b b a a s s e e m m e e n n t t s s , , t t u u n n n n e e l l s s a a n n d d o o t t h h e e r r R R F F s s h h i i e e l l d d e e d d e e n n v v i i r r o o n n m m e e n n t t s s . . T T h h e e 4 4 8 8 7 7 1 1 0 0 i i s s t t u u n n e e d d f f o o r r t t h h e e 8 8 0 0 0 0 M M H H z z S S M M R R b b a a n n d d a a n n d d t t h h e e 4 4 8 8 7 7 2 2 2 2 i i s s t t u u n n e e d d f f o o r r t t h h e e 9 9 0 0 0 0 M M H H z z S S M M R R b b a a n n d d . . T T h h e e s s e e u u n n i i t t s s w w o o r r k k b b y y r r e e c c e e i i v v i i n n g g a a n n d d a a m m p p l l i i f f y y i i n n g g t t h h e e B B a a s s e e T T X X s s i i g g n n a a l l s s v v i i a a a a d d o o n n o o r r a a n n t t e e n n n n a a d d i i r r e e c c t t e e d d a a t t t t h h e e d d e e s s i i r r e e d d b b a a s s e e s s i i t t e e . . T T h h i i s s R R F F p p a a t t h h i i s s c c a a l l l l e e d d t t h h e e ‘ ‘ d d o o w w n n l l i i n n k k ” ” . . T T h h e e a a m m p p l l i i f f i i e e d d b b a a s s e e T T X X s s i i g g n n a a l l i i s s r r e e - - r r a a d d i i a a t t e e d d v v i i a a a a n n t t e e n n n n a a ( ( s s ) ) o o r r r r a a d d i i a a t t i i n n g g c c a a b b l l e e i i n n t t o o t t h h e e “ “ S S e e r r v v i i c c e e A A r r e e a a ” ” . . S S u u b b s s c c r r i i b b e e r r m m o o b b i i l l e e R R F F s s i i g g n n a a l l s s a a r r e e r r e e c c e e i i v v e e d d b b y y t t h h e e s s a a m m e e s s e e r r v v i i c c e e a a r r e e a a r r a a d d i i a a t t i i n n g g e e l l e e m m e e n n t t s s , , a a m m p p l l i i f f i i e e d d i i n n t t h h e e “ “ u u p p l l i i n n k k ” ” R R F F p p a a t t h h t t o o b b e e r r a a d d i i a a t t e e d d b b a a c c k k t t o o t t h h e e b b a a s s e e v v i i a a t t h h e e d d o o n n o o r r a a n n t t e e n n n n a a . . T T h h e e L L N N A A s s a a n n d d P P o o w w e e r r A A m m p p l l i i f f i i e e r r s s a a r r e e b b r r o o a a d d b b a a n n d d . . T T h h e e s s a a m m e e m m o o d d e e l l s s a a r r e e u u s s e e d d f f o o r r t t h h e e u u p p l l i i n n k k a a n n d d d d o o w w n n l l i i n n k k o o n n b b o o t t h h t t h h e e 4 4 8 8 7 7 1 1 0 0 a a n n d d 4 4 8 8 7 7 2 2 2 2 . . L L i i k k e e w w i i s s e e , , t t h h e e c c o o n n t t r r o o l l b b o o a a r r d d i i s s t t h h e e s s a a m m e e f f o o r r b b o o t t h h m m o o d d e e l l s s . . D D i i f f f f e e r r e e n n t t a a t t i i o o n n i i s s p p r r o o v v i i d d e e d d b b y y t t h h e e d d u u p p l l e e x x i i n n g g f f i i l l t t e e r r s s o o n n t t h h e e b b a a s s e e a a n n d d s s e e r r v v i i c c e e a a r r e e a a c c o o n n n n e e c c t t o o r r s s t t h h a a t t d d e e t t e e r r m m i i n n e e t t h h e e b b a a s s i i c c p p a a s s s s b b a a n n d d a a n n d d d d i i r r e e c c t t t t h h e e R R F F s s i i g g n n a a l l s s t t o o t t h h e e p p r r o o p p e e r r g g a a i i n n p p a a t t h h , , u u p p l l i i n n k k a a n n d d d d o o w w n n l l i i n n k k r r e e s s p p e e c c t t i i v v e e l l y y . . B B o o t t h h l l i i n n k k s s h h a a v v e e a a u u t t o o m m a a t t i i c c g g a a i i n n c c o o n n t t r r o o l l ( ( A A G G C C ) ) i i n n t t h h e e p p o o w w e e r r a a m m p p l l i i f f i i e e r r s s t t o o p p r r e e v v e e n n t t o o v v e e r r d d r r i i v v e e . . M M a a n n u u a a l l g g a a i i n n a a d d j j u u s s t t m m e e n n t t i i s s p p r r o o v v i i d d e e d d i i n n t t h h e e L L N N A A s s t t a a g g e e . . O O v v e e r r d d r r i i v v e e l l i i m m i i t t i i n n g g i i s s p p r r o o v v i i d d e e d d b b y y t t h h e e A A G G C C c c i i r r c c u u i i t t r r y y a a n n d d s s e e t t a a t t t t h h e e f f a a c c t t o o r r y y a a n n d d s s o o t t h h a a t t t t h h e e 4 4 8 8 7 7 1 1 0 0 s s e e r r i i e e s s w w i i l l l l n n o o t t e e x x c c e e e e d d t t h h e e F F C C C C l l i i m m i i t t s s f f o o r r s s p p u u r r i i o o u u s s e e m m i i s s s s i i o o n n s s T T h h e e c c o o n n t t r r o o l l b b o o a a r r d d d d i i s s t t r r i i b b u u t t e e s s D D C C p p o o w w e e r r t t o o t t h h e e a a m m p p l l i i f f i i e e r r m m o o d d u u l l e e s s a a n n d d m m o o n n i i t t o o r r s s e e a a c c h h m m o o d d u u l l e e f f o o r r a a n n y y f f a a u u l l t t c c o o n n d d i i t t i i o o n n . . L L E E D D i i n n d d i i c c a a t t o o r r s s p p r r o o v v i i d d e e v v i i s s u u a a l l d d i i a a g g n n o o s s t t i i c c s s w w h h i i l l e e t t h h e e 1 1 5 5 p p i i n n d d i i n n c c o o n n n n e e c c t t o o r r h h a a s s D D C C a a n n d d T T T T L L t t e e s s t t p p o o i i n n t t s s f f o o r r m m o o r r e e i i n n d d e e p p t t h h t t r r o o u u b b l l e e s s h h o o o o t t i i n n g g . . Block Diagram Duplexers 48710 5595 48722 J09020 Service Base PA80-9942 LNA80-0002 PA80-9942 LNA80-0002 Uplink 48710 806-824 MHz 48722 896-902 MHz Downlink 48710 851-869 MHz 48722 935-941 MHz Control Board

