LCGFMR5XKFK-Band Level Probing Radar

D R A F T Application Continuous, non-contact level measurement of liquids, pastes and slurries Features FMR50 • Attractively-priced device for basic supply and storage applications as well as utility processes • Encapsulated PVDF or PP cladded horn antenna • Maximum measuring range: 30 m (98 ft); for version with enhanced dynamics: 40 m (131 ft) • Process connection : 1½" thread , mounting bracket or with slip-on flange • Temp. range: –40 to +130 °C (–40 to +266 °F) • Pressure range: –1 to +3 bar (–14.5 to +43.5 psi) • Accuracy: ± 2 mm Your benefits • Reliable measurement even for changing product and process conditions • Integrated data memory (HistoROM) for high availability • Intuitive operating menu in national languages for easy commissioning • Simple integration into control or asset management systems • Exact diagnostic and process information to assist fast decisions • International approvals for use in hazardous areas • 5-point linearity protocol • WHG and marine approvals • SIL2 according to IEC 61508, SIL3 in case of homogeneous or heterogeneous redundancy • System integration via HART/PROFIBUS PA (Profile 3.02)/FOUNDATION Fieldbus Technical Information Micropilot FMR50 Level radar Level measurement in liquids TI01039F/00/EN/01.12 71162666 D R A F T Table of contents Micropilot FMR50 2V. 1, Rev. 6, 4-10-2012Endress+Hauser Table of contents Important document information................3 Document conventions...........................3 Function and system design....................5 Measuring principle.............................5 Input.....................................7 Measured variable..............................7 Measuring range...............................7 Operating frequency............................10 Transmitting power............................10 Output...................................11 Output signal................................11 Signal on alarm...............................12 Linearization................................12 Galvanic isolation.............................12 Protocol-specific data...........................12 Power supply.............................16 Terminal assignment...........................16 Device plug connectors..........................23 Supply voltage...............................24 Power consumption............................26 Current consumption...........................26 Power supply failure............................27 Potential equalization...........................27 Terminals..................................27 Cable entries ................................27 Cable specification.............................27 Overvoltage protection..........................28 Performance characteristics...................29 Reference operating conditions.....................29 Maximum measured error........................29 Measured value resolution........................30 Reaction time................................30 Influence of ambient temperature...................30 Installation...............................31 Installation conditions...........................31 Measuring conditions...........................35 Installation in vessel (free space)....................36 Installation in stilling well........................39 Installation in bypass...........................42 Vessels with heat insulation.......................45 Environment..............................46 Ambient temperature range.......................46 Ambient temperature limits.......................46 Storage temperature............................47 Climate class................................47 Geometric height according to IEC61010-1 Ed.3..........47 Degree of protection............................47 Vibration resistance............................47 Cleaning the antenna...........................47 Electromagnetic compatibility (EMC).................48 Process..................................49 Process temperature range........................49 Process pressure range..........................49 Dielectric constant.............................49 Mechanical construction.....................50 Dimensions.................................50 Weight....................................53 Materials...................................53 Operability...............................57 Operating concept.............................57 Local operation...............................57 Operation with remote display and operating module FHX50..58 Remote operation.............................58 Integration in tank gauging system...................62 System integration via Fieldgate.....................63 Certificates and approvals....................64 CE mark...................................64 C-Tick symbol...............................64 Ex approval.................................64 Dual seal according to ANSI/ISA 12.27.01..............64 Functional Safety..............................64 Pressure Equipment Directive......................64 Marine certificate (in preparation)...................64 Radio standard EN302729-1/2.....................64 Radio standard EN302372-1/2.....................65 FCC / Industry Canada..........................65 CRN approval................................66 Track record................................66 Other standards and guidelines .....................66 Ordering information........................67 Ordering information...........................67 5-point linearity protocol (in preparation)...............67 Customized parametrization.......................68 Accessories...............................69 Device-specific accessories........................69 Communication-specific accessories..................72 Service-specific accessories........................73 System components............................73 Documentation............................74 Standard documentation.........................74 Supplementary documentation.....................74 Safety Instructions (XA)..........................74 Register…

Text truncated - open the document above for the full version.

