[] QUICK START Follow the directions on these two pages to start using your phone right away. For more information, refer to the rest of this user guide. ... To turn on your phone You must turn on your phone in order to use any of its features. äPress for about a second, until the icon appears on the display. ... To make a call äDial the number on the keypad, then press . ... To hang up ä Press . ... To answer a call äWhen the phone rings, press to answer it. ... To save a number in the phone book 1.Enter the number you want to save. The [MENU] Smart Key changes to [SAVE]. See page 6 for more on Smart Keys. 2.Press the key under [SAVE]. 3.Follow the directions on the screen. See “Saving a number” on page 19 for more information. ... To speed dial a phone number 1.Enter a memory location from the phone book. 2.Press . pwr SEND END SEND SEND [ii] äPress the key under [MENU] to enter the menu structure. äPress or to scroll up or down through the menus. äEnter the menu and menu item number (such as 6 3 for Display > Banner) to open a menu item. äPress to back up one level without saving changes, or to cancel all the way out of the menus. C END [ ] QCP-860 ™ and QCP-1960 ™ USER GUIDE QUALCOMM Incorporated 6455 Lusk Boulevard, San Diego, California 92121-2779 U.S.A. http://www.qualcomm.com/cdma 80-68790-2EN_Rev - SEND 1 END 4 7 2 5 8 0 3 6 9 pwr C ι S029_56A1 -- QUALCOMM -- Apr 20 Thu 8:43 am D R [ MENU ] [ BOOK ] [iv] This manual is based on the production version of the QCP-860 and QCP-1960 telephones. Software changes may have occurred after this printing. QUALCOMM reserves the right to make changes in technical and product specifications without prior notice. The products and equipment described in this documentation are manufactured under one or more of the following U.S. Patents: 4,901,307, 5,056,109, 5,099,204, 5,101,501, 5,103,459, 5,107,225, 5,109,390, 5,193,094, 5,228,054, 5,257,283, 5,265,119, 5,267,261, 5,267,262, 5,280,472, 5,283,536, 5,289,527, 5,207,405, 5,309,474, 5,337,338, 5,339,046, 5,341,456, 5,383,219, 5,392,287, 5,396,516, D356,560, 5,408,697, 5,414,728, 5,414,796, 5,416,797, 5,426,392, 5,437,055, D361,065,5,442,322, 5,442,627, 5,452,473, 5,461,639, 5,469,115, 5,469,471, 5,471,497, 5,475,870, 5,479,475, 5,483,696, 5,485,486, 4,487,175, 5,490,165, 5,497,395, 5,499,280, 5,504,773, 5,506,865, 5,509,015, 5,509,035, 5,511,067, 5,511,073, 5,513,176, 5,515,177, 5,517,323, 5,519,761, 5,528,593, 5,530,928, 5,533,011, 5,535,239, 5,539,531, 5,544,196, 5,544,223, 5,546,459, 5,548,812, 5,559,881, 5,559,865, 5,561,618, 5,564,083, 5,566,000, 5,566,206, 5,566,357, 5,568,483, 5,574,773, 5,574,987, D375,740,5,576,662, 5,577,022, 5,577,265, D375,937,5,588,043, D376,804,5,589,756, 5,590,069, 5,590,406, 5,590,408, 5,592,548, 5,594,718, 5,596,570, 5,600,754, 5,602,834, 5,602,833, 5,603,096, 5,604,730, 5,604,459, 5,604,730, 5,608,722, 5,614,806, 5,617,060, 5,621,752, 5,621,784, 5,621,853, 5,625,876, 5,627,857, 5,629,955, 5,629,975, 5,638,412, 5,640,414, 5,642,398, 5,644,591, 5,644,597, 5,646,991, 5,652,814, 5,656,979, 5,655,229, 5,657,420, 5,659,569, 5,663,807. Other patents pending. FCC/IC Notice This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Copyright © 1998 QUALCOMM Incorporated. All rights reserved. Printed in the United States of America. QUALCOMM is a registered trademark and registered service mark of QUALCOMM Incorporated. Data on the Go is a registered trademark and Smart Keys, QCP-860, and QCP-1960 are trademarks of QUALCOMM Incorporated. [v] Customer Support Your service provider’s customer support department should be able to answer all your questions. You