K5B-TP100Low Power Process Control Transmitter

DRAFT TriggerPad TP -100/105 DESCRIPTION:______________________________ Rugged wireless remote control is within reach. Matric’s TriggerPad family of handheld transmitters are ideal for many material handling and process control applications such as jib cranes, sifting grates, slurry barges, and belt controls. TriggerPad handhelds are pocket sized operator control stations that provide long switch life, one hand operation, and extended battery life. With a typical range of 300 feet and a rugged molded enclosure, the TriggerPad is right at home on the plant floor, in a quarry, or in your tool belt. Consult our online catalog for the latest models and features in the TriggerPad family of handheld transmitters. FEATURES:_________________________________ • Sealed handheld enclosure • Range of 300 feet • License free radio (FCC Part 15B) • One month battery life (typical) • 1 million cycle sealed pushbuttons • Easy one hand operation • Custom labeling available APPLICATION:______________________________ Please Note: The TriggerPad 100/105 is not intended for use as an emergency stop device. The TriggerPad 100/105 is a transmit on command device. Data is transmitted from the TriggerPad only when a button is being pressed by an operator. CRC data error checking and data message identifiers are used to insure that transmitted data is correctly received and interpreted. The transmit on demand feature results in extended battery life (up to 1 month in most applications). However, without a continuously maintained communication link, the TriggerPad is not appropriate for applications that require a handheld shutdown for emergency or safety purposes. A system level risk assessment should be performed before any new control application is installed. SPECIFICATIONS:____________________________ • 8 bit controller with 2K flash and CPU watchdog • 3 AA batteries give 1 month operation (32 hours continuous) • 900MHz one way radio with 8 channels • Operational range of 0 - 300 feet • Internal antenna to prevent damage • Sealed enclosure • Operational temperature range of 0ºC to +70ºC • Storage temperature range of -40ºC to +85ºC • 2.75 inches X 1.375 inches X 7 inches, 12.5 oz • Mechanical tactile switches with 1,000,000 cycle switch life • Eight button membrane switch available with 2 digit LED (TP-105) • Optional belt clip and custom labels available • CRC data error checking CONFIGURATION:____________________________ Label There are several standard label configurations available for the TriggerPad, each geared to a typical TriggerPad application. If your application requires a unique label, our engineering staff can create a custom label according to your specifications. Please refer to the TriggerPad configuration sheet to select an off-the-shelf label or to specify a custom label. Radio Channel Configuration The TriggerPad supports eight channels to avoid interaction when multiple systems are employed in close proximity situations. The radio channel can be configured at the factory prior to shipment or by a customer’s technician in the field. See the configuration sheet to specify a channel for factory configuration. Channel Frequency 0 903.37 MHz 1* 906.37 MHz* 2 907.87 MHz 3 909.37 MHz 4 912.37 MHz 5 915.37 MHz 6 919.87 MHz 7 921.37 MHz *Factory default channel selection For safety reasons, on site radio channel configuration requires the following basic steps. 1. Power down and lock out any systems that could be operating at the frequencies shown above. 2. Set the TriggerPad channel. (See instructions below.) 3. Set the channel of the ProComm. (Refer to the appropriate receiver user manual, i.e. ProComm 100, for receiver configuration.) 4. Return processes and equipment to service. Please note, to avoid accidentally duplicating channels, it is recommended that the default channel NOT be used in a multi-station application. The following procedure will select the appropriate TriggerPad channel for use with any applicable Matric receiver. 1. Disconnect the associated reciever from power and field wiring. Also, disable any other devices that could be inadvertently activated by the TriggerPad during this process. 2. Remove the four corner screws and open the back of the TriggerPad. See diagram below. 3. Remove batteries. 4. Install channel setting link to position A as shown below. BATTERIES TriggerPad Links Enclosure Screw Location A 5. Install batteries. Note polarity on circuit board under batteries. 6. The current channel will be displayed on the LED indicators on the front of the TriggerPad. Press and release the top button to cycle through channels until the desired channel is displayed. See the diagram below to interpret channel numbers. 7. Remove the channel setting link and replace the cover. The TriggerPad is now ready for operation. Channel 0Channel 1Channel 2Channel 3 Channel 4Channel 5Channel 6Channel 7 INDICATORS:________ _______________________ The TriggerPad 100 provides 4 red LED indicators. One LED is located beside each button. These LEDs serve three functions. First, the LED next to a button will be illuminated when the button is depressed. This is hardwired visual feedback that the button has been activated. However, the active button indicator does not show the status of data transmission. Second, when no buttons are depressed, the top LED will blink to indicate a low battery condition. Third, the LEDs are used to indicate the selected channel. See the configuration section for details of channel selection. The TriggerPad 105 provides a two digit seven segment LED display. This display is used to set the one byte value that is transmitted with the switch status from the TP-105. To change the value, press the “Enter” switch while pressing either the up or down arrow. BATTERIES:________________________________ The TriggerPad 100/105 uses three standard AA batteries. Depending upon usage, these batteries should provide up to one month of operation. A low battery power state will be …

