JLFTIU2Telephone Interface Unit

Thank you for purchasing the Oracle Pro Gate System. This product has been designed and manufactured in The USA, utilizing the highest quality standards available. . Made With Pride In the USA. A manufacturer’s full One Year Warranty covers this product No Wiring or Trenching Required O r a c l e( t m ) O u t d o o r W i r e l e s s T e l e p h o n e I n t e r f a c e U n i t • Easy to install • Highly miniaturized unit requires minimal space • Up to 1000-foot range • Range extendable by using Oracle Repeaters • Digitally encrypted protocol for totally secure conversation • Digital sound quality ensures crystal clear audio • Highly adaptive penetration and channel handling protocols • Compatible with multiple Oracle PRO, MiniGAP, and FrontDoor units • Identify which gate or door a visitor is at with Caller ID and Distinctive Ring Tone • Gate Tamper Alert • Call forwarding function lets you control Gate Access when you are away • Can command the Gate at any time using telephone keypad o Distinctive Call Waiting o Call Waiting ID o Places Conversation On-Hold o Auto Reconnect to 1 st Connection o Busy Detect & Retry on Forwarded Calls o Programs via Telephone Keypad This product is compatible with Oracle PRO Gate Access Panel (GAP) model 600-10 or later and/or Oracle Repeater (RPT-1) model 604-3 or later. INSTALLING THE OTIU-EX 1) What will are you connecting the OTIU-EX-EX to? • Oracle Front Door go to step 1 • GAP unit go to step 2 • Mini GAP go to step 4 • Repeaters go to step 5 ACTIVATING THE OTIU-EX WITHIN AN EXISTING NETWORK RING When activating the OTIU-EX within an existing network, simply follow the instructions for “Activating the OTIU-EX with GAP” if the GAP is the Active (Main) Unit, the instructions for “Activating the OTIU- EX with MiniGAP” if the MiniGAP is the Active Unit, or “Activating the OTIU-EX with a FrontDoor” if the FrontDoor is the Active Unit. A few examples of an existing network are pictured as follows: Active Mode Intercom OTIU-EX Front Door MiniGAP NOTE: By activating the OTIU-EX to the Active Unit, you are activating the OTIU-EX into the existing network with no further steps to take. +18V POWER ACTIVE RING TIP TIP PHONE GND LINE To wire up the power adapter: Ground – Solid Black Wire +18V – Striped Wire The OTIU-EX should be mounted near the de-mark location. Antenna pointing downward. STEP 1 ACTIVATING THE OTIU-EX WITH FRONTDOOR (IF THERE IS NOT AN EXSISTING NETWORK) (NOTE: Both step A & B must occur within 15 seconds of each other) STEP2 ACTIVATING THE OTIU-EX WITH GAP (NOTE: Both step 1 & 2 must occur within 15 seconds of each other) Using the phone that is connected to the OTIU-EX, once you hear a dial tone press: * * 0 7 1. Hang up and the LEARN light will flash for up to 15 seconds. If it does not and you hear an error tone, see “How do I clear the memory”, in the FAQ section. Otherwise, repeat the process. 2. On the FrontDoor, press and hold down the learn button for 1 second, to put it into learn mode. NOTE: The learn button is a little black button located on the inside of the unit at the very top of the circuit board. The OTIU will ring the telephone and Caller ID will display " Unit Learned ". If hooking up multiple OFD units refer to “ MULTI-OFD MODE” in OFD manual. 1. Using the phone that is connected to the OTIU-EX, once you hear a dial tone press: ** 07 Hang up and the LEARN light will flash for up to 15 seconds. If it does not and you hear an error tone, see “How do I clear the memory”, in the FAQ section. Otherwise, repeat the process. 2. On the Gate Access Panel (GAP), enter the Master PIN number: For example: 1234 “Beep” Followed by: 05 The OTIU-EX will ring the telephone and Caller ID will display " Unit Learned ". If hooking up multiple GAP units see MULTI-GAP MODE in Gap Manual STEP 4 ACTIVATING THE OTIU-EX WITH MINIGAP (IF THERE IS NOT AN EXSISTING NETWORK) (NOTE: Both step 1 & 2 must occur within 15 seconds of each other) STEP 5 ACTIVATING THE OTIU-EX WITH A REPEATER (WITHIN AN EXISTING NETWORK) (NOTE: Both step 1 & 2 must occur within 15 seconds of each other) 1. Using the phone that is connected to the OTIU-EX, once you hear a dial tone press: **07 Hang up and the LEARN light will flash for up to 15 seconds. If it does not and you hear an error tone, see “How do I clear the memory”, in the FAQ section. Otherwise, repeat the process. 2. On the MiniGAP, press and hold down the learn button for 1 second, to put it into learn mode. NOTE: The learn button is a little black button located on the inside of the unit at the very top of the circuit board. The OTIU-EX will ring the telephone and Caller ID will display " Unit Learned ". Using the phone that is connected to the OTIU-EX . Once you hear a dial tone press: **07 “Beep” 1. Hang up and the LEARN light will flash for up to 15 seconds. If it does not and you hear an error tone, see “How do I clear the memory”, in the FAQ section. Otherwise, repeat the process. 2. Press the LEARN button on ONE of the Repeater Units. The LED by the LEARN button will light up for several seconds, then will go out and the OTIU-EX will ring the telephone and display “Unit Learned”, indicating a successful activation. NOTE: If the Repeater Units have not been previously activated to anything within an existing network, please follow the directions found in the Oracle Wire-free Repeater product manual. STUCCO: When used in a dwelling with stucco or cement walls, the RF range is reduced greatly. The Oracle Repeater will solve this issue. Place the repeater close to the house to mitigate this problem. USING THE OTIU-EX CALLER ID FUNCTION (Does NOT require Caller ID Service with your telephone company) CALL WAITING FUNCTION (Does NOT require Call Waiting Service with your telephone company) TO CHANGE THE NUMBER OF TIMES THE OTIU-EX RINGS THE PHONE When a visitor presses the CALL button, the telephone that is connected to the OTIU-EX will give a distinctive ring up to 4 times. Or in the case of having an expandabl…

