J9CWMD1XTracking Module

WMD Development Kit User Guide 80-XXXXX-1 Re v. A Mark Carter October 2009 3/23/20101QUALCOMM CONFIDENTIAL AND PROPRIETARY #Section Page 1Introduction3 2 Getting Started4 3CableConnections6 4PowerSupply Connection8 5Module Powering Up / Down10 6Telephone & Data Call Testing11 7Standards 12 8Regulatory Compliance13 Front Back Table of Contents 3/23/20102QUALCOMM CONFIDENTIAL AND PROPRIETARY Introduction •The WMD development kit enables telephone & Data functionality with the entire family of WMD modules. •The Kit includes: –WMD Module –Test Nest fixture –RF Antenna –Battery Pack –QCT Software –Handset –External Power Cable – Micro USB cable 3/23/20103QUALCOMM CONFIDENTIAL AND PROPRIETARY Getting Started •Apply Thermal Grease to pad 3/23/20104QUALCOMM CONFIDENTIAL AND PROPRIETARY Thermal Grease Insert Module •Insert the WMD module into the Test Nest fixture using the 90 pin connector with the JTAG connector still attached. 3/23/20105QUALCOMM CONFIDENTIAL AND PROPRIETARY WMD Module Cable Connections •Connect the internal RF cable 3/23/20106QUALCOMM CONFIDENTIAL AND PROPRIETARY RF Cable Handset Jack Micro USB Te s t Jumpers RUIM / SIM Slot 1.3M Pixel Camera (1x) Headset Jack Speaker Cable Connections •Connect the external antenna •Connect the handset •For UMTS connect 3M Pixel camera 3/23/20107QUALCOMM CONFIDENTIAL AND PROPRIETARY Handset Plug In 3M Pixel Camera (UMTS & EVDO) RF Antenna & GPS/Modem (1X) GPS (UMTS) Bluetooth Power Supply Connections •Connect the power supply cable & or plug in battery connector •Set power supply voltage to 3.7 volts – no battery •Battery will charge if power supply is set to 5 volts 3/23/20108QUALCOMM CONFIDENTIAL AND PROPRIETARY Micro USB PWR Cable Battery Connector Power Supply Connections -Alt •Alternate power connection to replace battery •Set power supply voltage to 3.7 volts 3/23/20109QUALCOMM CONFIDENTIAL AND PROPRIETARY Micro USB Power/Data Cable Alt Power Connector Alt Power Cable Module Power Up •Now power up the module by pressing the pwrbutton on the keypad •LCD and backlight turn on 3/23/201010QUALCOMM CONFIDENTIAL AND PROPRIETARY PWR button Telephone & Data Call Testing •Now the Module is ready for basic telephone & Data call functionality •Use keypad or USB/RF interfaces to initiate and end voice or data calls 3/23/201011QUALCOMM CONFIDENTIAL AND PROPRIETARY Standards The WMD module conforms to the following standards requirements: •CDMA –TIA/EIA IS-98E (CDMA2000 1x) •FCC –47 CFR Part 1 – RF radiation exposure limits –47 CFR Part 2 – Equipment authorization –47 CFR Part 15 – Intentional and unintentional radiators –47 CFR Part 22 – Cellular – 47 CFR Part 24 - PCS •Open Device Initiative Certification w/ VZW 3/23/201012QUALCOMM CONFIDENTIAL AND PROPRIETARY Regulatory Compliance Safety Warnings Do not operate the WMD module in the following environments: •In active blasting areas. •In potentially explosive environments such as refueling points, fuel depots or chemical plants. •Near medical equipment, especially life support equipment that might be susceptible to radio interference. •In an aircraft. –The WMD module transmissions could interfere with aircraft electrical and communication systems. Like cell phones, using the WMD module in an aircraft is illegal in some jurisdictions. – If cell phone usage is permitted while the aircraft is on the ground, normal WMD module operation is permitted as well. 3/23/2010QUALCOMM CONFIDENTIAL AND PROPRIETARY13 Regulatory Compliance The WMD module has been approved for mobile applications in the United States. Additional FCC certification is not required by host devices as long as the following conditions are met: •Maintain at least 20 cm separation between the antennas and the user’s body. •Maximum antenna gain (including cable loss): –Cellular band < 7 dBi –PCS band < 4 dBi •Independent WMD module operation. The WMD module must not be co-located or jointly operated with any other transmitter or antenna within the host device. •A label with the following (or similar) statement must be attached to the host end product: This device contains TxFCC ID:J9CWMD1X. •Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, 3/23/2010QUALCOMM CONFIDENTIAL AND PROPRIETARY14 Regulatory Compliance which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician to help. •Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the WMD module. 3/23/2010QUALCOMM CONFIDENTIAL AND PROPRIETARY15

