J9C-QCNCM825Qualcomm WiFi 7/BT Combo module

For additional information or to submit technical questions, go to: https://createpoint.qti.qualcomm.com Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets NO PUBLIC DISCLOSURE PERMITTED: Please report postings of this document on public servers or websites to: [email protected]. Confidential Distribution: Use or distribution of this item, in whole or in part, is prohibited except as expressly permitted by written agreement(s) and/or terms with Qualcomm Incorporated and/or its subsidiaries. Not to be used, copied, reproduced, or modified in whole or in part, nor its contents revealed in any manner to others without the express written permission of Qualcomm Technologies, Inc. All Qualcomm products mentioned herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark or registered trademark of Qualcomm Incorporated. Other product and brand names may be trademarks or registered trademarks of their respective owners. This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion contrary to U.S. and international law is strictly prohibited. Qualcomm Technologies, Inc. 5775 Morehouse Drive San Diego, CA 92121 U.S.A. © 2023 Qualcomm Technologies, Inc. and/or its subsidiaries. All rights reserved. QCNCM825 OEM Integrator Instructions 80-58492-3 Rev. AA April 20, 2023 80-58492-3 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 2 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Revision history Revision Date Description AA April 2023 Initial release 80-58492-3 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 3 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Contents 1 Introduction ............................................................................................................................................... 6 2 Applicable Module ..................................................................................................................................... 7 3 Available Global Modular Approvals from Qualcomm .............................................................................. 8 4 Additional Regulatory Conformance Testing and/or Submissions Required by the Integrator ................ 9 5 Compliant/Allowable Tx Power File ......................................................................................................... 10 6 Allowable Antennas to Use with the Radio Module ................................................................................ 11 7 Antenna Placement Inside the Host System and RF Exposure ................................................................ 13 8 Simultaneous Transmission with Other Integrated or Plug-In Radios ..................................................... 14 9 Module May Not Be Installed by End Users ............................................................................................ 15 10 Required Labeling on the Outside of the Host ....................................................................................... 16 10.1 FCC ............................................................................................................................................ 16 10.2 Taiwan NCC ............................................................................................................................... 17 10.3 European Community Radio Equipment Directive (RED) ......................................................... 17 10.4 UKCA ......................................................................................................................................... 18 11 Required Labeling on the Module ......................................................................................................... 19 11.1 FCC labeling on the Module ..................................................................................................... 19 11.2 Rest of world labeling on the Module ...................................................................................... 19 11.3 Instructions to download the sample global label artwork with certification IDs ........................................................................................................................................ 19 12 Required Regulatory Wording for User Manual/Installation Manual ................................................... 20 12.1 FCC compliance information .................................................................................................... 20 12.2 Industry Canada Notices ........................................................................................................... 21 12.3 European Community (RED) user manual wording and declaration ....................................... 22 12.4 European Community (RED) Declaration of Conformity for System ........................................ 24 12.5 RED and UKCA Declaration of Conformity for System ............................................................. 24 12.6 UKCA output power .................................................................................................................. 25 12.7 Taiwan user manual wording ................................................................................................... 25 12.8 Korea user manual wording ..................................................................................................... 25 QCNCM825 OEM Integrator Instructions Contents 80-58492-3 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 4 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 12.9 Brazil user manual wording ...................................................................................................... 26 12.10 …

Text truncated - open the document above for the full version.

Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121-1714 www.qualcomm.com 8 June 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Declaration Letter for Dual Client Devices (6CD) We, Qualcomm Technologies, Inc., attest that this device under FCC ID: J9C- QCNCM825 complies with device protocol requirements and operational restrictions for Dual Client Devices (6CD). a) This device does not support 6PP category and the maximum power does not exceed authorized values. b) This device will only associate and connect with a Low Power Indoor Access Point, Subordinate Device, or Standard Power Access Point and never directly link to any other client devices. c) This device will always initiate transmission under the control of a Low Power Indoor Access Point, Subordinate Device, or Standard Power Access Point except for brief communications before joining a network. These brief messages will only occur if the client has detected a Low Power Indoor Access Point, Subordinate Device, or Standard Power Access Point operating on a channel. These messages will have a time- out mechanism such that if this device does not receive a response from an AP, it will not continually repeat the request. d) This device, when associated and connected with a Low Power Indoor Access Point, Subordinate Device or Standard Power Access Point device, will operate at or below power levels advertised by the Low Power Indoor Access Point, Subordinate Device, or Standard Power Access Point: i. lower than or equal to the power advertised by the Low Power Indoor Access Point or Subordinate Device; and never above the maximum output power allowed by the FCC grant for clients associated with Low Power Indoor Access Points or Subordinate Devices. ii. 6 dB lower than the Standard Power Access Point’s authorized power level; and never above the maximum output power allowed by the FCC grant for clients associated with Standard Power Access Points. e) Contention-based protocol as demonstrated in the test report is permanently embedded in the module and is not host-dependent based protocol demonstrated in the test report. f) We acknowledge this device is subject to and in full compliance with the device restrictions listed below. All users are notified of these restrictions through the user manual. • Prohibited for control of or communications with unmanned aircraft systems, including drones. This device is prohibited for control of or communications with unmanned aircraft systems, including drones. Best Regards Stanley Lin/Wireless Regulatory, Staff Qualcomm Technologies Inc.