D R A F T Application Continuous, non-contact level measurement of liquids, pastes and slurries Features FMR51: • Premium device for level measurements even under extreme conditions • Maximum measuring range: 40 m (131 ft); for version with enhanced dynamics: 70 m (230 ft) • Process connection: 1½" thread/Tri-Clamp/flange • Temp. range: –196 to +450 °C (–321 to +842 °F) • Pressure range: –1 to +160 bar (–14.5 to +2 320 psi) • Accuracy: ± 2 mm Features FMR52: • Premium device for aggressive media as well as for highest hygiene requirements (ASME BPE, USP Class VI) • Flush mounted, completely filled PTFE horn antenna • Maximum measuring range: 40 m (131 ft); for version with enhanced dynamics: 60 m (197 ft) • Process connection: Flush mounted with cladded flange; process connections for hygiene requirements (Tri-Clamp, DIN 11851) • Temp. range: –40 to +200 °C (–40 to +392 °F) • Pressure range: –1 to +16 bar (–14.5 to +232 psi) • Accuracy: ± 2 mm Your benefits • Reliable measurement even for changing product and process conditions • Integrated data memory (HistoROM) for high availability • Intuitive operating menu in national languages for easy commissioning • Simple integration into control or asset management systems • Exact diagnostic and process information to assist fast decisions • International approvals for use in hazardous areas • 5-point linearity protocol • WHG and marine approvals • SIL2 according to IEC 61508, SIL3 in case of homogeneous or heterogeneous redundancy • System integration via HART/PROFIBUS PA (Profile 3.02)/FOUNDATION Fieldbus Technical Information Micropilot FMR51, FMR52 Level radar Level measurement in liquids TI01040F/00/EN/01.12 71162672 D R A F T Table of contents Micropilot FMR51, FMR52 2V. 1, Rev. 8, 4-10-2012Endress+Hauser Table of contents Important document information................4 Document conventions...........................4 Function and system design....................6 Measuring principle.............................6 Input.....................................8 Measured variable..............................8 Measuring range...............................8 Operating frequency............................13 Transmitting power............................13 Output...................................14 Output signal................................14 Signal on alarm...............................15 Linearization................................15 Galvanic isolation.............................15 Protocol-specific data...........................15 Power supply.............................19 Terminal assignment...........................19 Device plug connectors..........................26 Supply voltage...............................27 Power consumption............................29 Current consumption...........................29 Power supply failure............................30 Potential equalization...........................30 Terminals..................................30 Cable entries ................................30 Cable specification.............................30 Overvoltage protection..........................31 Performance characteristics...................32 Reference operating conditions.....................32 Maximum measured error........................32 Measured value resolution........................33 Reaction time................................33 Influence of ambient temperature...................33 Influence of gas layer...........................33 Gas phase compensation with external pressure sensor (PROFIBUS PA, in preparation).....................34 Installation...............................35 Installation conditions...........................35 Measuring conditions...........................40 Installation in vessel (free space)....................41 Installation in stilling well........................44 Installation in bypass...........................47 Vessels with heat insulation.......................50 Environment..............................51 Ambient temperature range.......................51 Ambient temperature limits.......................51 Storage temperature............................58 Climate class................................58 Geometric height according to IEC61010-1 Ed.3..........59 Degree of protection............................59 Vibration resistance............................59 Cleaning the antenna...........................59 Electromagnetic compatibility (EMC).................59 Process..................................60 Process temperature range........................60 Process pressure range..........................60 Dielectric constant.............................60 Mechanical construction.....................61 Dimensions.................................61 Weight....................................66 Materials...................................66 Operability...............................71 Operating concept.............................71 Local operation...............................71 Operation with remote display and operating module FHX50..72 Remote operation.............................72 Integration in tank gauging system...................76 System integration via Fieldgate.....................77 Certificates and approvals....................78 CE mark...................................78 C-Tick symbol...............................78 Ex approval.................................78 Dual seal according to ANSI/ISA 12.27.01..............78 Functional Safety..............................78 Sanitary compatibility...........................78 AD2000...................................78 Pressure Equipment Directive......................78 Marine certificate (in preparation)...................78 Radio standard EN302729-1/2.....................78 Radio standard EN302372-1/2.....................79 FCC / Industry Canada..........................79 CRN approval................................80 Track record................................80 Other standards and guidelines ..............…

Text truncated - open the document above for the full version.