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: J9CWMD1X To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Parts List Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request for 180 days on the following attachments: External Photos Internal Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during the certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Paul Guckian VP of Engineering Qualcomm Incorporated 3/23/2010

Date: June 23, 2008 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Paul Guckian VP, EMC/Regulatory Engineering QUALCOMM Incorporated

Applicant/Grantee Qualcomm INC. FCC ID: J9CWMD1X Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The final device is designed for mobile or fixed operation (Portable is not permitted – Reference TCB Exclusion List (17 July 2002) II (g)). Mobile or fixed location only. MPE report included. yes 2 The maximum antenna gain to allow compliance with RF exposure requirements is listed on the Grant of Certification for the module. Maximum antenna gain allowed is in the MPE report and will be listed on the grant. yes 3 The licensed module must have a FCC ID label on the module itself. That FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text: Contains “FCC ID: XXXYYYY” See Exhibit 8. yes 4 The Grant should include the following words in the device description or grant notes:“modular transmitter” or “transmitter module”. Listed on grant. yes

Exhibit 9 WMD 1x External Photographs FCC Part 22 & 24 Certification FCC ID: J9CWMD1X Model: WMD 1x STATEMENT OF CERTIFICATION The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the measurements of the sample’s radio frequency interference emissions characteristics as of the dates and at the times of the test under the conditions herein specified. Report Prepared by: QUALCOMM Incorporated 5775 Morehouse Drive San Diego, CA 92121-1714

