KNF-TX3G2Remote Control

SPAL USA
Remote Control - FCC ID KNF-TX3G2 - SPAL USA
Click to zoom

Application Details

Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Date of Grant
Jan 27, 2002
Application Purpose
Original Equipment
Date of Application
Jan 27, 2002
Equipment Note
Remote Control
Frequency Range
433.05000000 - 434.79000000
Company
SPAL USA
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗
↗

ID Label/Location Info

↗

Internal Photos

↗
↗
↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Letter of Agency Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Iowa Export - Import authorizes D.L.S. Electronic Systems, Inc. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. FCC Labeling Requirements and Information Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: KNF-TX3G2 The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Request for Confidentiality Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KNF-TX3G2 Please be advised that the following information is to be held confidential and behalf of APPLICANT NAME: • Block Diagram • Schematics • Parts Lists • External Photos • Internal Photos The application contains technical information which Iowa Export - Import deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Modification Letter Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue847-537-6488 Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KNF-TX3G2 Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. Change 1: There were no modifications made during testing. Change 2: Change 3: Change 4: Change 5: Change 6: Change 7: Change 8: Change 9 Change 10: Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Manufacturer’s Letter Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KNF-TX3G2 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

Cover Letter(s)

Letter of Agency Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that Iowa Export - Import authorizes D.L.S. Electronic Systems, Inc. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Signatory, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. FCC Labeling Requirements and Information Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: KNF-TX3G2 The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Request for Confidentiality Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KNF-TX3G2 Please be advised that the following information is to be held confidential and behalf of APPLICANT NAME: • Block Diagram • Schematics • Parts Lists • External Photos • Internal Photos The application contains technical information which Iowa Export - Import deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Modification Letter Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue847-537-6488 Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KNF-TX3G2 Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. Change 1: There were no modifications made during testing. Change 2: Change 3: Change 4: Change 5: Change 6: Change 7: Change 8: Change 9 Change 10: Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc. Manufacturer’s Letter Date: January 14, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KNF-TX3G2 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory Arnom C. Rowe EMC ENGINEER EMC-001375-NE D.L.S. Electronic Systems, Inc.

External Photos

Front of EUT/Buttons Back of EUT

External Photos

Front of EUT/Buttons Back of EUT

Internal Photos

Back Cover Removed Front Cover Removed Circuit Board Removed Circuit Board Component Side Circuit Board Button Side Inside Covers

Internal Photos

Back Cover Removed Front Cover Removed Circuit Board Removed Circuit Board Component Side Circuit Board Button Side Circuit Board with Battery Holder (metal) removed Inside Covers

Internal Photos

Back Cover Removed Front Cover Removed Circuit Board Removed Circuit Board Component Side Circuit Board Button Side Circuit Board with Battery Holder (metal) removed Inside Covers

Test Report

EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA TEST SPECIFICATION: FCC "Rules and Regulations", Part 15, Subpart C Sections 15.231 (a-d), 15.207 & 15.205 Intentional Radiators Periodic operation in the band 40.6 – 40.77 MHz & above 70 MHz THE FOLLOWING MEETS THE ABOVE TEST SPECIFICATION Formal Name: Remote Control TX3G2 Kind of Equipment: Low Power Transmitter Test Configuration: Stand Alone Transmitter FCC ID: KNF-TX3G2 Model Number: TX3G2 Serial Number: NA Dates of Test: October 11, 2001 Test Conducted For: Iowa Export Import 512 Tuttle Street Des Moines, Iowa 50309 NOTICE: Please see change information listed inside of this report. This report must not be used by the customer to claim product endorsement by NVLAP or any agency of the United States Government, and it cannot be reproduced (except in full), without the approval of D.L.S. Electronic Systems Inc. Page 1 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA SIGNATURE PAGE Report Written By: Arnom C. Rowe Test Engineer EMC-001375-NE Report Reviewed by: Jack Prawica Lab Manager Report Approved by: Brian J. Mattson General Manager Page 2 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA NVLAP Certificate of Accreditation available upon request. Page 3 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA TABLE OF CONTENTS i. Cover Page...........................................................................................................................1 ii. Signature Page.....................................................................................................................2 iv. NVLAP Scope of Accreditation..........................................................................................3 v. Table of Contents.................................................................................................................4 1.0 Summary of Test Report......................................................................................................5 2.0 Introduction..........................................................................................................................5 3.0 Object...................................................................................................................................5 4.0 Test Set-Up..........................................................................................................................6 5.0 Test Equipment....................................................................................................................6 6.0 Conducted Emission Measurements....................................................................................7 Appendix A – Conducted Data Taken During Testing........................................................8 Appendix A – Conducted Charts Taken During Testing.....................................................9 7.0 Field Strength of Spurious Emission Measurements.........................................................10 Radiated Spreadsheets for the Fundamental and Spurious Emission Measurements........12 Radiated Data for the Fundamental and Spurious Emission Measurements.....................17 8.0 Pulsed Operation (Duty Cycle Correction Factor).............................................................28 Pulsed Operation Graphs Taken During Testing...............................................................29 9.0 Bandwidths........................................................................................................................32 Graphs taken for the Fundamental Frequency and Bandwidth..........................................33 10.0 Restricted Bands................................................................................................................35 11.0 Photo Information and Test Set-Up...................................................................................36 12.0 Conducted Photos Taken During Testing..........................................................................37 12.0 Radiated Photos Taken During Testing.............................................................................38 13.0 Change Information...........................................................................................................41 14.0 Results of Tests..................................................................................................................42 15.0 Conclusion.........................................................................................................................42 TABLE 1 – EQUIPMENT LIST...................................................................................................43 Page 4 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA 1.0 SUMMARY OF TEST REPORT It was found that the Remote Control TX3G2 S/N NA “meets” the radio interference emission requirements of the FCC "Rules and Regulations", Part 15, Subpart C, Sections 15.231 (a-d), 15.207 and 15.205 for Intentional Radiators operating in the 433.92 MHz Frequency Band with periodic operation. This report contains the following number of pages. Text, Data Summary & Charts: 44 pages NOTE: The conducted emissions test was not required because the EUT is powered from a DC power source. It does not have a line cord to plug into the A.C. power line. 2.0 INTRODUCTION On October 11, 2001, a series of radio frequency interference measurements were performed on Low Power Transmitter, S/N NA. The tests were performed according to the procedures of FCC as stated in MP-1 “FCC Methods of Measurement for determining Compliance of Radio Control and Security Alarm Devices and Associated Receivers”. Tests were performed by personnel of D.L.S. Electronic Systems, Inc. who are responsible to Donald L. Sweeney, Senior EMC Engineer. 3.0 OBJECT The purpose of this series of tests was to determine if the …

