LCG-FG-FXA52X-32XFieldgate FXA52X/32X series with GSM Module

Endress and Hauser SE Co. KG

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: May 12, 2004
Application Purpose: Original Equipment
Date of Application: May 12, 2004
Equipment Note: Fieldgate FXA52X/32X series with GSM Module
Frequency Range: 1850.20000000 - 1909.80000000
Company: Endress and Hauser SE Co. KG
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TI369F/00/en Technical Information Fieldgate FXA320, FXA520 Gateways / Interfaces Gateway for Remote Monitoring of Sensors and Actuators via Web Browsers Application Fieldgates enable remote monitoring of connected 4...20 mA sensors/actuators, either via telephone lines (analogue), Ethernet TCP/IP or mobile communications (GSM). The measured data is web compatible (HTTP, HTML, WML) and can, therefore, be analysed in the web browser without additional software. For remote diagnosis and remote configuration, HART sensors are suitable in conjunction with FXA520. Their integrated time control make Fieldgates suitable for all applications in which more distant measuring points have to be sporadically analysed. Configurable monitoring of limit values with alarm signalling via e- mail or SMS make it possible to react directly to changes on-site. The supported data transfer in XML format allows for simple further analysis and processing of the measured data, through to integration into complex planning systems. Your benefits • Communication via modem, Ethernet or GSM/GPRS • Uses standard Internet protocols (TCP/IP, http) • Simple configuration with web browsers without additional software • Visualisation via Internet/Intranet in the web browser and/or WAP mobile phone • Limit value monitoring with alarm signalling via e-mail or SMS • Synchronised time stamping of all measured values • XML data transfer allows for simple further processing of the measured data FXA320 • Optionally, four binary inputs with event counter function and frequency measurement • Two 4...20 mA current inputs with integrated loop power supply • Selectable active/passive current input (for 2-wire and 4-wire devices) • Integrated communication resistor (250 Ω) for configuration via Commubox FXA520 • Web server for remote monitoring of up to 30 measuring points • Up to 4 measured values can be displayed per device (HART) • Intrinsically safe version [EEx ia]IIC for applications in hazardous areas • Remote diagnosis and remote configuration of connected HART devices • Applicable in 4...20 mA SIL 2 Loops (IEC 61508) Fieldgate FXA320, FXA520 2Endress + Hauser Table of contents Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Vendor Managed Inventory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Remote maintenance of measuring equipment (FXA520 only) . . . . 3 Communication interface . . . . . . . . . . . . . . . . . . . . . . 4 Internet connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Telephone network (analogue) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Mobile communications network (GSM) . . . . . . . . . . . . . . . . . . . . 5 GPRS support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Function and system design. . . . . . . . . . . . . . . . . . . . . 6 Measuring system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Analogue 4...20 mA inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 RS-485 interface (FXA 520 only) . . . . . . . . . . . . . . . . . . . . . . . . 10 HART channel 1&2 (FXA 520 only) . . . . . . . . . . . . . . . . . . . . . . 11 Binary inputs (FXA 320 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Output signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Overvoltage category as per EN 61010 . . . . . . . . . . . . . . . . . . . . 11 Protection class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Supply voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Operating conditions: Installation . . . . . . . . . . . . . . . 13 Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Operating conditions: Environment . . . . . . . . . . . . . . 14 Mounting location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Permitted ambient temperatures . . . . . . . . . . . . . . . . . . . . . . . . . 14 Climatic and mechanic application class . . . . . . . . . . . . . . . . . . . 14 Ingress protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Electromagnetic compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . 14 Application in protection functions . . . . . . . . . . . . . . . . . . . . . . . 14 Mechanical construction . . . . . . . . . . . . . . . . . . . . . . 15 Design, dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Plug-in connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Human interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Operation concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Certificates and approvals . . . . . . . . . . . . . . . . . . . . . 21 CE mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

External Photos

CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 55 (69) Photograghs of EUT Photo No.: 01 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 56 (69) Photo No.: 02 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 57 (69) Photo No.: 03 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 58 (69) Photo No.: 04 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 59 (69) Photo No.: 05 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 60 (69) Photo No.: 06 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 61 (69) Photo No.: 07 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 62 (69) Photo No.: 08 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 63 (69) Photo No.: 09 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 64 (69) Photo No.: 101 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 65 (69) Photo No.: 11 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 66 (69) Photo No.: 12 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 67 (69) Photograghs of Test set - up Photo No.: 13 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 68 (69) Photo No.: 14 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 69 (69) Photo No.: 15

ID Label/Location Info

Label Information F ieldgate FXA520/320 docu:Label_Information_FCC.doc Confidential CSE 04/30/04 Manufacturer Endress +Hauser GmbH+Co. KG Hauptstr. 1 D 79689 Maulburg Germany TypesFieldgate FXA52X/32X series with integrated GSM Module FCC ID: LCG-FG-FXA52X-32X Dimensions in mm : Label Information F ieldgate FXA520/320 docu:Label_Information_FCC.doc Confidential CSE 04/30/04 Label Placement:

Internal Photos

RF Exposure Info

FCC ID: LCG-FG-FXA52X-32X Prediction of MPE limit at given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 2 4R PG S π = where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 – 1500 f/1500 30 1500 – 100.000 1.0 30 where f = frequency in MHz Prediction GSM 1900 Antenna Type: 0dBi Antenna / 2dBi Antenna Maximum peak output power at antenna input terminal: 29.8 dBm Maximum peak output power at antenna input terminal: 954,99 mW Antenna gain(typical): 2 dBi Maximum antenna gain: 1,58 numeric Prediction distance: 20 cm Prediction frequency: 1880 MHz MPE limit for uncontrolled exposure at prediction frequency: 1 2 cm mW Power density at prediction frequency: with Antenna Gain of 0dBi 0,190 2 cm mW Power density at prediction frequency: with Antenna Gain of 2dBi 0,301 2 cm mW The MPE limit specified above will not be reached with the specified configuration of the product with the specified antenna gain of 2 dBi. The product satifies RF Exposure compliance requirements.

