KRET70AVHF Transceiver

RF Technology Pty Ltd
VHF Transceiver - FCC ID KRET70A - RF Technology Pty Ltd
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Jul 04, 2000
Application Purpose
Original Equipment
Date of Application
Jul 04, 2000
Equipment Note
VHF Transceiver
Frequency Range
66.00000000 - 88.00000000
Company
RF Technology Pty Ltd
Country
Australia

Documents & Files

Select a file to view

Users Manual

↗
↗

Block Diagram

↗

External Photos

↗
↗
↗
↗

ID Label/Location Info

↗
↗

Internal Photos

↗
↗
↗
↗

Operational Description

↗

Parts List/Tune Up Info

↗

Schematics

↗
↗

Test Report

↗
↗
↗
↗
↗
↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Test Report

TABLE OF CONTENTS LIST APPLICANT: RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTD. & RF POWER OUTPUT PAGE 3......MODULATION CHARACTERISTICS PAGE 4......OCCUPIED BANDWIDTH PAGE 5......SPURIOUS EMISSIONS AT ANTENNA TERMINALS PAGE 6......FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 7......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 8......FREQUENCY STABILITY PAGE 9......LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE EXHIBIT 2.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 3A........EXTERNAL FRONT VIEW PHOTOGRAPH EXHIBIT 3B........EXTERNAL REAR VIEW PHOTOGRAPH EXHIBIT 3C........EXTERNAL LEFT SIDE PHOTOGRAPH EXHIBIT 3D........EXTERNAL RIGHT SIDE PHOTOGRAPH EXHIBIT 3E-3F.....INTERNAL COMPONENT SIDE PHOTOGRAPHS EXHIBIT 3G-3H.....INTERNAL SOLDER SIDE PHOTOGRAPHS EXHIBIT 4.........BLOCK DIAGRAM EXHIBIT 5A........EXCITER SCHEMATIC EXHIBIT 5B........PA SCHEMATIC EXHIBIT 6.........CRYSTAL SPECIFICATION EXHIBIT 7A-7U.....USER'S MANUAL - INCLUDES: CIRCUIT DESCRIPTION (7H-7L) TUNING PROCEDURE (7M-7O) EXHIBIT 8A........OCCUPIED BANDWIDTH PLOT - CW EXHIBIT 8B........OCCUPIED BANDWIDTH PLOT EXHIBIT 9.........AUDIO FREQUENCY RESPONSE GRAPH EXHIBIT 10A.......MODULATION LIMITING - 25 kHz CH -300 Hz EXHIBIT 10B.......MODULATION LIMITING - 25kHz CH -1000 Hz EXHIBIT 10C.......MODULATION LIMITING - 25kHz CH -3000 Hz APPLICANT: RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A DATE: 3 June 2000 REPORT #: T:\CUS\R\RFPTYLTD\RFT182U0\EXTRAS\182U0.RPT PAGE: TABLE OF CONTENTS GENERAL INFORMATION REQUIRED FOR TYPE ACCEPTANCE 2.1033 (C) (1) (2) RF TECHNOLOGY PTY., LTD. will sell the FCC ID: KRET70A VHF transceiver in quantity, for use under FCC RULES PART 90. RF TECHNOLOGY PTY., LTD. Unit 10, 8 Leighton Place HORNSBY NEW SOUTH WALES 2077 AUSTRALIA 2.1033 (C) TECHNICAL DESCRIPTION (1) ALLOWED AUTHORIZED BANDWIDTH = 20.0KHz. 90.209(b)(5) Bn = 2M + 2DK M = 3000 D = 4.5 K (Peak Deviation) K = 1 Bn = 2(3.0K) + 2(4.5K)(1) = 6.0K + 9.0K =15.0 K Type of Emission: 15KOF3E 21033(C)(5) Frequency Range: 66-88 MHz (6) Power Range and Controls: This UUT has a power output of 25 watts. (7) 2,1033(c)(b) Maximum Output Power Rating: 25.0Watts into a 50 ohm resistive load. (8) DC Voltages and Current into Final Amplifier: POWER INPUT FINAL AMPLIFIER ONLY POWER OUT 25.4 Vce Volts 13.6v Ice Amps 6.2 Pin Watts 83.0 2.1033(c)(9) The tune-up procedure is included in the service manual. 2.1033(c)(10) Schematics are included as Exhibits 5A-5B. APPLICANT: RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A DATE: 3 June 2000 REPORT #: T:\CUS\R\RFPTYLTD\RFT182U0\EXTRAS\182U0.RPT PAGE #: 1 2.1033(c)(11) Photograph or drawing of the label showing the FCC ID and the location of the label are shown in Exhibits 1 and 2. 2.1033(c)(12) Photographs completely documenting the radio are included as exhibits 3A-3H. 2.1033(c)(13) N/A This is for devices that use digital modulation. 2.1033(c)(14) The data required by 2.1046 through 2.1057 follows; 2.1046(a) RF power output. The test procedure used was TIA/EIA-603 S2.2.1. RF power is measured by connecting a 50 ohm, resistive wattmeter to the RF output connec- tor. With a nominal battery voltage of 13.8V, and the transmitter properly adjusted the RF output measures: INPUT POWER: (13.4V)(6.2A) = 83.00Watts OUTPUT POWER: 25.0Watts Efficiency: 30% 2.1046(a) RF power output. The test procedure used was TIA/EIA-603 S2.2.1. /---------------\ | Dummy | /-| Microphone | | | | | \---------------/ | | /------------\ /------------\ /---------\ | | | | STANDARD | | RF | | | Transmitter|-----------| TRANSMITTER|---| POWER | \-| under test | | LOAD | | METER | \------------/ \------------/ \---------/ APPLICANT: RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A DATE: 3 June 2000 REPORT #: T:\CUS\R\RFPTYLTD\RFT182U0\EXTRAS\182U0.RPT PAGE #: 2 2.1047(a) Modulation characteristics: AUDIO FREQUENCY RESPONSE The audio frequency response was measured in accordance with TIA/EIA Specification TIA/EIA-603 S2.2.6.2.1. The audio frequency response curve is shown in Exhibit 9. 2.1049 AUDIO LOW PASS FILTER Transmitters utilizing analog emissions and meets the requirements of paragraph 90.210(c) therefore no low-pass filter response in included. 2.1049 AUDIO INPUT VERSUS MODULATION The audio frequency input versus deviation was measured in accordance with TIA/EIA Specification 603 S2.2.6.2.1. with the follow- ing exceptions; starting with 1000Hz the input was increased well beyond the deviation changing. This measurement was repeated for the band limits and any frequency deemed appropriate. See Exhibits 10A-10C. /---------------\ /----------\ /----------\ | Dummy | | Audio | | RMS | /-| Microphone |--| Generator| /-| VOLTMETER| | | | \----------/ | \----------/ | \---------------/ | |----------------------------------/ | /------------\ /------------\ /---------\ | | | | STANDARD | | Test | | | Transmitter|-----------| TRANSMITTER|---| Receiver| \-| under test | | PROBE | | | \------------/ \------------/ \---------/ 1.The test receiver audio bandwidth was <50Hz to >20,000Hz. APPLICANT: RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A DATE: 3 June 2000 REPORT #: T:\CUS\R\RFPTYLTD\RFT182U0\EXTRAS\182U0.RPT PAGE #: 3 2.1049 Occupied bandwidth: 90.210 (c) (1) On any frequency removed from the center of the author- ize bandwidth by a displacement of (fd in kHz) of more than 5kHz but not more than 10kHz At least 83log(fd/5)dB. (2) On any frequency removed from the center of the author ize bandwidth by a displacement of (fd in kHz) of more than 10kHz but not more than 250%of the authorized bandwidth: At least 29log(fd2/11)dB. (3) On any frequency removed from the center of the author ize bandwidth by a displacement of (fd in kHz) of more than 250% of the authorized bandwidth: At least 43+ 10log(P) dB. See Exhibit 8A-8B. 2.1049 Occupied bandwidth: Using TIA/EIA 2.2.11 sideband Spectrum TIA/EIA-603 S2.2.11 was used to measure the occ…