Exhibit 8 WMD1x FCC Label and Location FCC Part 22 & 24 Certification FCC ID: J9CWMD1X Model: WMD1x STATEMENT OF CERTIFICATION The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the measurements of the sample’s radio frequency interference emissions characteristics as of the dates and at the times of the test under the conditions herein specified. Report Prepared by: QUALCOMM Incorporated 5775 Morehouse Drive San Diego, CA 92121-1714 INCHES ONLY QUALCOMM CONFIDENTIAL AND PROPRIETARY C.M. Q.A. MFG P.E. ENG CHK DRW DATE CONTRACT NO. 5775 MOREHOUSE DRIVE SAN DIEGO, CA 92121-1714, U.S.A AA BB CC DD 8 8 7 7654 43 3 21 1 0.34 - 6.35 6.37 - 12.70 12.72 - 25.40 INCHESMM INCHES UNLESS OTHERWISE SPECIFIED DIMENSION UNITS ARE AS NOTED/PER NOTE 2 AND APPLY AFTER SURFACE TREATMENT TOLERANCES LINEARANGULAR EXCL OF SHEET METAL FLANGES 0° 30 HOLE DIAMETERS .013 - .250 .251 - .500 .501 - 1.000 THIRD ANGLE PROJECTION +0.13 -0.03 +0.15 -0.03 +0.25 -0.03 +.005 -.001 +.006 -.001 +.010 -.001 X ±2.5 .XXX.010 ± .03.XX± .X±.1 ± X.X±0.76 X.XX ±0.25 NONE DWG NO.SHREV SIZECAGE CODEDRAWING NOREV TITLE MM R 65 VER COPYRIGHT (C) 2010 QUALCOMM INCORPORATED. ALL RIGHTS RESERVED. NOT TO BE USED, COPIED, REPRODUCED IN WHOLE OR IN PART, NOR ITS CONTENTS REVEALED IN ANY MANNER TO OTHERS WITHOUT THE EXPRESS WRITTEN PERMISSION OF QUALCOMM. THIS TECHNICAL DATA MAY BE SUBJECT TO U.S. AND INTERNATIONAL EXPORT, RE-EXPORT OR TRANSFER ("EXPORT") LAWS. DIVERSION CONTRARY TO U.S. AND INTERNATIONAL LAW IS STRICTLY PROHIBITED. QUALCOMM IS A REGISTERED TRADEMARK OF QUALCOMM INCORPORATED IN THE UNITED STATES AND MAY BE REGISTERED IN OTHER COUNTRIES. OTHER PRODUCT AND BRAND NAMES MAY BE TRADEMARKS OR REGISTERED TRADEMARKS OF THEIR RESPECTIVE OWNERS. .75 ().50 1 LABEL, WMD ID D1DN14CA90-H6187A SCALE 1/1 SHEET 1 OF 1 CA90-H61871A REVISIONS REVDESCRIPTIONDATEAPPROVED A INITIAL RELEASE ---------- T.DAWSON 11/20/09 REQD SIG ON FILE 4+ MODEL INFORMATION CAD TOOL: PRO/ENGINEER NAMEREVISIONVERSION CA90-H6187-1A4 SEE SEPARATE PARTS LIST CA90-H6187-XX 14 SEE TABLE FOR CONTENT. 13 BAG AND TAG AS CA90-H6187 AND APPROPRIATE DASH NO. AND REV LETTER OF DWG/PL. MARKING SHALL HAVE .060 TO .160 INCH HIGH CHARACTERS. SEE DETAIL A FOR MARKING CONTENT. a. PART NUMBER b. APPROPRIATE DASH NUMBER c. DRAWING REVISION LEVEL d. PARTS LIST REVISION LEVEL PER APPROPRIATE REQUIRED DOCUMENT LIST (RDL) 12. LABEL HAS 0.03 DEAD ZONE ALL AROUND EDGE. SPACING BETWEEN LINES 0.015. 11. BARCODES REQUIRE AN ADDITIONAL 0.04 QUIET ZONE AT BEGINNING AND END. 10 CUT LABEL TO .75. 9 BAR CODE 39, NBW=.0033", NARROW T0 WIDE RATIO:3:1, HEIGHT =.08" 8 FONT: 6 POINT, UPPER CASE CHARACTERS, LEFT JUSTIFIED. 7 FONT: 6 POINT, UPPER CASE CHARACTERS, CENTER JUSTIFIED. 6. PRINTING INK: COLOR BLACK, PERMANENT AND RESISTANT TO SMEARING. 5. DIMENSIONS SHOWN ARE FOR REFERENCE ONLY AND ARE NOT FOR INSPECTION OR QUALITY PURPOSES. 4. WORKMANSHIP SHALL BE IN ACCORDANCE WITH QUALCOMM MECHANICAL WORKMANSHIP STANDARD 80-10767-1. 3. INTERPRET DIMENSIONS AND TOLERANCES PER ASME Y14.5M-1994. 2. ALL DIMENSIONS SHOWN ON THIS DRAWING ARE IN INCHES. 1. INTERPRET DRAWING PER ASME Y14.100. NOTES: UNLESS OTHERWISE SPECIFIED. #DESCRIPTIONID TEXTMCN AND REVISIONLINE 5LINE 6 -11X J9CWMD1X 20-H6012-1ESN: 74 XXX XXXESN BARCODE -2UMTSJ9CWMDUMTS20-H6273-HXIMEI: XXXXXXXXXXXXXXIMEI BARCODE -3EVDOJ9CWMDEVDO20-H6272-PXIMEI: X XIMEI BARCODE -XX ALTERED ITEM DRAWING CA90-H6187-1 13a 13b A / REV 13d 13c DETAIL A MARKING CONTENT 10 7 9142X 8143X

Exhibit 10 WMD 1x Internal Photographs FCC Part 22 & 24 Certification FCC ID: J9CWMD1X Model: WMD 1x STATEMENT OF CERTIFICATION The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the measurements of the sample’s radio frequency interference emissions characteristics as of the dates and at the times of the test under the conditions herein specified. Report Prepared by: QUALCOMM Incorporated 5775 Morehouse Drive San Diego, CA 92121-1714