may also call U.S. 619-651-4028 or 800-349-4478 (toll-free, U.S. only) for QUALCOMM Customer Service. Consult QUALCOMM’s web site at www.qualcomm.com for more information about all our phones. Visit the Cellular Telecommunications Industry Association (CTIA) website at www.wow-com.com (wow-com TM ) or call 888-901-SAFE (toll-free, U.S. only) for telecommunications industry standards and driving safety information. Accessories Accessories make your QUALCOMM phone even more powerful and easy to use. You can purchase a hands-free car kit, hands-free headset, leather case, desktop charger, external battery, and more. To obtain QUALCOMM accessories, visit the place where you bought your phone or an authorized QUALCOMM service center. You can also call 800-349-4188 (toll-free, U.S. only) or visit our website at www.qualcomm.com. [] [] [TABLE OF CONTENTS] Quick start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i Getting to know your phone . . . . . . . . . . . . . . . . . . . 1 Turning the phone on and off . . . . . . . . . . . . . . . . . . 1 Safe operating instructions . . . . . . . . . . . . . . . . . . . . 2 Understanding the display . . . . . . . . . . . . . . . . . . . . 3 Smart Keys.......................................................... 5 Standby mode ..................................................... 5 Using the keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Using the keyguard .............................................. 8 Charging the batteries . . . . . . . . . . . . . . . . . . . . . . . 9 Making and receiving calls . . . . . . . . . . . . . . . . . . . 10 Making and receiving calls . . . . . . . . . . . . . . . . . . . . 10 Redialing calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Recent history list............................................... 12 Service provider calling features . . . . . . . . . . . . . . . . 13 Caller ID ............................................................ 13 Three-way calling................................................ 13 Call forwarding ................................................... 14 Call waiting....…

Text truncated - open the document above for the full version.

© 1998 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) QUALCOMM INCORPORATEDDates of Tests: November 05-06, 1998 6455 Lusk BoulevardTest Report S/N: SAR.981105757.J9C San Diego, CA 92121-2779Test Site: PCTEST Lab, Columbia MD Attention: Mr. Jay Moulton Director of Engineering Regulatory FCC ID J9CQCP-1960 APPLICANT QUALCOMM INCORPORATED EUT Type:Single-Band PCS CDMA Phone Tx Frequency:1851.25 – 1908.75 MHz Rx Frequency:1931.25 – 1988.75 MHz Max Output Power:0.16 W (Conducted) Trade Name/Model(s):QUALCOMM QCP-1960 FCC Classification:Licensed Portable Transmitter Held to Ear (PCE) Application Type:Certification Serial Number:n/a (pre production) FCC Rule Part(s):2.1093; ET Docket 96.326; 24(E) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a) 981105757.J9C SAR Measurement ReportFCC Part 24 Certification © 1998 PCTEST Labi Table of Contents SCOPE .............................................................................1 INTRODUCTION / SAR DEFINITION ......................................2 SAR MEASUREMENT SET-UP .............................................3 E-FIELD PROBE SYSTEM ...................................................4 PHANTOM & BRAIN EQUIVALENT MATERIAL ......................7 SYSTEM SPECIFICATIONS ................................................. 