LNQWF672Wi-Fi 7 Outdoor Mesh AP

1 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. High-end Tri-Band WiFi 7 Outdoor Wireless AP WF-672A Product Datasheet VERSION 4.0 May, 2025 www.actiontec.com 2 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. ◼ Overview WF-672A is a is a high-end Wi-Fi 7, tri-band concurrent outdoor AP that delivers 6 spatial streams (2x2 in 2.4GHz/ 5GHz/6GHz or, in dual-band mode, 2x2 in 2.4GHz and 4x4 in 5GHz). It is specifically designed for high-density deployments in outdoor locations that demand exceptional performance. It supports advanced Wi-Fi7 technologies such as multi-link operation (MLO), up to 320MHz bandwidth for 6GHz radio, OFDMA, MU-MIMO, and 4096-QAM, all within the 802.11be protocol. With up to 9300Mbps aggregated data rates, WF-672A enables the establishment of a high-speed and stable wireless network. Whether you use a phone, tablet, or laptop, seamless internet access is available from anywhere within the coverage area. Built with enhanced transmission power and high-gain antenna, the WF-672A delivers the high throughput and reliable coverage required to keep everyone connected. WF-672A has the internal directional antenna. And there is another variant WF-672E can support the external OMNI antenna. It is flexible to meet the different application scenarios of users. Its compatibility with most wireless terminals makes it easy to establish a high-capacity Wi-Fi network, catering to diverse connectivity needs. After the 6GHz AFC function is enabled, WF-672A can work with the maximize transmission power and data speeds in the 6GHz band, while minimizing the channel interference. Furthermore, this Wi-Fi AP features the Bluetooth 5.0 and GPS, for convenient device deployment and management by users. The universal mount supports both wall and pole installation. It allows for adjusting the installation angle based on the actual usage environment to achieve optimal coverage effectiveness. For developers, the WF-672A offers support for Qualcomm's QSDK and OpenWiFi development platforms. This opens the door to streamlined software development, thanks to standardized interfaces, well-defined APIs, and pre- integrated stacks, reducing complexities and enhancing reliability. Additionally, OpenWiFi’s active community support provides valuable troubleshooting assistance, ensuring a future-proof and cost-efficient solution for innovative Wi-Fi applications. 3 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. ◼ Key Features ⚫ Supports pole and wall mounting ⚫ Access Points with tri-band 2x2:2 concurrent radios: - 2.4G 2x2 Wi-Fi (802.11b/g/n/ax/be), 20/ 40MHz, up to 688Mbps - 5G 2x2 Wi-Fi (802.11a/n/ac/ax/be), 20/ 40/ 80/ 160MHz, up to 2.882Gbps - 6G 2x2 Wi-Fi (802.11ax/be), 20/ 40/ 80/ 160/ 320MHz, up to 5.764Gbps ⚫ Radio Configuration - Tri-band mode, 2x2 in 2.4GHz/ 5GHz/6GHz - Dual-band mode, 2x2 in 2.4GHz and 4x4 in 5GHz - Software configurable of Tri-band and Dual-band ⚫ Antennas - Internal tri-band directional antenna ⚫ 1x RJ45 2.5GE Ethernet port ⚫ 1x 10G SFP+ ⚫ BLE 5.0 ⚫ GPS ⚫ Three-Axis, digital magnetometer (optional) ⚫ Pressure sensor (optional) ⚫ Temperature sensor (optional) ⚫ TPM (optional) ⚫ 1x Factory default reset button ⚫ 1x USB Type-C console port ⚫ 1x RGB LEDs for visual indication ⚫ IP67 ⚫ 1x AC power supply ⚫ TIP OpenWiFi compatible 4 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. ◼ Specifications Item WF-672A Dimension (W x D x H) 270mm x 153mm x 85mm, without bracket Weight 1600g, without bracket Installation Pole mounting or wall mounting LEDs 1 x RBG (Software-defined) Interface • 1x 2.5GE Ethernet Port, with 802.3 bt PoE(PD） ** 802.3at PoE, with restricted features • 1x 10G SPF+ • 1x 12V/2.5A AC power input • 1x Factory reset button • 1x USB Type-C console port Power Input • 802.3bt PoE (PD) ** 802.3bt PoE supports the full feature ** 802.3at PoE, supports limited feature, with 2.5G Eth Port or SFP+ • 12V/2.5A AC power input Max Power consumption < 30W Environmental Specification Temperature Operation: -40°C～+65°C Storage: -40°C～+85°C Operating Humidity 5%～95% (non-condensing) Elevations 2km Dustproof and Waterproof IP67 Compliance • ETL Listed (NRTL): Conforms to UL 62368-1 and CSA C22.2 No. 62368- 1 5 Notice: Actiontec has the sole right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time, and to discontinue any product or service without notice. Actiontec has the final interpretation. Item WF-672A • CB with IEC/EN 62368-1 IEC 60950-22 (Basic safety certificate for worldwide marketing) • GB 9254 -2008(Class B of Product) EN55032, EN55035, EN61000-4-3 Level 4; EN61000-4-2, FCC Part 15B • FCC DOC Part 15 Class B (US) • FCC Part 15 Subpart C 15.247 (US) • FCC Part 15 Subpart E 15.407 (US) Reliability AFR AFR (Annualized Failure Rate) < 1.5% (in continuous operation) Chipset SoC Qualcomm IPQ5332 Flash eMMC5.0 4GB, 16MB Nor Flash reserved DDR 1GB 16bit DDR4 memory Wi-Fi Interface Operating frequency 2.4G radio: 2.4000GHz~2.4835GHz 5G radio: 5.150~5.250,5.250~5.350,5.470~5.725, 5.725~5.850 GHz 6G radio: 5.945~7.125GHz (Closed via software) Data Rate 802.11b: 1, 2, 5.5, and 11Mbps…