global solutions : local support ª Heptaband external wireless antenna offers ultimate bandwidth with over seven frequency ranges Laird Technologies Heptaband portable wireless antennas provide excellent radio transmission characteristics while offering the ultra flexibility of seven bands in one profile. With operating frequencies of 824 - 894 MHz, 880 - 960 MHz, 1575 MHz, 1710 - 1880MHz, 1850 - 1990 MHz, 1920 - 2170 MHz, 2400 - 2500 MHz, the antenna is the ideal choice when multiple band widths are required in various regional and global applications. Additionally, the blade style antenna features both knuckle and swivel snap-in or SMA/TNC/RPTNC connector options. Features and Benefits: Operates simultaneously in more than seven frequency bands • supporting - Cellular, Quadband GSM+UMTS/3G, GPS, AWS, WIFI, WLAN and WISP Available in knuckle swivel snap or SMA/TNC/RPTNC • connector options. Blade style external antenna measures only 7.33”• Applications Wireless Terminal, Point-of-Sale, Machine to Machine, • Automatic Meter Reading and Home Security Heptaband ™ Exterior Wireless Antennas www.lairdtech.com For sales information: In the USA please telephone +1-800-323-3757 In Asia please telephone +886-2-2286-2828 In Europe please telephone +46-8-555-722-00 Heptaband ™ Exterior Wireless Antennas global solutions : local support ª IAS-SPEC-HEPTABAND-03/08 Any information furnished by Laird Technologies and its agents is believed to be accurate and reliable. Responsibility for the use and application of Laird Technologies materials rests with the end user since Laird Technologies and its agents cannot be aware of all potential uses. Laird Technologies makes no warranties as to the fitness, merchantability, or suitability of any Laird Technologies materials or products for any specific or general uses. Laird Technologies shall not be liable for incidental or consequential damages of any kind. All Laird Technologies products are sold pursuant to the Laird Technologies domestic terms and conditions of sale in effect from time to time, a copy of which will be furnished upon request. SpEcIFIcAtIonS: Electrical Frequency Range: 824-894 MHz, 880-960 MHz, 1575 MHz, 1710-1880 MHz, 1850-1990 MHz, 1920-2170 MHz, 2400-2500 MHz Gain 1 - 3 dBi VSWR <2.5:1 polarization Linear Azimuth (3dB beamwidth) Omnidirectional Impedance 50 Ω power 10 W Mounting Style Snap-in/Captive, SMA, RPSMA, TNC, RPTNC Dimensions (mm) 6.3" x .36" (161 x 9.3) typical Azimuth pattern Model number part number Mounting Style color HEptA-SM MAF94300 SMA Black HEptA-RSM MAF94301 RP-SMA Black HEptA-tn-G MAF94302 TNC Gray HEptA-Rtn MAF94303 RP-TNC Black HEptA-Ip04 MAF94304 SNAPIN/CAPTIVE, 100mm of RG178 coax Black with I-PEX connector HEptA-MMcX04 MAF94305 SNAPIN/CAPTIVE, 100mm of RG178 coax Black MMCX connector HEptA-FL04 MAF94306 SNAPIN/CAPTIVE, 100mm of RG178 coax Black flying lead HEptA-tn MAF94307 TNC Black HEptA90-tn MAF94309 TNC, Blade Angle - 90 degree Black typical Elevation pattern