Master: FCC Part22H Date: February 25, 2001 Test Report:1W03979 Applicant:Radio Frequency Systems 4100 SW Research Way Corvallis, OR 97333 USA Equipment Under Test:48710 & 48722 (EUT)Signal Booster In Accordance With:FCC Part 90 Tested By:Nemko Canada Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Group Manager Date: Total Number of Pages:88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 2 of 88 Table of Contents Section 1. Summary of Test Results......................................................................................3 Section 2. General Equipment Specification........................................................................5 Section 3. RF Power Output..................................................................................................6 Section 4. Occupied Bandwidth..........................................................................................11 Section 5. Spurious Emissions at Antenna Terminals........................................................36 Section 6. Field Strength of Spurious..................................................................................85 Section 7. Frequency Stability.............................................................................................87 Section 8. Test Equipment List...........................................................................................88 Annex A Test Diagrams....................................................................................................A1 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 3 of 88 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 90. New Submission & Family ListingProduction Unit Class II Permissive ChangePre-Production Unit AMP Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: _____________________________________ DATE: ___________________ Glen Westwell, Wireless Technologist Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 4 of 88 Summary Of Test Data Name Of TestPara. No.Result RF Power Output2.1045Complies Occupied Bandwidth2.1049Complies Spurious Emissions at Antenna Terminals2.1051Complies Field Strength of Spurious Emissions2.1053Complies Frequency Stability2.1055Complies Footnotes For N/A’s: Test Conditions: IndoorTemperature:24 °C Humidity:36 % OutdoorTemperature:23 °C Humidity:38 % . Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 5 of 88 Section 2.General Equipment Specification Manufacturer: Radio Frequency Systems Model No.: 48710 & 48722 Serial No.: 48710: 01231521624 48722: 01231521625 Date Received In Laboratory: June 16, 2001 Nemko Identification No.: Item # 1 & 2 Supply Voltage Input: 120 VAC Frequency Range: 48710Downlink:851 – 869MHz Uplink:806 – 824MHz 48722Downlink:935 – 941MHz Uplink:896 – 902MHz Output Impedance: 50 ohms RF Output (Rated): DXW & D7W = 0.5W (27dBm) F3E = 1W (30 dBm) Emission Designator: DXW D7W F3E Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 6 of 88 Section 3.RF Power Output Para. No.: 2.1045 Test Performed By: Glen WestwellDate of Test: June 28, 2001 Minimum Standard:± 1dB Test Results:Complies. Measurement Data:See attached graphs. The maximum RF output power is within ± 1dB of the manufacturer’s rating. The RF output power is de-rated according to the number of channels via AGC and is equal to Pmax –10LogN. Pmax = Maximum RF output power. N = Number of channels. Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 7 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 8 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 9 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 10 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 11 of 88 Section 4.Occupied Bandwidth Para. No.: 2.1049 Test Performed By: Glen WestwellDate of Test: June 28, 2001 Minimum Standard:N/A Test Results:Complies. There is no degradation in the output signal. Test Data:See attached graph(s). The occupied bandwidth was measured by comparison of the input to the output signal. This was done in order to determine if there was any degradation to the output signal due to the amplification through the signal booster. Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 12 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 13 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 14 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 15 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 16 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: …

Text truncated - open the document above for the full version.

Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 26 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 27 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 28 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 29 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 30 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 31 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 32 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 33 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 34 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 35 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 36 of 88 Section 5.Spurious Emissions at Antenna Terminals Para. No.: 2.1051 Test Performed By: Glen WestwellDate of Test: June 29, 2001 Minimum Standard:-13dBm Test Results:Complies. Test Data:See attached graphs. Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 37 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 38 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 39 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 40 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 41 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 42 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 43 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 44 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 45 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 46 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 47 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 48 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 49 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 50 of 88

Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 51 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 52 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 53 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 54 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 55 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 56 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 57 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 58 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 59 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 60 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 61 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 62 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 63 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 64 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 65 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 66 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 67 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 68 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 69 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 70 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 71 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 72 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 73 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 74 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 75 of 88

Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 76 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 77 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 78 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 79 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 80 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 81 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 82 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 83 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 84 of 88 Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 85 of 88 Section 6.Field Strength of Spurious Para. No.: 2.1053 Test Performed By: Glen WestwellDate of Test: July 4, 2001 Minimum Standard:-13dBm Test Results:Complies. Test Data:48710 & 48722 • All emissions were searched up to the 10 th harmonic for both the base and service area. • No emissions were detected within 20dB of the emission limit. Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 86 of 88 Photographs of Test Setup (Worst Case Configuration) Front View Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 87 of 88 Section 7.Frequency Stability Para. No.: 2.1055 Test Performed By: Glen WestwellDate of Test: July 5, 2001 Minimum Standard:2.1055 Test Results:Complies. The maximum frequency drift is 0Hz. Measurement Data:Standard Test Frequency:48710: 815, 860MHz 48722: 899, 938MHz Standard Test Voltage:120 VAC -30°C to 50°C in 10°C Steps 20°C ± 15% Standard Test Voltage Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 EQUIPMENT: 48710 & 48722 Signal Booster Page 88 of 88 Section 8.Test Equipment List CAL CYCLE EQUIPMENTMANUFACTURERMODELSERIALLAST CAL.NEXT CAL. 1 YearSpectrum AnalyzerHewlett Packard8564E3846A01407Mar. 2/01Mar. 2/02 1 YearClimate ChamberThermotronSM-16C15649-SCOUCOU 1 YearAttenuatorNarda768-209507Oct. 12/00Oct. 12/01 1 YearAttenuatorNarda776B-20FA001400June 10/01June 10/02 1 YearHorn AntennaEMCO #231154336Dec. 1/00Dec. 1/01 3 YearSignal GeneratorRohde & SchwarzSM1Q03DE22004Sept. 18/00Sept. 18/03 1 YearRF AMPJCA2-4 GHzFA001496May 31/01May 31/02 1 YearRF AMPJCA1-2 GHzFA001498May 31/01May 31/02 1 YearRF AMPJCA4-8 GHzFA001497May 31/01May 31/02 1YearFrequency CounterHewlett PackardHP5350A2444A00135May 7/00Nov. 4/01 1 YearPower MeterHewlett PackardE4448BFA001413Jan. 16/01Jan. 16/02 1 YearPower SensorHewlett Packard8487AFA001419Jan. 16/01Jan. 16/02 NA: Not Applicable NCR: No Cal Required COU: CAL On Use Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 ANNEX A EQUIPMENT: 48710 & 48722 Signal Booster Page A1 of A4 Annex A Test Diagrams Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 ANNEX A EQUIPMENT: 48710 & 48722 Signal Booster Page A2 of A4 Para. No. 2.985 - R.F. Power Output Modulated Signal Source Insertion Unit EUT 50 ohm Load Millivoltmeter Para. No. 2.989 - Occupied Bandwidth EUTAttenuator Modulated Signal Source Spectrum Analyzer Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 ANNEX A EQUIPMENT: 48710 & 48722 Signal Booster Page A3 of A4 Para. No. 2.991 Spurious Emissions at Antenna Terminals EUT Attenuator Modulated Signal Source Spectrum Analyzer EUT Signal Generator No. 1 Signal Generator No. 3 Signal Generator No. 2 50 ohm Pad Spectrum Analyzer Attenuator Nemko Canada Inc.FCC PART 90 PROJECT NO.: 1W03979 ANNEX A EQUIPMENT: 48710 & 48722 Signal Booster Page A4 of A4 Para. No. 2.993 - Field Strength of Spurious Radiation Para. No. 2.995 - Frequency Stability Climate Chamber EUT Signal Generator Variable Power Supply Attenuator Frequency Counter 10 MHz Reference 10 METERS EUT NON-CONDUCTING TURN-TABLE 0.8 METER VARIABLE SEARCH HEIGHT (1 TO 4 m) TO TEST RECEIVER/SPECTRUM ANALYZER SEARCH ANTENNA
