Monday, August 08, 2022 Request for Modular Approval for FCC ID: J9CQCARD7280N2, J9CQCARD7280N, J9CQCARD7280P Item Requirements EUT 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly The module is equipped with its own shielding case. 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal The module has buffer modulation / data inputs. 3. The module must contain power supply regulation on the module The module has its own power supply regulation. 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Not applicable to licensed modules. 5. The module must demonstrate compliance in a stand-alone configuration The module was tested on evaluation board, and it’s not inside of another device during testing 6. The module must be labeled with its permanently affixed FCC ID label, or use an electronic display The module transmitter will be labeled with its own FCC ID, and for OEM integration the integration manual contains labeling instructions for the host device per Part 15.212 (vi) 7. The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee The module approved transmitter complies with all applicable rules and the integration manual contains any specific requirements addressed to the integrator and/or to the end-user of the final end-product. 8. The module must comply with RF exposure requirements The modular transmitter complies with RF exposure requirement. Sincerely, John Forrester Sr. Director Engineering, EMC-Regulatory Qualcomm Technologies, Inc. [email protected] Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121

Monday, August 08, 2022 To Whom it May Concern: Please be notified that I, John Forrester, an authorized representative of Qualcomm Technologies, Inc., have designated Sporton International Inc. to be a proxy to sign form 731 and other documentation exclusively related to the Type Certification of FCC ID: J9CQCARD7280N, FCC ID: J9CQCARD7280N2, FCC ID: J9CQCARD7280P. We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. Sincerely, John Forrester Sr. Director Engineering, EMC-Regulatory Qualcomm Technologies, Inc. [email protected] Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121 www.qualcomm.com

Monday, August 08, 2022 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: J9CQCARD7280N FCC ID: J9CQCARD7280N2 FCC ID: J9CQCARD7280P To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. • Schematic Diagram • Block Diagram • Part List • Operational Description • Tune-up Procedure • U-NII SW security Statement Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachment(s) for 180 days after the grant as outlined in Public Notice DA 04-1705. • External Photos • Internal Photos • Test Setup Photos • Integrator Instruction It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, John Forrester Sr. Director Engineering, EMC-Regulatory Qualcomm Technologies, Inc. [email protected] Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, CA 92121

QUALCOMM Incorporated _________ 5775 Morehouse Drive San Diego, CA 92121-1714 www.qualcomm.com April 29, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Authorization of Handling FCC Regulatory Applications To Whom It May Concern: I, hereby, authorize Mr. John Forrester, to handle FCC Regulatory related applications for QUALCOMM Incorporated and sign all required application documents. Best Regards, Paul Guckian VP, Engineering QUALCOMM Incorporated 5775 Morehouse Drive San Diego, CA 92121 Office: 858-651-1547 [email protected]

For additional information or to submit technical questions, go to: https://createpoint.qti.qualcomm.com Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets NO PUBLIC DISCLOSURE PERMITTED: Please report postings of this document on public servers or websites to: [email protected]. Confidential Distribution: Use or distribution of this item, in whole or in part, is prohibited except as expressly permitted by written agreement(s) and/or terms with Qualcomm Incorporated and/or its subsidiaries. Not to be used, copied, reproduced, or modified in whole or in part, nor its contents revealed in any manner to others without the express written permission of Qualcomm Technologies, Inc. All Qualcomm products mentioned herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark or registered trademark of Qualcomm Incorporated. Other product and brand names may be trademarks or registered trademarks of their respective owners. This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion contrary to U.S. and international law is strictly prohibited. Qualcomm Technologies, Inc. 5775 Morehouse Drive San Diego, CA 92121 U.S.A. © 2022 Qualcomm Technologies, Inc. and/or its subsidiaries. All rights reserved. QCARD7280N-3 Module Photographs 80-43641-100 Rev. AA August 1, 2022 80-43641-100 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 2 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Revision history Revision Date Description AA August 2022 Initial release QCARD7280N-3 Module Photographs 80-43641-100 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 3 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 1 Front Photographs 1.1 External QCARD7280N-3 Module Photographs 80-43641-100 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 5 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 2 Rear Photograph