Text truncated - open the document above for the full version.

APPLICATIONS INCLUDE: nContinuous Data Transfer nHome/Industrial Automation nWireless Networking nRemote Control nRemote Access nRemote Monitoring/Telemetry nFire/Security Alarms n Long-Range RFID n High-Quality Wireless Audio n Analog Signal Transfer n General Wire Elimination Page 1 HPSERIES-II TRANSMITTER MODULE DESIGNGUIDE FEATURES: n 8 Binary Selectable Transmission Frequencies n FM/FSK Modulation For Noise Immunity n C o s t - E ff e c t i v e n Precision Synthesized Frequency Reference n Direct Analog/Serial Interface n High Data Rate (50Kbps max.) n Can Be Used To Transmit Analog (Including Audio) or Digital Data n Wide Supply Range (2.7-16V DC) n Power-Down & CTS Functions n No Production Tuning nNo External RF Components Required (Except A n t e n n a ) n FCC Compliant Output Power (0dBm typical) DESCRIPTION: The HP Series-II transmitter module is designed for the c o s t - e f fe c t i ve, high-perfo rmance wireless tra n s fer of analog or digital data, in the popular 902-928MHz band. The transmitter offers eight selectable channels and, when paired with an HP Series-II receiver, is capable of transmitting analog and digital information for distances of up to 1000 ft.(under optimal conditions).To assure robust performance, the transmitter employs F M / F S K modulation and an advanced microprocessor-controlled s y n t h e s i zed architecture.L i ke all Linx modules, the HP S e ries-II requires no tuning and in most cases no ex t e rn a l RF components ( except an antenna), making integra t i o n s t ra i g h t fo r ward even for engineers lacking previous RF ex p e ri e n c e. Figure 1:Physical Dimensions HIGHPERFORMANCE RFMODULE TXM-900-HP-II PART# DESCRIPTION M D E V-900-HP-II E valuation Kit 900 MHz TXM-900-HP-II Transmitter 900 MHz RXM-900-HP-II R e c e i ver 900 MHz O R D E R I N GI N F O R M AT I O N Revised 2/1/00 Figure 3:Maximum ratings table Figure 2:Performance data table PERFORMANCEDATA TXM-900-HP-II Page 2 A B O U TT H E S EM E A S U R E M E N T S The performance parameters listed below are based on module operation at 25°C from a 5VDC supply unless otherwise noted. Absolute Maximum Ratings: Supply voltage Vcc, using pin 7-0.3to+18 VDC Operating temperature0°Cto+70°C Storage temperature-45°Cto+85°C Soldering temperature+260°C for 10 sec. Any input or output pin-0.3toVcc *NOTE* Exceeding any of the limits of this section may lead to permanent damage of the device.Furthermore, extended operation at these maximum ratings may reduce the life of this device. ParameterDesignationMin.TypicalMax.UnitsNotes Input Voltage (Vcc)V CC 2.7–16.0VDC– Supply currentI CC –1517mA– Sleep currentI CS ––50μA Operating frequencyF C 902–928MHz– Overall frequency accuracy-50–+50KHz– Output Power-30+4dBm– Spurious Emissions––-50dBc1 Harmonic Emissions––-50dBc– Occupied Bandwidth–32–KHz– PONto CTS High TimeT PON– 812mSec– Minimum OffT MINOFF 1––mSec– Channel Change TimeTime––1.2mSec– Fdev507595KHz p-p– * C AU T I O N * This product incorp o rates numerous static-sensitive components. A l ways wear an ESD wrist strap and observe proper ESD handling procedures when wo rking with this dev i c e. Failure to observe this precaution may result in module damage or fa i l u r e. 1.Tested to 2nd Harmonic