LNQ-WF825Tri-band Wi-Fi 7 Wireless AP

1 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. Tri-band Wi-Fi7 Router WF-825 Product Datasheet VERSION1.0 Oct, 2023 www.actiontec.com 2 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. ◼ Overview The tri-band Wi-Fi 7 WF-825 is designed to provide Wi-Fi network connectivity for homes and business based on the latest 802.11be chipset design. With the WF-825, the user can utilize EasyMesh R4, which provides a self-configuring, self-healing and self-managing Wi-Fi network. It dynamically selects the most reliable Wi-Fi path and enables fast and seamless handoffs for end-users. WF-825 is one of the best performing WiFi 7 router in the market. It supports 802.11ax on all Wi-Fi radio bands. The 2.4G radio supports 4x4 802.11b/g/n/ax MIMO. The 5G radio supports 4x4 802.11a/n/ac/ax/be MIMO. The 6G radio supports 4x4 802.11a/n/ac/ax/be MIMO WF-825 can meet the requirements for high- speed real-time traffic and high-bandwidth entertainment, such as 4K video, video game streaming and VR. With global deployments in mind, the WF-825 utilized standard AC/DC adapter, allowing easy adaptation everywhere in every country. 3 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. ◼ Key Features ⚫ Desktop placement ⚫ 2.4GHz 40MHz 4x4 802.11b/g/n/ax ⚫ 5GHz 160MHz 4x4 802.11a/n/ac/ax/be ⚫ 6GHz 160MHz 4x4 802.11a/n/ac/ax/be ⚫ WPA/WPA2-PSK(AES)/WPA3 ⚫ 8 x Integrated Wi-Fi antennas ⚫ 1 x 10GbE WAN ⚫ 1 x 10GbE LAN ⚫ 3 x 2.5GbE LAN ⚫ 4 x Status LED (multi-color) ⚫ 1 x USB3.0 ⚫ 1 x WPS button ⚫ 1 x Reset button ⚫ 1 x DC jack ⚫ Supports router/extender functions ⚫ Supports TR-069 management ⚫ Supports EasyMesh R4 4 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. ◼ Application Scenario ◼ Three WF-825 and WF-710G can form a Wi-Fi mesh network. One configured as the Gateway and the other two configured as the Wi-Fi Extender: Internet Fiber / Ethernet Ethernet Gateway Extender Extender EasyMesh Network ◼ Software Features Category Features Network Bridge Mode - DHCP Client - Backhaul with 2.4G/5G Wi-Fi/Ethernet Router Mode - IPv4 - IPv6 - NAT - WAN DHCP client - LAN DHCP server - DNS server 5 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. - DHCP reservation - uPNP - Port forwarding - Backhaul with Ethernet IGMP Snooping Wi-Fi 2.4GHz bandwidth: 20/40MHz, 5GHz bandwidth: 20/40/80/160MHz 802.11 k/v/r Band steering Channel scan DFS SSID broadcast WPA/WPA2/WPA3 PSK security TR-069 Management Network topology display - Device connected - Client accessed - Channel - Backhaul type Network optimize WPA/WPA2/WPA3 PSK security Freeze client Device information - Status - Online time - IP address - MAC address - Firmware version - Channel Client information - Status - Online time - IP address - MAC address - Channel Network statistic chart - Bandwidth usage - RSSI - Channel congestion - Event 6 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. Utilities - Reboot device - Upgrade remotely - Speed Test ◼ Specification Item WF-825 Dimension (D x H) 202mm x 85mm x 235mm (High) Installation Desktop placement LEDs 4x Status LED (multi-color) Interface 1 x 10GbE WAN 1 x 10GbE WAN 3 x 2.5GbE LAN 1 x DC jack Input Voltage +12V/5A Power consumption < 50W Environmental Specification Temperature Operation: 0°C～+35°C Storage: -40°C～+85°C Operating Humidity 5%～95% (non-condensing) Elevations 86kPa～106kPa altitude Dustproof and Waterproof IP20 Compliance • IEC 62368-1:2014 (Second Edition)+A11: 2017 • UL 62368-1, 2nd Ed, 2014-12-01 (Audio/video, information and communication technology equipment Part 1: Safety requirements) • CAN/CSA C22.2 No. 62368-1-14, 2nd Ed (Audio/video, information and communication technology equipment Part 1: Safety requirements) 7 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. Item WF-825 • FCC • ETL • RoHS 2011/65/EU compliant (RoHS 10 compliant, no Pb) Reliability MTBF > 300,000 Hours Telcordia SR-332, Reliability Prediction Procedures for Electronic Equipment, Issue 3, Method 1, Case 3, GB/GC (Ground Benign, Controlled) environment, 25ºC ambient temperature. Steady state, not including software failure. AFR AFR (Annualized Failure Rate) < 1.5% (in continuous operation) Chipset Wi-Fi SoC Qualcomm Flash 4GB eMMC DDR 1GB DDR4 RAM Wi-Fi Interface Operating frequency 2.4G radio: 2.4000GHz~2.4835GHz 5G radio: 5.150~5.250,5.250~5.350,5.470~5.725, 5.725~5.850GHz 6G radio: 5.925 ~ 7.125GHz Data Rate 802.11b: 1, 2, 5.5, and 11Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48 and 54Mb/s 802.11n: MCS0~MCS15 802.11ac: MCS0 ~ MCS9 802.11ax: MCS0~MCS11 Rece…

