L7KTSPB-01UltraSite EDGE Base Transceiver Station

FCC Part 24 Sample Label Exhibit and Location (TSPB) Background color is white Text color is black Complies with Part 24, FCC rules. FCC ID : L7KTSPB-01 200% of Actual Size

FCC ID: L7KTSPB-01 October 8, 2001 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention:Applications Examiner Applicant:Nokia Inc. dba Nokia Networks 6000 Connection Drive, Irving , Texas 75039 Equipment:Nokia UltraSite EDGE 1900 MHz Base Station Transceiver Module FCC ID:L7KTSPB-01 Specification:for a 47 CFR 24 Licensed Certification Dear Examiner: The following application for Grant of Equipment Authorization is presented on behalf of Nokia Inc. dba Nokia Networks for the Licensed Certification of their Model: UltraSite EDGE 1900MHz Base Station (BTS) Transceiver Module. Enclosed, please find a complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR 24, for a Base Station (BTS) Transceiver Module. If you have any questions, please contact the undersigned, who is authorized to act as Agent. Sincerely, Chris Harvey, Director EMC Laboratory MET Laboratories, Inc. FCC ID: L7KTSPB-01 Met 11107- 2 -October 8, 2001 MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 ENGINEERING TEST REPORT in support of the Application for Grant of Equipment Authorization EQUIPMENT:Nokia UltraSite EDGE 1900 MHz Base Station FCC ID:L7KTSPB-01 Specification:47 CFR 24 On Behalf of the Applicant:Nokia Inc. dba Nokia Networks 6000 Connection Drive Irving, TX 75039 Manufacturer:Nokia Inc. dba Nokia Networks 6000 Connection Drive Irving, TX 75039 Manufacturer’s Mr. Steve Mitchell Representative Test Date(s):14-20 Aug. 2001 ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 24 of the FCC Rules under normal use and maintenance. ______________________ Liming Xu EMC Engineer, MET Laboratories FCC ID: L7KTSPB-01 EMC 11107- 3 -November 5, 2001 Summary of Test Results These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 24, of 47 CFR. All tests were conducted using measurement procedure ANSI C63.4-1992. Type of Submission/Rule Part: Original Filing/Part 24 EUT:Nokia Networks Ultrasite EDGE BTS Transceiver Module FCC ID:L7KTSPB-01 Type of Emissions:343KGXW (GMSK) 333KGXW (8PSK) RF Power output:GMSK :1.5 Watts at lowest channel of PCS band 1.4 Watts at highest channel of PCS band 37.0 Watts at all other chanels 8PSK 5.0Watts at lowest channel of PCS band 2.8 Watts at highest channel of PCS band 45.0Watts at all other chanels Frequency Range (MHz): 1850-1910 receive and 1930-1990 Transmit (1930.2-1989.8) Frequency Stability:+/- 20 Hz Summary of Test Data Name of TestFCC Rule Part/SectionResults Radiated Spurious Emissions2.1053; 24.238(a)Complies Occupied Bandwidth2.1049Complies RF Power Output2.1046; 24.232(a),(c)Complies Spurious Emissions at Antenna Terminals 2.1051; 24.238(a)Complies Spurious Emissions at Antenna Terminals Frequency Block Edges 2.1051; 24.238(b)Complies Frequency Stability over temperature variations 2.1055(a)(1)Complies Frequency Stability over supply Voltage variations 2.1055(d)(1)Complies Modulation Characteristics2.1047(a)Complies FCC ID: L7KTSPB-01 EMC 11107- 4 -November 5, 2001 1.0INTRODUCTION The following data is presented on behalf of the Applicant, Nokia Inc. dba Nokia Networks, as verification of the compliance of the Nokia Base Station (BTS) Transceiver Module, UltraSite EDGE 1900 MHz to the requirements of 47 CFR 24. 2.0TEST SITE All testing was conducted at MET Laboratories, Inc., 914 West Patapsco Avenue, Baltimore, Maryland 21230-3493. Radiated emissions measurements were performed on a three-meter semi-anechoic chamber (Equivalent to an Open Area Test Site, OATS). A complete site description is on file with the FCC Laboratory Division as 31040/SIT/MET. 3.0TEST EQUIPMENT USED ManufacturerEquipmentCalibration Due Date @ time of testing Cal. Interval Hewlett Packard8563A Spectrum Analyzer9/14/02annual EMCOBiconical Antenna 31043/21/02annual EMCOEMCO Log Periodic Antenna11/01/01annual EMCODouble Ridge Guided Horn2/27/02annual Hewlett Packard8594EM Analyzer1/8/02annual 4.0EQUIPMENT UNDER TEST CONFIGURATION The Base Station (BTS) Transceiver Module was configured with AC/DC power supply modules and an external PC to program the EUT to output a 8-PSK/GMSK Modulation type PCS RF signal. The EUT with host external computer was configured for maximum signal gain and bandwidth. The EUT was operated in a manner representative of the typical usage of the equipment. During all testing, system components were manipulated within the confines of typical usage to maximize each emission. 5.0TEST TYPE(S) 5.1Radiated Emissions: 47 CFR2.1053, , 24.238(a) 5.2Occupied Bandwidth: 47 CFR2.1049 5.3RF Power Output: 47 CFR 2.1046, 24.232(a), © 5.4Spurious Emission at Antenna Terminals: 47 CFR 2.1051, 24.238(a) 5.5Spurious Emission at Antenna Terminals at Frequency Block edges +/- 1 MHz, 47 CFR 2.1051, 24.238(b) 5.6Frequency Stability over temperature variations: 47 CFR 2.1055(a)(1) 5.7Frequency Stability over variations in supply voltage: 47 CFR 2.1055(d)(1) 5.8 Modulation Characteristics: 47 CFR 2.1047(a) FCC ID: L7KTSPB-01 EMC 11107- 5 -November 5, 2001 Po&[43%10Log(45)]'&13dBm 6.0TEST RESULTS 6.1TEST TYPE: Radiated Emissions 6.1.1TECHNICAL SPECIFICATION:2.1053; 24.238(a) 6.1.2TEST DATE(S):17 Aug. 2001 6.1.3MEASUREMENT PROCEDURES: As required by §2.1053, field strength of spurious radiation measurements were made in accordance with the general procedures of ANSI C63.4-1992 "Methods of Measurement of Radio-Noise Emissi…