Notes: Page 3 Figure 8:Modulation Linearity for Triangle Wave Input Figure 9:Output Power vs. Supply Voltage Figure 4:Power-On Timing TYPICALPERFORMANCEGRAPHS Figure 6:Modulation Linearity for Square Wave Input Figure 7:Modulation Linearity for Sine Wave Input Figure 5:Channel Change Timing PHYSICALPACKAGING The transmitter is packaged as a hybrid through- hole SIP-style module with 10 pins spaced at .1" i n t e rvals with a .3" gap between pins 2 & 3. Baseband components occupy the rear of the board while high-frequency components are grouped on the front. PRODUCTION CONSIDERATIONS The SIP module may be installed using hand- or wave-solder techniques.The module should not be subjected to reflow.If the module is subject to production wash cycles, adequate drying time should be allowed prior to power-up.If the wash cycle introduces contaminants, the module’s perfo rmance may be adversely affected. Figure 10:Physical package 1.00 V/div1.00 V/div +/-1.0 V 10.0 ms/div 0.0 s 120 mV 2.00 V/div1.00 V/div+/-1.0 V 500 μs/div 0.0 s1.67 V Page 4 PINDESCRIPTION Figure 11:Pin functions and equivalent circuits Page 5 THEORY OF OPERATION The HP-II-TXM is a high-performance, eight-channel, FM transmitter capable of transmitting analog or digital data. Digital information is modulated at the transmitter using FSK (frequency shift keying), the binary fo rm of frequency modulation. FSK offers significant advantages over AM-based modulation methods, i.e., increased noise immunity and the ability of the receiver to “capture”in the presence of multiple signals. These advantages will be particularly appreciated in crowded bands like those in which the HP-II operates.While FSK modulation is not the most bandwidth- efficient manner of modulating digital data, it is an excellent choice for reliable, low-cost, low-power RF products such as the HP Series-II. To transmit analog information the module reverts to FMmodulation.In this mode simple to complex waveforms can be introduced at the transmitter’s data pin and recovered with minimal distortion at the receiver’s analog output pin. The user-supplied antenna is connected at pin 2 (see Figure 1).The HP Series- II transmitters are designed to operate with a 50-ohm load. An accurate 12.00MHz VCXO (voltage-controlled crystal oscillator) serves as the frequency reference for the transmitter.The modulation input pin is connected to the VCXO through a two-pole low-pass filter.The low-pass filter is used to shape the incoming data and limit the transmission bandwidth to 25kHz. The reference frequency is directly modulated.This method affords two benefits. First, it eliminates the need for a frequency conversion in the transmitter, reducing size, cost, and current consumption.Second…

Text truncated - open the document above for the full version.

Matric Limited Hill City Road R.R. #1, Box 421A 814/677-0716 Seneca, PA 16346 Fax 814/678-1302 Letter Of Agency March 21,2001 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite Cl10 McLean, VA 22101 To Whom It May Concern: Please be advised that Matric Limited authorizes Washington Laboratories to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (A TCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b ), to the application is subject to denial of federal benefits, that includes FCC benefits.