Test Report

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 Saarbrücken Telefon: +49 (0)681 598-0 Telefax: - 9075 Test report No.: 2-3524-01-01/04 This test report consists of 69 pagesPage 1 (69) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 081/94-D0 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report No. : 2-3524-01-01/04 Endress + Hauser : Fieldgate FXA52x/32x FCC Part : 24 / 15 FCC ID : LCG-FG-FXA52X-32X CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 2 (69) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 3 (69) 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory The test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR registration number: TTI-P-G-081/94-D0 Listed by: Federal Communications Commission (FCC) Identification/Registration No : 90462 Accredited Bluetooth TM Test Facility (BQTF) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM 1.3Details of applicant Name :Endress+Hauser GmbH+Co. KG Street :Hauptstr. 1 City :79689 Maulburg Country :Germany Telephone:+49 7622 282042 Telefax :+49 7622 2815042 Contact :Christian Seiler Telephone+49 7622 282042 [email protected] 1.4 Application details Date of test : 2004-02-02 and 2004-02-06 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 4 (69) 1.5 Test item Type of equipment : GSM/GPRS 900, 1800, PCS 1900 Gateway for Remote Monitoring of Sensors and Actuators via Web Browsers Type designation: here: Fieldgate FXA320 (FXA 320- AA4BB) Manufacturer: see applicant Street: City: Country: Serial numbers: IMEI: Additional information : Frequency: 1850.2 – 1909.8 MHz Type of modulation: 300KGXW Number of channels : 300 (PCS1900) Antenna: see Test set up Power supply (AC): 85 – 253 V 50 / 60Hz Power supply (AC) (Test) : 110 V/ 60Hz Output power GSM 1900 : cond : 29.8 dBm Peak, rad: EIRP: 27.8 dBm (Burst) ERP: 25.65 dBm (Burst); Type of equipment: Temperature range : -30°C - +60°C FCC – ID: LCG-FG-FXA52x-32x Hardware: V1.00 Software: 01.01.01.-1 20031118 TEST SET-UP : • Temperature sensor TSM 187-A • EC part E12 - HART • Static binars input over Altra 27V DC • Triband antenna T Nr.: 52018396 (900;1800; 1900) E&H 1.6Test standards: FCC Part 24 Part 15 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 5 (69) 2 Technical test For Part 24 we use the substitution method ( TIA/EIA 603). All measurements in this report were performed in peak mode. The product is also able to work in GPRS mode 10. We made all measurements in PEAK – mode. In this mode there is no difference between GSM and GPRS. The only difference is in the value of modulation AVERAGE, that is 3 dB higher in GPRS – mode 10 than in GSM mode Remarks: We tested the FXA 320. There are no RF differences in behavior to the FXA 520 Test setup: The radiated measurements were performed with the build – in power supply. No deviations from the technical specification(s) were ascertained in the course of the tests performed. FINAL VERDICT: PASS Technical responsibility for area of testing : 2004-02-09RSC 8431Gillmann DateSectionNameSignature Technical responsibility for area of testing : 2004-02-09RSC 8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 6 (69) 2.2Test report TEST REPORT Test report no. : 2-3524-01-01/04 CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 7 (69) TEST REPORT REFERENCE LIST OF MEASUREMENTS PARAMETER TO BE MEASURED PAGE PART PCS 1900 POWER OUTPUT SUBCLAUSE § 24.2328 FREQUENCY STABILITY SUBCLAUSE § 24.23511 AFC FREQ ERROR VS. VOLTAGE12 AFC FREQ ERROR VS. TEMPERATURE13 EMISSIONS LIMITS SUBCLAUSE §24.23814 RECEIVER SPURIOUS RADIATION SUBCLAUSE § 15.10926 CONDUCTED SPURIOUS EMISSIONS31 BLOCK EDGE COMPLIANCE FOR BLOCK A AND C40 OCCUPIED BANDWIDTH SUBCLAUSE §2.98942 CONDUCTED EMISSIONS SUBCLAUSE § 15.107/20748 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS53 TEST SITE CETECOM ICT Services GmbH Test report No..: 2-3524-01-01/04Date: 2004.02.09Page 8 (69) REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 PART PCS 1900 POWER OUTPUT SUBCLAUSE § 24.232 Summary: This paragraph contains both average , peak output powers and EIRP measurements for the mobile station. In all cases, the peak output power is within the required mask (this mask is specified in the JTC standards, TIA PN3389 Vol. 1 Chap 7, and is no FCC requirement). Method of Measurements: The mobile was set up for the max. output power with pseudo random data modulation. The power was measu…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ralf Reimelt(R&D Radar Level Measurement)

[email protected]00497622281890Fax: 004976222815890

Technical Contact

Endress and Hauser GmbH and CoChristian Seiler

[email protected]

Hauptstrasse 1, · Maulburg · Germany

Test Firm

Cetecom ICT Services GmbHRalf Hoehn

[email protected]49-681-598-8455Fax: 49-681-598-8475

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	24E	1.85 GHz - 1.91 GHz	600.00 mW	300KGXW	28.0000000000 Hz

Confidentiality

Long Term

Grant Notes

Output power listed is EIRP. This device contains GSM 900MHz and GSM 1800MHz functions that are not operational in U.S. Territories. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Antennas used for this device must not exceed 2 dBi gain for mobile and fixed operating configurations.