Text truncated - open the document above for the full version.

Test Report

RF Technology Pty ., LTD KRET70A 0 5 10 15 20 25 30 35 40 100100010000 Frequency rms mVolts audio response RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A JOB # 182U0 EXHIBIT # 9

Test Report

Modulation Limiting RF Technology Pty., LTD. KRET 70A 0 1000 2000 3000 4000 5000 0 2040 6080100 rms Volts Deviation 300 Hz RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A JOB # 182U0 EXHIBIT # 10A

Test Report

Modulation Limiting RF Technology Pty., LTD KRET 70A 0 1000 2000 3000 4000 5000 051015202530 rms mVolts Deviation 1000 Hz RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A JOB # 182U0 EXHIBIT # 10B

Test Report

Modulation Limiting RF Technology Pty., LTD. KRET70A 0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 0 10203040 rms mVolts Deviation 3000 Hz RF TECHNOLOGY PTY., LTD. FCC ID: KRET70A JOB # 182U0 EXHIBIT # 10C

Contact Information

Applicant

Frank Romanin
[email protected]61-2 9484-1022Fax: 61-2 9484-1288

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
19066 MHz - 88 MHz25 W15K0F3E0.0005000000 %
Grant Notes
Grant Conditions � The antenna used for this transmitter must be fixed-mounted on outdoor permanent structures. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of �1.1307 (b)(3).
