JLFTIU1WIRELESS INTERCOM

Model OTIU 608-1 4/20/2006 Patents Pending Made With Pride In the USA. A manufacturer’s full One Year Warranty covers this product. TABLE OF CONTENTS No Wiring or Trenching Required - 12 - ∑ Easy to install ∑ Highly miniaturized unit requires minimal space ∑ 1000-foot standard range ∑ Range extendable by using Oracle Repeaters ∑ Digitally encrypted protocol for totally secure conversation ∑ Digital sound quality ensures crystal clear audio ∑ Highly adaptive penetration and channel handling protocols ∑ Compatible with multiple Oracle PRO, MiniGAP, and FrontDoor units ∑ Identify which gate or door a visitor is at with Caller ID and Distinctive Ring Tone ∑ Call forwarding function lets you control Gate Access when you are away ∑ Can command the Gate at any time using telephone keypad o Distinctive Call Waiting o Call Waiting ID o Busy Detect & Retry on Forwarded Calls o Programs via Telephone Keypad
              !
  "     # $!    "  #   "   %$     &  "  " "        ' "  ( )
*
      "
+  " ,    ( -       ' "  (  International Electronics, Inc. Part 15 FCC ID: JLFTIU1 Part 68 US: 6sqCI08BTIU1 IC: Model: OTIU Country Of Origin: USA Oracle limited LIFETIME WARRANTY International Electronics Inc. (IEI) warrants this product to be free of defects in materials and workmanship, for its usable lifetime. For a period of ONE YEAR following purchase, IEI will repair or replace the product free of charge, including parts, labor, return shipping to you, and handling. All repairs or replacements are at the discretion of the Manufacturer. This warranty excludes items that have been abused, altered, incorrectly installed, or repaired by an unauthorized person. Changes or modifications not expressly approved by the Manufacturer could void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. This warranty is limited to the product only. No consequential damages are covered. After the initial one year of operation, the limited lifetime warranty will cover parts, labor, and return shipping to you, with a minimal handling charge specific to the product, as listed below: Telephone Interface unit: $40.00 If you have installation or operation questions or are in need of warranty service, please contact our Product Support department by email at [email protected] or call 360-254-1564 Tuesday-Friday 7-5 Pacific Time. If the issue is not resolvable, a manufacturer’s warranty repair order may be issued. To have the product(s) sent for warranty service. A Return Authorization number will be issued for warranty service, which must be put on the outside of the package, to be received and handled properly. Packages for warranty service may be sent to the following address. Packages with no RA# may not be accepted. IEI 5913C NE 127th AVE, Suite 800 Vancouver, WA 98682
Please include a note describing the problem that you are having and a copy of your original sales receipt (within the first year). If the warranty service is outside the first year, please include a check made out to IEI, based on the list of handling fees, shown above. Please note that you may need to send multiple units for warranty service, testing, and upgrading, though only the applicable fee for handling the failed unit(s) will be charged. Please allow 2-4 weeks for service and return shipping. If an EXPEDITED repair/replacement is requested, a 100% surcharge applies. In this case, please write EXPEDITED after the RA number. IEI will attempt to return expedited repair orders within one week, except during holidays. Oracle (TM) Wireless Telephone Interface Unit Thank you for purchasing the Oracle Telephone Interface Unit. This product has been designed and manufactured in the USA, utilizing the highest quality standards available. Model OTIU 608-1 4/20/2006 Patents Pending QUICK LIST OF FUNCTIONS TROUBLESHOOTING AND FREQUENTLY ASKED QUESTIONS How do I clear the memory of the OTIU I connect the OTIU but I don't hear a dial tone TO ENABLE/DISABLE CALL FORWARDING - 2 - It is not getting the expected transmission range While entering numbers, it goes to a dial tone - 1 - Check the line and phone connections. NOTE: I dial *9 and hear a beep, then an error tone I dial **, but it won't accept the rest of the command The telephone doesn't ring when someone presses "CALL" This product is compatible with Oracle PRO Gate Access Panel (GAP) model 600 - 8 or later and/or Oracle Repeater (RPT-1) model 604-2 or later. Clearing the memory will not affect any OTIU settings or programmed phone numbers, it will only clear any network connections. To clear the memory, use the telephone that is directly connected to the OTIU and dial: After the “BEEP”, hang up the telephone . You will now need to reactivate the OTIU into any network you may have. * * # 8 All numbers and symbols must be dialed within 3 seconds of each other, otherwise the unit times out and goes back to a dial tone. Check the phone connections and if it is a two- line phone, be sure that it is on LINE 1. If you receive a dual- tone error sound when attempting to open a gate, make sure that the OTIU is indeed programmed to the correct GAP, MiniGAP, or FrontDoor Unit and that the Gate Controller in question has been taught to the master unit as well. If an OTIU has already been taught, trying to re-teach it will soun…

Text truncated - open the document above for the full version.


