JLFOMG2MiniGap II

MOUNTING TEMPLATE (Use this template as a guide for mounting screw pl acement) NOTE: The manufacturer is not responsible for any radio o r TV interference caused by unauthorized modifications to this equipment. Chan ges or modifications not expressly approved by the party responsible for com pliance could void the user’s authority to operate the equipment. If you have installation or operation questions, pl ease see above, or check out the expanded FAQ at th e manufacturer’s web page at www.reporterwireless.com . You can receive free technical assistance or warr anty service, by email at [email protected] or call 888.679.7994 x 290 Tuesday-Friday 8-5 PST Warranty : This product is warranted to be free of defects for the period of One Year from the date of purchase. The warranty covers parts, labor, and return shipping to you, but not a ll accessories . IEI will repair or replace any defective product at our discretion. Warranty does not cover misuse or damage other than due to n ormal operating conditions. If you need to send th e system to IEI for repair, contact IEI for a Return Authorization number via email: techsupp@nwl ink.com . Packages without a Return Authorization number will be rejected. MiniGAP2 System Features : • Easy to mount on any surface or in any location • Weather Resistant Design • Use Ou tside the Front door or for a side door • Wireless Gate Access Control • Up to Two Year battery life • Secure digital connection • Unlimited number of units can operate on a property, without interfering with other Intercom networks. Made With Pride In the USA . This product is covered by a manufacturer’s full One Year Warranty. FCC STATEMENT This device complies with FCC part 15 rules. It may not cause harmful interference with other devices, and must accept interference from other devices. Thank you for purchasing the Oracle MiniGAP2. This product has been designed and manufactured in the USA, utilizing the highest quality standards available. Model OMG2 102406 Patents pending The Or acle™ MiniGAP2 unit can be your primary door and gate access system or used as an accessory to a Gate Access Panel (GAP). For privacy, your Oracle system forms an exclusive network, and responds only to other units in your network. (Patent Pending) Since this MiniGAP2 Access and Intercom system requires no connection to wall power, it is perfect for remote locations. Please read the instructions carefully. S etting Up the MiniGAP2 Installation Make sure that the CALL button is in easy reach of a visitor. To mount the MiniGAP2 with four screws, use the included mounting template (see Back Page) as a guide for screw placement. Tighten the top two screws halfway. Place the back of the MiniGAP2 on the two top screws and tighten. Put the other two screws in the bottom holes and tighten. Note: Do not assemble the front of the unit until it has been activated. Use the double-sided mounting tape to mount the MiniGAP2 on a metal, glass, or other smooth surface where you wouldn’t want to use screws. Note: For best results, clean both surfaces that the double-sided mounting tape will be in contact with, using the included alcohol wipe. Peel the protective paper off of the mounting tape and firmly press it onto the back of the MiniGAP2. Press firmly on the back of the tape to push out any trapped air bubbles. When ready to do so, peel the red protective paper from the mounting tape and firmly press the MiniGAP2 on to the surface that you wish to mount it on. Note: Do not assemble the front of the unit until it has been activated. Batteries Place four AA Alkaline batteries in the battery pack. The batteries should last up to two years with average use. Note: If used in location that will be below -10 ° C (20 ° F) Lithium batteries are recommended. A Double-beep every ten minutes indicates low batteries. Add PHOTO HERE Activating Oracle Accessory Units The MiniGAP2 is shipped with Dip Switch #1 in the UP position making it an “Active” unit. If the MiniGAP2 is going to be the “Passive” unit, Dip Switch #2 will need to be in the DOWN position and then follow the directions listed under “Multi-GAP Mode”. Activating a Gate Control Unit (GCU) (only if this MiniGAP2 is the “Active” unit) Press and hold down the GCU learn button for 1 second. Within 20 seconds press and hold down the MiniGAP2 learn button for 10 seconds or until the MiniGAP2 beeps in response as it activates the GCU. Activating Oracle Intercoms (only if this MiniGAP2 is the “Active” unit) Press and release the LEARN button on the Intercom. Within 20 seconds, press and hold down the MiniGAP2 learn button for one second . The Intercom will beep in response when it joins the system network. NOTE: For a Wall Flush mount Intercom, hold down both buttons of the Intercom for 3 seconds (until the channel lights start fast-flashing) then release them. Assembling the MiniGAP2 Put the two halves of the Intercom body together and place the 4 black screws in the top and bottom holes on the front of the unit and tighten with the hex key provided. The Intercom is ready to use. Using the MiniGAP When a visitor presses the CALL button, Intercom units will give an attention-getting beep and if unanswered, continue to beep for 40 seconds. During this time, Intercoms will ONLY connect to the MiniGAP2. Hold down the TALK button on an Intercom to speak to the visitor. Release the TALK button to hear the response. This will be a secure conversation and other Intercoms will not interfere. To activate a Gate Control Unit press the REMOTE button while talking to a visitor. To activate a Gate Control Unit without a visitor pressing the CALL button, hold the Intercom’s REMOTE button for 10 seconds (not available in Multi-GAP mode). Multi-GAP Mode To put the unit in Multi-GAP (Gate Access Panel) Mode, place dipswitch #1 DOWN (towards the circuit board) placing the unit into “Passive” mode. This unit will now act as an accessory to an “Active” GAP or “Active” MiniGAP2 module within …
