Test report Our reference : 21JE0068-YW-1 Page: 2 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Table of Contents Page 1 GENERAL INFORMATION3 1.1 Product Description4 1.2 Test Specification4 1.3 Methods & Procedures4 1.4 Exclusion from satndards4 1.5 Test Location4 2 SYSTEM TEST CONFIGURATION5 2. 1 Operation Environment 5 2.2 Justification5 2. 3 EUT Exercise Software5 2.4 Test Procedure5 Figure 2.1 Configuration of Tested System6 3 MEASUREMENT PHOTOS7 Figure 3.1 Radiated Measurment Photos7 4 RADIATED EMISSION DATA8 4.1 Field Strength Calculation9 4.2 Measurement Uncertainty9 5 TEST EQUIPMENT USED10 APPENDIX11 A:Test Data 12-13 Test report Our reference : 21JE0068-YW-1 Page: 3 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1 GENERAL INFORMATION APPLICANT: Calsonic Kansei Corp. ADDRESS: 5-24-15 Minamidai,Nakano-Ku,Tokyo, Japan,164-8602 Tel: +81-3-5385-0111 Fax: +81-3-3383-1171 E-mail: [email protected] Contact Person : Yasuo Saruki REGULATION(S): FCC Part 15 Subpart B §15.109(a) MODEL NUMBER: TSTC15 FCC ID: KBRTSTC15 SERIAL NUMBER: PT1-32 KIND OF EQUIPMENT: Keyless Entry System (Receiver) TESTED DATE: June 1, 2001 RECEIPT DATE OF SAMPLE : May 24, 2001 REPORT FILE NUMBER: 21JE0068-YW-1 TEST SITE: A-PEX Yokowa No.3 Open Test Site Test report Our reference : 21JE0068-YW-1 Page: 4 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1.1 Product Description Model: TSTC15 (referred to as the EUT in this report) is a Keyless Entry System (Receiver). The specification is as following : Type of receiver: Super heterodyne Receiving Frequency: 315MHz Intermediate Frequency: 10.7MHz Antenna type: Integral copper wire antenna Operation Voltage: DC 12V(Regulated lead-acid battery) 1.2 Test Specification Test Specification: FCC Part 15 Subpart B § 15.109 Radiated emission limits Title: FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators 1.3 Methods & Procedures No.ItemTest ProcedureSpecificationRemarks 1Conducted emissionFCC/ANSI C63.4:1992 §15.107 - 2Radiated emissionFCC/ANSI C63.4:1992§15.109(a)3m 1.4 Exclusion from standards No.ItemTest ProcedureSpecificationRemarks 1Conducted emissionFCC/ANSI C63.4:1992§15.107- * This test was not performed since EUT dose not have AC power port. 1.5 Test Location A-PEX International Co.,Ltd. Yokowa No.3 test site 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 Japan Telephone number: +81-596-39-1485 Facsimile number: +81-596-39-0232 This site has been fully described in a report submitted to FCC office, and listed on September 12, 2000(Registration number: 90412) and it was accepted Industry Canada on May,2001(IC2973-3). *NVLAP Lab. code : 200109-0 Test report Our reference : 21JE0068-YW-1 Page: 5 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 2 SYSTEM TEST CONFIGURATION 2.1 Operation Environment Temperature: See data Humidity: See data Power supply: DC 12V 2.2 Justification The system was configured in typical fashion (as a customer would normally use it) for testing. 2.3 EUT Exercise Software The EUT exercise program used during radiated testing was designed to exercise the various system components in a manner similar to typical use. The sequence is used: Operation Mode : Receiving 2.4 Test Procedure Tabletop Equipment Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1.5m, raised 80cm above the conducting ground plane. Test was made with the antenna positioned in both the horizontal and vertical planes of polarization. The measurement antenna was varied in height above the conducting ground plane to obtain the maximum signal strength. The measurement distance was 3m. Test report Our reference : 21JE0068-YW-1 Page: 6 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Figure2.1 Configuration of Tested System Front View (A):EUT (C)(B) * Cabling was taken into consideration and test data was taken under worse case conditions. Top View (B) (A) (C) * Cabling was taken into consideration and test data was taken under worse case conditions. Description of EUT and Support Equipment No.ItemModel numberSerial numberManufacturerRemark AKeyless Entry System (Receiver) TSTC15PT1-32Calsonic Kansei Corp.EUT BKeyless Entry System (Transmitter) 174N/ACalsonic Kansei Corp.- CCar Battery38B19R1301975Shin-Kobe Electric Machinery Co.,Ltd. - List of cables used No.NameLength (m)ShieldRemark DC Power Cable 0.5N– Test report Our reference : 21JE0068-YW-1 Page: 7 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 3 MEASURMENT PHOTOS Figure 3.1 Radiated Measurement Photos Test report Our reference : 21JE0068-YW-1 Page: 8 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 4 RADIATED EMISSION DATA The initial step in collecting radiated data was a spectrum analyzer peak scan of the measurement range (30MHz-1000MHz). The final data was reported in the worst-case emissions. The minimum margin to the limit is as follows : AntReceiverCorrectionField FrequencyPolReadingFactorStrengthLimitMargin (MHz)(dB V) (dB)(dB V/m)(dB V/m) (dB)…

Text truncated - open the document above for the full version.

Test report Our reference : 21JE0068-YW-1 Page: 7 of 13 Issued date: June 4, 2001 FCC ID: KBRTSTC15 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 3 MEASURMENT PHOTOS Figure 3.1 Radiated Measurement Photos
