JLFEC1Echo Remote

1 Model OPG-K5/K250 Setup Instructions 1: Setting up the Echo Remote: • Will the Echo Remote (ERMT) be used with an ULTRX900-R Unit in Receiver Mode? ƒ No: Go to Step 2. ƒ Yes: Place the Ultra RX 900 Unit in Learn Mode by disconnecting the power and waiting at least 5 seconds before reapplying power. - Within 15 seconds, press the large button on the remote. - The Ultra RX 900 Unit will buzz indicating success. - Proceed to Step 5. 2: Setting up the Echo Remote: • Will the Echo Remote be used with a Gate Access Panel (GAP) or Keypad (OWK) that includes a GCU or ULTRX900-R as the gate activator? ƒ No: Go to Step 3. ƒ Yes: The Echo Remote needs to be taught directly to the Active Unit (GAP or OWK). To put the Echo Remote in Learn Mode, press the large button, button 2 and button 4 at the same time, for 1 second and release. - On the GAP or Keypad Unit, enter in the Master Pin Number, followed by 05. - The remote will give an acceptance beep indicating success. - Proceed to Step 6. Oracle (TM) Echo Remote Universal Wireless Solutions Model ERMT 12/11/2007 Patents Pending Thank you for purchasing the Oracle Echo Remote. This Compatibility: • Compatible with Oracle GCU (Gate Controller Unit)/DFGCU (Dual Frequency Gate Controller Unit), up to 4 units • Compatible with Oracle UltraRX 900 Receiver Module • Oracle Gate Controller Unit (GCU)/Dual Frequency Gate Controller Unit (DFGCU). Can be used alone (up to 4 GCU/DFGCU’s) or in combination with Oracle GAP and other Access Control and Communication products. product has been designed and manufactured in the USA, utilizing the highest qualit y standards available. Features: • For: Gates, Garage Doors, Security Systems, Lighting and anything Electric! • 4 Button, Multi Channel design, can control 4 devices • Lithium Battery Lasts for Years and will not be effected by high vehicle temperatures and humidity • Over 1000 Feet Of Range through multiple channels, chosen automatically • Audible and Visual Indication Of Command Receipt, as well as indication of failure • Automatic Retry of Command on Multiple Radio Channels • 125 Channel, Digital, Ultra-Secure, 900 MHz • Built-in Unique ID as well as "Learning" of Network ID. WEIGAND compatible • All functions Performed automatically by Built-in Microprocessor 3a: Setting up the Echo Remote: • Will the Echo Remote be used with a Gate Controller Unit (GCU) or a Dual Frequency Gate Controller Unit (DFGCU) as the gate activator? NOTE: If activating an Echo remote directly to a GCU/DFGCU, there can be NO other Primary Gate Access Unit in the network. ƒ No: Go to Step 4. ƒ Yes: Press the Learn button on the GCU/DFGCU once, until the LED lights up solid, and release. - Within 5 seconds, on the Echo Remote press the large button, button 2 and button 4 at the same time, for 1 second, until the LED lights up, and release. - The LED on both units will double blink, 3 times, and the remote will beep, indicating success. - Proceed to Step 3b. 3b: Setting up the Echo Remote: • Will you be using more than 1 Echo Remote? ƒ No: Go to Step 3c. ƒ Yes: NOTE: Before starting this step, please make sure you disconnect power to the GCU/DFGCU. On the additional Echo Remote, press the large button, button 2 and button 4 at the same time, for 1 second, until the LED lights up, and release. - Within 5 seconds, on the main Echo Remote (the one activated to the GCU/DFGCU), press the large button only, 1 time. - The LED on the additional unit will double blink, 3 times, and the LED on the main unit will blink twice, indicating success. - For any additional remotes please repeat Step 3b for each unit that will be used. - Proceed to Step 3c. 3c: Setting up the Echo Remote: • Will you be using more than 1 GCU/DFGCU with your Echo Remotes? ƒ No: Go to Step 6. ƒ Yes: NOTE: This will allow up to (4) gate controllers to be activated independently by each of the 4 buttons based on their controller ID# (1-4).. Setting the Gate Controller ID (1-4) ƒ If you are using more then one Gate Controller, the additional units must have their ID set. The Gate Controller ID is set by changing dipswitches #1&2 in the Gate Control Unit (see picture below) 2 GCU ID SW1 SW2 1 off off 2 on off 3 off on 4 on on Example: The dipswitches for Gate Controller #2 would look like this: ƒ Proceed to Step 6. 4: Setting up the Echo Remote: • The Echo Remote needs to be taught directly to the Active Unit (MiniGAP (OMG) Unit, Basic Access (OMG2) Unit, or Push-To-Exit (OPE) Unit) • To put the Echo Remote in Learn Mode, press the large button, button 2 and button 4 at the same time, for 1 second and release. • On the OMG, OMG2, or OPE, press and release the black learn button located inside the unit on the circuit board. - The remote will give an acceptance beep indicating success. - Proceed to Step 6. ! Clearing the Memory If you get an error tone at any time or need to re-teach a unit, you will need to clear the memory. • To clear the memory on an Ultra RX 900, hold down the learn button, located on the inside of the unit, until the LED gives blinks 4 times, twice. • To clear the memory on a GCU, hold down the learn button until the LED gives 4 double blinks. • To clear the memory on a MiniGAP, Basic Access or Push-To-Exit, hold down the learn button until you hear a low tone. • To clear the memory on an Echo Remote, press the large button, button 2 and button 4 at the same time until you hear a beep. General Operation 5: Using the Echo Remote with the ULTRX900-R in receiver mode: • Once the Echo Remote has been taught to the Ultra RX 900 unit, the buttons will automatically operate as follows: ƒ Large Button – Activates Relay #1 ƒ Button #2 – Activates Relay #2 ƒ Button #3 – Activates Output 3 ƒ Button #4 – Activates Output 4 See the ULTRX900-R Instruction manual for more detailed instructions. 6: Using the Echo Remote with an Active Unit: • Once the Echo Remote has been taught to a GAP, Keypad, MiniGAP, Basic Access, Push-To-Exit, or DFGCU, the buttons will automatical…

