To Whom It May Concern:: As per FCC Public Notice # DA 00-1407: Requirement #3: The Equipment Under Test (EUT), which was qualified as an RF modular at Compatible Electronics, Inc. on (Date), was tested in the following configuration: The RF Module was setup outside a Desktop configuration. The RF Module was connected to a Mini PCI to CardBus extender (Adapter #1), via the Mini PCI connector. The Mini PCI to CardBus extender was then connected to a CardBus to PCI adapter (Adapter #2), which was connected to the PCI Bus of the Desktop computer. Both, adapter and extender were copper shielded and grounded (Chassis Ground) in order to prevent radiated emissions getting out of the desktop computer via the extender and possibly out of the RF Module. In order to test the RF module, half of the Extender was outside the desktop computer. Because of this particular setup, the other half of the extender was grounded to Chassis ground using copper tape. The Module’s own RF Shielding was NOT connected to chassis ground. The tabs of the Mini PCI Module were connected to Chassis ground. In a real notebook computer environment, these tabs connect the digital ground of the Mini PCI Card to Chassis ground.

MODULAR TRANSMITTER REQUIREMENTS 1. The Modular Transmitter has its own power supply regulation located on U7 & U15 (Please See BOM or Schematics) 2. The Modular Transmitter has its own RF Shielding (See External and Internal Photographs) 3. The Modular Transmitter has antenna that complies with section 15.203. It has a UFL at the RF Transmitter Module End to (either hardwired to the antenna or to an MMCX end, depending on OEM configuration) 4. The Module Transmitter was tested in a stand-along configuration (See Compatible Electronics Test Report) 5. The Modular Transmitter will be labeled with its own FCC ID. Also, the Notebook Computer Manufacturer will be informed to display a label referring to the enclosed module. The exterior label will say: “Contains Transmitter Module FCC ID: J3OM3AWEB56GA” or “Contains TXFCCID: J3OM3AWEB56GA 6. The RF Exposure Limits Mentioned in Section 15.247 (b)(4) of the FCC Rules and regulations are included in the Manual (See Application)

114 OLINDA DRIVE • •• • BREA, CALIFORNIA 92823 • •• • (714) 579-0500 • •• • FAX (714) 579-1850 1 December 5, 2001 American TCB 6731 Whittier Ave., Suite C110 McLean, VA 22101 Subject: Request for Certification of the Xircom, Inc. MPCI Type 3A 802.11B Wireless + V.92 Modem Card Model: M3AWEB56GA FCC ID: J3OM3AWEB56GA Gentlemen: We have enclosed a package for the certification of the Xircom, Inc. MPCI Type 3A 802.11B Wireless + V.92 Modem Card Model: M3AWEB56GA We are requesting that the MPCI Type 3A 802.11B Wireless + V.92 Modem Card be approved as a modular transmitter. Only 1 antenna (Rangestar) will be certified for the modular approval. The other antenna (Foxconn) is included in the test report to show a typical configuration for the module, but is to not be part of the modular approval. We have enclosed the completed Form 731 with the applicable exhibits. If you have any questions or need any additional information, please give me a call at (714) 579-0500. Sincerely, Kyle Fujimoto Test Engineer

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 26, 2001 RE: Xircom, Inc. FCC ID: J3OM3AWEB56GA I have a few comments on this Application. 1.) The FCC is still using Adobe 4.0 as their preferred document software. It is completely incompatible with the security settings you used in converting your Exhibits using Acrobat 5.0. I was not able to remove the encryption myself, so I must ask you to remove all encryption and upload all documents again to the American TCB website. Please use the word Revised in the MS-DOS file name. 2.) Please extract the test setup photos from the test report and add to the Test Setup photos Exhibit. 3.) It is not completely clear where the label will be placed in the card. Please provide photo or line drawing identifying where the label will be placed on the device. 4.) There is a statement in the Test Report which states that the Foxcom antenna is not part of the modular approval. Is this true? If so, why are you showing it in the RF Exposure report? 5.) There is a local oscillator which shows up ~400MHz below the carrier frequency. If the LO is present when the Tx is placed in Rx mode, or the transmitter final stage is turned off, it is considered an Unintentional emission, and therefore subject to the Class B limits. Was this emission investigated? 6.) A Confidentiality Request letter is required. 7.) Is a Part 68 Application for this device pending? If you have any questions give me a call. William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

