J9CQSIP7180P7c Modular Platform

All Qualcomm products mentioned herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. Other product and brand names may be trademarks or registered trademarks of their respective owners. This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion contrary to U.S. and international law is strictly prohibited. Qualcomm Technologies, Inc. 5775 Morehouse Drive San Diego, CA 92121 U.S.A. © 2020 Qualcomm Technologies, Inc. and/or its subsidiaries. All rights reserved. QSIP7180/QSIP7180P Module Integrator Instruction 80-11139-4 Rev. AD September 22, 2020 80-11139-4 Rev. AD MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 2 Revision history Revision Date Description AA July 2020 Initial release AB September 2020 Updated AC September 2020 Updated AD September 2020 Updated 80-11139-4 Rev. AD MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 3 Contents 1 Introduction ............................................................................................................................................... 6 2 Product Overview ...................................................................................................................................... 7 3 Available Global Modular Approvals from Qualcomm .............................................................................. 8 4 Integrated Product Test and Certification Requirements .......................................................................... 9 5 Additional Regulatory Conformance Testing and/or Submissions Required by the Integrator .............. 11 6 Compliant/Allowable Tx Power File ......................................................................................................... 12 7 Allowable Antennas to Use with the Radio Module ................................................................................ 13 7.1 Antenna Filing Process in Japan, Korea and Taiwan ................................................................... 15 7.1.1 Notification of all antenna models to be used with the Module .................................. 15 8 Antenna Placement Inside the Host System and RF Exposure ................................................................ 16 9 Simultaneous Transmission with Other Integrated or Plug-In Radios ..................................................... 17 10 Required Labeling on the Outside of the Host ....................................................................................... 18 10.1 FCC ............................................................................................................................................ 18 10.2 European Community Radio Equipment Directive (RED) ......................................................... 18 10.3 Taiwan NCC ............................................................................................................................... 19 10.3.1 For host system use QSIP7180P (WIFI SKU). The NCC requires a label on the outside of the host system visible to the end user. ...................................... 19 10.3.2 For host system use QSIP7180 (WWAN+WIFI SKU). The NCC requires host system to obtain a unique NCC certificate and approval number. QSIP7180 NCC certificate maybe leveraged during host system NCC certification process. ............................................................................. 19 10.4 Other countries ......................................................................................................................... 20 11 Required Labeling on the Module ......................................................................................................... 21 11.1 FCC labeling on the Module ..................................................................................................... 21 11.2 Rest of the world labeling on the Module ................................................................................ 21 12 Required Regulatory Wording for User Manual/Installation Manual ................................................... 22 12.1 FCC compliance information .................................................................................................... 22 12.2 European Community (RED) user manual wording and declaration ....................................... 23 QSIP7180/QSIP7180P Module Integrator Instruction Contents 80-11139-4 Rev. AD MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 4 12.3 European Community (RED) Declaration of Conformity for System ........................................ 24 12.4 Brazil user manual wording ...................................................................................................... 24 12.5 Taiwan user manual wording ................................................................................................... 25 12.6 Japan user manual wording ...................................................................................................... 26 12.7 India user manual wording ....................................................................................................... 26 80-11139-4 Rev. AD MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 5 Tables Table 4-1 47CFR Rules Parts Addressed in Modular Certification .............................................................. 10 Table 7-1 Allowed maximum gain (dBi), including antenna cable loss ....................................................... 13 80-11139-4 Rev. AD MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 6 1 Introduction This document provides information regulatory information and process required for a host product that integrates the QSIP7180 module. It addresses both using the QSIP7180 module in a host product and obtaining certifications/authorizations for the specific markets…

Text truncated - open the document above for the full version.

Thursday, July 11, 2019 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To Whom It May Concern: I, hereby, authorize Mr. John Forrester, to handle FCC Regulatory related applications for Qualcomm Technologies, Inc. and sign all required application documents. Best Regards, ____________________ Paul Guckian VP, Engineering Office: 858-651-1547 [email protected] 5775 Morehouse Drive, San Diego, CA 92121 Qualcomm Technologies, Inc. www.qualcomm.com