Wednesday, March 01, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Certification designating a U.S. agent for service of process pursuant to Part 2.911(d)(7) To whom it may concern, Qualcomm Technologies, Inc., Grantee Code J9C (“the applicant”) certifies that, as of the date of the filing of application, Paul Guckian is designated as the U.S. agent for the purpose of accepting service of process on behalf of the applicant. FRN: 0022707111 The physical U.S. address and email for the designated agent are: 5775 Morehouse Drive, San Diego, CA 92121, USA [email protected] The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The agent accepts the designation by (the applicant) as the U.S. agent to accept service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. Sincerely, Paul Guckian Qualcomm Technologies, Inc. VP, Engineering, EMC-Regulatory [email protected] Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121 www.qualcomm.com

Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121-1714 www.qualcomm.com 8 June 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Declaration Letter To Whom It May Concern: We declare the UUT will be under control Low-power indoor access point and Standard power Access Point, the UUT can adjust a transmitter’s output power based on access point categories which to connected. This function is auto controlled by software. Further, we declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Thank you for your attention. Best Regards Stanley Lin/Wireless Regulatory, Staff Qualcomm Technologies Inc.

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: June 8, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, Qualcomm Technologies, Inc. (“the applicant”) certifies that the equipment FCC ID: J9C-QCNCM825 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Qualcomm Technologies, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, _________________________ Stanley Lin/Wireless Regulatory, Staff Qualcomm Technologies Inc. Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121 www.qualcomm.com

Date: 2023/06/08 FCC ID: J9C-QCNCM825 To the attention of: Federal Communications Commission Authorization and Evaluation Division Declaration Letter for Client Devices We, Qualcomm Technologies, Inc., attest that this device under FCC ID: J9C-QCNCM825 complies with device protocol requirements and operational restrictions for Client Devices. a) This device will only associate and connect with an indoor access point or subordinate device and never directly connects to other client devices. b) Client devices must be under control of an U-NII-4, Indoor access point or subordinate device. c) Clients shall passively scan to associate with access point or subordinate. d) Clients are permitted to initiate a brief probe message requesting to join and associated with a specific Access Point or Subordinate. e) Clients cannot have a direct connection to the internet to source the internet to other clients, access points, subordinates or clients from a wired or direct connection. f) We acknowledge this device is subject to and in full compliance with the device restrictions listed below. All users are notified of these restrictions through the user manual. • A statement in a conspicuous location on the device and the user's manual: “Section 15.19 Statement (if not on the device) If you should have any questions regarding this declaration, please do not hesitate to contact us, thank you! Sincerely yours, Stanley Lin/Wireless Regulatory, Staff Qualcomm Technologies Inc. Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121-1714 www.qualcomm.com

Qualcomm Technologies, Inc. 5775 Morehouse Drive San Diego, CA 92121-1714 www.qualcomm.com 9/12/2022 Attestation Letter To Whom It May Concern: With this letter, we (Qualcomm Technologies, Inc.) confirm the Qualcomm Access Point reference board Model: RDP433, FW version: IPQ9574.ILQ.12.1-00307-P-1 used in this application is designed per IEEE 802.11be Draft Version 2.0 Published July 2022. Best Regards, Paul Guckian Vice President, Engineering Qualcomm Technologies, Inc.

Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121-1714 www.qualcomm.com 8 June 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: J9C-QCNCM825 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. • Schematics Diagram • Block Diagram • Theory of Operation • Software Security Statement Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days. • External photos • Test Setup photos • Internal Photos • Integrator Instruction It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Best Regards Stanley Lin Qualcomm Technologies, Inc.

Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121-1714 www.qualcomm.com 8 June 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. To whom it may concern: I, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch to act on our behalf in all manners relating to application for equipment authorization of J9C- QCNCM825 1. Receiving and exchanging data for the purposes of obtaining FCC grant for model FCC ID: J9C- QCNCM825 under this permissive change application. 2. Such authorization includes and is limited to preparing and submitting applications and corresponding documentation and information for certification of model FCC ID:J9C- QCNCM825 This authorization expires 1 year past the date indicated at the top of this letter. This authorization supersedes all previous authorizations provided by the undersigned. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Best Regards Stanley Lin Qualcomm Technologies, Inc.