To Whom It May Concern: As per FCC Public Notice # DA 00-1407: Requirement #3: The Equipment Under Test (EUT), which was qualified as an RF modular at Compatible Electronics, Inc. on (Date), was tested in the following configuration: Setup #1: The RF Module was setup outside a Desktop configuration. The RF Module was connected to a Mini PCI to CardBus extender (Adapter #1), via the Mini PCI connector. The Mini PCI to CardBus extender was then connected to a CardBus to PCI adapter (Adapter #2), which was connected to the PCI Bus of the Desktop computer. Both, adapter and extender were copper shielded and grounded (Chassis Ground) in order to prevent radiated emissions getting out of the desktop computer via the extender and possibly out of the RF Module. In order to test the RF module, half of the Extender was outside the desktop computer. Because of this particular setup, the other half of the extender was grounded to Chassis ground using copper tape. The Module’s own RF Shielding was NOT connected to chassis ground. The tabs of the Mini PCI Module were connected to Chassis ground. In a real notebook computer environment, these tabs connect the digital ground of the Mini PCI Card to Chassis ground. Setup #2: The RF Module was setup inside a Desktop configuration. The RF Module was connected to a PCI Caddy, which is a Mini PCI to PCI card adapter. The TX Antenna of the RF Module is mechanically attached to the PCI Caddy on the outside of the metal slot. The antenna was mechanically design to be at a 90 degree angle from the backside of the desktop computer in order to avoid breaking the antenna when located close to a wall or any other objects. Consequently when RF emission measurements were taken in this setup, the 90 degree angle of the antenna (which was originally the same antenna gain as setup #1) was causing many more additional RF reflections with respect to the back of the desktop computer (which was metal). Because of this very specific test setup, (plus our marketing strategy of the 90 degree angle antenna) the only way to comply FCC Subpart C regulations, was to REDUCE the ANTENNA GAIN (antenna Gain= -4dbi) in order to keep the same RF output power used in setup #1. Furthermore, it was proven that the worst-case scenario was in setup #1 due to the higher antenna gain & also the PCI Bus clock of the desktop computer was physically longer with respect to the load (RF Module) Setup #1 used an ANTENNA GAIN of 0dbi Please see Compatible Electronics Test Reports/Packages for Photographs and Data.

US FCC Part 68 Registration Document Number: 142-1170-006 A Compliance Engineering US FCC Part 68 Registration For Mini PCI Type 3A 802.11b Wireless Ethernet + Modem 56 Model: M3AWEB56GA XIRCOM, INC. 2300 CORPORATE CENTER DRIVE THOUSAND OAKS, CA 91320 (805) 376-9300 DATE: July 20, 2001 COVER PAGE REGISTRATION TOTAL PAGES 1 1 2 This document shall not be reproduced except in full, without the written approval of Xircom, Inc.

RESPONSES TO QUESTIONS FROM AMERICAN TCB FOR THE FCC-ID: J3OM3AWEB56GA 1.) The FCC is still using Adobe 4.0 as their preferred document software. It is completely incompatible with the security settings you used in converting your Exhibits using Acrobat 5.0. I was not able to remove the encryption myself, so I must ask you to remove all encryption and upload all documents again to the American TCB website. Please use the word Revised in the MS-DOS file name. Response: All of the exhibits were submitted using Adobe Acrobat 4, not 5, as stated in your letter. The files were not encrypted, they were merely protected so that they could not be modified. This is the identical way that we have been submitting data to the FCC and TCBs for years. 2.) Please extract the test setup photos from the test report and add to the Test Setup photos Exhibit. Response: The Setup Photos are under M3AWEB56GA\TestSetupPhotos\SETUP_TCB.PDF 3.) It is not completely clear where the label will be placed in the card. Please provide photo or line drawing identifying where the label will be placed on the device. Response: The FCC-ID Label exhibit has been revised and will include the photo and drawing showing where the label will be placed on the device. Please see the file FCC-ID_Label_Revised.pdf 4.) There is a statement in the Test Report which states that the Foxcom antenna is not part of the modular approval. Is this true? If so, why are you showing it in the RF Exposure report? Response: Please see the Justification Letter from Xircom under Additional Information explaining why this is. 5.) There is a local oscillator which shows up ~400MHz below the carrier frequency. If the LO is present when the Tx is placed in Rx mode, or the transmitter final stage is turned off, it is considered an Unintentional emission, and therefore subject to the Class B limits. Was this emission investigated? Response: The frequency range was investigated from 10 kHz to 25 GHz in Tx/Rx mode. All emissions within 20 dB of the limit are reported on the data sheets. 6.) A Confidentiality Request letter is required. Response: The Confidentiality Request has been loaded under cover letters. We forgot to upload that exhibit, sorry for the inconvenience. 7.) Is a Part 68 Application for this device pending? Response: The Part 68 Grant has been uploaded under Additional Information under the file pt68reg.pdf