Text truncated - open the document above for the full version.


  USA Manufacturers Of Quality Consumer Electronics 5913 NE 127 th Ave, Suite 800, Vancouver WA 98682 August 28, 2005 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Gentlemen: This letter will authorize the appointment of M. FLOM ASSOCIATES, INC. to act as our Agent in all FCC matters. This appointment is affective until otherwise notified by us. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. International Electronics, Inc. Shary Nassimi, President

FCC ID: JLFTIU2 Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, Chamberlain Group, Inc., hereby request confidentiality for the block diagram, schematic and product description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Barbara Kelkhoff Manager of Regulatory Affairs Chamberlain Group, Inc. 845 Larch Ave. Elmhurst, IL. 60126

OTIU-EX Active Devices Item Part Type Designator(s) Qty Mfg Function 1 MMBT2222 Q3...8 6 ST Micro NPN transistor 2 KST43MTF Q10 1 FairChild NPN transistor 3 KST93MTF Q9 1 FairChild PNP transistor 4 7.3728Mz Y1 1 Abracon crystal 5 ADF7020 U2 1 Analog 900mhz transceiver 6 ATMega32 U3 1 Atmel Microcontroller 7 11.0592Mhz Y2 1 Abracon crystal 8 LMV932 IC6 1 National dual op-amp 9 TPS76630D V3 1 TI 3.3V regulator 10 78M05 V1 1 ST Micro 5V regulator 11 78M15 V2 1 ST Micro 15V regulator 11 UPG2214 U1 1 CEL T/R switch 12 XE3005 IC3 1 Xemics Audio Codec 13 CPC5602 Q1 1 Clare FET 14 CPC5621 IC1 1 Clare DAA 15 H11AA814A OK2B 1 Fairchild Opto 16 FZT853TA Q2 1 Zetex NPN transistor 17 LTC3479 IC2 1 Linear Tech 1Mhz Switching Reg

Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Date: September 12, 2007 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: International Electronics Inc. Equipment: Oracle Telephone Interface FCC ID: JLFTIU2 FCC Rules: 15.249 Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax List Of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: International Electronics Inc. FCC ID: JLFTIU2 By Applicant: 1. Letter Of Authorization 2. Identification Drawings Label Location of Label Compliance Statement Location of Compliance Statement 3. Documentation: 2.1033(B) (3) User Manual (4) Operational Description (5) Block Diagram (5) Schematic Diagram (7) Photographs Parts List Active Devices By FTL Inc. A. Testimonial & Statement of Certification B. Statement of Qualifications Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Transmitter Certification of Model: Oracle Telephone Interface to Federal Communications Commission Rule Part(s) 15.249 Date Of Report: September 12, 2007 At the Request of: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 Attention of: Shary Nassimi, President (360) 241-9090 email: [email protected] Supervised By: Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax The applicant has been cautioned as to the following: 15.21 Information to User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Table Of Contents Rule Description Page . Test Report 1 2.1033(c) General Information Required 2 . Standard Test Conditions and Engineering Practices 6 2.1053(a) Field Strength of Spurious Radiation 7 15.239 Radiated Output Power 9 15.109 Radiated Emissions 10 15.207 A/C Powerline Conducted Emissions 18 Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Page 1 of 23 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Required information per ISO 17025 a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0790008 d) Client: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 e) Identification: Oracle Telephone Interface Description: Telephone Interface f) EUT Condition: Not required unless specified in individual tests. g) Report Date: September 12, 2007 EUT Received: September 1, 2007 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with FTL internal quality manual. m) Supervised by: Hoosamuddin S. Bandukwala, Lab Director n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Flom Test Labs FTL p0770012, d0790008 3356 N. San Marcos Place, Suite 107 Page 2 of 23 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax List Of General Information Required For Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 15.249 Sub-Part 2.1033 (c)(1): Name and Address of Applicant: International Electronics Inc. 5913-C NE 127th Ave, Suite 800 Vancouver, WA 98682 (c)(2): FCC ID: JLFTIU2 Model Number: Oracle Telephone Interface (c)(3): Instruction Manual(s): Please See Attached Exhibits (c)(4): Type of Emission: N/A (c)(5): FREQUENCY RANGE, MHz: 903 to 926 (c)(6): Power Ratin…