Tuesday, March 14, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Authorization of Handling FCC Regulatory Applications FCC Grantee Code J9C To Whom It May Concern: I, hereby, authorize Mr. Stanley Lin, to handle FCC Regulatory related applications for Qualcomm Technologies, Inc. FCC Grantee Code J9C and sign all required application documents. Best Regards, ________________________ Paul Guckian Qualcomm Technologies, Inc. VP, Engineering, EMC-Regulatory [email protected] Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121 www.qualcomm.com

Reference No.: BWIN-WTW-P23020421_EXT Page 1/9 CONSTRUCTION PHOTOS OF EUT Reference No.: BWIN-WTW-P23020421_EXT Page 2/9 Reference No.: BWIN-WTW-P23020421_EXT Page 3/9 Reference No.: BWIN-WTW-P23020421_EXT Page 4/9 Antenna 1 (Brand: Hong-Bo / Model: 260-25094) Reference No.: BWIN-WTW-P23020421_EXT Page 5/9 Reference No.: BWIN-WTW-P23020421_EXT Page 6/9 Antenna 2 (Brand: Hong-Bo / Model: 260-25083) Reference No.: BWIN-WTW-P23020421_EXT Page 7/9 Reference No.: BWIN-WTW-P23020421_EXT Page 8/9 Antenna 3 (Brand: Hong-Bo / Model: 260-25084) Reference No.: BWIN-WTW-P23020421_EXT Page 9/9

PROPOSED FCC ID LABEL AND LOCATION Top of EUT FCC / IC Label Location (on Shielding cover) QUALCOMM TECHNOLOGIES, INC. FCC ID: J9C-QCNCM825 IC: 2723A-QCNCM825 Model: QCNCM825 CMIIT ID: XXXXXXXXXXX (M)

Reference No.: BWIN-WTW-P23020421_INT Page 1/2 CONSTRUCTION PHOTOS OF EUT Reference No.: BWIN-WTW-P23020421_INT Page 2/2

Report No.: MFBWIN-WTW-P2302042 R1Page No. 1 / 11Report Format Version: 7.1.0 Cancels and replaces the report No.: MFBWIN-WTW-P23020421-4 dated 2023/7/5 RF EXPOSURE REPORT CERTIFICATE OF CONFORMITY FCC Rule Part: FCC Part 2 (Section 2.1091) Report No.: MFBWIN-WTW-P23020421 R1 FCC ID: J9C-QCNCM825 Product: Qualcomm WiFi 7/BT Combo module Brand: Qualcomm Model No.: QCNCM825 Received Date: 2023/2/13 Test Date: 2023/6/12 Issued Date: 2023/7/6 Applicant: Qualcomm Technologies, Inc. Address: 5775 Morehouse Drive, San Diego, CA 92121-1714 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laborator y Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Desi gnation Number: 723255 / TW2022 Approved by: , Date:2023/7/6 Wen Yu / Assistant Manager This test report consists of 11 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Phoenix Huang / Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBWIN-WTW-P2302042 R1Page No. 2 / 11Report Format Version: 7.1.0 Cancels and replaces the report No.: MFBWIN-WTW-P23020421-4 dated 2023/7/5 Table of Contents Release Control Record ....................................................................................................................................................... 3 1 Certificate .................................................................................................................................................................... 4 2 Applicable RF Exposure Limit .................................................................................................................................. 5 3 Test Results ................................................................................................................................................................ 8 4 Conclusion ................................................................................................................................................................ 10 5 Information of the Testing Laboratories ................................................................................................................ 11 Report No.: MFBWIN-WTW-P2302042 R1Page No. 3 / 11Report Format Version: 7.1.0 Cancels and replaces the report No.: MFBWIN-WTW-P23020421-4 dated 2023/7/5 Release Control Record Issue No. Description Date Issued MFBWIN-WTW-P2302042 Original release. 2023/7/5 MFBWIN-WTW-P2302042 R1 Add the simultaneously transmission conditions list on section 3. 2023/7/6 Report No.: MFBWIN-WTW-P2302042 R1Page No. 4 / 11Report Format Version: 7.1.0 Cancels and replaces the report No.: MFBWIN-WTW-P23020421-4 dated 2023/7/5 1 Certificate Product: Qualcomm WiFi 7/BT Combo module Brand: Qualcomm Test Model: QCNCM825 Sample Status: Engineering sample Applicant: Qualcomm Technologies, Inc. Test Date: 2023/6/12 FCC Rule Part: FCC Part 2 (Section 2.1091) Standard: KDB 447498 D04 Interim General RF Exposure Guidance v01 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Report No.: MFBWIN-WTW-P2302042 R1Page No. 5 / 11Report Format Version: 7.1.0 Cancels and replaces the report No.: MFBWIN-WTW-P23020421-4 dated 2023/7/5 2 Applicable RF Exposure Limit § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatialaverage SAR of 8 W/kg, averaged over…

Text truncated - open the document above for the full version.