Text truncated - open the document above for the full version.

Report No.: R25S1040063-UE 11 of 23 Internal Photograph (1) EUT Photo (2) EUT Photo (With AC Power) Report No.: R25S1040063-UE 12 of 23 (3) EUT Photo (With AC Power) (4) EUT Photo Report No.: R25S1040063-UE 13 of 23 (5) EUT Photo (6) EUT Photo Report No.: R25S1040063-UE 14 of 23 (7) EUT Photo (Without AC Power) (8) EUT Photo (Without AC Power) Report No.: R25S1040063-UE 15 of 23 (9) EUT Photo (10) EUT Photo Report No.: R25S1040063-UE 16 of 23 (11) EUT Photo (12) EUT Photo Report No.: R25S1040063-UE 17 of 23 (13) EUT Photo (14) EUT Photo Report No.: R25S1040063-UE 18 of 23 (15) EUT Photo (16) EUT Photo Report No.: R25S1040063-UE 19 of 23 (17) EUT Photo (18) EUT Photo Report No.: R25S1040063-UE 20 of 23 (19) EUT Photo (20) EUT Photo Report No.: R25S1040063-UE 21 of 23 (21) EUT Photo (22) EUT Photo Report No.: R25S1040063-UE 22 of 23 (23) EUT Photo (24) EUT Photo Report No.: R25S1040063-UE 23 of 23 (25) EUT Photo (26) EUT Photo

Report No.: R25S1040063-UT 1 of 6 RF Test Setup Photograph For BLE & 2.4G & 6G Description: Radiated Spurious Emissions Test Setup for 9 kHz ~ 30 MHz (WJ-AC2) Description: Radiated Spurious Emissions Test Setup for 30 MHz ~ 1 GHz (WJ-AC2) Report No.: R25S1040063-UT 2 of 6 Description: Radiated Spurious Emissions Test Setup for 1 GHz ~ 18 GHz (WJ-AC2) Description: Radiated Spurious Emissions Test Setup for above 18 GHz (WJ-AC2) Report No.: R25S1040063-UT 3 of 6 For 5G Description: Radiated Spurious Emissions Test Setup for 9 kHz ~ 30 MHz (WJ-AC2) Description: Radiated Spurious Emissions Test Setup for 30 MHz ~ 1 GHz (WJ-AC2) Report No.: R25S1040063-UT 4 of 6 Description: Radiated Spurious Emissions Test Setup for 1 GHz ~ 18 GHz (WJ-AC2) Description: Radiated Spurious Emissions Test Setup for above 18 GHz (WJ-AC2) Report No.: R25S1040063-UT 5 of 6 Description: Front View of Conducted Spurious Emissions Test Setup for Power Port (WZ-SR2) Description: Side View of Conducted Spurious Emissions Test Setup for Power Port (WZ-SR2) Report No.: R25S1040063-UT 6 of 6 Description: Conducted Test Setup (WZ-SR6)

Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 JingHong 3D Chamber Structure •EMT-24 Series System Components • Chambers • EM T Quest Software • Positioning Systems • Chamber Room Size: L*W*H= 5*5*5 M VSWR were performed using a keysight S-parameter Network Analyzer. E5071C High performance PC CMW500 Active Measurement Active switch E5071C Passive Measurement Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z Y X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 1/2/9： 2400-25000MHz 3/4/5/6: 5150-5850MHz 7/8: 5925-7125MHz 10: 1575MHz 极化： +/-45° 1 2 3 4 5 6 7 8 9-BT 朝下 GPS 10 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 2G-12G-2 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 5G-35G-4 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 5G-55G-6 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 6G-76G-8 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 2G-9 BT 10 GPS Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 1&21&3 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 1&41&5 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 1&61&7 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 1&81&9 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 2&32&4 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 2&52&6 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 2&72&8 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 2&93&4 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 3&53&6 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 3&73&8 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 3&94&5 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 4&64&7 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 4&84&9 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 5&65&7 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 5&85&9 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 6&76&8 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 6&97&8 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 7&98&9 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 1&102&10 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 3&104&10 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 5&106&10 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 7&108&10 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 9&10 Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiency peakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 efficiencypeakgain Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X Design Shanghai Communication Technology co.,Ltd Measurement Report 0512-36877197 Z X -Z -Y Z Y -Z -X