Text truncated - open the document above for the full version.

Actiontec Electronics Inc 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States 012423-17 rev2 Certification Application Attestation Statements Date: March 8, 2024 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ____ Actiontec Electronics Inc _____ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) _____ Actiontec Electronics Inc _____ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☑ - is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: __________________________ ______ Zhe Liu ______ (Signature 2 ) (Print name) Title: _______ Product Manager _____ Company: __ Actiontec Electronics Inc _ Telephone: __ (909) 313-8262 ___ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

Actiontec Electronics Inc. 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States U.S. Agent Designation for Service of Process TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: Actiontec Electronics, Inc. Grantee Code: LNQ Contact Name: Zhe Liu Street Address: 2445 Augustine Dr Suite 501 City/Province/Zip: Santa Clara, CA 95054 Telephone No: (909) 313-8262 Email: [email protected] FRN: 0005810783 Applicant Signature 1 : Date: 2024/03/01 Signed by (Printed Name/Title): Zhe Liu / Product Manager 1 - Letters should be placed on appropriate letterhead.

Letter of Declaration on Indoor Access Point (6ID) Operation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: LNQ-WF825 To Whom It May Concern We, Actiontec Electronics Inc (Address: 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States), attest that this Indoor Access Point device complies with the following requirements of Part 15E of the FCC’s rules for 6G bands: Protocol attestation statement: An 11ax/be IEEE AP’s Transmit Power Envelope element has information fields for power limits for connecting client/subordinate devices. The information is embedded in this device’s signals and used to tell the connecting clients/subordinate that the max TX powers it is allowed to transmit. There is a regulatory info field in this device’s beacon and probe response frames which detail this device type when the client/subordinate associates to this device. Statement acknowledging device restrictions: 1. This device operating in the 5.925-7.125 GHz band is supplied power from a wired connection, has an integrated antenna, is not battery-powered, and does not have a weatherized enclosure. 2. This device's operation will not be allowed on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet only in the 5.925-6.425 GHz band. 3. This device is prohibited for control of or communications with unmanned aircraft systems, including drones. Sincerely, _________________ Name: Zhe Liu Position: Product Manager Date: 2024-03-01

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID: LNQ-WF825 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, _________________ Name: Zhe Liu Position: Product Manager Date: 2024-03-01

Declaration of Authorization We Name: Actiontec Electronics Inc Address: 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States Declare that: Name Representative of agent: Marlin Chen Agent Company name: MRT Technology (Suzhou) Co., Ltd Address: D8 Building, Youxin Industrial Park, No.2 Tian'edang Rd., Wuzhong Economic Development Zone City: Suzhou Country: China is authorized to apply for Certification of the following product(s): Product: Tri-band Wi-Fi 7 Wireless AP FCC ID: LNQ-WF825 Model: GRBE330C, WF-825 Sincerely, _________________ Name: Zhe Liu Position: Product Manager Date: 2024-03-01