All Qualcomm products mentioned herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark or registered trademark of Qualcomm Incorporated. Other product and brand names may be trademarks or registered trademarks of their respective owners. This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion contrary to U.S. and international law is strictly prohibited. Qualcomm Technologies, Inc. 5775 Morehouse Drive San Diego, CA 92121 U.S.A. © 2022 Qualcomm Technologies, Inc. and/or its subsidiaries. All rights reserved. QCARD7280N-3 - LABEL AND PLACEMENT DOCUMENT 80-43641-10 Rev. AC August 25, 2022 80-43641-10 Rev. AC MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 2 Revision history Revision Date Description AA August 2022 Initial release AB August 2022 Updated IC name AC August 2022 Updated model name QCARD7280N-3 - LABEL AND PLACEMENT DOCUMENT 80-43641-10 Rev. AC MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 3 1 ID ■ Regulatory Model: QCARD7280N-3 ■ FCC ID: J9CQCARD7280N ■ IC: 2723A-J9CQCARD7280N 1.1 Label 2 Placement

QCARD7280N-3 Module Photographs 80-43641-100 Rev. AA Confidential – Qualcomm Technologies, Inc. and/or its affiliated companies – May Contain Trade Secrets 4 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 1.2 Internal

TEL : 886-3-327-3456 Page : 1 of 9 FAX : 886-3-328-4978 Issued Date : Aug. 31, 2022 Form version: 220617 RF EXPOSURE EVALUATION REPORT Report No. : FA1N1011-04 RF EXPOSURE EVALUATION REPORT FCC ID : J9CQCARD7280N Equipment : QCARD7280 Brand Name : Qualcomm Model Name : QCARD7280N-3 Applicant : Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, California 92121, United State Manufacturer : Qualcomm Semiconductor Limited No. 16-1 Zhanye 2nd Rd. East District Hsinchu City, 300091 (Taiwan) Standard : 47 CFR Part 2.1091 We, SPORTON INTERNATIONAL INC has been evaluated this product in accordance with 47 CFR Part2.1091 and it complies with applicable limit. Sporton Lab is accredited to ISO 17025 by Taiwan Accreditation Foundation (TAF code: 1190) and the FCC designation No. TW1190 under the FCC 2.948(e) by Mutual Recognition Agreement (MRA) in FCC evaluation. The results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. Laboratory, the test report shall not be reproduced except in full SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) Approved by: Cona Huang / Deputy Manager TEL : 886-3-327-3456 Page : 2 of 9 FAX : 886-3-328-4978 Issued Date : Aug. 31, 2022 Form version: 220617 RF EXPOSURE EVALUATION REPORT Report No. : FA1N1011-04 Table of Contents 1. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 4 2. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 5 3. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 6 4. RF EXPOSURE EVALUATION ................................................................................................................... 7 4.1. Collocated assessment ..................................................................................................................... 8 TEL : 886-3-327-3456 Page : 3 of 9 FAX : 886-3-328-4978 Issued Date : Aug. 31, 2022 Form version: 220617 RF EXPOSURE EVALUATION REPORT Report No. : FA1N1011-04 History of this test report Report No. Version Description Issued Date FA1N1011-04 Rev. 01 Initial issue of report Aug. 31, 2022 TEL : 886-3-327-3456 Page : 4 of 9 FAX : 886-3-328-4978 Issued Date : Aug. 31, 2022 Form version: 220617 RF EXPOSURE EVALUATION REPORT Report No. : FA1N1011-04 1. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type QCARD7280 Brand Name Qualcomm Model Name QCARD7280N-3 FCC ID J9CQCARD7280N Wireless Technology and Frequency Range WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band IV: 1710 MHz ~ 1755 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 12: 699 MHz ~ 716 MHz LTE Band 13: 777 MHz ~ 787 MHz LTE Band 14: 788 MHz ~ 798 MHz LTE Band 25: 1850 MHz ~ 1915 MHz LTE Band 26: 814 MHz ~ 849 MHz LTE Band 30: 2305 MHz ~ 2315 MHz LTE Band 38: 2570 MHz ~ 2620 MHz LTE Band 41: 2496 MHz ~ 2690 MHz LTE Band 48: 3550 MHz ~ 3700 MHz LTE Band 66: 1710 MHz ~ 1780 MHz LTE Band 71: 663 MHz ~ 698 MHz 5G NR n2 : 1850 MHz ~ 1910 MHz 5G NR n5 : 824 MHz ~ 849 MHz 5G NR n25 : 1850 MHz ~ 1915 MHz 5G NR n38 : 2570 MHz ~ 2620 MHz 5G NR n41 : 2496 MHz ~ 2690 MHz 5G NR n48 : 3550 MHz ~ 3700 MHz 5G NR n66 : 1710 MHz ~ 1780 MHz 5G NR n70 : 1695 MHz ~ 1710 MHz 5G NR n71 : 663 MHz ~ 698 MHz 5G NR n77: 3700 MHz ~ 3980 MHz, 3450MHz ~ 3550MHz WLAN 2.4 GHz Band: 2400 MHz ~ 2483.5 MHz WLAN 5.2 GHz Band: 5150 MHz ~ 5250 MHz WLAN 5.3 GHz Band: 5250 MHz ~ 5350 MHz WLAN 5.6 GHz Band: 5470 MHz ~ 5725 MHz WLAN 5.8 GHz Band: 5725 MHz ~ 5850 MHz WLAN 6E: 5925 MHz ~ 6425 MHz, 6425 MHz ~ 6525 MHz, 6525 MHz ~ 6875 MHz, 6875 MHz ~ 7125 MHz Bluetooth: 2400 MHz ~ 2483.5 MHz Mode RMC 12.2Kbps HSDPA HSUPA LTE: QPSK, 16QAM, 64QAM, 256QAM 5G NR: DFT-s-OFDM/CP-OFDM, Pi/2 BPSK/QPSK/16QAM/64QAM/256QAM WLAN:802.11a/b/g/n/ac/ax HT20/HT40/VHT20/VHT40/VHT80/VHT160/HE20/HE40/HE80/HE160 Bluetooth BR/EDR/LE EUT Stage Identical Prototype Remark: 1. Changing model name. The only difference is that, on the variant model, FR2 related components are depopulated. After assessing, since the test result is not affected by the changes, all the test cases were performed on original report which can be referred to Sporton Report Number FA1N1011. Reviewed by: Jason Wang Report Producer: Daisy Peng TEL : 886-3-327-3456 Page : 5 of 9 FAX : 886-3-328-4978 Issued Date : Aug. 31, 2022 Form version: 220617 RF EXPOSURE EVALUATION REPORT Report No. : FA1N1011-04 2. Maximum RF average output power among production units Remark: In RF test, EUT TX power level was configured via the test mode and set slightly higher than the maximum power level to cover the range of TX power variation among units Mode Band Number Maximum Average Power (dBm) WCDMA B2 25.20 WCDMA B4 25.20 WCDMA B5 25.20 LTE B2 25.20 LTE B4 25.20 LTE B5 25.20 LTE B12 25.20 LTE B13 25.20 LTE B14 25.20 LTE B25 25.20 LTE B26 25.20 LTE B30 25.20 LTE B38 25.20 LTE B38(HPUE) 27.20 LTE B41 25.20 LTE B41(HPUE) 27.20 LTE B48 25.20 LTE B66 25.20 LTE B71 25.20 FR1 n2 25.20 FR1 n5 25.20 FR1 n25 25.20 FR1 n38 25.20 FR1 n41 25.20 FR1 n41(HPUE) 27.20 FR1 n48 25.20 FR1 n66 25.20 FR1 n70 25.20 FR1 n71 25.20 FR1 n77 25.20 FR1 n77(HPUE) 27.20 Mode Maximum Average Power (dBm) BT BLE 11.05 BT BR/EDR 20.16 2.4GHz WLAN 22.86 5GHz WLAN 20.46 6GHz WLAN 15.81 TEL : 886-3-327-3456 Page : 6 of 9 FAX : 886-3-328-4978 Issued Date : Aug. 31, 2022 Form version: 220617 RF EXPOSURE EVALUATION REPORT Report No. : FA1N1011-04 3. RF Exposure Limit Introduction Per 1.1307(b)(3), (i) For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more …

Text truncated - open the document above for the full version.