TP100 Front TP100 Side TP100 Back

Model: TP100 Part No. : ________________ Serial No.: _______________ FCC ID: K5B-TP100 MATRIC LIMITED Hill City Road, R.R. #1, Box 421A Seneca, PA 16346

Model: TP100 Part No. : ________________ Serial No.: _______________ FCC ID: K5B-TP100 MATRIC LIMITED Hill City Road, R.R. #1, Box 421A Seneca, PA 16346

TP100 Cover Removed TP100 PCB Bottom TP100 PCB Top TP100 Shield Removed

THEORY OF OPERATION The module is a high-performance, eight-channel, FM transmitter capable of transmitting analog or digital data. Digital information is modulated at the transmitter using FSK (frequency shift keying), the binary form of frequency modulation. FSK offers significant advantages over AM-based modulation methods, i.e., increased noise immunity and the ability of the receiver to “capture” in the presence of multiple signals. These advantages will be particularly appreciated in crowded bands like those in which the transmitter operates. While FSK modulation is not the most bandwidth-efficient manner of modulating digital data, it is an excellent choice for reliable, low-cost, low-power RF products. To transmit analog information the module reverts to FM modulation. In this mode simple to complex waveforms can be introduced at the transmitter’s data pin and recovered with minimal distortion at the receiver’s analog output pin. The user-supplied antenna is connected at pin 2. The transmitter is designed to operate with a 50-ohm load. An accurate 12.00MHz VCXO (voltage-controlled crystal oscillator) serves as the frequency reference for the transmitter. The modulation input pin is connected to the VCXO through a two-pole low-pass filter. The low-pass filter is used to shape the incoming data and limit the transmission bandwidth to 25kHz. The reference frequency is directly modulated. This method affords two benefits. First, it eliminates the need for a frequency conversion in the transmitter, reducing size, cost, and current consumption. Second, it allows the modulation to occur within the loop bandwidth of the frequency synthesizer allowing a wide modulation bandwidth of 50Hz to 25kHz. The modulated 12.00MHz reference frequency is applied to the Phase-Locked Loop (PLL). The PLL, combined with a 902-928MHz VCO, forms a stable frequency synthesizer that can be programmed to oscillate at a number of preset frequencies. An on-board micro-controller reads the channel-selection lines and programs the PLL to the desired channel frequency. The micro-controller also monitors the status of the PLL and indicates when the transmitter is stable and ready to transmit data by asserting the CTS line high. A buffer amplifier is used to isolate the VCO from the antenna and to increase the output power of the transmitter. The output of the buffer amplifier is connected to a LPF, which is used to suppress harmonic emissions. All harmonic specifications are based on a 50-ohm load.

