L7KTSTB-01UltraSite EDGE Base Transceiver Station

NOTICE: Please be sure the following exhibits have already been submitted for: Confirmation Number: TC760843 FCC ID: L7KTSTB-01 Click Here For Attachment Submission Instructions ID Label/Location Info External Photos Schematics Test Report Users Manual Internal Photos Parts List/Tune Up Info Operational Description Exhibit Type Confidential Description File File Format ID Label/Location Info gfedc label and locationBrowse... Adobe Acrobat PDF External Photos gfedc external photosBrowse... Adobe Acrobat PDF Schematics gfedcb schematicsBrowse... Adobe Acrobat PDF Test Report gfedc test reportBrowse... Adobe Acrobat PDF Users Manual gfedcb users manualBrowse... Adobe Acrobat PDF Internal Photos gfedcb internal photosBrowse... Adobe Acrobat PDF Parts List/Tune Up Info gfedcb tuning proceduresBrowse... Microsoft Word Operational Description gfedc descriptionBrowse... Adobe Acrobat PDF gfedc Browse... gfedc Browse... gfedc Browse... gfedc Browse... gfedc Browse... Send File(s) To FCC Mail your comments or suggestions (To: [email protected]) FCC - Federal Communications Commission -

FCC Part 22 Sample Label Exhibit and Location (TSTB) Background color is white Text color is black Complies with Part 22, FCC rules. FCC ID : L7KTSTB-01 200% of Actual Size

October 8, 2001 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention:Applications Examiner Applicant:Nokia Inc. dba Nokia Networks 6000 Connection Drive, Irving , Texas 75039 Equipment:Nokia UltraSite EDGE 800 MHz Base Station Transceiver Module FCC ID:L7KTSTB-01 Specification:for a 47 CFR 22 Licensed Certification Dear Examiner: The following application for Grant of Equipment Authorization is presented on behalf of Nokia Inc. dba Nokia Networks for the Licensed Certification of their Model: UltraSite EDGE 800MHz Base Station (BTS) Transceiver Module. Enclosed, please find a complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR 22, for a Base Station (BTS) Transceiver Module. If you have any questions, please contact the undersigned, who is authorized to act as Agent. Sincerely, Chris Harvey, Director EMC Laboratory MET Laboratories, Inc. FCC ID: L7KTSTB-01 Met 11107- 2 -October 8, 2001 MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 ENGINEERING TEST REPORT in support of the Application for Grant of Equipment Authorization EQUIPMENT:Nokia UltraSite EDGE 800 MHz Base Station FCC ID:L7KTSTB-01 Specification:47 CFR 22 On Behalf of the Applicant:Nokia Inc. dba Nokia Networks 6000 Connection Drive Irving, TX 75039 Manufacturer:Nokia Inc. dba Nokia Networks 6000 Connection Drive Irving, TX 75039 Manufacturer’s Mr. Steve Mitchell Representative Test Date(s):14-20 Aug. 2001 ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 22 of the FCC Rules under normal use and maintenance. _____________________________ Liming Xu EMC Engineer, MET Laboratories FCC ID: L7KTSTB-01 EMC 11107- 3 -November 5, 2001 Summary of Test Results These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 22 of 47 CFR. All tests were conducted using measurement procedure ANSI C63.4-1992. Type of Submission/Rule Part: Original Filing/Part 22 EUT:Nokia Networks UltraSite EDGE BTS Transceiver Module FCC ID:L7KTSTB-01 Type of Emissions:360KGXW (GMSK) 357KGXW (8PSK) RF Power output:GMSK : 40.0 Watts full power (some channels are documented as being reduced power in the Block Edge Power Section 6.5 of this report) 8PSK : 8PSK : 46.0Watts full power (some channels not documented as being reduced power in the Block Edge Power Section 6.5 of this report) Frequency Range (MHz): 824-849 receive and 869-894 Transmit ( 869.2-893.8) Frequency Stability:+/- 20Hz Summary of Test Data Name of TestFCC Rule Part/SectionResults Radiated Spurious Emissions2.1053 2.1057, 22.901(d) and 22.917(e). Complies Occupied Bandwidth2.1049, 22.901(d) ,22.917(e).Complies RF Power Output2.1046, 22.913(a).Complies Spurious Emissions at Antenna Terminals 2.1051,22.901(d) and 22.917(e). Complies Out of band emissions2.1051, 22.901(d) ,22.917(e).Complies Frequency Stability over temperature variations 2.1055(a)(1)Complies Frequency Stability over supply Voltage variations 2.1055(d)(1)Complies Modulation Characteristics2.1047(a)Complies FCC ID: L7KTSTB-01 EMC 11107- 4 -November 5, 2001 1.0INTRODUCTION The following data is presented on behalf of the Applicant, Nokia Inc. dba Nokia Networks, as verification of the compliance of the Nokia Base Station (BTS) Transceiver Module, UltraSite EDGE 800 MHz to the requirements of 47 CFR 22. 2.0TEST SITE All testing was conducted at MET Laboratories, Inc., 914 West Patapsco Avenue, Baltimore, Maryland 21230-3493. Radiated emissions measurements were performed in a three-meter semi-anechoic chamber. A complete site description is on file with the FCC Laboratory Division as 31040/SIT/MET. 3.0TEST EQUIPMENT USED ManufacturerEquipmentCalibration Due Date @ time of testing Cal. Interval Hewlett Packard8563A Spectrum Analyzer9/14/02annual EMCOBiconical Antenna 31043/21/02annual EMCOEMCO Log Periodic Antenna11/01/01annual EMCODouble Ridge Guided Horn2/27/02annual Hewlett Packard8594EM Analyzer1/8/02annual 4.0EQUIPMENT UNDER TEST CONFIGURATION The Base Station (BTS) Transceiver Module was configured with AC/DC power supply modules and an external PC to program the EUT to output a 8-PSK/GMSK Modulation type RF signal. The EUT with host external computer was configured for maximum signal gain and bandwidth. The EUT was operated in a manner representative of the typical usage of the equipment. During all testing, system components were manipulated within the confines of typical usage to maximize each emission. 5.0TEST TYPE(S) 5.1Radiated Emissions: 47 CFR2.1053, 2.1057, 22.901(d) and 22.917(e). 5.2Occupied Bandwidth: 47 CFR2.1049, 22.901(d) and 22.917(e). 5.3RF Power Output: 47 CFR 2.1046, 22.913(a). 5.4Spurious Emission at Antenna Terminals: 47 CFR 2.1051, 22.901(d) and 22.917(e). 5.5Out of band emissions: 22.901(d) and 22.917(e). 5.6Frequency Stability over temperature variations: 47 CFR 2.1055(a)(1) 5.7Frequency Stability over variations in supply voltage: 47 CFR 2.1055(d)(1) 5.8 Modulation Characteristics: 47 CFR 2.1047(a) FCC ID: L7KTSTB-01 EMC 11107- 5 -November 5, 2001 Po&[43%10Log(45)]'&13dBm 6.0TEST RESULTS 6.1TEST TYPE: Radiated Emissions 6.1.1TECHNICAL SPECIFICATION:2.1053, 2.1057, 22.901(d) and 22.917(e). 6.1.2TEST DATE(S):17 Aug. 2001 6.1.3MEASUREMENT PROCEDURES: As required by §2.1053, field strength of spurious radiation measurements were made in accordance with the general procedures of ANSI C63.4-1992 "Methods of Measur…