TEL : 886-3-327-0868 Page Number : 1 of 17 FAX : 886-3-327-0855 Issued Date : Aug. 29, 2022 Report Version : 01 FCC TEST REPORT Report No.: 1N1011-04 SPOT CHECK EVALUATION FCC ID : J9CQCARD7280N Equipment : QCARD7280 Model Name : QCARD7280N-3 Applicant : Qualcomm Technologies, Inc. 5775 Morehouse Drive, San Diego, California 92121, United State Standard : 47 CFR Part 2, 22(H), 24(E), 27, 90(R), 90(S), 96 FCC Part 15 Subpart C §15.247 FCC Part 15 Subpart E §15.407 The product was received on May 03, 2022 and testing was performed from Jun. 14, 2022 to Aug. 26, 2022. We, Sporton International Inc. Wensan Laboratory, would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. Wensan Laboratory, the test report shall not be reproduced except in full. Approved by: Louis Wu Sporton International Inc. Wensan Laboratory No.58, Aly. 75, Ln. 564, Wenhua 3rd, Rd., Guishan Dist., Taoyuan City 333010, Taiwan (R.O.C.) TEL : 886-3-327-0868 Page Number : 2 of 17 FAX : 886-3-327-0855 Issued Date : Aug. 29, 2022 Report Version : 01 FCC TEST REPORT Report No.: 1N1011-04 TABLE OF CONTENTS History of this test report ................................................................................................................................. 3 1. Introduction Section .................................................................................................................................. 4 2. Model Difference Information ................................................................................................................... 5 3. Spot Check Verification Data Section ...................................................................................................... 6 4. Reference detail Section ......................................................................................................................... 11 5. List of Measuring Equipment .................................................................................................................. 12 Appendix A. Test Setup Photographs TEL : 886-3-327-0868 Page Number : 3 of 17 FAX : 886-3-327-0855 Issued Date : Aug. 29, 2022 Report Version : 01 FCC TEST REPORT Report No.: 1N1011-04 History of this test report Version Description Issued Date 01 Initial issue of report Aug. 29, 2022 TEL : 886-3-327-0868 Page Number : 4 of 17 FAX : 886-3-327-0855 Issued Date : Aug. 29, 2022 Report Version : 01 FCC TEST REPORT Report No.: 1N1011-04 1. Introduction Section FCC ID: J9CQCARD7280N2 (parent model) and FCC ID: J9CQCARD7280N (variant model) use the same identical internal printed circuit board layouts, while the variant model depopulates mmWave related components, details are available in the operational description. Based on their similarity, the FCC Part 15C (equipment class: DSS, DTS) and FCC Part 15E (equipment class: NII, 6CD) and FCC Part 22, 24, 27, 90, 96 (equipment class: PCB, CBE) reuse the original model’s result and do spot-check, following the FCC KDB 484596 D01 v01. The spot check data in this report is used to justify the data reuse. The applicant should take full responsibility that the test data as referenced in this report represent compliance for this FCC ID (FCC ID: J9CQCARD7280N). TEL : 886-3-327-0868 Page Number : 5 of 17 FAX : 886-3-327-0855 Issued Date : Aug. 29, 2022 Report Version : 01 FCC TEST REPORT Report No.: 1N1011-04 2. Model Difference Information J9CQCARD7280N2 and J9CQCARD7280N use the identical internal printed circuit board layout, and the major differences which may relate to RF are listed below:  Hardware: the only difference is that, on the variant model, FR2 related components are depopulated.  Software: the software which associates with RF parameters in WCDMA/ LTE/ 5G FR1/ WiFi is identical between the reference and the variant. The detail of similarity and difference is illustrated in the operational description. Based on the information, spot check of conducted power and emission level was performed and presented in this report to justify the data referencing. TEL : 886-3-327-0868 Page Number : 6 of 17 FAX : 886-3-327-0855 Issued Date : Aug. 29, 2022 Report Version : 01 FCC TEST REPORT Report No.: 1N1011-04 3. Spot Check Verification Data Section Conducted power test and conducted/radiated spurious emission test configurations were selected from the worst cases identified in the parent model and tested to demonstrate the test data from original model remains representative for the variant model. Summary for power and CSE/RSE spot check for each rule entry and technology is listed as below: Test Item Mode J9CQCARD7280N2 Parent Worst Result J9CQCARD7280N Variant Check Result Difference (dB) Conducted Power (dBm) WWAN UMTS Band 2 24.90 24.66 -0.24 WWAN UMTS Band 4 24.47 24.36 -0.11 WWAN UMTS Band 5 24.20 23.96 -0.24 WWAN LTE Band 2 24.23 24.22 -0.01 WWAN LTE Band 4 24.07 24.17 0.10 WWAN LTE Band 5 23.70 23.76 0.06 WWAN LTE Band 12 23.71 23.88 0.17 WWAN LTE Band 13 23.66 23.68 0.02 WWAN LTE Band 14 23.72 23.67 -0.05 WWAN LTE Band 25 24.25 24.19 -0.06 WWAN LTE Band 26 23.74 23.72 -0.02 WWAN LTE Band 30 23.70 24.19 0.49 WWAN LTE Band 38 25.80 26.07 0.27 WWAN LTE Band 41 25.81 26.14 0.33 WWAN LTE Band 48 24.55 24.41 -0.14 WWAN LTE Band 66 24.09 24.21 0.12 WWAN LTE Band 71 23.81 23.80 -0.01 WWAN LTE CA 5B 24.65 24.60 -0.05 WWAN LTE CA 66B 23.69 24.09 0.40 WWAN LTE CA 66C 23.48 23.12 -0.36 WWAN LTE CA 38C 26.14 25.65 -0.46 WWAN LTE CA 41C 26.21 25.99 -0.22 WWAN LTE CA 48C 23.25 22.93 -0.32 WWAN NR n2 24.22 24.43 0.21 WWAN NR n5 24.06 23.99 -0.07 WWAN NR n25 24.50 24.37 -0.13 WWAN NR n38 24.53 24.46 -0.07 WWAN NR n41 26.56 26.22 -0.34 WWAN NR n48 24.26 24.26 0.00 WWAN NR n66 24.65 24.55 -0.10 WWAN NR n70 24.32 23.92 -0.40 WWAN NR n71 24.13 24.12 -0.01 WWAN…