Report No.: R25S1040063-U202 79 of 232 802.11be-EHT40 Out-of-Band Emissions - Ant 1 Channel 03 (2422 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 80 of 232 802.11be-EHT40 Out-of-Band Emissions - Ant 1 Channel 09 (2452 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 81 of 232 A.6 Radiated Spurious Emission Test Result Test Site WJ-AC2 Test Engineer Bob Zhang Test Date 2025-07-29 Test Mode 802.11b Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20 dB below limit line within 1-18 GHz, there is not show in the report. Test Channel Frequency (MHz) Reading Level (dBμV) Factor (dB/m) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization 01 3713.20 40.88 -1.71 39.17 74.00 -34.83 Peak Horizontal 4823.30 43.36 0.05 43.41 74.00 -30.59 Peak Horizontal 8352.50 39.42 6.23 45.65 74.00 -28.35 Peak Horizontal 3789.70 41.17 -1.36 39.81 74.00 -34.19 Peak Vertical 4823.30 42.10 0.05 42.15 74.00 -31.85 Peak Vertical 5377.50 41.34 -0.05 41.29 74.00 -32.71 Peak Vertical 06 4087.20 41.70 -1.55 40.15 74.00 -33.85 Peak Horizontal 4874.30 41.46 0.19 41.65 74.00 -32.35 Peak Horizontal 7528.00 40.08 5.10 45.18 74.00 -28.82 Peak Horizontal 3847.50 40.33 -1.16 39.17 74.00 -34.83 Peak Vertical 4870.90 40.83 0.22 41.05 74.00 -32.95 Peak Vertical 7303.60 41.09 5.16 46.25 74.00 -27.75 Peak Vertical 11 4923.60 44.91 0.35 45.26 74.00 -28.74 Peak Horizontal 7733.70 40.24 5.28 45.52 74.00 -28.48 Peak Horizontal 8355.90 39.94 6.26 46.20 74.00 -27.80 Peak Horizontal 3810.10 40.69 -1.50 39.19 74.00 -34.81 Peak Vertical 5003.50 41.66 0.31 41.97 74.00 -32.03 Peak Vertical 8296.40 39.42 6.20 45.62 74.00 -28.38 Peak Vertical Note: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB/m) Factor (dB/m) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: R25S1040063-U202 82 of 232 Test Site WJ-AC2 Test Engineer Bob Zhang Test Date 2025-07-29 Test Mode 802.11g Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20 dB below limit line within 1-18 GHz, there is not show in the report. Test Channel Frequency (MHz) Reading Level (dBμV) Factor (dB/m) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization 01 4330.30 41.94 -1.44 40.50 74.00 -33.50 Peak Horizontal 5103.80 43.76 0.13 43.89 74.00 -30.11 Peak Horizontal 7725.20 40.75 5.37 46.12 74.00 -27.88 Peak Horizontal 3799.90 40.55 -1.40 39.15 74.00 -34.85 Peak Vertical 4264.00 41.56 -1.74 39.82 74.00 -34.18 Peak Vertical 5008.60 40.84 0.37 41.21 74.00 -32.79 Peak Vertical 06 4734.90 41.57 0.39 41.96 74.00 -32.04 Peak Horizontal 7310.40 33.02 5.18 38.20 54.00 -15.80 Average Horizontal 7310.40 43.33 5.18 48.51 74.00 -25.49 Peak Horizontal 11325.80 41.82 5.70 47.52 74.00 -26.48 Peak Horizontal 3786.30 41.24 -1.37 39.87 74.00 -34.13 Peak Vertical 5061.30 41.45 0.27 41.72 74.00 -32.28 Peak Vertical 11783.10 43.24 5.00 48.24 74.00 -25.76 Peak Vertical 11 3890.00 41.38 -1.20 40.18 74.00 -33.82 Peak Horizontal 4748.50 41.11 0.21 41.32 74.00 -32.68 Peak Horizontal 11448.20 42.39 5.43 47.82 74.00 -26.18 Peak Horizontal 3954.60 40.37 -1.22 39.15 74.00 -34.85 Peak Vertical 4758.70 40.18 0.08 40.26 74.00 -33.74 Peak Vertical 11703.20 42.23 5.33 47.56 74.00 -26.44 Peak Vertical Note: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB/m) Factor (dB/m) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: R25S1040063-U202 83 of 232 Test Site WJ-AC2 Test Engineer Bob Zhang Test Date 2025-07-29 Test Mode 802.11n-HT20 Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20 dB below limit line within 1-18 GHz, there is not show in the report. Test Channel Frequency (MHz) Reading Level (dBμV) Factor (dB/m) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization 01 4009.00 39.62 -1.27 38.35 74.00 -35.65 Peak Horizontal 4825.00 40.87 0.06 40.93 74.00 -33.07 Peak Horizontal 11728.70 42.87 5.07 47.94 74.00 -26.06 Peak Horizontal 4009.00 40.00 -1.27 38.73 74.00 -35.27 Peak Vertical 4860.70 38.12 0.20 38.32 74.00 -35.68 Peak Vertical 7460.00 36.62 5.30 41.92 74.00 -32.08 Peak Vertical 06 3788.00 40.73 -1.37 39.36 74.00 -34.64 Peak Horizontal 4927.00 38.81 0.34 39.15 74.00 -34.85 Peak Horizontal 7460.00 37.51 5.30 42.81 74.00 -31.19 Peak Horizontal 3856.00 40.19 -1.34 38.85 74.00 -35.15 Peak Vertical 4901.50 39.99 0.13 40.12 74.00 -33.88 Peak Vertical 7458.30 38.82 5.29 44.11 74.00 -29.89 Peak Vertical 11 3820.30 40.79 -1.43 39.36 74.00 -34.64 Peak Horizontal 4796.10 40.82 -0.02 40.80 74.00 -33.20 Peak Horizontal 8316.80 39.48 6.32 45.80 74.00 -28.20 Peak Horizontal 3924.00 37.56 -1.26 36.30 74.00 -37.70 Peak Vertical 4910.00 38.95 0.22 39.17 74.00 -34.83 Peak Vertical 11767.80 40.16 4.93 45.09 74.00 -28.91 Peak Vertical Note: Measure Level (dBμV/m) = Reading Level (dBμV) + Factor (dB/m) Factor (dB/m) = Cable Loss (dB) + Antenna Factor (dB/m) - Pre_Amplifier Gain (dB) Report No.: R25S1040063-U202 84 of 232 Test Site WJ-AC2 Test Engineer Bob Zhang Test Date 2025-07-29 Test Mode 802.11n-HT40 Remark: 1. Average measurement was not performed if peak level lower than average limit. 2. Other frequency was 20 dB below limit line within 1-18 GHz, there is not show in the report. Test Channel Frequency (MHz) Reading Level (dBμV) Factor (dB/m) Measure Level (dBμV/m) Limit (dBμV/m) Margin (dB) Detector Polarization 03 3786.30 40.67 -1.37 39.30 74.00 -34.70 Peak Horizontal 4842.00 40.87 0.10 40.97 74.00 -33.03 Peak Horizontal 11296.90 40.51 5.67 46.18 74.00 -27.82 Peak Horizontal 4073.60 38.80 -1.43 37.37 74.00 -36.63 Peak Vertical 4794.40 38.99 -0.05 38.94 74.00 -35.06 Peak Vertical 11373.40 39.72 5.61 45.33 74.00 -28.67 Peak Vertical 06 3883.20 40.01 -1.24 38.77 74.00 -35.23 Peak Horizontal 4649.90 39.70 -0.…

Text truncated - open the document above for the full version.