Text truncated - open the document above for the full version.

Test Report

EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA TEST SPECIFICATION: FCC "Rules and Regulations", Part 15, Subpart C Sections 15.231 (a-d), 15.207 & 15.205 Intentional Radiators Periodic operation in the band 40.6 – 40.77 MHz & above 70 MHz THE FOLLOWING MEETS THE ABOVE TEST SPECIFICATION Formal Name: Remote Control TX3G2 Kind of Equipment: Low Power Transmitter Test Configuration: Stand Alone Transmitter FCC ID: KNF-TX3G2 Model Number: TX3G2 Serial Number: NA Dates of Test: October 11, 2001 Test Conducted For: Iowa Export Import 512 Tuttle Street Des Moines, Iowa 50309 NOTICE: Please see change information listed inside of this report. This report must not be used by the customer to claim product endorsement by NVLAP or any agency of the United States Government, and it cannot be reproduced (except in full), without the approval of D.L.S. Electronic Systems Inc. Page 1 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA SIGNATURE PAGE Report Written By: Arnom C. Rowe Test Engineer EMC-001375-NE Report Reviewed by: Jack Prawica Lab Manager Report Approved by: Brian J. Mattson General Manager Page 2 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA NVLAP Certificate of Accreditation available upon request. Page 3 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA TABLE OF CONTENTS i. Cover Page...........................................................................................................................1 ii. Signature Page.....................................................................................................................2 iv. NVLAP Scope of Accreditation..........................................................................................3 v. Table of Contents.................................................................................................................4 1.0 Summary of Test Report......................................................................................................5 2.0 Introduction..........................................................................................................................5 3.0 Object...................................................................................................................................5 4.0 Test Set-Up..........................................................................................................................6 5.0 Test Equipment....................................................................................................................6 6.0 Conducted Emission Measurements....................................................................................7 Appendix A – Conducted Data Taken During Testing........................................................8 Appendix A – Conducted Charts Taken During Testing.....................................................9 7.0 Field Strength of Spurious Emission Measurements.........................................................10 Radiated Spreadsheets for the Fundamental and Spurious Emission Measurements........12 Radiated Data for the Fundamental and Spurious Emission Measurements.....................17 8.0 Pulsed Operation (Duty Cycle Correction Factor).............................................................28 Pulsed Operation Graphs Taken During Testing...............................................................29 9.0 Bandwidths........................................................................................................................32 Graphs taken for the Fundamental Frequency and Bandwidth..........................................33 10.0 Restricted Bands................................................................................................................35 11.0 Photo Information and Test Set-Up...................................................................................36 12.0 Conducted Photos Taken During Testing..........................................................................37 12.0 Radiated Photos Taken During Testing.............................................................................38 13.0 Change Information...........................................................................................................41 14.0 Results of Tests..................................................................................................................42 15.0 Conclusion.........................................................................................................................42 TABLE 1 – EQUIPMENT LIST...................................................................................................43 Page 4 EMC Test Services Report No. 9371 1250 Peterson Drive, Wheeling, Illinois 60090, USA 1.0 SUMMARY OF TEST REPORT It was found that the Remote Control TX3G2 S/N NA “meets” the radio interference emission requirements of the FCC "Rules and Regulations", Part 15, Subpart C, Sections 15.231 (a-d), 15.207 and 15.205 for Intentional Radiators operating in the 433.92 MHz Frequency Band with periodic operation. This report contains the following number of pages. Text, Data Summary & Charts: 44 pages NOTE: The conducted emissions test was not required because the EUT is powered from a DC power source. It does not have a line cord to plug into the A.C. power line. 2.0 INTRODUCTION On October 11, 2001, a series of radio frequency interference measurements were performed on Low Power Transmitter, S/N NA. The tests were performed according to the procedures of FCC as stated in MP-1 “FCC Methods of Measurement for determining Compliance of Radio Control and Security Alarm Devices and Associated Receivers”. Tests were performed by personnel of D.L.S. Electronic Systems, Inc. who are responsible to Donald L. Sweeney, Senior EMC Engineer. 3.0 OBJECT The purpose of this series of tests was to determine if the …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Dan McNeal(QC/Engineering Manager)
[email protected]800-345-0327Fax: 800-654-7725

Technical Contact

DLS Eelctronics Systems IncArnom Rowe
[email protected]847-535-6400

1250 Peterson Drive · Wheeling, Illinois · United States

Test Firm

DLS Electronic Systems, Inc.William Stumpf
[email protected]847-537-6400Fax: 847-537-6488

Technical Specifications

#Rule PartsFrequency RangePower OutputEmission
115.231433.05 MHz - 434.79 MHz100.00 mW10K0A1D
Confidentiality
Long Term
