FCC ID: KJ8KYE-3725SW SECTION 5 PHOTOGRAPHS FCC ID: KJ8KYE-3725SW PHOTOS OF THE TESTED EUT The following photos are attached: Photo 1. EUT, Front View Photo 2. EUT, Front View, Cover Up Photo 3. EUT, Rear View, Cover Up Photo 4. Internal View, Top Side Photo 5. Internal View, Bottom Side FCC ID: KJ8KYE-3725SW Photo 1. EUT, Front View FCC ID: KJ8KYE-3725SW Photo 2. EUT, Front View, Cover Up FCC ID: KJ8KYE-3725SW Photo 3. EUT, Rear View, Cover Up FCC ID: KJ8KYE-3725SW Photo 4. Internal View, Top Side

SECTION 3 LABELING INFORMATION FCC ID: KJ8KYE-3725SW FCC ID: KJ8KYE-3725SW FCC ID: KJ8KYE-3725SW

FCC ID: KJ8KYE-3725SW Photo 4. Internal View, Top Side FCC ID: KJ8KYE-3725SW Photo 5. Internal View, Bottom Side FCC ID: KJ8KYE-3725SW

FCC ID: KJ8KYE-3725SW FCC ID: KJ8KYE-3725SW MEASUREMENT/TECHNICAL REPORT COMPANY NAME:Wayne Dalton Corporation MODEL:KEP1-0000 FCC ID:KJ8KYE-3725SW DATE:July 23, 1999 This report concerns (check one): Original grant X Class II change_____ Equipment type: Low Power Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? yes_____ No X If yes, defer until:_________________ date N.A. agrees to notify the Commission by N.A. date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: United States Technologies, Inc. 3505 Francis Circle Alpharetta, GA 30004 Phone Number: (770) 740-0717 Fax Number: (770) 740-1508 FCC ID: KJ8KYE-3725SW TABLE OF CONTENTS AGENCY AGREEMENT LETTER OF CONFIDENTIALITY SECTION 1 GENERAL INFORMATION Product Description SECTION 2 TESTS AND MEASUREMENTS Configuration of Tested Test Facility Test Equipment Modifications Periodic Operation Field Strength of Fundamental Emission Field Strength of Spurious Emissions 20 dB Bandwidth of Fundamental Emission Frequency Tolerance of Carrier Signal Radiated Digital Device Emissions Power Line Conducted Emissions SECTION 3 LABELING INFORMATION SECTION 4 BLOCK DIAGRAM(S)/SCHEMATICS SECTION 5 PHOTOGRAPHS SECTION 6 USER'S MANUAL FCC ID: KJ8KYE-3725SW LIST OF FIGURES AND TABLES FIGURES Test Configuration Photograph(s) for Spurious and Fundamental Emissions Field Strength of Fundamental Emission Field Strength of Spurious Emissions Bandwidth of Fundamental Emission TABLES EUT and Peripherals Test Instruments Field Strength of Fundamental Emission Field Strength of Spurious Emissions Bandwidth of Fundamental Emission Radiated Emissions Power Line Conducted Emissions FCC ID: KJ8KYE-3725SW SECTION 1 GENERAL INFORMATION FCC ID: KJ8KYE-3725SW GENERAL INFORMATION Product Description The Equipment Under Test (EUT) is a Wayne Dalton Corporation, Model KEP1-0000, 372.5 MHz Keyless Entry Transmitter. The EUT is a thirteen button transmitter with a keypad, and part of a system which connects to a garage door opener. The EUT incorporates an internal antenna which is etched directly into the PCB. Related Submittal(s)/Grant(s) The EUT will be used with a receiver (application already submitted and approved under FCC ID: KJ8SAR-3725GE). FCC ID: KJ8KYE-3725SW SECTION 2 TESTS AND MEASUREMENTS FCC ID: KJ8KYE-3725SW TESTS AND MEASUREMENTS Configuration of Tested System The sample was tested per ANSI C63.4, Methods of Measurement from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (1992). Conducted and radiated emissions data were taken with the test receiver or spectrum analyzer's resolution bandwidth