LCGFMR5XKTTank Level Probing Radar

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT Level measurement in liquids Application • Continuous, non-contact level measurement of liquids, pastes and slurries • Encapsulated PVDF or PP cladded horn antenna • Maximum measuring range: 40 m (131 ft) • Process temperature: –40 to +130 °C (–40 to +266 °F) • Process pressure: –1 to +3 bar (–14.5 to +43.5 psi) • Accuracy: ± 2 mm • International explosion protection certificates; WHG; marine approvals • Linearity protocol (3-point, 5-point) Your benefits • Reliable measurement even for changing product and process conditions • HistoROM data management for easy commissioning, maintenance and diagnostics • Highest reliability due to Multi-Echo Tracking • SIL2 according to IEC 61508, SIL3 in case of homogeneous or heterogeneous redundancy • Seamless integration into control or asset management systems • Intuitive user interface in national languages •Bluetooth® wireless technology for commissioning, operation and maintenance via free iOS / Android app SmartBlue • Easy proof test for SIL and WHG • Heartbeat Technology™ Products SolutionsServices Technical Information Micropilot FMR50 Free space radar unbekannt unbekannt DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT Micropilot FMR50 2V. 10, Rev. 2, 1-10-2019Endress+Hauser Table of contents Wichtige Hinweise zum Dokument..............4 Symbols....................................4 Terms and abbreviations........................6 Registered trademarks..........................7 Function and system design...................8 Measuring principle............................8 Input....................................10 Measured variable............................10 Measuring range.............................10 Operating frequency..........................13 Transmitting power...........................13 Output..................................14 Output signal...............................14 Signal on alarm..............................15 Linearization...............................15 Galvanic isolation............................15 Protocol-specific data..........................15 Power supply.............................20 Terminal assignment ..........................20 Device plug connectors.........................28 Supply voltage..............................29 Power consumption...........................31 Current consumption..........................31 Power supply failure..........................32 Potential equalization.........................32 Terminals.................................32 Cable entries ...............................32 Cable specification............................32 Overvoltage protection.........................33 Performance characteristics..................34 Reference operating conditions...................34 Maximum measured error.......................34 Measured value resolution......................35 Reaction time...............................35 Influence of ambient temperature.................35 Installation...............................36 Installation conditions.........................36 Measuring conditions..........................39 Installation in vessel (free space)..................40 Installation in stilling well.......................44 Installation in bypass..........................46 Container with heat insulation....................48 Environment..............................49 Ambient temperature range.....................49 Ambient temperature limits.....................49 Storage temperature..........................50 Climate class...............................50 Altitude according to IEC61010-1 Ed.3..............50 Degree of protection..........................51 Vibration resistance...........................51 Cleaning the antenna..........................51 Electromagnetic compatibility (EMC)...............51 Process..................................52 Process temperature, Process pressure..............52 Dielectric constant............................52 Mechanical construction....................53 Dimensions................................53 Weight...................................58 Materials: GT19 housing (plastic)..................59 Materials: GT20 housing (die-cast aluminum, powder- coated)...................................60 Materials: Antenna and process connection...........61 Materials: Weather protection cover................62 Operability...............................63 Operating concept............................63 Local operation..............................64 Operation with remote display and operating module FHX50...................................64 Operation via Bluetooth® wireless technology..........65 Remote operation............................66 Integration in tank gauging system.................69 SupplyCare inventory management software..........70 Certificates an approvals....................73 CE mark...................................73 RoHS.....................................73 RCM-Tick marking............................73 Ex approval................................73 Dual seal according to ANSI/ISA 12.27.01............73 Functional safety.............................73 WHG.....................................73 Pressure equipment with allowable pressure ≤ 200 bar (2 900 psi)..........................73 Radio standard EN302729......................74 Radio standard EN 302372......................75 FCC......................................75 Industry Canada.............................75 Japanese radio approval........................75 CRN approval...............................75 Track record................................76 Test, Certificate..............................77 Hard-copy product documentation.................77 Other standards and guidelines...................78 Ordering information.......................79 Ordering information..........................79 3-point linearity protocol.......................80 5-point linearity protocol.....................…

Text truncated - open the document above for the full version.