PHOTOGRAPHS OF EUT Report No.: EP042002-06 EUT: 7c Modular Platform (Brand Name: Qualcomm / Model Name: QSIP7180P) TEL : 886-3-327-3456 Page Number : 1 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 1.Photograph of the EUT PHOTOGRAPHS OF EUT Report No.: EP042002-06 EUT: 7c Modular Platform (Brand Name: Qualcomm / Model Name: QSIP7180P) TEL : 886-3-327-3456 Page Number : 2 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP042002-06 EUT: 7c Modular Platform (Brand Name: Qualcomm / Model Name: QSIP7180P) TEL : 886-3-327-3456 Page Number : 4 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP042002-06 Host: Fixture (Brand Name: Qualcomm / Model Name: 7c module platform carrier board) TEL : 886-3-327-3456 Page Number : 5 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 2. External Photograph of the Host 2. External Photographs of the Host PHOTOGRAPHS OF EUT Report No.: EP042002-06 Host: Fixture (Brand Name: Qualcomm / Model Name: 7c module platform carrier board) TEL : 886-3-327-3456 Page Number : 6 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP042002-06 Host: Fixture (Brand Name: Qualcomm / Model Name: 7c module platform carrier board) TEL : 886-3-327-3456 Page Number : 7 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 List of Accessory for Host (Fixture): Specification of Accessory WLAN Antenna 1 Brand Name WNC Model Name 81.EBJ15.005 WLAN Antenna 2 Brand Name WNC Model Name 81.EBJ15.005 Remark: For accessories equipped with this EUT, please refer to the following photos. 3. Photograph of Accessory for the Host PHOTOGRAPHS OF EUT Report No.: EP042002-06 Host: Fixture (Brand Name: Qualcomm / Model Name: 7c module platform carrier board) TEL : 886-3-327-3456 Page Number : 8 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP042002-06 Antenna (Brand Name: WNC / Model Name: 81.EBJ15.005) TEL : 886-3-327-3456 Page Number : 9 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 4. Antenna Photograph 2. External Photographs of the Host WLAN Antenna 1 PHOTOGRAPHS OF EUT Report No.: EP042002-06 Antenna (Brand Name: WNC / Model Name: 81.EBJ15.005) TEL : 886-3-327-3456 Page Number : 10 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP042002-06 Antenna (Brand Name: WNC / Model Name: 81.EBJ15.005) TEL : 886-3-327-3456 Page Number : 11 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 WLAN Antenna 2 PHOTOGRAPHS OF EUT Report No.: EP042002-06 Antenna (Brand Name: WNC / Model Name: 81.EBJ15.005) TEL : 886-3-327-3456 Page Number : 12 of 12 FAX : 886-3-328-4978 Issued Date : Oct. 23, 2020 Report Version : 02 ─────THE END────

All Qualcomm products mentioned herein are products of Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. Other product and brand names may be trademarks or registered trademarks of their respective owners. This technical data may be subject to U.S. and international export, re-export, or transfer (“export”) laws. Diversion contrary to U.S. and international law is strictly prohibited. Qualcomm Technologies, Inc. 5775 Morehouse Drive San Diego, CA 92121 U.S.A. © 2020 Qualcomm Technologies, Inc. and/or its subsidiaries. All rights reserved. QSIP7180P - Label Document 80-11139-42 Rev. AA September 24, 2020 FCC Use Only 80-11139-42 Rev. AA MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 2 Revision history Revision Date Description AA September 2020 Initial release FCC Use Only QSIP7180 - Label Document 80-11139-42 Rev. AA MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 3 Contents 1 QSIP7180P Label ........................................................................................................................................ 4 2 Label Placement ......................................................................................................................................... 5 FCC Use Only QSIP7180 - Label Document 80-11139-42 Rev. AA MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 4 1 QSIP7180P Label The Label shall be permanently fixed at a prominent position on the host device. □ Regulatory Model: QSIP7180P □ FCC ID:J9CQSIP7180P FCC Use Only QSIP7180 - Label Document 80-11139-42 Rev. AA MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION 5 2 Label Placement FCC Use Only

PHOTOGRAPHS OF EUT Report No.: EP042002-06 Brand Name: Qualcomm/ Model Name: QSIP7180P TEL : 886-3-327-3456 Page Number : 6 of 6 FAX : 886-3-328-4978 Issued Date : Oct. 07, 2020 Report Version : 01 ─────THE END────