Declaration of Conformity We Name: Actiontec Electronics Inc Address: 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States Declare that: Product: Tri-band Wi-Fi 7 Wireless AP FCC ID: LNQ-WF825 Model: GRBE330C, WF-825 Product which bears the above FCC ID is also compliant with the FCC requirements for sDOC. And the sDOC procedure shall be carried out prior to marketing the device in the US. Sincerely, _________________ Name: Zhe Liu Position: Product Manager Date: 2024-03-01

Refer to KDB 442812 D01 SDR apps Guide v02r03 Section II FCC ID: LNQ-WF825 Description Software (Section 2.944 (c)) 1.1 General software operational description. ACTIONTEC WiFi Extender WF-825 supports IEEE 802.11 a/b/g/n/ac/ax/be standards, Modulation Techniques as follows: GFSK OFDM,OFDMA and DSSS 802.11b_DSSS: DBPSK, DQPSK, CCK 802.11a/n-HT20/n-HT40_OFDM: BPSK, QPSK, 16QAM, 64QAM 802.11ac-VHT20/ac-VHT40/ac-VHT80/ac-VHT160_OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM 802.11ax-HE20/ax-HE40/ax-HE80/ax-HE160_OFDMA: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM 802.11be-EHT320_OFDMA:BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM,4096QAM 1.2 Describe all the radio frequency parameters that are modified by the software without any hardware changes. This device does not supports to modify TX power via software or hardware after leaving the factory. Users are allowed to modify the frequency channels, allowed channel list is compliance with FCC regulatory requirements. 1.3 High level (simplified) block diagram of the software architecture. Refer to exhibit 2 behind this table. Labelling 2.1 How is the device to be labeled? Will the device have a single label or will it use an electronic label per Section 2.925 (e)? Each device will have a single label with Model Number and FCC ID. 2.2 How can the FCC verify, in the field, that the correct version of the software is running in the device? Submit a description of this capability and instructions for the FCC to use in the field to verify that proper software is operating in the device The FW revision will be displayed in the TR-069 management system. 2.3 Describe the means by which software version numbers can be related to any future Class III permissive changes. For example: v01.01 was the software version for the Initial grant. Version v17.01 was for the first Class III Change. Any Version betweenV01.001 to V16.99 is assumed to be representative of the equipment exhibits in the initial grant. Version V22.15 would represent the version as modified by the Class III change. The firmware version of the WF-825 follows the format 0.3.yy.xx-WF825-pro.yy can be used to identify any future Class III permissive changes, xx is the firmware revision. Security 3.1 Describe the procedure that ensures that third parties (Professional installers, qualified personnel, authorized certified technicians, end users, etc. – not direct employees) cannot operate US sold devices on any other regulatory domain frequencies, or in any manner that is in violation of the certification. All the access including console port and Telnet/SSH are all disabled. The source is a read‐only web page. And the web server is secured with firewalls. This device does not support field upgrade. The only management interface is TR-069 management system. And RF-related and country code are not under control of TR-069 management system. All parameters (RF, Frequencies and etc.) indicating different countries are permanent settings in ROM. So if a device is a product for US, it cannot be changed to another region. 3.2 Explain if any third parties have the capability to operate a US sold device on any other regulatory domain frequencies, or in any manner that is in violation of the certification. Third parties don’t have the capability. 3.3 Describe how the software updates are distributed for all regulatory domains and what procedures ensures that a product sold in the US can only operate as granted on US frequencies and at authorized radio parameters. All the access including console port and Telnet/SSH are all disabled. The source is a read‐only web page. And the web server is secured with firewalls. This device does not support field upgrade. The only management interface is TR-069 management system. And RF-related and country code are not under control of TR-069 management system. All parameters (RF, Frequencies and etc.) indicating different countries are permanent settings in ROM. So if a device is a product for US, it cannot be changed to another region. 3.4 If the product cannot be modified by third parties and can only operate as granted on US frequencies and with authorized radio parameters, explain how this is achieved. All the access including console port and Telnet/SSH are all disabled. The source is a read-only web page. And the web server is secured with firewalls. This device does not support field upgrade. The only management interface is TR-069 management system. And RF-related and country code are not under control of TR-069 management system. All parameters (RF, Frequencies and etc.) indicating different countries are permanent settings in ROM. So if a device is a product for US, it cannot be changed to another region. 3.5 What stops third parties from loading non-US versions of software onto products intended for US sale? All the access including console port and Telnet/SSH are all disabled. The source is a read‐only web page. And the web server is secured with firewalls. This device does not support field upgrade. And RF-related and country code are not under control of TR-069 management system. All parameters (RF, Frequencies and etc.) indicating different countries are permanent settings in ROM. So if a device is a product for US, it cannot be changed to another region. 3.6 Can third parties make factory level changes to reload non-US domain codes, etc. No Unauthorized changes (hack) to the software 4.1 Describe how open source is the operating code for granted RF properties. Describe the difficulty and proprietary nature of the code that controls the RF parameters as granted. ACTIONTEC firmware in WF-825 is not open source, it is locked and installed at the factory, it is not permitted to load any open source codes. How the firmware controls the RF parameters as granted: See more details in 3.1 Exhibit 1: Radio Parameters The product disabled console port and Telnet/SSH. The source is a read‐only web page. And the web server is secured with firewalls. Available settings to the end u…