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT Level measurement in liquids Application • Continuous, non-contact level measurement of liquids, pastes and slurries • Horn antenna (FMR51); flush mounted, completely filled PTFE horn antenna (FMR52) • Maximum measuring range: 70 m (230 ft) • Process temperature: –196 to +450 °C (–321 to +842 °F) • Process pressure: –1 to +160 bar (–14.5 to +2 320 psi) • Accuracy: ± 2 mm • International explosion protection certificates; WHG; marine approvals • Linearity protocol (3-point, 5-point) Your benefits • Reliable measurement even for changing product and process conditions • HistoROM data management for easy commissioning, maintenance and diagnostics • Highest reliability due to Multi-Echo Tracking • SIL2 according to IEC 61508, SIL3 in case of homogeneous or heterogeneous redundancy • Seamless integration into control or asset management systems • Intuitive user interface in national languages •Bluetooth® wireless technology for commissioning, operation and maintenance via free iOS / Android app SmartBlue • Easy proof test for SIL and WHG • Heartbeat Technology™ Products SolutionsServices Technical Information Micropilot FMR51, FMR52 Free space radar unbekannt unbekannt DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT Micropilot FMR51, FMR52 2V. 10, Rev. 3, 1-10-2019Endress+Hauser Table of contents Wichtige Hinweise zum Dokument.............. 4 Symbols....................................4 Terms and abbreviations........................6 Registered trademarks..........................7 Function and system design................... 8 Measuring principle............................8 Input....................................10 Measured variable............................10 Measuring range.............................10 Operating frequency..........................15 Transmitting power...........................15 Output..................................16 Output signal...............................16 Signal on alarm..............................17 Linearization...............................17 Galvanic isolation............................17 Protocol-specific data..........................17 Power supply.............................22 Terminal assignment ..........................22 Device plug connectors.........................30 Supply voltage..............................31 Power consumption...........................33 Current consumption..........................33 Power supply failure..........................34 Potential equalization.........................34 Terminals.................................34 Cable entries ...............................34 Cable specification............................34 Overvoltage protection.........................35 Performance characteristics..................36 Reference operating conditions...................36 Maximum measured error.......................36 Measured value resolution......................37 Reaction time...............................37 Influence of ambient temperature.................37 Influence of gas layer..........................37 Gas phase compensation with external pressure sensor (PROFIBUS PA, FOUNDATION Fieldbus).............38 Installation...............................39 Installation conditions.........................39 Measuring conditions..........................43 Mounting cladded flanges.......................44 Installation in vessel (free space)..................44 Installation in stilling well.......................48 Installation in bypass..........................51 Container with heat insulation....................53 Environment..............................54 Ambient temperature range.....................54 Ambient temperature limits.....................54 Storage temperature..........................62 Climate class...............................63 Altitude according to IEC61010-1 Ed.3..............63 Degree of protection..........................63 Vibration resistance...........................63 Cleaning the antenna..........................63 Electromagnetic compatibility (EMC)...............63 Process..................................64 Process temperature, Process pressure..............64 Dielectric constant............................66 Mechanical construction....................67 Dimensions................................67 Weight...................................77 Materials: GT18 housing (stainless steel, corrosion- resistant)..................................78 Materials: GT19 housing (plastic)..................79 Materials: GT20 housing (die-cast aluminum, powder- coated)...................................80 Materials: Antenna and process connection...........81 Materials: Weather protection cover................83 Operability...............................84 Operating concept............................84 Local operation..............................85 Operation with remote display and operating module FHX50...................................85 Operation via Bluetooth® wireless technology..........86 Remote operation............................87 Integration in tank gauging system.................90 SupplyCare inventory management software..........91 Certificates an approvals....................94 CE mark...................................94 RoHS.....................................94 RCM-Tick marking............................94 Ex approval................................94 Dual seal according to ANSI/ISA 12.27.01............94 Functional safety.............................94 WHG.....................................94 Sanitary compatibility.........................94 NACE MR 0175 / ISO 15156.....................95 NACE MR 0103.............................95 Pressure equipment with allowable pressure ≤ 200 bar (2 900 psi)..........................95 Marine certificate............................95 Radio standard EN302729......................95 Radio standard EN 302372......................96 FCC..........................…

