LLIBWM24Superheterodyne Wireless Surveillance Monitor

May 7, 1998 Federal Communications Commission Authorization & Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:HITRON Systems, Inc. FCC ID: LLIBWM24 Gentlemen: Transmitted herewith, on behalf of HITRON Systems Inc., is a Notification application of the following wireless superheterodyne monitor receiver (composite device): FCC ID:LLIBWM24 MODEL:BWM2412A EQUIP. Class:Low Power Communications Receiver (CYY) EUT Type:Wireless Superheterodyne Surveillance Monitor FREQ. Range:2.4 GHz – 2.4835 GHz Attached is the attestation statement, measurement report (Radiated emission data, Line Conducted emission data, and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagrams, schematic diagrams, and the user's manual. Please note that this receiver Notification application is simultaneously submitted with the Certification application of the transmitter section (FCC ID: LLIBWC24). Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Se Bong, LEE – Project Manager HITRON Systems, Inc.

Test Report S/N: DoC.980501317.MSADeclaration of Conformity Test Date(s): May 04-05, 1998FCC DoC Class B © 1998 PCTEST LabModel: E15BL NVLAP Lab Code: 100431-0 HANSOL Electronics, Inc. Test Report S/N: DoC.980501317.MSADeclaration of Conformity Test Date(s): May 04-05, 1998FCC DoC Class B © 1998 PCTEST LabModel: E15BL NVLAP Lab Code: 100431-0 HANSOL Electronics, Inc. Test Report S/N: DoC.980501317.MSADeclaration of Conformity Test Date(s): May 04-05, 1998FCC DoC Class B © 1998 PCTEST LabModel: E15BL NVLAP Lab Code: 100431-0 HANSOL Electronics, Inc. Test Report S/N: DoC.980501317.MSADeclaration of Conformity Test Date(s): May 04-05, 1998FCC DoC Class B © 1998 PCTEST LabModel: E15BL NVLAP Lab Code: 100431-0 HANSOL Electronics, Inc. Test Report S/N: DoC.980501317.MSADeclaration of Conformity Test Date(s): May 04-05, 1998FCC DoC Class B © 1998 PCTEST LabModel: E15BL NVLAP Lab Code: 100431-0 HANSOL Electronics, Inc. Test Report S/N: DoC.980501317.MSADeclaration of Conformity Test Date(s): May 04-05, 1998FCC DoC Class B © 1998 PCTEST LabModel: E15BL NVLAP Lab Code: 100431-0 HANSOL Electronics, Inc.

© 1998 PCTEST Lab FCC ID SAMPLE LABEL LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Fig 12. Sample label (SEE NEXT PAGE)

Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Date(s): April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabFCC ID: LLIBWM24 NVLAP Lab Code: 100431-0 HITRON Systems, Inc. Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Date(s): April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabFCC ID: LLIBWM24 NVLAP Lab Code: 100431-0 HITRON Systems, Inc. Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Date(s): April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabFCC ID: LLIBWM24 NVLAP Lab Code: 100431-0 HITRON Systems, Inc. Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Date(s): April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabFCC ID: LLIBWM24 NVLAP Lab Code: 100431-0 HITRON Systems, Inc. Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Date(s): April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabFCC ID: LLIBWM24 NVLAP Lab Code: 100431-0 HITRON Systems, Inc. Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Date(s): April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabFCC ID: LLIBWM24 NVLAP Lab Code: 100431-0 HITRON Systems, Inc.

PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com NOTIFICATION OF COMPLIANCE HITRON Systems, Inc.Dates of Tests: April 07-08, 1998 555-34, Baiksuk-Dong, Cheonan-City,Test Report S/N: Rx.980323229.LLI ChoongNam, KOREA 330-220 Test Site: PCTEST Lab., MD U.S.A. Attn: Se Bong, LEE - Project Manager FCC IDENTIFIER APPLICANT FCC Rule Part(s):§15 (Notification); ANSI C-63.4 (1992) Equipment Class:Low Power Communications Receiver (CYY) EUT Type:Wireless Superheterodyne Receiver (Composite Device) (5.5" Monochrome Monitor for Wireless Babycare System) Rx Freq. Range:2.4 - 2.4835 GHz Resolution:400 TV Lines (at center) Trade Name/Model:HITRON BWM2412A This device has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Lab Code 100431-0 LLIBWM24 HITRON SYSTEMS, INC. © 1998 PCTEST Engineering Lab., Inc. Superheterodyne Receiver FCC Part 15 - Notification © 1998 PCTEST Engineering Laboratory, Inc. CYY TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED)7-8 TEST DATA (RADIATED) 9 ACCURACY OF MEASUREMENT 10 LIST OF TEST EQUIPMENT 11 TEST SOFTWARE USED 12 RECOMMENDATION / CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name:HITRON SYSTEMS, INC. Address:555-34, Baiksuk-Dong, Cheonan-City ChoongNam, KOREA 330-220 Attention:Se Bong, Lee - Project Manager R & D Dept. Display Team •FCC ID:LLIBWM24 •Equipment Class:Low Power Communications Receiver (CYY) •Equipment Type:Wireless Superheterodyne Receiver (Composite Device) 5.5" Monochrome Monitor for Wireless Babycare System •Model:BWM2412A •Camera Transmitter:FCC ID: LLIBWC24 (§15.249) •Test Procedures:ANSI C63.4 (1992) •FCC Rule Part(s):§15 (Notification) •Rx Freq. Range:2.4 - 2.4835 GHz •Dates of Tests: April 07-08, 1998 •Place of Tests: PCTEST Lab, Columbia, MD U.S.A. •Test Report S/N:Rx.980323229.LLI NOTE: This receiver Notification application is simultaneously filed with the transmitter Certification application (FCC ID: LLIBWC24). Lab Code 100431-0 Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Dates: April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabHITRON Systems Inc. FCC ID: LLIBWM241 Wireless Monitor Receiver (2.4 - 2.4835 GHz) Introduction The measurement procedures described in MP-3, entitled ‘‘FCC Methods of Measurements of Output Signal Level, Output Terminal Conducted Spurious Emissions, Transfer Switch Characteristics, and Radio Noise Emissions From TV Interface Devices,’’ and ANSI C63.4- 1992 were used in determining EME emanating from HITRON Wireless Monitor Receiver. These measurement tests were conducted at PCTEST Engineering Laboratory facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the high- est points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39°11’15" N latitude and 76°49’38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of PCTEST meas- urement facility was found to be in compliance with Federal Communications Commis- sion requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Fig. 1. The map above shows the Columbia vicinity area. The map also shows PCTest Lab, FCC Lab and BWI airport. (Scale 1"=2miles) Test Report S/N: Rx.980323229.LLISuperheterodyne Receiver Test Dates: April 07-08, 1998FCC Part 15 - Notification © 1998 PCTEST LabHITRON Systems Inc. FCC ID: LLIBWM242 Wireless Monitor Receiver (2.4 - 2.4835 GHz) Product Information Equipment Description: The Equipment Under Test (EUT) is the HITRON Wireless Superheterodyne Monitor Receiver FCC ID: LLIBWM24. The EUT is a wireless video babycare monitor unit with built-in Audio/Video Receiver. Rx Frequency Range:2.4 - 2.4835 GHz CRT:5.5" Scan System:CCIR Standard, 2:1 Interlaced Scanning Frequency:15.625 kHz - Horizontal 50 Hz - Vertical Resolution:400 TV Lines (at center) Antenna:High-Gain Telescopic Antenna Video Input:0.5 - 2.0 Vp-p (Synchronous negative polarity) Audio Amp:0.5W max. (Speaker 16Ω) Power Supply:Youk Young Electronics Co., Ltd. AC Power Adapter Model: AD60002 230VAC 50Hz, 15VDC 1.2A Power Consumption:12W (max.) Power Cord:Unshielded EMI suppression device(s) installed in production: *see schematics (Appendix B) EMI suppression device(s) added and/or modified during testing: *none Tes…