8 MEASUREMENT PROCESS ................................................9 TEST POSITION OF THE PHONE .........................................10 ANSI/IEEE C95.1 RF EXPOSURE LIMITS ..............................11 MEASUREMENT UNCERTAINTIES ......................................12 TEST DATA SUMMARY ...................................................... 13 SAR TEST EQUIPMENT LIST .............................................. 14 CONCLUSION / REFERENCES ...........................................15 ATTACHMENT A – TEST PLOTS ATTACHMENT B – PHOTOGRAPHS Test Report S/N: SAR.981105757.J9CSAR Measurement Report Test Dates: November 05-06, 1998FCC Part 24 Certification PCS CDMA Phone (Tx 1851.25-1908.75 MHz) © 1998 PCTEST LabQUALCOMM FCC ID: J9CQCP-1960 (Model: QCP-1960)1 SAR MEASUREMENT REPORT Scope - Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name:QUALCOMM INCORPORATED ADDRESS :6455 Lusk Boulevard San Diego, CA 92121-2779 Attention :Jay Moulton Director of Engineering Regulatory • EUT Type:Single-Band PCS CDMA Phone • FCC IDENTIFIER:J9CQCP-1960 • Trade Name:QUALCOMM • Model:QCP-1960 • S/N:Pre-production • Tx Frequency Range:1851.25 -1908.75 MHz • Rx Frequency Range:1931.25 – 1988.75 MHz • Application Type: Certification • FCC Classification:Licensed Portable Transmitter Held to Ear (PCE) • FCC Rule Part(s):§ 24(E); § 2.1093, Docket 96-326 • Max. Output Power:0.16 W (Conducted) • Modulation :CDMA • Antenna:Helical (λ/2) • Antenna Dimensions:13.85 cm. (Length) • Dates of Test(s):November 05-06, 1998 • Place of Test(s):PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.:SAR.981105757.J9C 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Figure 1. SAR Test Set-up Lab Code 100431-0 Test Report S/N: SAR.981105757.J9CSAR Measurement Report Test Dates: November 05-06, 1998FCC Part 24 Certification PCS CDMA Phone (Tx 1851.25-1908.75 MHz) © 1998 PCTEST LabQUALCOMM FCC ID: J9CQCP-1960 (Model: QCP-1960)2 1.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects a…

Text truncated - open the document above for the full version.

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/98121627_ZOOM.VLT Start : 16-Dec-98 08:07:23 am End : 16-Dec-98 08:20:32 am Radio Type : QUALCOMM Model Number : J9CQCP-1960 Serial Number : 3104 Frequency : 1851.25 MHz Peak Trans. Pwr : 0.160 W Start Trans. Pwr: 0.160 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 42.900 Mixture Conductivity = 1.650 Comment : QUALCOMM QCP PCS PHONE CHAN 0025 PCTEST Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.200 PCTEST Amplifier Channel Settings : 0.250 0.233 0.225 Max Location : X = 3.500, Y = -1.000, Z = 0.000 (cm) Value = 10.366 Measured Values (volts) = 9.622E-003 6.791E-003 4.696E-003 3.460E-003 2.531E-003 1.864E-003 1.412E-003 1.065E-003 7.954E-004 5.679E-004 4.352E-004 4.257E-004 2.747E-004 2.522E-004 1.745E-004 1.341E-004 1.052E-004 8.189E-005 9.767E-005 4.935E-005 4.804E-005 Calc. Voltage @ Surface (Vs) = 0.0138 Voltage @ 1.00 cm (Vt) = 0.0035 Ave. Voltage (Vs+Vt)/2 = 0.0086 Ave. SAR over 1 g (mW/g) = 0.9575 0 2 4 6 8 10 12 14 mVolts -1012345 Z centimeters SAR Scan File : 98121627_ZOOM Start : 16-Dec-98 08:07:23 am End : 16-Dec-98 08:20:32 am QUALCOMM/J9CQCP-1960/3104;1851.25MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/42.900/1.650 File : 98121627_ZOOM Start : 16-Dec-98 08:07:23 am End : 16-Dec-98 08:20:32 am QUALCOMM/J9CQCP-1960/3104;1851.25MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/42.900/1.650 10.37 9.74 9.12 8.50 7.88 7.26 6.64 6.02 5.40 4.77 File : 98121627_ZOOM Start : 16-Dec-98 08:07:23 am End : 16-Dec-98 08:20:32 am QUALCOMM/J9CQCP-1960/3104;1851.25MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/42.900/1.650 10.37 9.74 9.12 8.50 7.88 7.26 6.64 6.02 5.40 4.77 