Text truncated - open the document above for the full version.

Trade Register Munich HRB 85742 VAT ID No. DE129484267 Information pursuant to Section 2(1) DL-InfoV (Germany) at www.tuev-sued.de ed.com/imprint Managing Directors: Dr. Peter Havel (CEO) Dr. Jens Butenandt Patrick van Welij Phone: +49 (0) 9421 55 22-0 Fax: +49 (0) 9421 55 22-99 www.tuev-sued.de TÜV SÜD Product Service GmbH Äußere Frühlingstraße 45 94315 Straubing Germany TÜV SÜD Product Service RESPONSIBLE FOR NAME DATE SIGNATURE Project Management Matthias Stumpe 2020-02-05 SIGN-ID 326500 Authorised Signatory Markus Biberger 2020-02-05 SIGN-ID 326509 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD Product Service document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with CFR 47, Part 15, Subpart C and ISED RSS-Gen Issue 5 March 2019 Amendment 1, RSS-211 Issue 1 March 2015. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing Matthias Stumpe 2020-02-05 SIGN-ID 326500 Laboratory Accreditation DAkkS Reg. No. D-PL-11321-11-02 Laboratory recognition Registration No. BNetzA-CAB-16/21-15 Industry Canada test site registration 3050A-2 EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with CFR 47, Part 15, Subpart C and ISED RSS-Gen Issue 5 March 2019 Amendment 1, RSS-211 Issue 1 March 2015. Report on the FCC and IC Testing of the Endress+Hauser SE+Co.KG K-Band Level Probing Radar. Model: FMR50T / FMR51T In accordance with CFR 47, Part 15, Subpart C and ISED RSS-GEN Issue 5, RSS-211 Issue 2 Prepared for: Endress+Hauser SE+Co.KG Hauptstraße 1 79689 Maulburg Germany FCC ID: LCGFMR5XKT IC : 2519A-5KT COMMERCIAL-IN-CONFIDENCE Date: 2020-02-05 Document Number: TR-20351-65854-02 | Issue: 05 Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 59 Contents 1 Report Summary ......................................................................................................................... 2 1.1 Report Modification Record ........................................................................................................... 2 1.2 Introduction .................................................................................................................................... 2 1.3 Brief Summary of Results ............................................................................................................. 3 1.4 Product Information ....................................................................................................................... 4 1.5 Deviations from the Standard ........................................................................................................ 8 1.6 EUT Modification Record .............................................................................................................. 8 1.7 Test Location ................................................................................................................................. 9 2 Test Setups ................................................................................................................................ 10 3 Test Details ................................................................................................................................ 14 3.1 AC Power Line Conducted Emissions ........................................................................................ 14 3.2 Fundamental Emission 99% Bandwidth ..................................................................................... 17 3.3 Frequency stability ...................................................................................................................... 19 3.4 Unwanted emissions ................................................................................................................... 26 3.5 Restricted bands of operation ..................................................................................................... 47 3.6 Exposure of Humans to RF Fields .............................................................................................. 56 4 Measurement Uncertainty ........................................................................................................ 57 Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 59 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 2019-09-24 2 RSS-211 added to test report 2019-11-29 3 “Radar mounted to the tank” added to the Operation Mode and Test Setup 3.2.4 RSS-211 added to test report Chapter “Test Setups” added to test report 2019-12-16 4 Clause 5.3 of RSS-211 added to the Brief Summary of Results Limitation table of clause 5.3 added into the section 3.4 2019-12-17 5 Chapter “Exposure of Humans to RF Fields” revised”. 2020-02-05 Table 1 1.2 Introduction Applicant Endress+Hauser SE+Co.KG Manufacturer Endress+Hauser SE+Co.KG Model Number(s) FMR50T, FMR51T Serial Number(s) N/A Hardware Version(s) N/A Software Version(s) N/A Number of Samples Tested 2 Test Specification/Issue/Date CFR 47, Part 15, Subpart C ISED RSS-Gen Issue 5 March 2019 Amendment 1 RSS-211 Issue 1 March 2015 Test Plan/Issue/Date --- Order Number Date 120/1017713879 2019-07-16 Date of Receipt of EUT 2019-07-30 Start of Test 2019-07-30 Finish of Test 2019-12-04 Name of Engineer(s) Matthias Stumpe Related Document(s) ANSI C63.10 (2013) KDB 890966 D01 Meas level Probing Radars v01r01 Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 59 1.3 Brief Summary of Results A brief sum…