  USA Manufacturers Of Quality Consumer Electronics 5913 NE 127 th Ave, Suite 800, Vancouver WA 98682 REQUEST FOR CONFIDENTIALITY April 19, 2006 Federal Communications Commission, EQUIPMENT APPROVAL SERVICES, P. O. Box 358315 Pittsburgh, PA 15251-5315 ATTN: Authorization & Evaluation Division PER: 47 CFR 0.457 and 0.459 RE: TIU FCCID JLFTIU1 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application as listed below, i.e. Schematic, Block Diagrams, Theory of Operation, Active Devices. These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, International Electronics, Inc Shary Nassimi, President

Back of EUT Reverse sex SMA connector Reverse SMA connector

Location of Label is on back of EUT.

FCC Label for TIU FCC ID: JLFTIU1 US: 6sqCI08BTIU1
                !
  "     # $!    "   #    "    Label location: Rear Panel


  USA Manufacturers Of Quality Consumer Electronics 5913 NE 127 th Ave, Suite 800, Vancouver WA 98682 Alignment Procedure FCCID JLFTIU1 Oracle Wireless Gate Control Unit This device requires no tuning or alignment.

Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: JLFTIU1 (866) 311-3268 phone, (480) 926-3598 fax MFA p0620011, d0630049 Transmitter Certification of Model: Telephone Interface Unit FCC ID: JLFTIU1 to Federal Communications Commission Rule Part(s) 15.249 Date Of Report: March 24, 2006 Amended Report June 7, 2006 On the Behalf of the Applicant: International Electronics Inc. At the Request of: P.O. 13653 International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 Attention of: Shary Nassimi, President (360) 241-9090 email: [email protected] Supervised By: David E. Lee, FCC/IC Compliance Manager Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: JLFTIU1 (866) 311-3268 phone, (480) 926-3598 fax MFA p0620011, d0630049 The Applicant has been cautioned as to the following: 15.21 Information to User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 FCC ID: JLFTIU1 (866) 311-3268 phone, (480) 926-3598 fax MFA p0620011, d0630049 Table Of Contents Rule Description Page . Standard Test Conditions and Engineering Practices 5 2.1053(a) Field Strength of Radiated Emissions 6 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 11 2.202(g) Necessary Bandwidth and Emission Bandwidth 16 Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 1 of 16 Chandler, Arizona 85225-7176 FCC ID: JLFTIU1 (866) 311-3268 phone, (480) 926-3598 fax MFA p0620011, d0630049 Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0630049 d) Client: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 e) Identification: Telephone Interface Unit FCC ID: JLFTIU1 Description: Wireless Intercom f) EUT Condition: Not required unless specified in individual tests. g) Report Date: March 24, 2006 EUT Received: February 17, 2006 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: David E. Lee, FCC/IC Compliance Manager n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 2 of 16 Chandler, Arizona 85225-7176 FCC ID: JLFTIU1 (866) 311-3268 phone, (480) 926-3598 fax MFA p0620011, d0630049 List Of General Information Required For Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 15.249 Sub-Part 2.1033 (c)(1): Name and Address of Applicant: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 Manufacturer: Applicant (c)(2): FCC ID: JLFTIU1 Model Number: Telephone Interface Unit (c)(3): Instruction Manual(s): Please See Attached Exhibits (c)(4): Type of Emission: FM (c)(5): FREQUENCY RANGE, MHz: 902 - 928 (c)(6): Power Rating, mV/m @ 3m: 49.00 Switchable Variable X N/A (c)(7): Maximum Power Rating, W: 50 mv/m @ 3m 15.203: Antenna Requirement: The antenna is permanently attached to the EUT X The antenna uses a unique coupling The EUT must be professionally installed The antenna requirement does not apply Flom Test Labs 3356 N. San Marcos Place, Suite 107 Page 3 of 16 Chandler, Arizona 85225-7176 FCC ID: JLFTIU1 (866) 311-3268 phone, (480) 926-3598 fax MFA p0620011, d0630049 Subpart 2.1033 (continued) (c)(8): Voltages & Currents in All Elements in Final RF Stage, Including Final Transistor or Solid State Device: Collector Current, A = See Manual Collector Voltage, Vdc = See Manual Supply Voltage, Vdc = 18.0 (c)(9): Tune-Up Procedure: Please See Attached Exhibits (c)(10): Circuit Diagram/Circuit Description: Including description of circuitry & devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation and limiting power. Please See Attached Exhibits (c)(11): Label Information: Please See Attached Exhibits (c)(12): Photographs: Please See Attached Exhibits (c)(13): Digital Modulation Description: ___ Attached Exhibits _x_ N/A (c)(14): Test and Measurement Data: Follows Flom Test Labs 3356 N. San M…