Text truncated - open the document above for the full version.


  USA Manufacturers Of Quality Consumer Electronics 5913 NE 127 th Ave, Suite 800, Vancouver WA 98682 August 28, 2005 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Gentlemen: This letter will authorize the appointment of M. FLOM ASSOCIATES, INC. to act as our Agent in all FCC matters. This appointment is affective until otherwise notified by us. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. International Electronics, Inc. Shary Nassimi, President

FCC ID: JLFEC1 Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, Chamberlain Group, Inc., hereby request confidentiality for the block diagram, schematic and product description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Barbara Kelkhoff Manager of Regulatory Affairs Chamberlain Group, Inc. 845 Larch Ave. Elmhurst, IL. 60126

Futura Echo Active Devices Item Part Type Designator(s) Qty Mfg Function 1 MMBT2222 Q3 1 ST Micro NPN transistor 2 3.6864Mz Y1 1 Abracon crystal 3 ADF7020 U2 1 Analog 900mhz transceiver 4 ATMega88 IC2 1 Atmel Microcontroller 5 11.0592Mhz Y2 1 Abracon crystal 6 UPG2214 U1 1 CEL T/R switch 7 NCP1400 U3 1 On-Semi 180 Khz Boost Regulator

Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Date: September 13, 2007 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: International Electronics Inc. Equipment: Futura Echo FCC ID: JLFEC1 FCC Rules: 15.249 Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax List Of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: International Electronics Inc. FCC ID: JLFEC1 By Applicant: 1. Letter Of Authorization 2. Identification Drawings Label Location of Label Compliance Statement Location of Compliance Statement 3. Documentation: 2.1033(B) (3) User Manual (4) Operational Description (5) Block Diagram (5) Schematic Diagram (7) Photographs Block Diagram Parts List Active Devices 4. Draft Specification Information By FTL Inc. A. Testimonial & Statement of Certification B. Statement of Qualifications Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Transmitter Certification of Model: Futura Echo to Federal Communications Commission Rule Part(s) 15.249 Date Of Report: September 13, 2007 At the Request of: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 Attention of: Shary Nassimi, President (360) 241-9090 email: [email protected] Supervised By: Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax The applicant has been cautioned as to the following: 15.21 Information to User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Table Of Contents Rule Description Page . Test Report 1 2.1033(c) General Information Required 2 . Standard Test Conditions and Engineering Practices 5 2.1053(a) Field Strength of Spurious Radiation 6 15.109 Radiated Emissions 10 Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Page 1 of 15 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Required information per ISO Guide 17025: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0790010 d) Client: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 e) Identification: Futura Echo Description: Oracle Echo Remote f) EUT Condition: Not required unless specified in individual tests. g) Report Date: September 13, 2007 EUT Received: September 1, 2007 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with FTL internal quality manual. m) Supervised by: Hoosamuddin S. Bandukwala, Lab Director n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Flom Test Labs MFA p0770013, d0790010 3356 N. San Marcos Place, Suite 107 Page 2 of 15 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax List Of General Information Required For Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 15.249 Sub-Part 2.1033 (c)(1): Name and Address of Applicant: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 Manufacturer: (c)(2): FCC ID: JLFEC1 Model Number: Futura Echo (c)(3): Instruction Manual(s): Please See Attached Exhibits (c)(4): Type of Emission: N/A (c)(5): FREQUENCY RANGE, MHz: 903 to 926 (c)(6): Power Rating, W: Switchable Variable x N/A (c)(7): Maximum Power Rating, W: 50 m…
