KA324WAN5Wireless LAN Bridge

i www.solectek.com SOLECTEK CORPORATION 6370 Nancy Ridge Dr. Suite 109 San Diego, CA 92121 858-450-1220 fax 858-457-2681 ii
Copyright Solectek Corporation 2000 All rights reserved. Reproduction, adaptation, or translation without prior written per- mission is prohibited, except as allowed under the copyright laws. Revision number 1.01 First edition, March 2000 Printed in USA The information contained in this document is subject to change without notice. Solectek Corporation makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties or merchantability and fitness for a particular purpose. Solectek Corporation shall not be liable for errors contained herein or for incidental or consequential damage in connection with the furnishing, performance, or use of this material. i Regulatory Information The SkyWay Series Wireless Bridge/Router operates in the 2.4 GHz band, complies with the IEEE 802.1D MAC bridging standard and supports SNMP monitoring if IP routing is enabled. Federal Communications Commission (FCC) Radio Frequency Interference Statement This device complies with Part 15 of FCC Rules. Operation of this device is subject to the following two conditions: • It may not cause harmful interference. • It must accept any interference that may cause undesired operation. Information to the User In order to comply with FCC RF exposure requirements, a minimum separation dis- tance of 27 in. must be maintainted between the antenna and any persons. When installing the antenna, ensure that this clearance is maintained while the product is in operation. This device must be installed and used in strict accordance with the manufacturer's instructions. However, there is no guarantee that interference to radio communica- tions will not occur in a particular commercial installation. In case the device does cause harmful interference with an authorized radio service, the user/operator shall promptly stop operating the device until harmful interference has been limited. Solectek Corpo- ration is not responsible for any radio or television interference caused by unautho- rized modification of this device or the substitution or attachment of connecting cables and equipment other than specified by Solectek Corporation. The correction of inter- ference caused by such unauthorized modification, substitution, or attachment will be the responsibility of the user. ii Steps for minimizing or eliminating radio and television interference: • Change the channel • Reorient the radio or TV receiving antenna. • Relocate the computer and SkyWay Series Wireless Bridge/Router unit with respect to the receiver. • Plug the computer and SkyWay Series Wireless Bridge/Router into a different outlet so the computer and bridge/router are on different branch circuits. If necessary, consult the dealer or an experienced radio/TV technician for additional suggestions. You may find the booklet called "How to Identify and Resolve Radio-TV Interference Problems" prepared by the Federal Communications Commission helpful. The booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, as stock number 004-000-00345-4. This product was FCC certified under test conditions that included the use of shielded I/O cables and connectors between system components. To be in compliance with FCC regulations, the user must use shielded cables and connectors and install them properly. Radio Transmission Notice This product is a low power (less than 1 Watt), direct-sequence, spread-spectrum radio system pre-set to transmit and receive signals in the 2.4-2.4835 GHz frequency band. This product has been certified by the U.S. Federal Communications Commis- sion for use in the United States of America in that band. The manufacturer makes no representation as to the availability of the above-mentioned frequency band for such use in other countries. Any prospective user of this product outside the United States of America should, prior to such use, contact the government department or other agency responsible for assigning radio frequencies in the country in which use is proposed to determine whether such department or agency has any objection to operation of the product in the 2.4-2.4835 GHz band, and whether there are any other local devices generating signals in that band which might be expected to interfere with the operation of this product. The manufacturer shall not be responsible for any operation of this product which is in violation of local law, creates interference harmful to other local devices, or results in a malfunction of this product caused by outside interference. End User License Agreement Notice: Read below before installing and using this device. Installing and using this device indicates your acceptance of these terms and conditions. If you do not accept the terms, you must return the unused device and all related software immediately. You may not use, copy, modify, or transfer the enclosed device, related documenta- tion, or any software programs residing in or included with the device (collectively, the "product"), except as expressly provided in this license. Regulatory Information: iii License. The technology and intellectual property embodied in the Product (the "Technology") are licensed, not sold, to you. You have a nonexclusive and nontransfer- able right only to connect the Product to and to use the Technology with a single license control utility. You may not modify or make inoperable authorization keys or license control utilities. You may not transfer, sublicense or assign a license to the Prod- uct or the Technology to another party except in accordance with Solectek's Product License Transfer Policy in effect at the time of such license grant. You understand that the Technology belongs to Solectek or its third party licensors (col- lectively, "Solectek"), and they have the right to enforce this license. You agree to keep confidential and …

Text truncated - open the document above for the full version.

Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 3/15/00Solectek Corporation SkyWay Wireless LAN Bridge FCC ‘C’ Certification Report 99-244 (Rev. A)KA324WAN54 2.2 Solectek SkyWay Transceiver System Specifications Product Name:SkyWay Wireless LAN Bridge Serial Number:N/A (Pre-production) Type of Equipment:DSSS Transceiver Modulation:2 Mbits/s QPSK, 5.5 Mbits/s MOBK, 11 Mbits/s CCK Chip Rate:11Mchips/s Operating Frequency:2407 – 2470 MHz Number of Channels:11 Channels Channel Spacing:6 MHz Bandwidth (6dB OBW):12MHz maximum Power Rating:26dBm direct (High Power) 16dBm direct (Low Power) Antenna Gain:Accommodates Solectek issued antennas with gains ranging from 6dBi to 24dBi Emission Designation:Direct Sequence Spread Spectrum, 2.4GHz ISM Band Emission Designator:22MOX7D Oscillator Frequencies:32.768KHz, 44MHz, 50MHz, 560MHz (IF LO), 2160MHz (RF LO) 280MHz (IF), 2440MHz (RF)

i www.solectek.com SOLECTEK CORPORATION 6370 Nancy Ridge Dr. Suite 109 San Diego, CA 92121 858-450-1220 fax 858-457-2681 ii  Copyright Solectek Corporation 2000 All rights reserved. Reproduction, adaptation, or translation without prior written per- mission is prohibited, except as allowed under the copyright laws. Revision number 1.01 First edition, March 2000 Printed in USA The information contained in this document is subject to change without notice. Solectek Corporation makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties or merchantability and fitness for a particular purpose. Solectek Corporation shall not be liable for errors contained herein or for incidental or consequential damage in connection with the furnishing, performance, or use of this material. i Regulatory Information The SkyWay Series Wireless Bridge/Router operates in the 2.4 GHz band, complies with the IEEE 802.1D MAC bridging standard and supports SNMP monitoring if IP routing is enabled. Federal Communications Commission (FCC) Radio Frequency Interference Statement This device complies with Part 15 of FCC Rules. Operation of this device is subject to the following two conditions: • It may not cause harmful interference. • It must accept any interference that may cause undesired operation. Information to the User In order to comply with FCC RF exposure requirements, a minimum separation dis- tance of 27 in. must be maintained between the antenna and any persons. When installing the antenna, ensure that this clearance is maintained while the product is in operation. This device must be installed and used in strict accordance with the manufacturer's instructions. However, there is no guarantee that interference to radio communica- tions will not occur in a particular commercial installation. In case the device does cause harmful interference with an authorized radio service, the user/operator shall promptly stop operating the device until harmful interference has been limited. Solectek Corpo- ration is not responsible for any radio or television interference caused by unautho- rized modification of this device or the substitution or attachment of connecting cables and equipment other than specified by Solectek Corporation. The correction of inter- ference caused by such unauthorized modification, substitution, or attachment will be the responsibility of the user. ii Steps for minimizing or eliminating radio and television interference: • Change the channel • Reorient the radio or TV receiving antenna. • Relocate the computer and SkyWay Series Wireless Bridge/Router unit with respect to the receiver. • Plug the computer and SkyWay Series Wireless Bridge/Router into a different outlet so the computer and bridge/router are on different branch circuits. If necessary, consult the dealer or an experienced radio/TV technician for additional suggestions. You may find the booklet called “How to Identify and Resolve Radio-TV Interference Problems” prepared by the Federal Communications Commission help- ful. The booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, as stock number 004-000-00345-4. This product was FCC certified under test conditions that included the use of shielded I/O cables and connectors between system components. To be in compliance with FCC regulations, the user must use shielded cables and connectors and install them properly. Point-to-Point (CFR 15.247 b) Solectek ensures that its intentional radiators that operate in the ISM band (2.4 GHz) and that are configured with directional antennas for point-to-point use will always comply with FCC transmitter power mandates. This transmitter output power control does not diminish user’s or installer’s responsi- bility to ensure that the point-to-point system is used in the manner prescribed by the Code of Federal Regulations. This directive forbids and excludes the use of point-to- multipoint systems and omni-directional applications as well as multiple co-located intentional radiators. Radio Transmission Notice This product is a low power (less than 1 Watt), direct-sequence, spread-spectrum radio system pre-set to transmit and receive signals in the 2.4-2.4835 GHz frequency band. This product has been certified by the U.S. Federal Communications Commis- sion for use in the United States of America in that band. The manufacturer makes no representation as to the availability of the above-mentioned frequency band for such use in other countries. Any prospective user of this product outside the United States of America should, prior to such use, contact the government department or other agency responsible for assigning radio frequencies in the country in which use is proposed to determine whether such department or agency has any objection to operation of the product in the 2.4-2.4835 GHz band, and whether there are any other local devices generating signals in that band which might be expected to interfere with the operation of this product. Regulatory Information iii The manufacturer shall not be responsible for any operation of this product which is in violation of local law, creates interference harmful to other local devices, or results in a malfunction of this product caused by outside interference. End User License Agreement Notice: Read below before installing and using this device. Installing and using this device indicates your acceptance of these terms and conditions. If you do not accept the terms, you must return the unused device and all related software immediately. You may not use, copy, modify, or transfer the enclosed device, related documenta- tion, or any software programs residing in or included with the device (collectively, the “product”), except as expressly provided in this license. License. The technology and intellectual property embodied in the Product (the “Technology”) are licensed, not sold, to you. You have a nonexclusive and nontransf…

