KUTMD318LIGHTING REMOTE CONTROL

1. INTRODUCTION Dimmable Receiver Module Dimmable Receiver Module Model MD-318 TM Thank you for your purchase of a SkylinkHome lighting receiver, Dimmable Receiver Module Model MD-318. This Dimmable Receiver Module allows you to wirelessly turn on and off, dim and brighten different TM lighting fixtures with the SkylinkHome lighting transmitters. The Dimmable Receiver Module MD-318 can communicate with up to 8 transmitters, so user has the option to add more transmitters to the system, such as more remote controls, or motion sensors etc. TM All wireless signal communications within the SkylinkHome lighting system are based on rolling code technology to ensure highest security is used. The following items are included in this package: - Dimmable Receiver Module - Screws and Accessories 2. INSTALLATION “PROG” switch Press the desired button 1. Turn off power to the circuit at the circuit breaker of the lighting fixture that you plan on installing the Dimmable Receiver Module to. Remove the lighting fixture so the Live and Neutral wires are exposed. WARNING: Failure to turn off power at the circuit breaker can result in electrical shock causing severe or fatal injury. Note: Lighting Load The Dimmable Receiver Module is designed to operate maximum load of 300W at 120VAC. Do not connect loading that exceeds this maximum rating. 2. Follow the diagrams below to install the Dimmable Receiver Module with the 3 wires: Neutral, Live and Load. Use the provided screws to secure the Dimmable Receiver Module. 3. After all the wires are connected, ensure that all of the wire connectors are attached securely and there should be no exposed copper wiring. Straighten the antenna. 4. Secure the MD-318 to a flat surface by 2 screws or you may place it inside the lighting fixture. Install the lighting fixture back to the original configuration. 5. Turn the circuit breaker back on and turn on the wall switch that is used to operate this lighting fixture. 6. The light will be on and you should hear a single beep. The Dimmable Receiver Module is installed properly and you can begin programming transmitters to the Dimmable Receiver Module. 3. PROGRAMMING TRANSMITTERS In order to operate the Dimmable Receiver Module remotely with a trans- mitter, it must be programmed to the Dimmable Receiver Module. Each Dimmable Receiver Module can be operated by up to 16 different trans- mitters (or 16 different command signals). To program a transmitter into the Dimmable Receiver Module, follow the instructions below. 1. The Dimmable Receiver Module should be power off initially. This can be done by switching off the wall switch or circuit breaker of the lighting fixture. 2. Power on the Dimmable Receiver Module by switching on the wall switch or circuit breaker. You will hear beeping from the Dimmable Receiver Module and the light connected to the module should be on. The beeping indicates the Dimmable Receiver Module is now in programming mode and it will stay in this mode for 20 seconds. 3. Press the PROG button on the back of the transmitter with a sharp object. 4. Press the button on the transmitter that you would like to program into the Dimmable Receiver Module. 5. Once the transmitter is programmed, the light will be off, indicating you have successfully programmed the transmitter to the Dimmable Receiver Module. 6. You may operate the light with the programmed transmitter. Note: To program other transmitters/sensors (besides TC transmitter), please refer to the instructions of the transmitters/sensors. You may follow the same instructions to program additional transmitters or sensors to operate the Dimmable Receiver Module. CAUTION Installation is required and enclosed instructions must be followed carefully to all steps and notes. If you are uncertain or uncomfortable performing this installation, please consult a qualified electrician. This manual should also be retained for future reference. 4. OPERATING MODES The Dimmable Receiver Module can control the light in 2 different operating modes. 1) On / Off Mode - Allows operating the light either on and off, without dimming function. 2) Dimming Mode - Allows operating the light in on, off and dimming (dim / brighten) modes. Light must be either incandescent light and designated dimming compact fluorescent light. The factory default operating mode is on/off mode. However, if your light is dimmable, you may change the operating mode to Dimming Mode. To change the operating modes, please follow the instructions below. 1. Turn on the light by activating the programmed transmitter. 2. Press and hold onto a button on the transmitter that is programmed to the module for 10 seconds. 3. The light will flash. If it flashes once, that means it is in On / Off Mode. If the light flashes twice, that means it is in Dimming Mode. 4. Repeating step 3 above will toggle the setting between On / Off Mode and Dimming Mode. 5. ON / OFF OPERATION The MD-318 Dimmable Receiver Module allows on / off operation, when the programmed button is activate, it will transmit a signal to toggle its current status. For example, if a signal is received when the light is off, that signal will turn on the light. Note: If the Dimmable Receiver Module is installed on a ceiling lighting fixture, you can use the transmitter to operate the light remotely only if the wall switch is in the ON position. If the wall switch is off, no power is provided to the Dimmable Receiver Module and therefore, it cannot operate the light. In case the transmitter is misplaced, you can still operate the lighting fixture with the wall switch normally. Screws and Accessories ON OFF Remote Works Remote Does Not Work Before Installation Live (Usually Black) Load Live (Usually Black) Neutral (Usually White) Neutral (Usually White) (White) (Red) (Black) TM After Installation Input Voltage: 120VAC, 60Hz Maximum Load: 300W at 120AVC Operating Frequency: 318MHz Wiring: Neutral, Live, Load (18 AWG) 10. TECHNICAL SPECIFICATIONS 11. FCC The R…

Text truncated - open the document above for the full version.