TEL : 886-3-327-3456 Page : 1 of 6 FAX : 886-3-328-4978 Issued Date : Sep. 23, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA042002-06 RF EXPOSURE EVALUATION REPORT FCC ID : J9CQSIP7180P Equipment : 7c Modular Platform Brand Name : Qualcomm Model Name : QSIP7180P Applicant : Qualcomm Technologies, Inc. 5775 Morehouse Dr.San Diego, CA 92121-1714 (USA) Manufacturer : Qualcomm Technologies, Inc. 5775 Morehouse Dr.San Diego, CA 92121-1714 (USA) Standard : 47 CFR Part 2.1091 We, SPORTON INTERNATIONAL INC has been evaluated this product in accordance with 47 CFR Part 2.1091 and it complies with applicable limit. The results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, the test report shall not be reproduced except in full. Sporton Lab is accredited to ISO 17025 by Taiwan Accreditation Foundation (TAF code: 1190) and the FCC designation No. TW1190 under the FCC 2.948(e) by Mutual Recognition Agreement (MRA) in FCC evaluation. SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) Approved by: Cona Huang / Deputy Manager TEL : 886-3-327-3456 Page : 2 of 6 FAX : 886-3-328-4978 Issued Date : Sep. 23, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA042002-06 Table of Contents 1. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) .............................................................................. 4 2. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 4 3. RF EXPOSURE LIMIT INTRODUCTION ..................................................................................................... 5 4. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 6 4.1. Standalone Power Density Calculation .............................................................................................. 6 4.2. Collocated Power Density Calculation ............................................................................................... 6 TEL : 886-3-327-3456 Page : 3 of 6 FAX : 886-3-328-4978 Issued Date : Sep. 23, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA042002-06 History of this test report Report No. Version Description Issued Date FA042002-06 Rev. 01 Initial issue of report Sep. 23, 2020 TEL : 886-3-327-3456 Page : 4 of 6 FAX : 886-3-328-4978 Issued Date : Sep. 23, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA042002-06 1. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type 7c Modular Platform Brand Name Qualcomm Model Name QSIP7180P FCC ID J9CQSIP7180P Wireless Technology and Frequency Range WLAN 2.4GHz Band: 2400 MHz ~ 2483.5 MHz WLAN 5.2GHz Band: 5150 MHz ~ 5250 MHz WLAN 5.3GHz Band: 5250 MHz ~ 5350 MHz WLAN 5.6GHz Band: 5470 MHz ~ 5725 MHz WLAN 5.8GHz Band: 5725 MHz ~ 5825 MHz Bluetooth: 2400 MHz ~ 2483.5 MHz Mode WLAN: 802.11a/b/g/n/ac HT20/HT40/VHT20/VHT40/VHT80 Bluetooth BR/EDR/LE EUT Stage Identical Prototype Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Reviewed by: Jason Wang Report Producer: Wan Liu 2. Maximum RF average output power among production units Mode Maximum Average power(dBm) 2.4GHz WLAN 2Tx Total Power 22.50 5GHz WLAN 2Tx Total Power 22.50 Bluetooth 12.00 TEL : 886-3-327-3456 Page : 5 of 6 FAX : 886-3-328-4978 Issued Date : Sep. 23, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA042002-06 3. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: 퐒= 퐏퐆 ퟒ훑퐑 ퟐ Where: S = Power Density P = Output Power at Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Distance from Transmitting Antenna TEL : 886-3-327-3456 Page : 6 of 6 FAX : 886-3-328-4978 Issued Date : Sep. 23, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA042002-06 4. Radio Frequency Radiation Exposure Evaluation 4.1. Standalone Power Density Calculation Band Antenna Gain (dBi) Maximum Power (dBm) Maximum EIRP (dBm) Maximum EIRP (W) Average EIRP (mW) Power Density at 20cm (mW/cm^2) Limit (mW/cm^2) Power Density / Limit WLAN 2.4GHz MIMO 10.0 22.5 32.5 1.78 1778.28 0.354 1.000 0.354 WLAN 5GHz MIMO 7.5 22.5 30.0 1.00 1000.00 0.199 1.000 0.199 Bluetooth 10.0 12.0 22.0 0.16 158.49 0.032 1.000 0.032 4.2. Collocated Power Density Calculation 5GHz WLAN Power Density / Limit Bluetooth Power Density / Limit Σ(Power Density / Limit) of 5GHz WLAN+Bluetooth 0.199 0.032 0.231 Note: 1. Σ(Power Density / Limit): This is a summation of [(power density for each transmitter/antenna included in the simultaneous transmission)/ (corresponding MPE limit)], for 5GHz WLAN + Bluetooth. 2. Considering the 5GHz WLAN collocation with the Bluetooth transmitter of the EIRP performance listed in the table above, the aggregated (power density /limit) is smaller than 1, and MPE of 2 collocated transmitters is compliant Conclusion: Based on FCC OET Bulletin 65 Supplement C and 47 CFR §2.1091, the analysis concludes that this product when transmitting in standalone within a host device, is compliant with the FCC RF exposure requirements in mobile exposure condition, provided the conducted power and antenna gain do not exceed the limits for each given frequency band per wireless technology as follow table: Device Technology Frequency (MHz) Maximum Conducted Power (dBm) Stanalone Maximum Antenna Gain (dBi) Collocated Maximum Antenna Gain (dBi) QSIP7180P 2.4GHz WLAN 2400~2483.5 2…