REVISIONS REV.DESCRIPTIONDATEAPPROVED APer ECN 2277906-07-01N. Guetschoff BPer ECN 2338107-31-01N. Guetschoff UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONS DECIMALS ANGLES ±0.008 MATERIAL FINISH DO NOT SCALE DRAWING CONTRACT NO. APPROVALS DATE DRAWN K. Hovsepian 07-31-01 CHECKED N. Guetschoff07-31-01 APPROVED M. Muschovic07-31-01 L. Meyer- L. Thum- LABEL APPROVALS, DUMMY, M3AWEB56GA SIZE FSCM NO.DRAWING NO.REV. A830-1757-001 B SCALE FULL SHEET 1 OF 1 THIS DOCUMENT CONTAINS INFORMATION PROPRIETARY TO XIRCOM, INC. AND IS FURNISHED TO FOR THE PURPOSE OF INSTALLATION, OPERATION OR MAINTENANCE OF THE ITEM(S) DESCRIBED HEREIN. ALL OTHER USES OF THIS DOCUMENT OR ITS CONTENTS ARE NOT AUTHORIZED BY XIRCOM, INC. © 2001 ALL RIGHTS RESERVED. COPYING OF THIS DOCUMENT IS UNLAWFUL WITHOUT THE WRITTEN PERMISSION OF XIRCOM, INC., THOUSAND OAKS, CA 91320-1420. 4 6 7 9 1 2 3 5 1 8 2 141.30mm (5.56”) 123.60mm (4.87”) 97.80mm (3.85”) 44.10mm (1.74”) 4.50mm (.18”) FOR PLACEMENT ONLY DOES NOT PRINT 37.90mm (1.49”) 36.10mm (1.42”) 2X 8.10mm (.32”) 10X R1.00mm (R.04”) 2X R1.00mm (R.04”) 4X R1.00mm (R.04”) R0.60mm (R.03”) R3.30mm (R.13”) Canada: xxx,xxxx,xxxxA CANADA ICES/NMB-003 Class/Classe (B) This Class B digital apparatus meets all requirements of the Canadian Interference-Causing equipment Regulations. TELEPERMIT PTC 211 / 00 / 119 RN = 1 This Xircom M3AWEB56GA Mini PCI Modem may be connected to the Telecom Network CANADA LBL E178682E178682 SIRIM 049700-AQV1137 CNC xx-xxxx SCT xxxxxxxx-xxx AG/UM-2000.096 X-XXX-XX-XXXX X-XXX-XX-XXXX XXXXXXXX GZAEXXXX NYAEXXXX AXX-XXXJP 2.4 DS4 CAUTION - To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord. TURK TELEKOM ONAY NO GCF xxxxx CTU xxxx x T xxxx DXX-MXX-X FOR HOME OR OFFICE USE Tested to Comply with FCC Standards FCC ID: J3OM3AWEB56GA Licensed under U.S. Patent No: x,xxx,xxx Product of Malaysia N232 Model: M3AWEB56GA CIB S&E xxxx This unit complies with Part 68 of FCC Regulations. FCC Registration Number 2U6MLA-xxxxx-M5-E REN 1.0B 0.5A CUS 21.00mm (.83”) 15.20mm(.60”) 24.60mm(.97”) 2X 42.50mm(1.67”) 97.80mm (3.85”) 46.20mm (1.82”) 10.40mm (.41”) 4.40mm (.17”) 1.90mm (.07”) • REF ARTWORK #832-2645-001B, ADOBE ILLUSTRATOR 9.0 FILE • LABEL MATERIAL MUST BE UL APPROVED • A/W PART NUMBERS TO PRINT ON ALL FILM LAYERS (CMYK OR PMS) IF FILM IS REQUIRED • LABELS TO BE PRINTED ON FLAT SHEETS OR ON ROLLS (TO BE DETERMINED BY MANUFACTURING) • MARK PART NUMBER AND REVISION IN CONSPICUOUS AREA ON OUTSIDE OF BULK PACKAGING • ALL TEXT/GRAPHICS TO BE BLACK UNLESS OTHERWISE INDICATED • GREEN=PANTONE 375 FINISH• GLOSSY MATERIAL • 2 LAYERS OF 3M#1350-1,WHITE, POLYESTER FILM W/ACRYLIC ADHESIVE (OR EQUIV), 0.10[0.004] TOTAL THICKNESS, (0.025[0.001] THICK FILM WITH 0.025[0.001] THICK ADHESIVE PER LAYER), UL-510 RATED MATERIAL.” NOTES:(UNLESS OTHERWISE SPECIFIED) 8 3