Text truncated - open the document above for the full version.

Solectek Corporation 6370 Nancy Ridge Dr., Suite 109 San Diego, CA 92121 Friday, December 10, 1999 Federal Communications Commission 7435 Oskland Mills Rd. Columbia, MD 21046 USA Subject:Request for withholding from the public the disclosure of schematic diagrams and system diagrams pursuant to an application for certification. Applicant:Solectek Corporation Product:Skyway Series Transceiver Model:KA324WAN5 Dear Sir, Solectek Corp. requests that both the schematic and block diagrams submitted within this application be withheld from public disclosure as per section 0.459 of the FCC rules. This request is made under the provisions of section 0.457(d) of the Commission’s rules and also section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding of documentation materials from public inspection to protect the applicant, (Solectek Corporation) as such disclosure might be harmful to the applicant and provide unjustified benefits to its competitors. Larry Butler VP Engineering Solectek Corporation

March 6, 2000 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Request for withholding from the public the disclosure of schematic diagrams, system diagrams and functional description pursuant to an application for certification APPLICANT: Solectek Corporation PRODUCT: SkyWay Series Transceiver MODEL: KA324WAN5 To Whom It May Concern: Solectek Corporation respectfully requests that the schematic and block diagrams, as well as the functional description submitted within this application be withheld from public disclosure as per Section 0.459 of the FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission’s rules and also Section 552(b)(4) of the Freedom of Information Act. These sections authorized the withholding of documentation materials from public inspection to protect the applicant (Solectek Corporation), as such disclosure might be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Larry Butler VP of Engineering

Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN51 EXTERIOR VIEW OF EUT WITH I/O CABLES ATTACHED Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN52 TOP VIEW OF EUT Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN53 BOTTOM VIEW OF EUT Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN54 END VIEW OF EUT SHOWING CONNECTORS Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN55 BOTTOM VIEW OF EUT SHOWING POLE-MOUNTING BRACKET Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN56 BOTTOM VIEW OF EUT SHOWING WALL-MOUNTING BRACKET Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN57 TOP VIEW OF LAMBDA AC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN58 BOTTOM VIEW OF LAMBDA AC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN59 TOP VIEW OF ARTESYN DC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN510 BOTTOM VIEW OF ARTESYN DC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN511 CLOSEUP VIEW OF ARTESYN DC POWER SUPPLY (LABELING)

Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN51 EXTERIOR VIEW OF EUT WITH I/O CABLES ATTACHED Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN52 TOP VIEW OF EUT Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN53 BOTTOM VIEW OF EUT Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN54 END VIEW OF EUT SHOWING CONNECTORS Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN55 BOTTOM VIEW OF EUT SHOWING POLE-MOUNTING BRACKET Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN56 BOTTOM VIEW OF EUT SHOWING WALL-MOUNTING BRACKET Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN57 TOP VIEW OF LAMBDA AC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN58 BOTTOM VIEW OF LAMBDA AC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN59 TOP VIEW OF ARTESYN DC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN510 BOTTOM VIEW OF ARTESYN DC POWER SUPPLY Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN511 CLOSEUP VIEW OF ARTESYN DC POWER SUPPLY (LABELING)