Text truncated - open the document above for the full version.

SDR (Software Defined Radio) Cover Letter Refer to KDB 442812 D01 SDR apps Guide v02r03. The following six questions can be used for determining if a radio can elect to be, or must be an SDR. 1. Can the RF parameters of the device be altered through software? Ye s - go to 2. No, not an SDR Answer: YES 2. Can third parties not permitted by the Commission through specific filings modify, configure, or load different software, or make configuration settings to operate the device or host hardware radio frequency parameters (frequency range, modulation type, maximum output power or other radio parameters) in any other way than granted (or expected to be granted)? Yes, must be an SDR. No - go to 3. Answer: YES 3. Is the device capable of operating in any other in any other way than granted, or will be, granted? Ye s , - go to 4. No - go to 5. Answer: YES 4. Is this a Part 15 client Device as defined in Section 15.202 (as opposed to a master device)? Yes, qualifies as a part 15 client devices - go to 5. No, must be an SDR. Answer: NO 5. Does the manufacturer elect SDR? Yes, elects to be an SDR. No, Not an SDR Answer: YES Conclusion: According to the above questions reply, we can confirm this device (FCC ID: LNQ-WF825) must be a SDR device. __________________ Name: Zhe Liu Position: Product Manager Date: 2024-03-01

Declaration letter For our business issue and marketing requirement, we would like to list different model numbers as following: Model No.: GRBE330C, WF-825 Model Difference: there is not any hardware or software differences between GRBE330C and WF-825, only for different brand name. _________________ Name: Zhe Liu Position: Product Manager Date: 2024-03-01

Report No.: 2312RSU008-UE 1 of 5 External Photograph (1) EUT Photo (2) EUT Photo Report No.: 2312RSU008-UE 2 of 5 (3) EUT Photo (4) EUT Photo Report No.: 2312RSU008-UE 3 of 5 (5) EUT Photo (6) EUT Photo Report No.: 2312RSU008-UE 4 of 5 (7) EUT Photo (8) EUT Photo Report No.: 2312RSU008-UE 5 of 5 (9) EUT Photo

SN: 1JGYYWW00001 Indoor use only Designed in USA Made in China FCC ID: LNQ-WF825 Model Number: WF-825 Input:12V DC 5A MAC: XX:XX:XX:XX:XX:XX LabelereH

Report No.: 2312RSU008-UE 1 of 9 Internal Photograph (1) EUT Photo (2) EUT Photo Report No.: 2312RSU008-UE 2 of 9 (3) EUT Photo (4) EUT Photo Report No.: 2312RSU008-UE 3 of 9 (5) EUT Photo (6) EUT Photo Report No.: 2312RSU008-UE 4 of 9 (7) EUT Photo (8) EUT Photo Report No.: 2312RSU008-UE 5 of 9 (9) EUT Photo (10) EUT Photo Report No.: 2312RSU008-UE 6 of 9 (11) EUT Photo (12) EUT Photo Report No.: 2312RSU008-UE 7 of 9 (13) EUT Photo (14) EUT Photo Report No.: 2312RSU008-UE 8 of 9 (15) EUT Photo (16) EUT Photo Report No.: 2312RSU008-UE 9 of 9 (17) EUT Photo