CPL CAPITAL PROSPECT LTD. MODEL : MD-318 LABELING DIAGRAM DATE : SEPT 19, 2010 PAGE : 1 OF 1 REV: A PROPRIETARY INFORMATION LABEL SIZE : 35 X 15MM Assembled in China 120 Volts AC 60Hz 300 Watts FOR INDOOR USE ONLY No serviceable parts inside. REMOTE CONTROL X XXX ® Model : MD-318 Assembled in China 120 Volts AC 60Hz 300 Watts FOR INDOOR USE ONLY No serviceable parts inside. REMOTE CONTROL X XXX ® FCC ID : KUTMD318 Model : MD-318 IC : 4454A-MD318 FCC ID : KUTMD318 IC : 4454A-MD318

FCC Test Report E4064136301KY Type / Model Name: MD-318 Brand Name: SKYLINK Product Description: LIGHTING REMOTE CONTROL Applicant: Capital Prospect Limited FCC ID : KUTMD318 File No. E4064136301KY, page 2 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 FCC -- T E S T R E P O R T Test Report No. : E4064136301KY Oct 09,2010 ______________________________________________________________________________________________ Date of issue Type / Model Name: MD-318 Brand Name : SKYLINK Product Description： LIGHTING REMOTE CONTROL Applicant： Capital Prospect LTD. Address： Room 03, 13/F., Block B, Veristrong Ind. Centre, 34-36 Au Pui Wan Street, Fo Tan, N.T., Hong Kong Test Result according to the standards listed in clause 1 test standards: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. File No. E4064136301KY, page 3 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 Contents 1 TEST STANDARDS 4 2 SUMMARY 5 3 EQUIPMENT UNDER TEST 6 3.1 PHOTO DOCUMENTATION OF THE EUT 6 3.2 POWER SUPPLY SYSTEM UTILISED 7 3.3 SHORT DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) 7 4 TEST ENVIRONMENT 8 4.1 ADDRESS OF THE TEST LABORATORY 8 4.2 ENVIRONMENTAL CONDITIONS 8 4.3 STATEMENT OF THE MEASUREMENT UNCERTAINTY 8 5 TEST CONDITIONS AND RESULTS 9 5.1 RADIATED DISTURBANCE (ELECTRIC FIELD) 9 5.2 CONDUCTED DISTURBANCE 11 6 USED TEST EQUIPMENT AND ACCESSORIES 13 File No. E4064136301KY, page 4 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 1 TEST STANDARDS The tests were performed according to following standards: FCC Part 15 Subpart B:2007-9-20 Radio frequency devices-Unintentional Radiators ANSI C63.4:2003 Method of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz File No. E4064136301KY, page 5 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 2 SUMMARY GENERAL REMARKS: N/A FINAL ASSESSMENT: The equipment under test fulfils the FCC requirements cited in test standard listed in section 1. Date of receipt of test sample : Jan 07, 2010 Testing commenced on : Jun 10, 2010 Testing concluded on : Oct 09, 2010 Reviewed by: Prepared by: Ivan Toa Technical Manager Kidd Yang Engineer File No. E4064136301KY, page 6 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 3 EQUIPMENT UNDER TEST 3.1 Photo documentation of the EuT Front View Back View File No. E4064136301KY, page 7 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 3.2 Power supply system utilised Power supply voltage: AC 120V/60Hz 3.3 Short description of the Equipment under Test (EuT) The EuT is a 318MHz receiver and powered by AC 120V. The radio receiver is designed as a module to receive the signal from the transmitter. When the device receives the signal from the transmitter, It will responds to activate electronic switch. Number of tested samples: One Serial number: Not Labelled Dimensions: L: 7.6cm W: 7.0cm H: 2.0cm EuT operation mode: The equipment under test was operated during the measurement under the following conditions: - Operation mode 1: Maximum load + receiving mode - - EuT configuration: The following interface cables and peripheral devices were connected during the measurements: Interface cables: Interface cable Length Type Line Line termination [m] shieldedunshielded Power cable 1.2 2 wire   LISN Power cable 0.8 2 wire   To Lamp Peripheral devices: Kind of equipment Model and/or Manufacturer 300W Lamp(120V/60Hz) Philips File No. E4064136301KY, page 8 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 4 TEST ENVIRONMENT 4.1 Address of the test laboratory emitel (Shenzhen) Limited Building 2, 171 Meihua Road, Futian District, Shenzhen, 518049 China FCC Registration No.: 746887 4.2 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 86-106 kPa 4.3 Statement of the measurement uncertainty The data and results referenced in this document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities. The measurement uncertainty was calculated for all measurements listed in this test report acc. to CISPR 16-4-2 /11.2003 „Uncertainties, statistics and limit modelling – Uncertainty in EMC measurements“ and is documented in the quality system acc. to ISO 17025. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. The manufacturer has the sole responsibility of continued compliance of the device. File No. E4064136301KY, page 9 of 13 emitel (Shenzhen) Limited, Building 2, 171 Meihua Road, Futian District, Shenzhen, P.R.China 518049 F10_25_Rev5_0 Freigabe: 15.03.2006 5 TEST CONDITIONS AND RESULTS 5.1 Radiated disturbance (electric field) For test instruments and accessories used see section 6 Part I1. 5.1.1 Description of the test location Test location: Semi-Anechoic Chamber Test distance: 3m 5.1.2 Photo documentation of the test set-up 5.1.3 Test result The test was carried out in the following operation mode(s): - Maximum load +receiving mode Frequency range: 30MHz to 2000MHz Min. limit margin -18.6dB at 636.0MHz. The requirements are FULFILLED Remarks: 1) According to FCC part 15.33(b), sin…