AB-CD-EF-1234-567 87654321 FCCID:KA324WAN5 CANADAXXXXXXXXXXX ThisdeviceiscertifiedtocomplywithPart15ofFCCRules.Operationissubjecttothetwoconditions: (1)thisdevicemaynotcauseharmfulinterference,and (2)thisdevicemustacceptanyinterferenceincludinginterferencethatmaycauseundesiredoperation ThisdeviceiscertifiedtocomplywithIndustryCanadaRulesRSS/CNR139.Operationissubjecttothe followingtwoconditions: (1)thisdevicemaynotcauseinterference,and (2)thisdevicemustacceptanyinterferenceincludinginterferencethatmaycauseundesiredoperation ofthedevice. Model:AB-CD-EF-1234-567 P/N:12345678 S/N:87654321 Voltage:100-240V@47-63Hz I.T.E. 52UK Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Exterior Photographs 99-244KA324WAN51 EUT LABEL PLACEMENT

Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN51 INTERIOR VIEW OF EUT WITH COVER REMOVED (Showing PCB and Power Supply Board) Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN52 TOP VIEW OF HIGH POWER ETHERNET PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN53 BOTTOM VIEW OF HIGH POWER ETHERNET PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN54 TOP VIEW OF HIGH POWER FIBER OPTIC PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN55 BOTTOM VIEW OF HIGH POWER FIBER OPTIC PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN56 TOP VIEW OF LOW POWER ETHERNET PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN57 BOTTOM VIEW OF LOW POWER ETHERNET PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN58 TOP VIEW OF LOW POWER FIBER OPTIC PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN59 BOTTOM VIEW OF LOW POWER FIBER OPTIC PCB Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN510 TOP VIEW OF ASTEC POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN511 BOTTOM VIEW OF ASTEC POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN512 TOP VIEW OF AVANSYS POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN513 BOTTOM VIEW OF AVANSYS POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN514 TOP VIEW OF CONDOR POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN515 BOTTOM VIEW OF CONDOR POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN516 TOP VIEW OF DATEL POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN517 BOTTOM VIEW OF DATEL POWER SUPPLY BOARD Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 259-7170 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 12/20/99Solectek Corporation SkyWay Wireless LAN Bridge Interior Photographs 99-244KA324WAN518 TOP VIEW OF LAMBDA AC POWER SUPPLY ASSEMBLY (Cover Removed)

SkyWay Series High Speed/Long Range Wireless Bridge/Router Features: v Up to 11 Mbps Wireless Data Rate (up to 64 Sub-Stations) v Links Distances of up to 30 Miles (48 Km) v Up to 4,000 ft (1.22 Km) of 10/100 Ethernet and RS-422 Connections v Bridging and Static IP Routing v Full SNMP Management v Fiber and Copper 10/100 Ethernet Options v Web-Based Management * v Remote Configuration via Telnet (over TCP/IP) * v Remote Software Updates via TFTP, X-modem, or Y-modem v Single, ruggedized, mast-mounted unit (UL Outdoor rated) v FCC, Industrie Canada, ETSI, and UL certified v Milspec connectors for reliable service v AC and DC power options Additional Features include: v RF Anti-Interference (Reed-Solomon Coding) * v RF Data Encryption (31 bits) v Bandwidth Mangement (Service Providers) v Minimum Guaranteed Bandwidth (Private Networks) v Voice over IP Support * v Routing Protocols such as RIP, RIPII, OSPF, IGMP and BGP4 * * Only available with 2nd release products SkyWay – A Full-Function Unit The SkyWay outdoor wireless bridge/router is capable of high speed data transfer for distances up to 30 miles (48 km) utilizing Solectek’s proven RF polling protocol. With SkyWay series products, there is no need for an indoor unit. SkyWay is user friendly, cost effective and can be easily mounted on a rooftop or on a mast or tower up to 4,000 feet. SkyWay Series’ industrial grade, ruggedized unit is impermeable and designed to withstand all harsh environments for extended periods. Point-to-Point or Multi-Point Applications SkyWay products can be used anywhere high speed data transfer or internet access is required including corporate offices, educational campuses, healthcare facilities, manufacturing, or retail. Configurations can be set for Point-to-Point or Multi-Point applications. Each SkyWay unit can function as a base station (central site), a substation (remote site), or either end of a point-to-point link. Solectek’s broad selection of FCC and Industrie Canada certified antennas ensures that desired radio coverage can be obtained. Bandwidth Allocation Solectek’s proprietary polling protocol allows for flexibility in bandwidth allocation. Separate models are designed for service providers and for private networks. Service Providers: With the bandwidth management feature, service providers can set bandwidth variations dependant on specific customer requirements and billing arrangements. Private Networks: For private networks, each remote location is guaranteed a minimum bandwidth a…