Description of the M3AWEB56GA The MPCI Type III A 802.11B + Modem 56K Card Model: M3AWEB56GA is a WLAN Mini PCI adapter that enables high-speed access to internet and intranet assets without wires. This card uses the IEEE 802.11 protocol to enable communications between the host computer and either another host computer or a network, using the 2.4GHz ISM Radio Band for the communications medium. The host computer uses the adapter for communications in the same way that it would use an Ethernet Network Interface Card (NIC). The M3AWEB56GA also has a 56k Modem Wide Area Network using the Telecommunication Lines.

T e c h n i c a l S p e c i f i c a t i o n S h e e t 2.4 GHz Bluetooth™ Antenna — P/N 100902 Ultima™ Series Antennas This small embedded antenna provides the most reliable, easy-to-use, and adjustment-free antenna technology for handling during assembly and implementation by developers. Typical Mounting Typical VSWR Typical Pattern Features •Small and lightweight •No tuning components •Available in tape and reel or tray packing for automatic mounting Electrical Frequency Range2400 – 2500 MHz Peak Gain (1) 0 dBi VSWR (1) less than 2.0:1 Polarizationlinear Azimuth Beamwidthomnidirectional Power Handling10 Watt cw Feed Point Impedance50 Ohms unbalanced Note (1) Figures dependent on ground plane size Mechanical Size18.2 x 3.9 x 1.6 mm Weightless than 1 g Mountingsurface mount technology Dimensions Typical Pad Layout © 2000 RangeStar Wireless, Inc. RangeStar, RangeStar Wireless, and Ultima are trademarks or registered trademarks of RangeStar Wireless, Inc. All rights reserved. Protected by one or more U.S. Patents 5,507,012; 5,666,125; 5,777,586; 5,945,954; 5,999,140; D417,221; 6,095,820; and other U.S. and foreign patents pending. Specification subject to change without notice. http://www.rangestar.com201T262D-2 5.0 4.0 3.0 2.0 1.0 24002475245024752500 Frequency (MHz) Ratio (:1) 0° 90°270° azimuth plane – red elevation plane – blue 18.2 mm 3.9 mm 1.6 mm Land Copper with Solder Resist Board Material signal ground not to scale +5 dBi 0 dBi RangeStar™ antenna test PCB ground SPECIFICATIONS: ANTENNA TYPE: OMNIDIRECTIONAL, MONOPOLE ANTENNA 1. ELECTRICAL CHARACTERISTICS: 1-1 LOW LEVEL CONTACT RESISTANCE : 20 mini- ohms Max.. 1-2 PRODUCT VSWR IN 2.4 GHZ TO 2.5 GHZ IN FREE AIR : 2.0 Max.. 1-3 INSULATION RESISTANCE : 5000 M ohms Min. 1-4 DIELECTRIC WITHSTANDING VOLTAGE : 500 VAC 1-5 IMPEDANCE : 50 ohms. 1-6 CONNECTOR VSWR : 1.5 Max.. 1-7 PRODUCT AVERAGE GAIN IN 2.4 TO 2.5 GHZ IN FREE AIR
-9.0 TO –11.0 dB 2. MECHANICAL CHARACTERISTICS: 2-1 MECHANICAL SHOCK : No discontinuity > 1 μ s per Method EIA-364-27B. 2-2 VIBRATION : No discontinuity > 1 μ s per Method EIA-364-28D, Condition V, letter D. 2-3 DURABILITY : 500 cycles. 2-4 FERRITE RETENTION FORCE : 10 kg Min.. 2-5 CONNECTOR CRIMP FORCE : 3 kg Min.. 3. ENVIRONMENTAL CHARACTERISTICS: 3-1 OPERATING TEMPERATURE : -40°C TO +125°C 3-2 TEMPERATURE LIFE : Subject mated samples at 105 ± 3 ° C for 1000 hours per Method EIA-364-17B. 3-3 TEMPERATURE HUMIDITY CYCLING : Subject mated samples to 10 cycles between 25 to 65 ° C at 95% RH for 240 hours per Method EIA-364-31A, Method III and Condition C unpowered, omitting sub-cycle 7b. 3-4 THERMAL SHOCK : Subject mated samples to 5 cycles between -40 to 125°C per Method EIA-364-32. FOXCONN HON HAI PRECISION INDUSTRY CO.,LTD. TAIPEI TAIWAN R.O.C. APPD: H.C.YU 11/26/01 TITLE: IEEE 802.11B WHIP WIRELESS ANTENNA CHKD: H.C.YU 11/26/01 X1 SMKTB18- 11108 H.C.YU PROD.NO.: 2RAN005-00 2RAN005-01 2RAN005-02 DR.: H.L.HSIAO 11/23/01 REV ECN.NO. APPD. DWG. NO.: 389-0000-025 REV.: X1 SHEET: 1 OF 1 Samples of Rickshaw B with –4.0 dB gain Radiation pattern in desktop Sample 1 Sample 2 Sample 3 Sample 4 Sample 5