adjusted to 9 kHz and 120 kHz, respectively. All measurements are peak unless stated otherwise. The video filter associated with the spectrum analyzer was off throughout the evaluation process. Interconnecting cables were manipulated as necessary to maximize emissions. A block diagram of the tested system is shown in Figure 1. Test configuration photographs for spurious and fundamental emissions are shown in Figure 2. Since the EUT is typically mounted to the wall, it was placed into a continuous mode of transmit and placed in an upright position. Test Facility Testing was performed at US Tech's measurement facility at 3505 Francis Circle, Alpharetta, GA. This site has been fully described and submitted to the FCC, and accepted in their letter marked 31040/SIT. Additionally this site has also been fully described and submitted to Industry Canada (IC), and has been approved under file number IC2982. Test Equipment Table 2 describes test equipment used to evaluate this product. MODIFICATIONS: No modification was made to bring the EUT into compliance with FCC Rules and Regulations. FCC ID: KJ8KYE-3725SW FIGURE 1 TEST CONFIGURATION EUT FCC ID: KJ8KYE-3725SW FIGURE 2A Photograph(s) for Spurious and Fundamental Emissions FCC ID: KJ8KYE-3725SW FIGURE 2B Photograph(s) for Spurious and Fundamental Emissions FCC ID: KJ8KYE-3725SW TABLE 1 EUT and Peripherals PERIPHERAL MANUFACTURER MODEL NUMBER SERIAL NUMBER FCC ID:CABLES P/D Keyless Entry Transmitter Wayne Dalton Corporation (EUT) KEP1-0000NoneKJ8KYE- 3725SW (Pending) None FCC ID: KJ8KYE-3725SW TABLE 2 TEST INSTRUMENTS TYPEMANUFACTURERMODELSN. SPECTRUM ANALYZERHEWLETT-PACKARD8593E3205A00124 SPECTRUM ANALYZERHEWLETT-PACKARD8558B2332A09900 S A DISPLAYHEWLETT-PACKARD853A2404A02387 COMB GENERATORHEWLETT-PACKARD8406A1632A01519 RF PREAMPHEWLETT-PACKARD8447D1937A03355 RF PREAMPHEWLETT-PACKARD8449B3008A00480 HORN ANTENNAEMCO31153723 ROBERTS ANTENNASCOMPLIANCE DESIGN A100167 BICONICAL ANTENNAEMCO31109307-1431 LOG PERIODIC ANTENNA EMCO31469110-3600 LISNSOLAR ELE.8028N/A THERMOMETERFLUKE525215250 MULTIMETERFLUKE8553710469 FUNCTION GENERATOR TEKTRONIXCFG250CFG250TW15059 PLOTTERHEWLETT-PACKARD7475A2325A65394 BILOGCHASECBL6112A2238 FCC ID: KJ8KYE-3725SW Periodic Operation (47 CFR 15.231(a1)) A transmitter manually activated must automatically deactivate within not more than 5 seconds of being released. The transmitter is a 13 button transmitter. The EUT continues to transmit while each button is being pressed. The EUT ceases transmission almost immediately upon being released and appears to finish the current packet being transmitted. Therefore the longest period of time the transmitter should take to deactivate is a packet length, or 52.25 msec as shown in Figure 3. FCC ID: KJ8KYE-3725SW FIGURE 3 Periodic Operation 15.231(a)(c1) FCC ID: KJ8KYE-3725SW Field Strength of Fundamental Emission (47 CFR 15.231b) Measurements were made using a peak detector. Field strength of the peak fundamental emission is shown in Table 3 and Figure 4. Duty Cycle Correction During 100 msec: Each function key sends a different series of characters, but each packet period (125.0 msec) never exceeds a series of 79* long (375.0 μs) and short (150.0 μs) pulses. Assuming any combination of short or long pulses may be obtained due to encoding the worse case …