D R A F T Application Continuous, non-contact level measurement in powdery to granular bulk solids Features FMR56: • Attractively-priced basic device for standard process conditions, as for example in bulk cargo silos and storage tanks • PP-cladded horn antenna • Maximum measuring range: 30 m (98 ft) • Process connection: Mounting bracket or slip-on flange with variable flange seal for alignment • Temperature range: –40 to +80 °C (–40 to 176 °F) • Pressure range: –1 to +3 bar (–14.5 to +43.5 psi) • Accuracy: ± 3 mm Features FMR57: • Premium device for highly demanding solid applications; ideally suited for measurements in high silos, bunkers and stockpiles • Horn or parabolic antenna • Air purge connection integrated • Maximum measuring range: 70 m (230 ft) • Process connection: 1½" thread or flange • Temperature range: –40 to +400 °C (–40 to 752 °F) • Pressure range: –1 to +16 bar (–14.5 to +232 psi) • Accuracy: ± 3 mm Your benefits • Reliable measurement even for changing product and process conditions • Integrated data memory (HistoROM) for high availability • Intuitive operating menu in national languages for easy commissioning • Simple integration into control or asset management systems • Exact diagnostic and process information to assist fast decisions • International approvals for use in hazardous areas • 5-point linearity protocol • SIL2 according to IEC 61508, SIL3 in case of homogeneous or heterogeneous redundancy • System integration via HART/PROFIBUS PA (Profile 3.02)/FOUNDATION Fieldbus Technical Information Micropilot FMR56, FMR57 Level radar Level measurement in bulk solids TI01042F/00/EN/01.12 71162681 D R A F T Table of contents Micropilot FMR56, FMR57 2V. 1, Rev. 6, 19-10-2012Endress+Hauser Table of contents Important document information................3 Document conventions...........................3 Function and system design....................5 Measuring principle.............................5 Input.....................................7 Measured variable..............................7 Measuring range...............................7 Operating frequency............................8 Transmitting power.............................8 Output....................................9 Output signal.................................9 Signal on alarm...............................10 Linearization................................10 Galvanic isolation.............................10 Protocol-specific data...........................10 Power supply.............................14 Terminal assignment...........................14 Device plug connectors..........................21 Supply voltage...............................22 Power consumption............................24 Current consumption...........................24 Power supply failure............................25 Potential equalization...........................25 Terminals..................................25 Cable entries ................................25 Cable specification.............................25 Overvoltage protection..........................26 Performance characteristics...................27 Reference operating conditions.....................27 Maximum measured error........................27 Measured value resolution........................27 Reaction time................................28 Influence of ambient temperature...................28 Installation...............................29 Installation conditions...........................29 Measuring conditions...........................36 Installation in vessel (free space)....................37 Vessels with heat insulation.......................46 Environment..............................47 Ambient temperature range.......................47 Ambient temperature limits.......................47 Storage temperature............................51 Climate class................................51 Geometric height according to IEC61010-1 Ed.3..........51 Degree of protection............................51 Vibration resistance............................51 Cleaning the antenna...........................51 Electromagnetic compatibility (EMC).................52 Process ..................................53 Process temperature range........................53 Process pressure range..........................53 Dielectric constant.............................53 Mechanical construction.....................54 Dimensions.................................54 Weight....................................61 Materials...................................62 Operability...............................67 Operating concept.............................67 Local operation...............................67 Operation with remote display and operating module FHX50..68 Remote operation.............................68 System integration via Fieldgate.....................72 Certificates and approvals....................73 CE mark...................................73 C-Tick symbol...............................73 Ex approval.................................73 Dual seal according to ANSI/ISA 12.27.01..............73 Functional Safety..............................73 AD2000...................................73 Pressure Equipment Directive......................73 Marine certificate (in preparation)...................73 Radio standard EN302729-1/2.....................73 Radio standard EN302372-1/2.....................74 FCC / Industry Canada..........................74 CRN approval................................75 Track record................................75 Other standards and guidelines .....................75 Ordering information........................76 Ordering information...........................76 5-point linearity protocol (in preparation)...............76 Customized parametrization.......................77 Accessories...............................78 Device-specific accessories........................78 Communication-specific accessories..................81 Service-specific accessories..................…

Text truncated - open the document above for the full version.