Doc.No.:3.8.05 Rev – 10.3 Regulatory WLAN Antenna Information 1/13 Regulatory WLAN Antenna Information (Template) English Language Required for Regulatory Review / Approval \ Platform information Brand Tester’s name Tester’s signature Test Date platform (ex: Yes, No or NA) Platform type (ex: regular NB, convertible PC, AIO...etc) *SAR minimum separation (mm) Hong-Bo Eason Tseng 2021/1/14 NA WiFi Monopole *****Please fill in exact product model name and make sure the model name is visible on product cover or any parts for end users recognize for authority inspection. Antenna information Vendor Type Antenna Part number (Main) Hong-Bo Monopole 260-25084 manufacture name manufacture address Changshu HongBo Telecommunication Technology Co., Ltd. No. 8, Liuzhou Road, Lushan Industrial Park, Xinxing Development Zone, Changshu City, Jiangsu Province,China Peak gain w/ cable loss (dBi)* 2.4GHz 2400-2483.5 MHz 5.2GHz 5150-5250MHz 5.3GHz 5250-5350MHz 5.6GHz 5470-5725MHz 5.8GHz 5725-5850MHz 5.9GHz 5850-5925MH 6.2GHz 5925-6425MHz 6.5GHz 6425-6525MHz 6.7GHz 6525-6875MHz 7.0 GHz 6875-7125MHz Main 3.22 3.35 3.42 4.77 4.72 4.71 4.75 4.29 4.81 4.74 Doc.No.:3.8.05 Rev – 10.3 Regulatory WLAN Antenna Information 2/13 Table of contents 1. Applicable test method 2. Test & System Description a. Test setup b. Equipment list 3. Setup photo Section 1. Antenna Assembly Specifications Section 2. Radiation characteristics of antenna loaded in Host Platform 4. Antenna information used for conformity with limits Doc.No.:3.8.05 Rev – 10.3 Regulatory WLAN Antenna Information 3/13 1. Applicable test methods This test report is prepared for PIFA antenna testing under a AMS-8500 Full Anechoic Chamber. ETS-Lindgren AMS-8500 system is 3D fully anechoic chamber, it is applied to the "Conical Cut test method" the detail description is described as below, The Conical Cut method requires the ability of the Measurement Antenna to be physically rotated in the theta plane (overhead) of the EUT for implementations using a single Measurement Antenna, Eleven conical cuts are required to capture data at every 15 degrees from the EUT, with the top (0 degrees) and bottom (180 degrees) cuts not being measured. Typically, the EUT will remain affixed to a turntable during the entire measurement process. The Measurement Antenna will be positioned at a starting theta angle. The EUT will then be rotated around the full 360 degrees of phi rotation, The Measurement Antenna will then be positioned at the next theta angle, and the process repeated. 2. Test & System Description b. Equipment list Doc.No.:3.8.05 Rev – 10.3 Regulatory WLAN Antenna Information 4/13 Name Manufacture Type/Model Serial Number Cal. Date Cal. Due Date ENA Series Network Analyze Keysight E5071C MY46108594 2021/8/3 2023/8/3 RF Switch Keysight 3499A MY4200955 NCR NCR Multi-Axis Positioner Controller ETS-Lindgren 2090 N/A NCR NCR Medium-Duty Positioner ETS-Lindgren 2015 N/A NCR NCR Measurement Horn Antenna EMCO Aug-64 86722 NCR NCR Measurement software ETS-Lindgren EM-Quest 1195 NCR NCR Doc.No.:3.8.05 Rev – 10.3 Regulatory WLAN Antenna Information 5/13 3. Setup photo Doc.No.:3.8.05 Rev – 10.3 Regulatory WLAN Antenna Information 6/13 Antenna Information Section 1. Antenna Assembly Specifications 1A 1B 1C 1D 1E 1F 1G 1H Antenna Part Number Manufacturer Antenna Type Cable Assembly Part Number and Information Freq Range MHz * Peak Gain W/ Cable loss (dBi) Peak Gain w/o Cable Loss (dBi) Max VSWR Cable Loss (dB) 260-25084 Hong-Bo Monopole 50 ohm Coaxial length: 200mm diameter: 1.13LLS Connector type…

Text truncated - open the document above for the full version.
