LNQ802URGMega G+ Wireless USB Adapter

User’s Guide 1 Wireless LAN 802.11g NIC Series 802URG User’s Guide Version 1.0 User’s Guide 2 Copyright statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. October 2005 User’s Guide 3 Contents 1. Introduction ...............................................................................................................4 2. Wireless LAN Basics ................................................................................................5 3. Installation for Windows platform ...........................................................................6 3.1. Installation Overview ...........................................................................................7 3.2. Install Procedure for Windows XP......................................................................8 3.3. Install Procedure for Windows 98/ME/2000 ....................................................... 9 4. Configuration Utility ................................................................................................11 5. Troubleshooting ...................................................................................................... 12 6. Certification: ............................................................................................................ 13 User’s Guide 4 1. Introduction Thank you for purchasing your Wireless LAN 802.11g Adapter. This User’ s Guide will assist you with the installation procedure. The package you have received should contain the following items: • Wireless LAN 802.11g Adapter • CD containing Wireless network adapter utility & drivers and User’s Guide Note: if anything is missing, please contact your vendor Note: This manual is valid for all Wireless LAN 11g Series products, such as PC Card, USB, mini-USB, PCI adapter, mini-PCI...etc. User’s Guide 5 2. Wireless LAN Basics Wireless LAN (Local Area Networks) systems offer a great number of advantages over a traditional, wired system. Wireless LANs (WLANs) are more flexible, easier to setup and manage and often more cost effective than their wired equivalence. Using radio frequency (RF) technology, WLANs transmit and receive data over the air, minimizing the need for wired connections. Thus, WLANs combine data connectivity with user mobility, and, through simplified configuration, enable movable LANs. With wireless LANs, users can access shared information without looking for a place to plug in and network managers can set up or augment networks without installing or moving wires. Wireless LANs offer the following productivity, convenience and cost advantages over traditional wired networks: • Mobility - Wireless LAN systems can provide LAN users with access to real-time information anywhere in their organization. This mobility supports productivity and service opportunities not possible with wired networks. • Installation Speed and Simplicity - Installing a wireless LAN system can be fast and easy and can eliminate the need to pull cable through walls and ceilings. • Installation Flexibility - Wireless technology allows the network to go where wires cannot go. • Reduced Cost-of-Ownership - While the initial investment required for wireless LAN hardware might be higher than the cost of wired LAN hardware, overall installation expenses and life-cycle costs will be significantly lower. Long-term cost benefits are greatest in dynamic environments requiring frequent moves, adds, and changes. • Scalability - Wireless LAN systems can be configured in a variety of topologies to meet the needs of specific applications and installations. Configurations are easily changed and range from peer- to-peer to full infrastructure networks, also allow roaming over a broad area. User’s Guide 6 3. Installation for Windows platform The following section will assist you in installing wireless LAN Adapter successfully. You will first install software (Utility) and then insert / attach the Wireless LAN Adapter to your system, and finally set the network properties to accommodate resource sharing and select the type of wireless network that you wish to install. The Wireless LAN card can easily be installed and used, without bothering to connect cables for keeping your computer to use network resources. User’s Guide 7 3.1. Installation Overview Here are some steps you will perform in establishing your wireless network connection: z Install the Access Point at first. AP is needed in case of Infrastructure network mode. z Install the software using the Install CD. z Install the Wireless LAN Card (WIRELESS LAN 802.11g Adapter). z Install the network protocol(s) required to communicate on your network. Most likely you will need the TCP/IP protocol. User’s Guide 8 3.2. Install Procedure for Windows XP 1. Insert the given Installation CD in the CD-ROM, then browse the CD content and find a file which be named setup.exe, double click it for beginning the installation. Follow the instruction to finish the installation. 2. After complete the procedure, insert your WLAN card into PCMCIA/PCI slot or USB connector of your system, and then system will detect new hardware. Note: Do not insert the WLAN Adapter until you are asked to do so, failure of which may result in unsuccessful installation of your WLAN device. User’s Guide 9 3.3. Install Procedure for Windows 98/ME/2000 1. Power on your computer and allow Windows 98/ME/2000 to load fully. 2. Be sure that the Wireless LAN 802.11g Adapter is not inserted yet. 3. Insert the given Installation CD in the CD-ROM, then browse the CD content and find a file which be named setup.exe, double click it for beginning the installation. 4. After complete the procedure, insert your WLAN card into PCMCIA/PCI slot or USB connector of your system, and then system will detect new hardware. Note: Do not insert the WLAN Adapter until …

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Made in Taiwan Mega G+ Wireless USB Adapter LNQ802URG

Page 3 Page 4 Page 5 Page 6

FCC ID: LNQ802URG Report No. RF940922L13B Operational Description This device is a Mega G+ Wireless USB Adapter, which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with DSSS technique will be applied. The EUT provides two RF chains, one chain with transmitter function, and one receiver chain. The transmitter of the EUT is powered by host equipment. The antennas used in this EUT are Dipole and Printed antenna without antenna connector. The other instruction, please have a look at the users manual.

