LEMGTM-56KM656Kbps Modem Board

User’s Guide For GTM-56KM6 Faxmodem NOTICE Information furnished by Garnet Systems Coporation is believed to be accurate and reliable. However, no responsibility is assumed by Garnet Systems Corporation for its use, nor any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent rights of Garnet Systems Corporation other than for circuitry embodied in Garnet Systems products. Garnet Systems reserves the right to change circuitry at any time without notice. This document is subject to change without notice. MNP is a resistered trademark of Microcom Inc. Windows is a resistered trademark of Microsoft Corporation. K56flex is a trademark of Rockwell International and Lucent Technologies . Garnet Systems Co.,Ltd. GTM-56KM6 User's Guide INTRODUCTION Garnet systems FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: GTM-56KM6 User's Guide INTRODUCTION Garnet systems - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Warning: You are cautioned that any change or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate such equipment. NOTE: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to insure compliance. GTM-56KM6 User's Guide INTRODUCTION Garnet systems Table of Contents 1. INTRODUCTION. ..............................................................3 2. INSTALLATION.................................................................5 2.1 INSTALLINGT THE MODEM.......................................5 2.2 PLUG AND PLAY FUNCTION.....................................7 2.3 DRIVER INSTALLATION IN WINDOWS 95/98 /98SE........7 2.4 HOW TO VERIFY MODEM INSTALLATION..................10 2.5 REMOVAL OF THE MODEM DRIVER..........................12 3. MODEM COMMAND AND S-RESISTER................................13 3.1 AT COMMAND.........................................................13 3.2 S-REGISTER............................................................15 GTM-56KM6 User's Guide INTRODUCTION Garnet systems 3 1. INTRODUCTION The Garnet Systems GTM-56KM6 Host Software Processed V.90/K56flex Modem Device Family supports high speed analog data, high speed fax operation over the PSTN world-wide and is offered i n several device models. Modem data pump and controller functions, traditionally enabled using dedicated hardware, are processed in a Pentium MMX-compatible CPU using host-signal processing modem software which is included in the SoftK56 modem. Refer to the Product Release Notice for the feature set available. In ITU-T V.90/K56flex data mode, the modem can receive data at speeds up to 56 kbps from a digitally connected V.90 or K56flex-compatible central site modem. A V.90/K56flex modem takes advantage of the PSTN which is primari ly digital except for the client modem to central office local loop and are ideal for applications such as remote access to an Internet Service Provider (ISP), on-line service, or corporate site. In this mode, the modem can transmit data at speeds up to V.34 rates. In V.34 data mode, the modem operates at li ne speeds up to 33.6 kbps. When applicable, error correction (V.42/MNP 2-4) and data compression (V.42 bis/MNP 5) maximi ze data transfer i ntegrity and boost average data throughput. Non-error-correcting mode is also supported. Fax Group 3 send and receive rates are supported up to 14.4 kbps, with T.30 protocol. GTM-56KM6 User's Guide FEATURES Garnet systems 4 FEATURES • Data modem - ITU-T V.90, K56flex, V.34 (33.6 kbps), V.32 bis, V.32, V.22 bis, V.22, V.23, and V.21; Bell 212A and 103 - V.42 LAPM and MNP 2-4 error correction - V.42 bis and MNP 5 data compression - V.25 ter (Annex A) and EIA/TIA 602 command set • Fax modem - V.17, V.29, V.27 ter, and V.21 ch 2 - EIA/TIA 578 C lass 1 and T.31 Class 1.0 commands • System compatibilities - Windows 95, Windows 95 OSR2, Windows 98, Windows NT 4.0, Windows 2000 operating systems - Microsoft's PC 98 Design Ini tiative compliant - Unimodem/V compliant • 32-bit PCI Local Bus interface - Conforms to the PC I Local Bus Specification, Production Version, Revision 2.1 - PCI Bus Mastering interface to the LVC - 33 MHz PC I clock support • Supports PC I Bus Power Management - ACPI Power Management Registers - PME# and APM support GTM-56KM6 User's Guide INSTALLING THE MODEM Garnet systems 5 2. INSTALLATION 2.1 Installing the Modem Please follow instructions as follows in order to install modem. - Turn off your computer and all attached peripheral devices (pri nter, monitor, etc.) and unplug them from the electrical outlet. CAUTION : To avoid risk of…

Text truncated - open the document above for the full version.

Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 20 of 24 A2-1 Label Requirements A class B digital equipment subject to certification by the FCC shall carry a warning label which includes the following statements: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This statement should be stuck in a conspicuous location on the device. If impossible, this warning label should be placed in a prominent location in the user’s manual. A2-2 ID Label Drawing Model No : GTM-56KM6 Serial No : xxxxxxx FCC ID: LEMGTM-56KM6 Garnet Systems Co., Ltd. Made in Korea A2-3 ID Label Location : Bottom side of EUT

Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 18 of 24 A1-1 External Photo of EUT(Top) A1-2 External Photo of EUT(Bottom)

Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 1 of 24 JungAng EMC Co., Ltd. 109-2, Yepyung-ri, Kumsa-myun, Youju-kun, Kyungki-do, KOREA TEL: 82 2 571 8217 FAX:82 31 764 0126 FCC EMI TEST REPORT Date of Test : July 18, 2000 Test Report No : 00JAC007.FCC Test Site : JungAng EMC Co., Ltd., Korea(31040/SIT 1300F2) Trade Name : N/A Manufacturer : Garnet Systems Co., Ltd. Address : Myungsung Bldg., 545-7, Dogok-Dong, Kangnam-Gu, Seoul, Korea Contact Person : Bong-Cheol Kim Tel No. : 82-2-2188-7188 Fax No. : 82-2-572-4911 Product : Modem Model : GTM-56KM6 Fcc Rule Part(s) : FCC Part 15 Subpart B Classification : Class B The device bearing the trade name and model specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C.63.4-1992. I attest to the accuracy of data and all measurement reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualification of all persons taking them. TaeHyun Nam President-JungAng EMC Co., Ltd. http://www.jaemc.co.kr Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 2 of 24 TABLE OF CONTENTS PAGE 1. Description of device 3 1.1 General 3 1.2 EUT Description 3 2. Test facility 4 3. Summary of results 4 3.1 Electromagnetic Emission 4 3.2 Modifications to the EUT 4 4. Tested system details 5 4.1 Peripherals and Others 5 4.2 Type of Cables Used 5 4.3 System layout on EUT and peripherals 6 5. Test result 7 5.1 RFI Voltage Measurement 7 5.2 RFI Field Strength Measurement 11 5.3 Minimum Margin 13 5.4 Sample Calculations 13 6. Test Equipments 14 7. Measurement Photos 15 7.1 Setup with RFI Voltage Emission Level 15 7.2 Setup with RFI Field Strength Emission Level 16 Appendix 1 Photos of EUT 17 Appendix 2 ID Label and Location 19 Appendix 3 System Block Diagram 22 Appendix 4 User’s Manual 24 Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 3 of 24 1. DESCRIPTION OF DEVICE 1.1 General Responsible Party Garnet Systems Co., Ltd. Contact Person B ong-Cheol Kim Tel No. : 82-2-2188-7188 Fax No. : 82-2-572-4911 Manufacturer Garnet Systems Co., Ltd. Myungsung BLDG., 545-7, Dogok-Dong, Kangnam-Gu, Seoul, Korea • Trade name N/A • Model name GTM-56KM6 • EUT Type Modem • Classification FCC Part 15 Subpart B Class B • Clock Speed Main Clock : 28.224 MHz • Rule Part(s) FCC Part 15 & Part 2 • Test Procedure(s) ANSI C63.4(1992) • Date of Tests July 18, 2000 • Place of Tests JungAng EMC Co., Ltd. 1.2 EUT Description This modem supports high speed analog data, high speed fax operation over the PSTN. In ITU-T V.90/K56flex data mode, this modem transmit/receive up to 54kbps from a digitally connected V.90 or K56flec-compatible central site modem. RR Note. This report may be reproduced in full. Partial reproduction may only be made with the written permission of the laboratory. The results in this report is only applied to the sample(s) tested. RR Note. Please refer to the duties and responsibilities of the Responsible Party attached. Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 4 of 24 2. TEST FACILITY The open field test site and conducted measurement facility used for this measurement, is located following address. This site was fully described in a report dated Nov. 24, 1998, that was submitted to the FCC. Our site and facility had been accepted in a letter dated Nov. 24, 1998(31040/SIT) : JungAng EMC Co., Ltd. Address : 109-2, Yepyung-ri, Kumsa-myun, Youju-kun, Kyungki-do, Korea The detailed description of the measurement facility was found to be in compliance with the requirements of 2.948 according to ANSI C63.4 on October 19, 1992. 3. SUMMARY OF RESULTS 3.1 Electromagnetic Emission RFI Voltage Measurement............................... PASS RFI Field Strength Measurement........................ PASS Although the measured emissions indicate that the EUT complies with the required limits, some measurements are close to these limits. When the uncertainty of measurement is considered, there is some possibility that the EUT may not be compliant. 3.2 Modifications to the EUT : None Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 5 of 24 4. TESTED SYSTEM DETAILS 4.1 Peripherals and Others : Description Model Name Serial No. Manufacturer FCC ID Computer DESKPRO 7836BVD20016 Compaq DoC Printer C2106A 3217S91901 HP B94C2106X Monitor VX700 M902080938 Gateway BGBTFV8705K Keyboard RT235BTW B13BC90L39GU Compaq AQ6-22K15 Mouse #1 M-S34 F13490N5BGF Compaq DZL211029 Mouse #2 Pro Mouse II 96002117 NEOTEC FSUGMZC7 4.2 Type of Cables Used: Device from Device to Type of Cable Length Type of shield Computer Monitor Signal cable 1.0 shielded Computer Printer Signal cable 1.8 shielded Computer Keyboard Signal cable 2.0 shielded Computer Mouse #1 Signal cable 1.5 shielded Computer Mouse #2 Signal cable 1.5 shielded Computer MODEM Signal cable 1.2 Non-shielded Computer Main Power Power cable 1.5 Non-shielded Monitor Main Power Power cable 1.5 Non-shielded Printer Main Power Power cable 1.5 Non-shielded Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 6 of 24 4.3 System layout on EUT and peripherals EUT Figure 4-1 System layout Monitor Computer Keyboard Mouse Mouse Printer Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 7 of 24 5. TEST RESULT 5.1 RFI Voltage Measurement 5.1.1 Measurement Instrumentation Used (model/serial no./manufacturer/last calibration/next calibration) Signal Analyzer............(PMM9000/3100J70602/PMM/08 …

Text truncated - open the document above for the full version.

Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 15 of 24 7. MEASUREMENT PHOTOS 7.1 Setup with the Maximized RFI Voltage Emission Level Model : GTM-56KM6 Test Report No. : 00JAC007.FCC  2000 JungAng EMC Co., Ltd. FCC ID : LEMGTM-56KM6 Page 16 of 24 7.2 Setup with the Maximized RFI Field Strength Emission Level