FCC ID: M3AWEB56GA Report Number: B11108D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 23 FCC PART 15, SUBPART C TEST METHOD: ANSI C63.4-1992 for MPCI TYPE 3A 802.11B WIRELESS + V.92 MODEM CARD Model: M3AWEB56GA Prepared for XIRCOM, INC. 2300 CORPORATE CENTER DRIVE THOUSAND OAKS, CALIFORNIA 91320 COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: NOVEMBER 13, 2001 REPORT APPENDICES TOTAL BODY A B C D PAGES 23 2 2 14 51 92 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. FCC ID: M3AWEB56GA Report Number: B11108D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 23 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. Description of Test Configuration 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 7. CHARACTERISTICS OF THE TRANSMITTER 15 7.1 Transmitter Power 15 7.2 Channel Number and Frequencies 15 7.3 Chipping Rate 15 7.4 Spreading Gain 15 7.5 Antenna Gain 15 7.6 Processing Gain 16 8. Test Procedures 17 8.1 RF Emissions 17 8.1.1 Conducted Emissions Test 17 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 18 8.2 6 dB Bandwidth for Direct Sequence Systems 20 8.3 Peak Output Power 20 8.4 Spectral Density Output 20 8.5 RF Antenna Conducted Test 21 8.6 RF Band Edges 21 8.7 Processing Gain 22 9. CONCLUSIONS 23 FCC ID: M3AWEB56GA Report Number: B11108D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 23 LIST OF APPENDICES APPENDIX TITLE A Modifications to the EUT B Additional Models Covered Under This Report C Diagrams, Charts and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors D Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site FCC ID: M3AWEB56GA Report Number: B11108D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 23 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested: MPCI Type 3A 802.11B Wireless + V.92 Modem Card Model: M3AWEB56GA S/N: N/A Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Xircom, Inc. 2300 Corporate Center Drive Thousand Oaks, California 91320 Test Date: November 8, 2001 File # For Canada IC2154-D Test Specifications : EMI requirements FCC Title 47, Part 15 Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247 Test Procedure: ANSI C63.4: 1992 Test Deviations: The test procedure was not deviated from during the testing. FCC ID: M3AWEB56GA Report Number: B11108D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 23 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 450 kHz – 30 MHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.207 2 Spurious Radiated RF Emissions, 10 kHz – 25000 MHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247(c) 3 Fundamental and Emissions produced by the intentional radiator in non-restricted bands, 10 kHz – 25 GHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247(c) 4 Emissions produced by the intentional radiator in restricted bands, 10 kHz – 25 GHz Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.205 and 15.209(a) 5 6 dB Bandwidth Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (a)(2) 6 Maximum Peak Output Power Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (b)(1) 7 RF Antenna Conducted Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (c) 8 Peak Power Spectral Density Conducted from the Intentional Radiator to the Antenna Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (d) 9 Processing Gain Complies with the relevant requirements of FCC Title 47, Part 15, Subpart C, section 15.247 (e) FCC ID: M3AWEB56GA Report Number: B11108D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 23 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the MPCI Type 3A 802.11B Wireless + V.92 Modem Card Model: M3AWEB56GA. Only the RF module itself is being approved. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the MPCI Type 3A 802.11B Wireless + V.92 Modem Card, referred to as EUT hereafter,…

Text truncated - open the document above for the full version.

FCC Processing Gain report of Intersil MiniPCI 2.4 GHz WLAN transceiver model ISL37400M for: -channel 1 at 11Mbps -channel 6 at 2 Mbps -channel 6 at 11 Mbps -channel 11 at 11 Mbps intersil PRISM radio Jamming Margin Test _________________________________________________________________________________________________________ _____________________________________________________________________________________ intersil Page 1 Testing for compliance with FCC rules 15-247e Carl Andren inters…