FCC CERTIFICATION TEST REPORT for Matric Limited Hill City Road R.R. #1 Box 421A Seneca, PA 16346 FCC ID: K5B-TP100 April 10, 2001 WLL PROJECT #: 6180X This report may not be reproduced, except in full, without the prior written consent of Washington Laboratories, Ltd. Matric Limited FCC ID:K5B-TP100 WLL Project #:6180X i TABLE OF CONTENTS 1.0 INTRODUCTION..................................................................................................................................................1 1.1 SUMMARY......................................................................................................................................................................1 2.0 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT).................................................................1 2.1 ON-BOARD OSCILLATORS...........................................................................................................................................1 3.0 TEST CONFIGURATION...............................................................................................................................1 3.1 TESTING ALGORITHM.................................................................................................................................................1 3.2 CONDUCTED EMISSIONS TESTING...........................................................................................................................2 3.3 RADIATED EMISSIONS TESTING...............................................................................................................................2 3.3.1 Radiated Data Reduction and Reporting............................................................................2 Tables Table 1. Radiated Emissions Results Table 2. System Under Test Table 3. Interface Cables Used Table 4. Measurement Equipment Used Appendices Appendix A. Statement of Measurement Uncertainty Matric Limited FCC ID:K5B-TP100 WLL Project #:6180X 1 FCC CERTIFICATION TEST REPORT for FCC ID: K5B-TP100 1.0 Introduction This report has been prepared on behalf of Matric Limited to support the attached Application for Equipment Authorization. The test and application are submitted for a Periodic Intentional Radiator under Part 15.249 of the FCC Rules and Regulations. The Equipment Under Test was the Matric Limited Model TP 100 transmitter. All measurements herein were performed according to the 1992 version of ANSI C63.4. The measurement equipment conforms to ANSI C63.2 Specifications for Electromagnetic Noise and Field Strength Instrumentation. Calibration checks are made periodically to verify proper performance of the measuring instrumentation. All measurements are performed at Washington Laboratories, Ltd. test center in Gaithersburg, MD. Site description and site attenuation data have been placed on file with the FCC's Sampling and Measurements Branch at the FCC laboratory in Columbia, MD. Washington Laboratories, Ltd. has been accepted by the FCC and approved by NIST NVLAP (NVLAP Lab Code: 200066-0) as an independent FCC test laboratory. All results reported herein relate only to the equipment tested. The measurement uncertainty of the data contained herein is ±2.3 dB. Refer to Appendix A for Statement of Measurement Uncertainty. This report shall not be used to claim product endorsement by NVLAP or any agency of the US Government. 1.1 Summary The Matric Limited TP 100 complies with the limits for an Intentional Radiator under Part 15.249 of the FCC Rules and Regulations. 2.0 Description of Equipment Under Test (EUT) The Matric Limited TP(Trigger Pad) 100 (EUT) is a hand-held industrial control transmitter operated by three (3)“AA” type batteries at 4.5VDC. The unit operates at 906.5 MHz and is used to control various material handling and process control applications. 2.1 On-board Oscillators The Matric Limited TP 100 contains the following oscillators: 3.686 MHz. 3.0 Test Configuration To complete the test configuration required by the FCC, the TP 100 was configured to continuously transmit and tested in all three orthogonal planes. The EUT is a standalone unit and contains no I/O ports or cables. 3.1 Testing Algorithm The TP 100 was turned on and configured to constantly transmit. The system was tested in all three orthogonal planes. Worst case emissions are recorded in the data tables. Matric Limited FCC ID:K5B-TP100 WLL Project #:6180X 2 3.2 Conducted Emissions Testing The TP 100 is battery-powered, therefore no conducted emissions testing was performed. 3.3 Radiated Emissions Testing The EUT was placed on an 80 cm high 1 x 1.5 meters non-conductive motorized turntable for radiated testing on a 3- meter open field test site. The emissions from the EUT were measured continuously at every azimuth by rotating the turntable. Biconical and log periodic broadband antennas were mounted on an antenna mast to determine the height of maximum emissions. The height of the antenna was varied between 1 and 4 meters. The peripherals were placed on the table in accordance with ANSI C63.4-1992. Cables were varied in position to produce maximum emissions. Both the horizontal and vertical field components were measured. The output from the antenna was connected, via a preamplifier, to the input of the spectrum analyzer. The detector function was set to quasi-peak or peak, as appropriate. The measurement bandwidth on the spectrum analyzer system was set to at least 120 kHz, with all post-detector filtering no less than 10 times the measurement bandwidth. For measurements above 1 GHz the measurement bandwidth was set to 1 MHz. 3.3.1 Radiated Data Reduction and Reporting To convert the raw spectrum analyzer radiated data into a form that can be compared with the FCC limits, it is necessary to account for various calibration factors that are supplied with the antennas and other measurement accessories. These factors are grouped into a composite antenna factor (AFc) and are supplied in the AFc column of Table 1. In addit…