Text truncated - open the document above for the full version.

TEL : 886-3-327-3456 Page Number : 1 of 42 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06B FCC RADIO TEST REPORT FCC ID : J9CQSIP7180P Equipment : 7c Modular Platform Brand Name : Qualcomm Model Name : QSIP7180P Applicant : Qualcomm Technologies, Inc. 5775 Morehouse Dr.San Diego, CA 92121-1714 (USA) Manufacturer : Qualcomm Technologies, Inc. 5775 Morehouse Dr.San Diego, CA 92121-1714 (USA) Standard : FCC Part 15 Subpart C §15.247 The product was received on Jun. 08, 2020 and testing was started from Jun. 11, 2020 and completed on Jul. 31, 2020. We, SPORTON INTERNATIONAL INC., EMC & Wireless Communications Laboratory, would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, the test report shall not be reproduced except in full. Approved by: Louis Wu SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) TEL : 886-3-327-3456 Page Number : 2 of 42 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06B Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ................................................................................................................................... 5 1.1 Product Feature of Equipment Under Test ........................................................................................ 5 1.2 Modification of EUT ........................................................................................................................... 5 1.3 Testing Location ................................................................................................................................ 6 1.4 Applicable Standards ......................................................................................................................... 6 2 Test Configuration of Equipment Under Test ......................................................................................... 7 2.1 Carrier Frequency Channel ............................................................................................................... 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 9 2.4 Support Unit used in test configuration and system .......................................................................... 9 2.5 EUT Operation Test Setup .............................................................................................................. 10 2.6 Measurement Results Explanation Example ................................................................................... 10 3 Test Result ................................................................................................................................................ 11 3.1 6dB and 99% Bandwidth Measurement .......................................................................................... 11 3.2 Output Power Measurement ............................................................................................................ 18 3.3 Power Spectral Density Measurement ............................................................................................ 19 3.4 Conducted Band Edges and Spurious Emission Measurement ..................................................... 26 3.5 Radiated Band Edges and Spurious Emission Measurement ........................................................ 35 3.6 Antenna Requirements .................................................................................................................... 39 4 List of Measuring Equipment ................................................................................................................. 40 5 Uncertainty of Evaluation........................................................................................................................ 42 Appendix A. Conducted Test Results Appendix B. Radiated Spurious Emission Appendix C. Radiated Spurious Emission Plots Appendix D. Duty Cycle Plots Appendix E Setup Photographs TEL : 886-3-327-3456 Page Number : 3 of 42 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06B History of this test report Report No. Version Description Issued Date FR042002-06B 01 Initial issue of report Sep. 17, 2020 TEL : 886-3-327-3456 Page Number : 4 of 42 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CBT4.0 Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06B Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 3.1 15.247(a)(2) 6dB Bandwidth Pass - 3.1 2.1049 99% Occupied Bandwidth Reporting only - 3.2 15.247(b)(3) Output Power Pass - 3.3 15.247(e) Power Spectral Density Pass - 3.4 15.247(d) Conducted Band Edges and Spurious Emission Pass - 3.5 15.247(d) Radiated Band Edges and Spurious Emission Pass Under limit 5.73 dB at 2312.660 MHz - 15.207 AC Conducted Emission Not Required - …

Text truncated - open the document above for the full version.

