L7KWTRC-01PCS Base Station Transceiver

FCC ID Label for WTRC (FCC ID: L7KWTRC-01)

Nemko Test Report No.: 4L0356RUS1 Applicant: Nokia Inc. 6000 Connection Drive Irving, Texas 75039 Equipment Under Test: UltraSite WCDMA Base Station Transceiver Unit with FCC ID: L7KWTRC-01 In Accordance With: FCC Part 24, Subpart E Broadband PCS Base Station Transmitter Tested By: Nemko Dallas Inc. 802 N. Kealy Lewisville, Texas 75057-3136 Authorized By: Tom Tidwell, Frontline Manager Date: 7/9/04 Total Number of Pages: 30 Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 2 of 30 Table of Contents Section 1. Summary of Test Results.......................................................................... 3 Section 2. General Equipment Specification.............................................................. 5 Section 3. RF Power Output ...................................................................................... 7 Section 4. Occupied Bandwidth ................................................................................. 9 Section 5. Spurious Emissions at Antenna Terminals ............................................. 11 Section 6. Field Strength of Spurious...................................................................... 15 Section 7. Frequency Stability................................................................................. 18 Section 8. Test Equipment List................................................................................ 20 ANNEX A - TEST DETAILS .......................................................................................... 21 ANNEX B - TEST DIAGRAMS ...................................................................................... 27 Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 3 of 30 Section 1. Summary of Test Results Manufacturer: Nokia Model No.: UltraSite WCDMA Base Transceiver Station Model Supreme Indoor Serial No.: 3J041801083 General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 24, Subpart E. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. NONE Nemko Dallas Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Dallas Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 4 of 30 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT RF Power Output 24.232 100W Complies Occupied Bandwidth 24.238 Unspecified Complies Spurious Emissions at Antenna Terminals 24.238(a) -13 dBm Complies Field Strength of Spurious Emissions 24.238(a) -13 dBm E.I.R.P. Complies Frequency Stability 24.235 ± 0.05 ppm Complies Measurement uncertainty is expressed to a confidence level of 95%. Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 5 of 30 Section 2. General Equipment Specification Supply Voltage Input: 48 Vdc Frequency Bands: TX Block A : 1930 – 1945 MHz Block D : 1945 – 1950 MHz Block B : 1950 – 1965 MHz Block E : 1965 – 1970 MHz Block F : 1970 – 1975 MHz Block C : 1975 – 1990 MHz Frequency Bands: RX Block A : 1850 – 1865 MHz Block B : 1865 – 1870 MHz Block C : 1870 – 1885 MHz Block D : 1885 – 1890 MHz Block E : 1890 – 1895 MHz Block F : 1895 – 1910 MHz W-CDMA GSM NADC (4M23F9W) (200KG7W) (40K0DXW) Type of Modulation and Designator: Maximum No. of Carriers: 1 Output Impedance: 50 ohms Per channel:416.9 mW RF Output: Software Duplexer Fullband Band Selection: Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 6 of 30 System Description The BTS performs the radio function of the Base Station System (BSS), and is connected to the Radio Network Controller (RNC) via the Abis interface, and to Mobile Stations (MS) via the Air interface (Antenna). The BSC is further connected to the Mobile Switching Center (MSC) and the Operation and Maintenance Center (OMC). Setup for testing: The transmitter was set up according to 3GPP TS 25.141 Test Model 1 for all tests except frequency stability. 64 DPCHs at 30 ksps (SF=128) distributed randomly across the code space, at random power levels and random timing offsets, were defined to simulate a realistic operating scenario which may have high PAR (Peak-to-Average Ratio). The transmitter was set up according to 3GPP TS 25.141 Test Model 4 for the frequency stability tests. System Diagram Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 7 of 30 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 2.1046 TESTED BY: David Light DATE: 6/28/2004 Test Results: Complies. Measurement Data: Refer to attached plot Modulation Type Frequency (MHz) Measured Output Power (dBm) Measured Output Power (mW) WCDMA 1960 26.2 416.9 Equipment Used: 1036-1064-1042 Measurement Uncertainty: +/- 1.6 dB Temperature: 22 °C Relative Humidity: 55 % Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATIO…

Text truncated - open the document above for the full version.

Nemko Dallas, Inc. FCC PART 24, SUBPART E FCC ID: L7KWTRC-01 BROADBAND PCS BASE STATION TRANSMITTER EQUIPMENT: Supreme Indoor Test Report No.: 4L0356RUS1 Page 17 of 30 Photographs of Test Setup