MRT Technology (Suzhou) Co., Ltd Report No.: 2312RSU008-U6 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2024-03-13 Template Version:0.0 1 of 10 RF Exposure Evaluation Declaration FCC ID: LNQ-WF825 Applicant: Actiontec Electronics Inc. Product: Tri-band Wi-Fi 7 Wireless AP Model No.: GRBE330C, WF-825 FCC Classification: Digital Transmission System (DTS) Unlicensed National Information Infrastructure (NII) 15E 6GHz Low Power Indoor Access Point (6ID) FCC Rule Part(s): FCC Part 2.1091 Evaluated Date: 2024-03-07 Result: Complies Reviewed By: Kevin Guo Approved By: Robin Wu The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standards through the calibration of the equipment and evaluated measurement uncertainty herein. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: 2312RSU008-U6 2 of 10 Revision History Report No. Version Description Issue Date Note 2312RSU008-U6 V01 Initial Report 2024-03-13 Valid Report No.: 2312RSU008-U6 3 of 10 CONTENTS Description Page 1. General Information ................................................................................................................................ 4 1.1. Applicant ........................................................................................................................................ 4 1.2. Manufacturer ................................................................................................................................. 4 1.3. Testing Facility ............................................................................................................................... 4 1.4. Product Information ....................................................................................................................... 5 1.5. Antenna Details ............................................................................................................................. 5 1.6. Device Classification ..................................................................................................................... 6 1.7. Applied Standards ......................................................................................................................... 6 2. RF Exposure Evaluation ......................................................................................................................... 7 2.1. Test Limits ..................................................................................................................................... 7 2.2. MPE Exemptions ........................................................................................................................... 8 2.3. Calculated Result ......................................................................................................................... 11 Report No.: 2312RSU008-U6 4 of 10 1. General Information 1.1. Applicant Actiontec Electronics Inc. 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States 1.2. Manufacturer Actiontec Electronics Inc. 2445 Augustine Drive Suite 501, Santa Clara, California 95054, United States 1.3. Testing Facility Test Site – MRT Suzhou Laboratory Laboratory Location (Suzhou - Wuzhong) D8 Building, No.2 Tian’edang Rd., Wuzhong Economic Development Zone, Suzhou, China Laboratory Location (Suzhou - SIP) 4b Building, Liando U Valley, No.200 Xingpu Rd., Shengpu Town, Suzhou Industrial Park, China Laboratory Accreditations A2LA: 3628.01 CNAS: L10551 FCC: CN1166 ISED: CN0001 VCCI: R-20025 G-20034 C-20020 T-20020 R-20141 G-20134 C-20103 T-20104 Test Site – MRT Shenzhen Laboratory Laboratory Location (Shenzhen) 1G, Building A, Junxiangda Building, Zhongshanyuan Road West, Nanshan District, Shenzhen, China Laboratory Accreditations A2LA: 3628.02 CNAS: L10551 FCC: CN1284 ISED: CN0105 Test Site – MRT Taiwan Laboratory Laboratory Location (Taiwan) No. 38, Fuxing 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) Laboratory Accreditations TAF: 3261 FCC: 291082, TW3261 ISED: TW3261 Report No.: 2312RSU008-U6 5 of 10 1.4. Product Information Product Name Tri-band Wi-Fi 7 Wireless AP Model No. GRBE330C, WF-825 Wi-Fi Specification 802.11a/b/g/n/ac/ax/be Bluetooth Specification V5.0 (Single mode, LE only) Antenna Information Refer to Section 1.7 Accessory Adapter Model: KL-WA150400-Q1 Input: 100-240V ~ 50/60Hz 2.0A Output: 15.0V ⎓ 4.0A Notes: 1. There is not any hardware or software differences between GRBE330C and WF-825, only for different brand. 2. The information of EUT was provided by the manufacturer, and the accuracy of the information shall be the responsibility of the manufacturer. 1.5. Antenna Details Antenna Type Frequency (MHz) TX Paths Antenna Gain (dBi) Directional Gain (dBi) Ant 0 Ant 1 Ant 2 Ant 3 Correlated Uncorrelated Wi-Fi Antenna PIFA 2412 ~ 2462 4 3.72 3.73 3.79 3.59 5.49 0.23 5180 ~ 5825 4 4.40 4.82 4.57 4.34 6.74 1.45 5925 ~ 7125 4 4.50 4.88 4.91 4.70 6.90 1.27 Bluetooth Antenna PCB 2402 ~ 2480 1 4.99 -- -- Remark: 1. The antenna gain and directional gain refer to manufacturer’s antenna specification. 2. The device supports CDD Mode, STBC mode and SISO mode, details refer to the table as below. 3. CDD signals are correlated, the directional gain as follows, For power measurements: Array Gain = 0 dB for N ANT ≤ 4, the directional gain = max antenna gain + array gain For power spectral density (PSD) measurements: the max directional gain (each angle) = 10 log[(10 G1 /20 + 10 G2 /20 + ... + 10 GN /20 ) 2 /N ANT ] 4. STBC signals are uncorrelated, the directional gain as follows, the max directional gain (each angle) = 10 log[(10 G1 /10 + 10 G2 /10 + ... + 10 GN /10 )/N ANT ] Report No.: 2312RSU008-U6 6 of 10 Test Mode T X Paths SISO CDD Mode STBC Mode Wi-Fi 2.4G 802.11b/g 4 X √ X 802.11n/ax 4 X X √ Wi-Fi 5G 802.11a 4 X √ X 802.11n/ac/ax/be 4 X X √ Wi-Fi 6G 802.11…