FCC ID: J9CWMD1X QUALCOMM 1 WMD 1x FCC Documentation FCC Part 22 & 24 Certification FCC ID: J9CWMD1X Model: WMD1x STATEMENT OF CERTIFICATION The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the measurements of the sample’s radio frequency interference emissions characteristics as of the dates and at the times of the test under the conditions herein specified. Report Prepared by: QUALCOMM Incorporated 5775 Morehouse Drive San Diego, CA 92121-1714 Tests that required an OATS site were performed by Nemko USA, Inc. FCC ID: J9CWMD1X / QUALCOMM 2 Table of Contents 1 INTRODUCTION .................................................................................................................................................. 3 2 OPERATIONAL DESCRIPTION ....................................................................................................................... 3 2.1 DEVICE DESCRIPTION ..................................................................................................................................... 3 2.2 TECHNOLOGIES SUPPORTED ............................................................................................................................ 4 2.3 MODULE/HOST ELECTRICAL INTERFACES ....................................................................................................... 4 3 DEVICE EQUIPMENT CATEGORY DECLARATIONS ................................................................................ 4 3.1 CDMA THROUGHPUT ..................................................................................................................................... 4 4 FCC CFR 47 §2.1033 REQUIREMENT DOCUMENTATION ......................................................................... 4 4.1 §2.1033 (C) (1) MANUFACTURE INFORMATION ................................................................................................ 4 4.2 §2.1033 (C) (2) FCC IDENTIFIER ..................................................................................................................... 5 4.3 §2.1033 (C) (3) USER MANUAL ....................................................................................................................... 5 4.4 §2.1033 (C) (4) EMISSIONS DESIGNATORS ....................................................................................................... 5 4.5 §2.1033 (C) (5) FREQUENCY RANGE. ............................................................................................................... 5 4.6 §2.1033 (C) (6) RANGE OF TRANSMIT POWER ................................................................................................. 5 4.7 §2.1033 (C) (7) MAXIMUM TRANSMIT POWER ................................................................................................. 6 4.8 §2.1033 (C) (8) DC VOLTAGES ....................................................................................................................... 6 4.9 §2.1033 (C) (9) TUNE-UP PROCEDURE ............................................................................................................. 6 4.10 §2.1033 (C) (10) SCHEMATIC .......................................................................................................................... 6 4.11 §2.1033 (C) (11) FCC IDENTIFIER DRAWING. .................................................................................................. 7 4.12 §2.1033 (C) (12) PHOTOGRAPHS...................................................................................................................... 7 4.13 §2.1033 (C) (13) MODULATION DESCRIPTION ................................................................................................. 7 4.13.1 CDMA2000 (1x) ....................................................................................................................................... 7 FCC ID: J9CWMD1X Introduction QUALCOMM 3 1 Introduction The Qualcomm Wearable Mobile Device (WMD) module is a very small Wireless Wide Area Network (WWAN) module that incorporates gpsOne technology. It is fully compatible with the CDMA2000 standard. The module design is optimized for minimal cost, minimum size, maximum battery life and positioning location performance. The module will have the following features:  CDMA2000 1x at 850 MHz and 1900 MHz  GPS at 1575 MHz  USB 2.0 high-speed interface 2 Operational Description 2.1 Device Description The Wearable Mobile Device (WMD) 1x is an ultra small, 21 x 22 x 4.5 mm WWAN module that can be integrated into a multitude of host devices. The WMD 1x module operates on the 800/1900 MHz CDMA2000 1x networks. The module uses Qualcomm’s QSC 6055 chip set and has stand alone GPS, AGPS and gpsOneXTRA-tm. Interfaces for the module include USB 2.0, I2C, RUIM support, LCD, camera, keypad, 2 LED control lines, vibrator control, audio and primary RF coax. HTT is designed to be placed in a user’s bag or attached to a belt or other article of clothing. The WMD design is optimized for minimal cost, minimal size, maximum battery life and superb position location performance. The WMD 1x device meets the following standards: IS-2000 for CDMA 1xRTT, IS-707-A Data, IS-637-B SMS, IS- 683-A Service provisioning, gpsOne and IS-98 CDMA Minimum Performance. Only 850 MHz (Cellular) and 1900 MHz (PCS) bands are used for operation. The DUT is a pre-production sample. The main on-board Qualcomm chipsets include:  Single chip solution (Baseband + RF + Power Management): QSC6055™ Key connectivity support includes: FCC ID: J9CWMD1X Device Equipment Category Declarations QUALCOMM 4  Generic 80-pin connector providing USB 2.0 high-speed, power, GPIOs and serial interfaces, audio and battery connection.  Antenna connector 2.2 Technologies Supported Table 2-1 describes the technology and bands supported. Section 3 contains additional information on device capabilities and equipment categories . Table 2-1 Technology and Bands Supported Mode Ba…

Text truncated - open the document above for the full version.