Text truncated - open the document above for the full version.

TEL : 886-3-327-0868 Page Number : 22 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B 3.3.6 Test Result of Power Spectral Density Plots (100kHz) <Ant. 4> <1Mbps> PSD 100kHz Plot on Channel 00 PSD 100kHz Plot on Channel 19 PSD 100kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 23 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B <2Mbps> PSD 100kHz Plot on Channel 00 PSD 100kHz Plot on Channel 19 PSD 100kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 24 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B <Ant. 5> <1Mbps> PSD 100kHz Plot on Channel 00 PSD 100kHz Plot on Channel 19 PSD 100kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 25 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B <2Mbps> PSD 100kHz Plot on Channel 00 PSD 100kHz Plot on Channel 19 PSD 100kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 26 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B 3.3.7 Test Result of Power Spectral Density Plots (3kHz) <Ant. 4> <1Mbps> PSD 3kHz Plot on Channel 00 PSD 3kHz Plot on Channel 19 PSD 3kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 27 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B <2Mbps> PSD 3kHz Plot on Channel 00 PSD 3kHz Plot on Channel 19 PSD 3kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 28 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B <Ant. 5> <1Mbps> PSD 3kHz Plot on Channel 00 PSD 3kHz Plot on Channel 19 PSD 3kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 29 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B <2Mbps> PSD 3kHz Plot on Channel 00 PSD 3kHz Plot on Channel 19 PSD 3kHz Plot on Channel 39 N/A TEL : 886-3-327-0868 Page Number : 30 of 49 FAX : 886-3-327-0855 Issue Date : Aug. 22, 2022 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR1N1011B 3.4 Conducted Band Edges and Spurious Emission Measurement 3.4.1 Limit of Conducted Band Edges and Spurious …