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/98121632_ZOOM.VLT Start : 16-Dec-98 09:41:11 am End : 16-Dec-98 09:49:44 am Radio Type : QUALCOMM Model Number : JPCQCP-1960 Serial Number : 3104 Frequency : 1851.25 MHz Peak Trans. Pwr : 0.160 W Start Trans. Pwr: 0.160 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 42.900 Mixture Conductivity = 1.650 Comment : QUALCOMM QCP PCS PHONE CHAN 0025 PCTEST Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.200 PCTEST Amplifier Channel Settings : 0.250 0.233 0.225 Max Location : X = 2.350, Y = 0.500, Z = 0.000 (cm) Value = 13.749 Measured Values (volts) = 1.275E-002 1.002E-002 7.485E-003 5.659E-003 4.302E-003 3.273E-003 2.581E-003 1.948E-003 1.535E-003 1.260E-003 1.017E-003 7.730E-004 6.255E-004 5.290E-004 4.287E-004 4.331E-004 4.234E-004 3.426E-004 2.704E-004 2.380E-004 2.181E-004 Calc. Voltage @ Surface (Vs) = 0.0166 Voltage @ 1.00 cm (Vt) = 0.0057 Ave. Voltage (Vs+Vt)/2 = 0.0111 Ave. SAR over 1 g (mW/g) = 1.2387 0 2 4 6 8 10 12 14 16 18 mVolts -1 0 1 2 3 4 5 Z centimeters SAR Scan File : 98121632_ZOOM Start : 16-Dec-98 09:41:11 am End : 16-Dec-98 09:49:44 am QUALCOMM/J9CQCP-1960/3104;1851.25MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/42.900/1.650 File : 98121632_ZOOM Start : 16-Dec-98 09:41:11 am End : 16-Dec-98 09:49:44 am QUALCOMM/J9CQCP-1960/3104;1851.25MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/42.900/1.650 13.75 13.08 12.41 11.75 11.08 10.41 9.75 9.08 8.41 7.75 File : 98121632_ZOOM Start : 16-Dec-98 09:41:11 am End : 16-Dec-98 09:49:44 am QUALCOMM/J9CQCP-1960/3104;1851.25MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/42.900/1.650 13.75 13.08 12.41 11.75 11.08 10.41 9.75 9.08 8.41 7.75

TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 619 546 3999 FAX 619 546 0364 Report No. S8568-03 Page 1 of 10 Rev.No 1.0 SPURIOUS RADIATED EMISSIONS DATA FOR QUALCOMM, INC. 10300 Campus Point Drive San Diego, CA 92121 Prepared by TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 619 546 3999 FAX 619 546 0364 Report No. S8568-03 Page 2 of 10 Rev.No 1.0 Measurement Requirements (Paragraph 2.993) The measurements which follow were performed by TÜV Product Service. To the best of my knowledge these tests were conducted in accordance with the procedures outlined in Part 2 of the Commission's Rules and Regulations. The data presented below demonstrates compliance with the appropriate technical standards. _____________________________ Floyd R. Fleury EMC Manager TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 619 546 3999 FAX 619 546 0364 Report No. S8568-03 Page 3 of 10 Rev.No 1.0 Emissions Test Conditions: SPURIOUS RADIATED EMISSIONS The Spurious Radiated Emissions measurements were performed using the following equipment: Test Equipment Used : Model No.Prop. No.DescriptionManufacturerSerial No.Cal Date n -8566B720Spectrum AnalyzerHewlett Packard2115A0084202/18/99 n -85662B721Spectrum Analyzer DisplayHewlett Packard2112A0218502/18/99 n -3115251Double Ridge Guide Antenna, 1-18 GHz EMCO249509/14/99 n -AA-190-06.00.0657High Frequency CableUnited Microwave Pro--N/A n -AA-190-30.00.0665High Frequency CableUnited Microwave Pro--N/A Remarks: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 619 546 3999 FAX 619 546 0364 Report No. S8568-03 Page 5 of 10 Rev.No 1.0 Photograph of Test Setup TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 619 546 3999 FAX 619 546 0364 Report No. S8568-03 Page 6 of 10 Rev.No 1.0 Photograph of Test Setup TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone 619 546 3999 FAX 619 546 0364 Report No. S8568-03 Page 7 of 10 Rev.No 1.0 Testing Facilities Certificates of Approval