Text truncated - open the document above for the full version.

Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 30 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB/m 17853.326667 --- 60.01 63.50 3.49 2.5 1000.000 150.0 V 290.0 48 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 8.2G 10G18G Level in dBμV/m Frequency in Hz Preview Result 2V-AVGPreview Result 1V-PK+Preview Result 2H-AVG Preview Result 1H-PK+FCC 15.209 (1m) PKFCC 15.209 (1m) AV Final_Result PK+Final_Result AVG Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 31 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB 24890.795455 --- 53.88 63.50 9.62 2.5 1000.000 150.0 V 126.0 40.4 25148.886364 57.27 --- 83.50 26.23 2.5 1000.000 150.0 V 126.0 40.4 0 10 20 30 40 50 60 70 80 90 18 19 20 21 22 23 24 25 2626.5 Level in dBμV/m Frequency in GHz Preview Result 2V-AVGPreview Result 1V-PK+Preview Result 2H-AVG Preview Result 1H-PK+FCC 15.209 (1m) PKFCC 15.209 (1m) AV Final_Result PK+Final_Result AVG FCC 15.209 (1m) AV Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 32 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB/m 38807.950000 --- 53.02 63.50 10.48 2.5 1000.000 150.0 H 278.0 44 38995.600000 60.85 --- 83.50 22.65 2.5 1000.000 150.0 V 159.0 44 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 26.5 28 30 32 34 36 38 40 Level in dBμV/m Frequency in GHz Preview Result 2H-AVGPreview Result 1H-PK+Preview Result 2V-AVG Preview Result 1V-PK+FCC 15.209 (1m) PKFCC 15.209 (1m) AV Final_Result PK+Final_Result AVG Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 33 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB/m 41033.750000 --- 70.20 75.60 5.40 2.5 1000.000 150.0 V 0.0 44 41053.125000 73.98 --- 95.60 21.62 2.5 1000.000 150.0 H 142.0 44 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 40 42 44 46 48 50 52 54 56 58 60 Level in dBμV/m Frequency in GHz Preview Result 2H-AVGPreview Result 1H-PK+Preview Result 2V-AVG Preview Result 1V-PK+FCC 15.209 (0.25m) PKFCC 15.209 (0.25m) AV Final_Result PK+Final_Result AVG Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 34 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB 60000.000000 79.67 --- 95.60 15.93 2.5 1000.000 150.0 V 225.0 47.8 60016.875000 --- 75.26 75.60 0.34 2.5 1000.000 150.0 H 228.0 47.8 10 20 30 40 50 60 70 80 90 100 60 65 70 75 80 85 90 Level in dBμV/m Frequency in GHz Preview Result 2V-AVGPreview Result 1V-PK+Preview Result 2H-AVG Preview Result 1H-PK+FCC 15.209 (0.25m) PKFCC 15.209 (0.25m) AV Final_Result PK+Final_Result AVG Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 35 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB/m 107584.444445 83.04 --- 109.56 26.52 2.5 1000.000 150.0 V 216.0 50 107660.888889 --- 80.53 89.56 9.03 2.5 1000.000 150.0 H 33.0 50 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 90 95 100 105 110 Level in dBμV/m Frequency in GHz Preview Result 2H-AVGPreview Result 1H-PK+Preview Result 2V-AVG Preview Result 1V-PK+FCC 15.209 (5cm) PKFCC 15.209 (5cm) AV Final_Result PK+Final_Result