FCC ID: J9CWMD1X MPE Analysis QUALCOMM Proprietary 1 WMD 1x MPE Evaluation Report FCC Part 22 & 24 Certification FCC ID: J9CWMD1X Model: WMD 1x STATEMENT OF CERTIFICATION The data, data evaluation and equipment configuration represented herein are a true and accurate representation of the measurements of the sample’s radio frequency interference emissions characteristics as of the dates and at the times of the test under the conditions herein specified. Report Prepared by: QUALCOMM Incorporated 5775 Morehouse Drive San Diego, CA 92121-1714 FCC ID: J9CWMD1X MPE Analysis QUALCOMM Proprietary 2 In this application we seek modular approval for the WMD 1x module to be used in a mobile configuration. Based on the FCC CFR 47 §1.1310, 2.1091, we have concluded that the WMD 1x module will comply with the FCC rules on RF exposure for mobile devices if the antenna again does not exceed 7 dBi in cellular and 4 dBi in PCS. The following analysis will demonstrate such compliance. The analysis will be done in both cellular and PCS bands which operates in North American. RF Exposure Limit According to FCC CFR 47 §1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Friis Transmission Formula Friis transmission formula: P d = (P out * G) / (4πR 2 ) Where, P d = power density (mW/cm 2 ) P out = output power to antenna (mW) G = gain of antenna in linear scale R = distance between observation point and center of the radiator (cm) FCC ID: J9CWMD1X MPE Analysis QUALCOMM Proprietary 3 WMD 1x Operating in Cellular Band (824 - 849 MHz) The highest peak conducted output power of WMD 1x module measured in cellular band is 24.6 dBm while the module operates in CDMA channel 384. Take the worst case as an example, in which an antenna with 7dBi gain is used. The resulted power density at a distance of 20cm can be calculated as follows: EIRP = 24.6 + 7 = 31.6 dBm = 1445.4 mW Power Density = (EIRP * DutyCycle) / (4πR 2 ) = 1445.4 * 1 / (4*π* 20 2 ) = 0.288 mW/cm 2 Where DutyCycle is 1 for CDMA (the worst case) and R is 20cm. The MPE limit for General Population/Uncontrolled Exposure is shown in the table above and can be derived as follows: MPE limit = 824/1500 = 0.55mW/cm 2 As per the above analysis, the resulted power density is below the MPE limit. Therefore the WMD 1x module in cellular band is compliant with the FCC rules on RF exposure. WMD 1x Operating in PCS Band (1850 - 1910 MHz) The highest peak conducted output power of WMD 1x module measured in PCS is 24.3 dBm while the module operates in CDMA channel 600. In the worst case, where an antenna gain is 4dBi, the resulted ERP can be expressed as follows: ERP = 24.3 + 4 - 2.15 = 26.15 dBm (0.412W) < 3 W In FCC CFR 47 §2.1091, it states that mobile devices identified in the section §2.1091(c) that operate at frequencies above 1.5 GHz with an ERP of 3 watts or more are required to perform routine environmental evaluation for RF exposure prior to equipment authorization or use; otherwise, they are categorically excluded. Therefore, as we can see this resulted ERP is below 3W, the routine environmental evaluation for RF exposure prior to equipment a uthorization or use for WMD 1x module in PCS band is categorically excluded. Conclusion The WMD 1x module meets the mobile 20 cm separation distance as specified in Section 2.1091 of the FCC rules. An appropriate RF exposure compliance statement will be placed in the User’s Guide.

Nemko USA, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 Phone (858) 755-5525 Fax (858) 452-1810 FCC Part 22 Subpart H and 24 Subpart E : 14/04/2010 VERIFICATION TEST REPORT Report Number: 2010 03145986 FCC Project Number: 40965 Nex Number: 145986 Applicant: Qualcomm Inc. 5775 Morehouse Dr San Diego, CA 92121 Equipment Under Test (EUT): Tracking Module Model: WMD 1x FCC ID: J9CWMD1X In Accordance With: FCC Part 22, Subpart H FCC Part 24, Subpart E Tested By: Nemko USA Inc. 11696 Sorrento Valley Road, Suite F San Diego, CA 92121 Authorized By: Alan Laudani, EMC/RF Test Engineer Date: March 12, 2010 Total Number of Pages: 30 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 FCC ID: J9CWMD1X Report Number: 2010 03145986 FCC Specification: FCC Part 22 Subpart H ,Part 24 Subpart E Page 2 Section1: Summary of Test Results General All measurements are traceable to national standards These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 22 and Part 24. Radiated tests were conducted is accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: Tracking Module Model: WMD 1x Specification: FCC Part 22, Subpart H FCC Part 24, Subpart E Date Received in Laboratory: March 11, 2010 Compliance Status: Complies Exclusions: None Non-compliances: None Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 FCC ID: J9CWMD1X Report Number: 2010 03145986 FCC Specification: FCC Part 22 Subpart H ,Part 24 Subpart E Page 3 Report Release History REVISION DATE COMMENTS - March 12, 2010 Prepared By: Alan Laudani -…

Text truncated - open the document above for the full version.