Report No.: R25S1040063-U202 62 of 232 802.11be-EHT20 Out-of-Band Emissions - Ant 0 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 63 of 232 802.11be-EHT40 Out-of-Band Emissions - Ant 0 Channel 03 (2422 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 64 of 232 802.11be-EHT40 Out-of-Band Emissions - Ant 0 Channel 09 (2452 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 65 of 232 802.11b Out-of-Band Emissions - Ant 1 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 66 of 232 802.11b Out-of-Band Emissions - Ant 1 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 67 of 232 802.11g Out-of-Band Emissions - Ant 1 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 68 of 232 802.11g Out-of-Band Emissions - Ant 1 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 69 of 232 802.11n-HT20 Out-of-Band Emissions - Ant 1 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 70 of 232 802.11n-HT20 Out-of-Band Emissions - Ant 1 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 71 of 232 802.11n-HT40 Out-of-Band Emissions - Ant 1 Channel 03 (2422 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 72 of 232 802.11n-HT40 Out-of-Band Emissions - Ant 1 Channel 09 (2452 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 73 of 232 802.11ax-HE20 Out-of-Band Emissions - Ant 1 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 74 of 232 802.11ax-HE20 Out-of-Band Emissions - Ant 1 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 75 of 232 802.11ax-HE40 Out-of-Band Emissions - Ant 1 Channel 03 (2422 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 76 of 232 802.11ax-HE40 Out-of-Band Emissions - Ant 1 Channel 09 (2452 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 77 of 232 802.11be-EHT20 Out-of-Band Emissions - Ant 1 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 78 of 232 802.11be-EHT20 Out-of-Band Emissions - Ant 1 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission

Report No.: R25S1040063-U202 45 of 232 802.11n-HT20 - AVGPSD - Ant 1 Channel 01 (2412 MHz) Channel 06 (2437 MHz) Channel 11 (2462 MHz) 802.11n-HT40 - AVGPSD - Ant 1 Channel 03 (2422 MHz) Channel 06 (2437 MHz) Channel 09 (2452 MHz) Report No.: R25S1040063-U202 46 of 232 802.11ax-HE20 - AVGPSD - Ant 1 Channel 01 (2412 MHz) Channel 06 (2437 MHz) Channel 11 (2462 MHz) 802.11ax-HE40 - AVGPSD - Ant 1 Channel 03 (2422 MHz) Channel 06 (2437 MHz) Channel 09 (2452 MHz) Report No.: R25S1040063-U202 47 of 232 802.11be-EHT20 - AVGPSD - Ant 1 Channel 01 (2412 MHz) Channel 06 (2437 MHz) Channel 11 (2462 MHz) 802.11be-EHT40 - AVGPSD - Ant Channel 03 (2422 MHz) Channel 06 (2437 MHz) Channel 09 (2452 MHz) Report No.: R25S1040063-U202 48 of 232 A.5 Conducted Band Edge and Out-of-Band Emissions Test Result Test Site WZ-SR6 Test Engineer Molly Wu Test Date 2025-07-23 ~ 2025-08-05 Test Mode Data Rate / MCS Channel No. Frequency (MHz) Limit 11b 1 Mbps 01 2412 30 dBc 11b 1 Mbps 06 2437 30 dBc 11b 1 Mbps 11 2462 30 dBc 11g 6 Mbps 01 2412 30 dBc 11g 6 Mbps 06 2437 30 dBc 11g 6 Mbps 11 2462 30 dBc 11n-HT20 MCS0 01 2412 30 dBc 11n-HT20 MCS0 06 2437 30 dBc 11n-HT20 MCS0 11 2462 30 dBc 11n-HT40 MCS0 03 2422 30 dBc 11n-HT40 MCS0 06 2437 30 dBc 11n-HT40 MCS0 09 2452 30 dBc 11ax-HE20 MCS0 01 2412 30 dBc 11ax-HE20 MCS0 06 2437 30 dBc 11ax-HE20 MCS0 11 2462 30 dBc 11ax-HE40 MCS0 03 2422 30 dBc 11ax-HE40 MCS0 06 2437 30 dBc 11ax-HE40 MCS0 09 2452 30 dBc 11be-EHT20 MCS0 01 2412 30 dBc 11be-EHT20 MCS0 06 2437 30 dBc 11be-EHT20 MCS0 11 2462 30 dBc 11be-EHT40 MCS0 03 2422 30 dBc 11be-EHT40 MCS0 06 2437 30 dBc 11be-EHT40 MCS0 09 2452 30 dBc Report No.: R25S1040063-U202 49 of 232 802.11b Out-of-Band Emissions - Ant 0 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 50 of 232 802.11b Out-of-Band Emissions - Ant 0 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 51 of 232 802.11g Out-of-Band Emissions - Ant 0 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 52 of 232 802.11g Out-of-Band Emissions - Ant 0 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 53 of 232 802.11n-HT20 Out-of-Band Emissions - Ant 0 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 54 of 232 802.11n-HT20 Out-of-Band Emissions - Ant 0 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 55 of 232 802.11n-HT40 Out-of-Band Emissions - Ant 0 Channel 03 (2422 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 56 of 232 802.11n-HT40 Out-of-Band Emissions - Ant 0 Channel 09 (2452 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 57 of 232 802.11ax-HE20 Out-of-Band Emissions - Ant 0 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 58 of 232 802.11ax-HE20 Out-of-Band Emissions - Ant 0 Channel 11 (2462 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 59 of 232 802.11ax-HE40 Out-of-Band Emissions - Ant 0 Channel 03 (2422 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission Report No.: R25S1040063-U202 60 of 232 802.11ax-HE40 Out-of-Band Emissions - Ant 0 Channel 09 (2452 MHz) Reference Level High Band Edge Spurious Emission Report No.: R25S1040063-U202 61 of 232 802.11be-EHT20 Out-of-Band Emissions - Ant 0 Channel 01 (2412 MHz) Reference Level Low Band Edge Spurious Emission Channel 06 (2437 MHz) Reference Level Spurious Emission

