KBRGSTU11Keyless Entry System for Cars

JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 400-90816R Issue Date : March 30, 2000 Page 1 of 17 EMI TEST REPORT JQA APPLICATION NO. : 400-90816R Model No. : KBRGSTU11 Type of Equipment : Keyless Entry System (Receiver) Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : KBRGSTU11 Applicant : Calsonic Kansei Corporation Address : 5-24-15 Minamidai, Nakano-ku, Tokyo 164-8602, Japan Manufacture : Calsonic Kansei Corporation Address : 5-24-15 Minamidai, Nakano-ku, Tokyo 164-8602, Japan Received date of EUT : March 7, 2000 Final Judgment : Passed TEST RESULTS IN THIS REPORT are obtained in use of equipment that is traceable to Electrotechnical Lab. of MITI Japan and Communications Research Lab. of MPT Japan. The test results only respond to the tested sample. It is not allowed to copy this report even partly without the allowance of the JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-90816R FCC ID :KBRGSTU11 Model No. :KBRGSTU11 Issue Date :March 30, 2000 Standard :CFR 47 FCC Rules Part 15 Page 2 of 17 JQA QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 6 1.4 EUT Modifications / Deviation from Standard 7 1.5 Test results / Uncertainty 8 1.6 Summary 9 1.7 Test Configuration / Operation of EUT 10 1.8 EUT Arrangement (Drawings) 11 1.9 Preliminary Test and Test-setup (Drawings) 12 – 14 1.10 EUT Arrangement (Photographs) 15 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N/A 2.2 Radiated Emission (Electric Field)30 MHz – 1000 MHz 16 – 17 C O P Y JQA Application No. :400-90816R FCC ID :KBRGSTU11 Model No. :KBRGSTU11 Issue Date :March 30, 2000 Standard :CFR 47 FCC Rules Part 15 Page 3 of 17 JQA QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and B (June 23, 1989) Superregenerative Receiver Test procedure : AC power line conducted emission and radiated emission tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers( 3 meters Site ). - Shielded Enclosure. Expiration date of FCC test facility filing : June 04, 2002 2) EMC Engineering Dept. Testing Div. is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2000) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : Keyless Entry System(Receiver) 2) Product Type : Pre-Production 3) Category : Low Power Communication Device Receiver 4) EUT Authorization : Certification 5) FCC ID : KBRGSTU11 6) Trade Name : NISSAN 7) Model No. : KBRGSTU11 8) Tuning Frequency Range : 315 MHz 9) Highest Frequency Used in the EUT : 304.3 10) Serial No. : None 11) Date of Manufacture : - 12) Power Rating : DC 12V 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-90816R FCC ID :KBRGSTU11 Model No. :KBRGSTU11 Issue Date :March 30, 2000 Standard :CFR 47 FCC Rules Part 15 Page 4 of 17 JQA QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan - Shielded Enclosure - Anechoic Chamber No. 2 (portable Type) Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 Sep. 1999 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/035 May 1999 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/030 Jun. 1999 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-6 Apr. 1999 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-855-2 Apr. 1999 1 Year - LISN KNW-407 Kyoritsu Electrical 8-757-1 Apr. 1999 1 Year - RF Cable 3D-2W Fujikura 155-21-005 Apr. 1999 1 Year - RF Cable 3D-2W Fujikura 155-21-006 Apr. 1999 1 Year - 50ohm Termination - SUHNER 154-06-501E0 Jan. 2000 1 Year - 50ohm Termination - SUHNER 154-06-502E0 Jan. 2000 1 Year C O P Y JQA Application No. :400-90816R FCC ID :KBRGSTU11 Model No. :KBRGSTU11 Issue Date :March 30, 2000 Standard :CFR 47 FCC Rules Part 15 Page 5 of 17 JQA QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(30 MHz – 1000 MHz) x - was performed in the following test site. - was not applicable. Test location : Safety Testing Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan x - Anechoic Chamber No. 2 (3 meters) - Anechoic Chamber No. 3 (3 meters) Validation of Site Attenuation : 1) Last Confirmed Date :March, 1999 2) Interval :1 year Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESV Rohde & Schwarz 872148/039 May 1999 1 Year - Test Receiver ESVS10 Rohde & Schwarz 826148/002 Jun. 1999 1 Year x - Test Receiver ESVP Rohde & Schwarz 881487/004 May 1999 1 Year - Test Receiver ESVP Rohde & Schwarz 881487/005 Dec. 1999 1 Year x - Antenna KBA-511A Kyoritsu Electrical 0-170-1 Nov. 1999 1 Year - Antenna KBA-511A Kyoritsu Electrical 0-201-13 Nov. 1999 1 Year x - Antenna KBA-611 Kyoritsu Electrical 0-147-14 Nov. 1999 1 Year - Antenna KBA-611 Kyoritsu Electrical 0-210-5 Nov. 1999 1 Year x - RF Cable 5D-2W Fujikura 155-21-001E0 Feb. 2000 1 Year - RF Cable 5D-2W Fujikura 155-21-002E0 Fe…