TEL : 886-3-327-3456 Page Number : 1 of 62 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CWL AC MA Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06C FCC RADIO TEST REPORT FCC ID : J9CQSIP7180P Equipment : 7c Modular Platform Brand Name : Qualcomm Model Name : QSIP7180P Applicant : Qualcomm Technologies, Inc 5775 Morehouse Dr.San Diego, CA 92121-1714 (USA) Manufacturer : Qualcomm Technologies, Inc 5775 Morehouse Dr.San Diego, CA 92121-1714 (USA) Standard : FCC Part 15 Subpart C §15.247 The product was received on Jun. 08, 2020 and testing was started from Jun. 11, 2020 and completed on Jul. 31, 2020. We, SPORTON INTERNATIONAL INC., EMC & Wireless Communications Laboratory, would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, the test report shall not be reproduced except in full. Approved by: Louis Wu SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) TEL : 886-3-327-3456 Page Number : 2 of 62 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CWL AC MA Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06C Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description .................................................................................................................................... 5 1.1 Product Feature of Equipment Under Test ........................................................................................ 5 1.2 Modification of EUT ........................................................................................................................... 5 1.3 Testing Location ................................................................................................................................ 6 1.4 Applicable Standards ......................................................................................................................... 6 2 Test Configuration of Equipment Under Test .......................................................................................... 7 2.1 Carrier Frequency and Channel ........................................................................................................ 7 2.2 Test Mode .......................................................................................................................................... 7 2.3 Connection Diagram of Test System ................................................................................................. 8 2.4 Support Unit used in test configuration and system .......................................................................... 8 2.5 EUT Operation Test Setup ................................................................................................................ 9 2.6 Measurement Results Explanation Example ..................................................................................... 9 3 Test Result ................................................................................................................................................. 10 3.1 6dB and 99% Bandwidth Measurement .......................................................................................... 10 3.2 Output Power Measurement ............................................................................................................ 12 3.3 Power Spectral Density Measurement ............................................................................................ 13 3.4 Conducted Band Edges and Spurious Emission Measurement ..................................................... 15 3.5 Radiated Band Edges and Spurious Emission Measurement ........................................................ 56 3.6 Antenna Requirements .................................................................................................................... 60 4 List of Measuring Equipment ................................................................................................................... 61 5 Uncertainty of Evaluation ......................................................................................................................... 62 Appendix A. Conducted Test Results Appendix B. Radiated Spurious Emission Appendix C. Radiated Spurious Emission Plots Appendix D. Duty Cycle Plots Appendix E. Setup Photographs TEL : 886-3-327-3456 Page Number : 3 of 62 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CWL AC MA Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06C History of this test report Report No. Version Description Issued Date FR042002-06C 01 Initial issue of report Sep. 17, 2020 TEL : 886-3-327-3456 Page Number : 4 of 62 FAX : 886-3-328-4978 Issued Date : Sep. 17, 2020 Report Template No.: BU5-FR15CWL AC MA Version 2.4 Report Version : 01 FCC RADIO TEST REPORT Report No. : FR042002-06C Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 3.1 15.247(a)(2) 6dB Bandwidth Pass - 3.1 2.1049 99% Occupied Bandwidth Reporting only - 3.2 15.247(b) Power Output Measurement Pass - 3.3 15.247(e) Power Spectral Density Pass - 3.4 15.247(d) Conducted Band Edges Pass - Conducted Spurious Emission Pass - 3.5 15.247(d) Radiated Band Edges and Radiated Spurious Emission Pass Under limit 1.06 dB at 2483.520 MH…

Text truncated - open the document above for the full version.

TEL : 886-3-327-3456 Page Number : C1 of C98 FAX : 886-3-328-4978 FCC RADIO TEST REPORT Report No. : FR042002-06C Appendix C. Radiated Spurious Emission Plots Test Engineer : Leo Lee, Mancy Chou, and Bigshow Wang Temperature : 21.4~22.9°C Relative Humidity : 52~61% Note symbol -L Low channel location -R High channel location TEL : 886-3-327-3456 Page Number : C2 of C98 FAX : 886-3-328-4978 FCC RADIO TEST REPORT Report No. : FR042002-06C 2.4GHz 2400~2483.5MHz WIFI 802.11b (Band Edge @ 3m) WIFI 2.4GHz 2400~2483.5MHz Band Edge @ 3m ANT 802.11b CH01 24…

Text truncated - open the document above for the full version.