MRT Technology (Suzhou) Co., Ltd. Report No.: R25S1040063-U202 Phone: +86-512-66308358 Report Version: V01 Web: www.mrt-cert.com Issue Date: 2025-12-05 Template Version: 2.1 1 of 232 RF MEASUREMENT REPORT FCC ID: LNQWF672 Applicant: Actiontec Electronics Inc. Product: Wi-Fi 7 Outdoor Mesh AP Model No.: WF-672A Brand Name: Actiontec FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15 Subpart C (Section 15.247) Result: Complies Received Date: 2025-06-23 Test Date: 2025-07-17 ~ 2025-09-24 Reviewed By: Kevin Guo Approved By: Robin Wu The test results relate only to the samples tested. This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report. Testing was performed in accordance with the applicable measurement procedures. The test results reported herein apply only to the specific item(s) tested. The test report shall not be reproduced except in full without the written approval of MRT Technology (Suzhou) Co., Ltd. Report No.: R25S1040063-U202 2 of 232 Revision History Report No. Version Description Issue Date Note R25S1040063-U202 V01 Initial Report 2025-12-05 Valid Report No.: R25S1040063-U202 3 of 232 CONTENTS Description Page 1. General Information ................................................................................................................................ 5 1.1. Applicant ...................................................................................................................................... 5 1.2. Manufacturer ................................................................................................................................ 5 1.3. Testing Facility ............................................................................................................................. 5 1.4. Product Information ...................................................................................................................... 6 1.5. Radio Specification under Test .................................................................................................... 7 1.6. Working Frequencies ................................................................................................................... 8 1.7. Antenna Details ............................................................................................................................ 9 2. Test Configuration ................................................................................................................................. 10 2.1. Test Mode................................................................................................................................... 10 2.2. Test System Connection Diagram ............................................................................................. 10 2.3. Test Software .............................................................................................................................. 11 2.4. Applied Standards ....................................................................................................................... 11 2.5. Test Environment Condition ........................................................................................................ 11 3. Antenna Requirements ......................................................................................................................... 12 4. Measuring Instrument ........................................................................................................................... 13 5. Decision Rules and Measurement Uncertainty .................................................................................. 14 5.1. Decision Rules ........................................................................................................................... 14 5.2. Measurement Uncertainty .......................................................................................…

Text truncated - open the document above for the full version.