AVG Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 36 of 59 EUT: P3 in TLPR operation (radar mounted to tank) Normal operation mode: Measurement with pulsed signal, Radar mounted to the tank -10 0 10 20 30 40 50 60 70 80 90 100 110 120 130 9k203050100k200 3005001M2M 3M5M10M20 30M Level in dBμV/m Frequency in Hz Preview Result 1-QPKFCC 15.209 mag (10 m) Final_Result QPKFinal_Result CAV Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 37 of 59 Final Results: Frequency QuasiPeak Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dB ms kHz cm deg dB 232.680000 17.11 46.00 28.89 1000.0 120.000 110.0 V -154.0 13.7 0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 30M 5060 80100M200300400500 8001G Level in dBμV/m Frequency in Hz Preview Result 1V-PK+Preview Result 1H-PK+ FCC 15.209_3mFinal_Result QPK Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 38 of 59 Final Results: Frequency MaxPeak CAverage Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB 8170.250000 --- 43.01 53.98 10.97 1000.0 1000.000 392.0 H 39.0 46.7 8170.250000 56.62 --- 73.97 17.35 1000.0 1000.000 392.0 H 39.0 46.7 0 10 20 30 40 50 60 70 80 90 100 1G2G3G4G5G67 8.2G Level in dBμV/m Frequency in Hz Preview Result 2H-AVGPreview Result 1H-PK+Preview Result 2V-AVG Preview Result 1V-PK+FCC 15.209 3 m PKFCC 15.209 3 m AV Final_Result PK+Final_Result CAV Document Number: TR-20351-65854-02 | Issue: 05 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 39 of 59 Final Results: Frequency MaxPeak Average Limit Margin Meas. Time Bandwidth Height Pol Azimuth Corr. MHz dBμV/m dBμV/m dBμV/m dB ms kHz cm deg dB 17848.426667 --- 59.92 63.50 3.58 2.5 1000.000 150.0 V 0.0 47.9 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 8.2G 10G18G Level in dBμV/m Frequency in Hz Preview Result 2H-AVGPreview Result 1H-PK+Preview Result 2V-AVG Preview Result 1V-PK+FCC 15.209 (1m) PKFCC 15.209 (1m) AV Final_Result PK+Final_Result AVG Document Number: TR-20351-65854-02 | Issu…

Text truncated - open the document above for the full version.

Document Number: Annex TR-20351-65854-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 5 1 Annex to the report TR-20351-65854-02 1.1 Equipment Under Test (EUT)# Figure 1 – EUT P1 (FMR50 with antenna Horn 40mm/1-1/2", PVDF encapsulated) Document Number: Annex TR-20351-65854-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 5 Figure 2 – EUT P3 (FMR51 with antenna Horn 40mm/1-1/2") Document Number: Annex TR-20351-65854-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 5 1.2 Test Setup Photos Figure 3- Test setup for radiated emission on EUT Figure 4 - Test setup for radiated emission on EUT Document Number: Annex TR-20351-65854-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 4 of 5 Figure 5 - Test setup for radiated emission on EUT Figure 6 - Test setup for radiated emission on EUT Document Number: Annex TR-20351-65854-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 5 of 5 Figure 6 - Test setup for radiated emission on EUT Figure 7 - Test setup for radiated emission on EUT