Text truncated - open the document above for the full version.

W H E N C O N N E C T I O N S C O U N T Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 W H E N C O N N E C T I O N S C O U N T W H E N C O N N E C T I O N S C O U N T Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 2 CIG WF-825 Wi-Fi Antenna Performance Report Galtronics Project: 8048 Prepared by Alissa Guo Jan 8 th , 2024 W H E N C O N N E C T I O N S C O U N T Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 3 3 Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 Introduction Galtronics develop edan antenna solution for CIG WF-825 There are 8 antennas : ➢Four Cabled PCB WIFI Dual Band antenna :-DB0,DB1,DB2 and DB3. ➢Four Cabled PCB WIFI 6GHz Band antenna :-6G0,6G1,6G2 and 6G3. The operating frequency of the Dual Band Antennas is 2.4 GHz-2.5 GHz and 5.15GHz-5.85GHz. The operating frequency of the 6GHz Antennas is 5.925 GHz-7.125 GHz. Measured return loss, isolation, peak gain, efficiency, composite gain and gain patternsof the antennas W H E N C O N N E C T I O N S C O U N T Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 4 TEST INFORMATION InstrumentManufacturerModel No.Asset No.Cali. IntervalCali. Due Date ENA Network AnalyzerKEYSIGHTE5071CMY467302341 Year2025/2/28 RF Switch BoxHWA-TECHZ9916A-NO1N/AN/AN/A SP24 ChamberHWA-TECH555N/A1 Year2024/12/1 HornAntennaHWA-TECHTN3112N/A1 Year2024/12/1 W H E N C O N N E C T I O N S C O U N T Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 5 TEST CONFIGURATION Chamber Test instrument W H E N C O N N E C T I O N S C O U N T Galtronics Proprietary and Highly Confidential Information Subject to Terms of Mutual NDA--专有产权和高度机密 6 Test Method The“greatcircle”cutmethod,wherebytheMeasurementAntennaremainsfixedandtheEUTisrotatedabouttwoaxesinsequential order.TheradiatedRFperformanceoftheEquipmentUnderTest(EUT)ismeasuredbysamplingtheradiatedtransmitpowerofthe mobileatvariouslocationssurroundingthedevice.Athree-dimensionalcharacterizationofthe'transmit'performanceoftheEUTispieced togetherbyanalyzingthedatafromthespatiallydistributedmeasurements. Datapointstakenevery3degreesinthethetaandinthephiaxesaredeemedsufficienttofullycharacterizetheEUT'sFar-Field radiationpatternandtotalradiatedpowerAllofthemeasuredpowervalueswillbeintegrated. Test ConditionTest EngineerTest Environment ( °C / %)Test Date RadiatedZack. You20-24 / 45-60 1.03.2024~1.05.2024 Band (MHz)Test Frequency (MHz) 2400-24842400 / 2450 / 2484 5170…

Text truncated - open the document above for the full version.
