KUTCSL2Remote Control Transmitter

GARAGE DOOR REMOTE CONTROL USER’S INSTRUCTIONS (MODEL : CSL-2) PROGRAMMING YOUR NEW TRANSMITTER 1. Open the case with a corn. 2. For code setting: With the receiver unit plugged in the AC outlet, press and hold the ‘learn’ button on the receiver and its LED light will flash. Then press the button on the transmitter until the receiver light stops flashing indicating it has learned the code. 3. Test the receiver unit with the transmitter. LIGHT Press the case to emit the light. BATTERY One 3 volt Lithium type (CR2032) battery included. WARNING If this transmitter triggers other garage doors in your neighborhood, change all your transmitters and receiver to a new code setting. DO NOT let children use the garage door transmitter without adult supervision. Children can injure themselves or others by the garage door. WARRANTY If, within one year from date of purchase, this product should become defective (except battery), due to faulty workmanship or materials, it will be repaired or replaced, without charge. Proof of purchase is required. FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CUSTOMER SERVICE Skylink will not be liable or responsible for any misuse or application of this product other than for its intended use. If you would like to order Skylink’s products or have difficulty getting them to work, please : 1. visit our FAQ section at www.skylinkhome.com or 2. email us at [email protected] (reply within 24 hours) or 3. call our toll free at 1-800-304-1187 from Monday to Friday, 9am to 5pm EST. Fax +800-286-1320 17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3 http://www.skylinkhome.com © 2005 SKYLINK TECHNOLOGIES INC.

Test Setup FCC ID : KUTCSL2 External Photo – Front External Photo - Rear

Test Setup FCC ID : KUTCSL2 Internal Photo - 1 (300MHz) Test Setup FCC ID : KUTCSL2 Internal Photo - 2 (300MHz) Internal Photo - 3 (300MHz) Test Setup FCC ID : KUTCSL2 Internal Photo – 4 (310MHz) Internal Photo – 5 (310MHz) Test Setup FCC ID : KUTCSL2 Internal Photo – 6 (318MHz) Internal Photo – 7 (318MHz) Test Setup FCC ID : KUTCSL2 Internal Photo – 8 (390MHz) Internal Photo – 9 (390MHz)

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2371 0521 Website: www.hk.intertek-etlsemko.com Capital Prospect Ltd. Application For Certification (FCC ID: KUTCSL2) Transmitter 0503246 DL/ Sandy Lee March 16, 2005 INTERTEK TESTING SERVICES FCC ID: KUTCSL2 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information EXHIBIT 9 : Confidentiality Request INTERTEK TESTING SERVICES FCC ID: KUTCSL2 ii MEASUREMENT/TECHNICAL REPORT Capital Prospect Ltd. - MODEL: MULTILINK CSL-2 FCC ID: KUTCSL2 March 16, 2005 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-08-03 Edition] provision. Report prepared by: Derek Leung Intertek Testing Services 2/F., Garment Center, 576, Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8539 Fax: 852-2371-0521 INTERTEK TESTING SERVICES FCC ID: KUTCSL2 iii Table of Contents 1.0 General Description..............................................................................................2 1.1 Product Description ..............................................................................................2 1.2 Related Submittal(s) Grants .................................................................................2 1.3 Test Methodology.................................................................................................3 1.4 Test Facility ..........................................................................................................3 2.0 System Test Configuration ...................................................................................5 2.1 Justification ..........................................................................................................5 2.2 EUT Exercising Software .....................................................................................5 2.3 Special Accessories .............................................................................................5 2.4 Equipment Modification ........................................................................................6 2.5 Measurement Uncertainty ....................................................................................6 2.6 Support Equipment List and Description ..............................................................6 3.0 Emission Results ..................................................................................................8 3.1 Field Strength Calculation ....................................................................................9 3.2 Radiated Emission Configuration Photograph ....................................................11 3.3 Radiated Emission Data.....................................................................................12 4.0 Equipment Photographs .....................................................................................17 5.0 Product Labelling ................................................................................................19 6.0 Technical Specifications ....................................................................................21 7.0 Instruction Manual ..............................................................................................23 8.0 Miscellaneous Information .................................................................................25 8.1 Measured Bandwidth .........................................................................................26 8.2 Discussion of Pulse Desensitization ...................................................................27 8.3 Calculation of Average Factor ............................................................................28 8.4 Emissions Test Procedures................................................................................29 9.0 Confidentiality Request ......................................................................................32 INTERTEK TESTING SERVICES FCC ID: KUTCSL2 iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf Test Report Timing Diagram timing.pdf Cover Letter Confidentiality Request request.pdf INTERTEK TESTING SERVICES FCC ID: KUTCSL2 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: KUTCSL2 2 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a Transmitter operating at 300, 310, 318 and 390MH…

Text truncated - open the document above for the full version.

300 MHz Bandwidth: 464 kHz 310 MHz Bandwidth: 478 kHz (Worst Case) 318 MHz Bandwidth: 468 kHz 390 MHz Bandwidth: 472 kHz

Test Setup FCC ID : KUTCSL2 Radiated Photo – Front Radiated Photo - Rear RADIATED Model No.: CSL-2 Job No.: 0503246 RADIATED Model No.: CSL-2 Job No.: 0503246