FCC ID: LNQ802URG Report No: SA940922L13B 1 RF EXPOSURE REPORT REPORT NO.: SA940922L13B MODEL NO.: 802URG ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Actiontec Electronics ADDRESS: 760 North Mary Avenue, Sunnyvale, CA 94086 USA ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: LNQ802URG Report No: SA940922L13B 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: LNQ802URG Report No: SA940922L13B 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: LNQ802URG Report No: SA940922L13B 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 0.6dBi or 1.148 (numeric) 6.2 Output Power into Antenna & RF Exposure value at distance 20cm: For 802.11b DSSS Modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241250.8160.0121.0 6243750.5820.0121.0 11246250.6990.0121.0 For 802.11g OFDM Modulation: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241220.0450.0051.0 6243720.2770.0051.0 11246220.1370.0051.0

FCC ID: LNQ802URG Report No.: RF940922L13B1Report Format Version 2.0.3 Reference No.: 941011L15 FCC TEST REPORT REPORT NO.:RF940922L13B MODEL NO.:802URG RECEIVED:Sep. 26, 2005 TESTED:Sep. 26 ~ Oct. 11, 2005 ISSUED:Oct. 21, 2005 APPLICANT:Actiontec Electronics ADDRESS: 760 North Mary Avenue, Sunnyvale, CA 94086 USA ISSUED BY:Advance Data Technology Corporation LAB ADDRESS:No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION:No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 64 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: LNQ802URG Report No.: RF940922L13B2Report Format Version 2.0.3 Reference No.: 941011L15 TABLE OF CONTENTS 1.CERTIFICATION........................................................................................................ 4 2.SUMMARY OF TEST RESULTS................................................................................ 5 2.1MEASUREMENT UNCERTAINTY ............................................................................. 5 3.GENERAL INFORMATION ........................................................................................ 6 3.1 GENERAL DESCRIPTION OF EUT........................................................................... 6 3.2 DESCRIPTION OF TEST MODES............................................................................. 7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST........................................................ 8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.............................. 9 3.2.3 GENERAL DESCRIPTION OF APPLIED STANDARDS............................................11 3.2.4 DESCRIPTION OF SUPPORT UNITS ......................................................................11 4. TEST TYPES AND RESULTS...................................................................................12 4.1 CONDUCTED EMISSION MEASUREMENT............................................................12 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................................12 4.1.2 TEST INSTRUMENTS ..............................................................................................12 4.1.3 TEST PROCEDURES...............................................................................................13 4.1.4 DEVIATION FROM TEST STANDARD .....................................................................13 4.1.5 TEST SETUP............................................................................................................14 4.1.6 EUT OPERATING CONDITIONS..............................................................................14 4.1.7 TEST RESULTS .......................................................................................................15 4.2 RADIATED EMISSION MEASUREMENT .................................................................21 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...............................................21 4.2.2 TEST INSTRUMENTS ..............................................................................................22 4.2.3 TEST PROCEDURES...............................................................................................23 4.2.4 DEVIATION FROM TEST STANDARD .....................................................................24 4.2.5 TEST SETUP............................................................................................................24 4.2.6 EUT OPERATING CONDITIONS..............................................................................24 4.2.7 TEST RESULTS .......................................................................................................25 4.3 6dB BANDWIDTH MEASUREMENT ........................................................................32 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ......................................................32 4.3.2 TEST INSTRUMENTS ..............................................................................................32 4.3.3 TEST PROCEDURE.................................................................................................33 FCC ID: LNQ802URG Report No.: RF940922L13B3Report Format Version 2.0.3 Reference No.: 941011L15 4.3.4 DEVIATION FROM TEST STANDARD .....................................................................33 4.3.5 TEST SETUP............................................................................................................33 4.3.6 EUT OPERATING CONDITIONS..............................................................................33 4.3.7 TEST RESULTS .......................................................................................................34 4.4 MAXIMUM PEAK OUTPUT POWER ........................................................................40 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT..........................40 4.4.2 INSTRUMENTS ........................................................................................................40 4.4.3 TEST PROCEDURES...............................................................................................41 4.4.4 DEVIATION FROM TEST STANDARD .....................................................................41 4.4.5 TEST SETUP............................................................................................................41 4.4.6 EUT OPERATING CONDITIONS..............................................................................41 4.4.7 TEST RESULTS .......................................................................................................42 4.5 POWER SPECTRAL DENSITY M…

Text truncated - open the document above for the full version.

FCC ID: LNQ802URG Report No.: RF940922L13B61Report Format Version 2.0.3 Reference No.: 941011L15 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: LNQ802URG Report No.: RF940922L13B62Report Format Version 2.0.3 Reference No.: 941011L15 RADIATED EMISSION TEST
