LNQGT704802.11b/g Wireless Gateway and Wireless Router

1 Connect the Gateway to a Computer Step 3Plug the smaller end of the Power Cordinto the Black Porton the back of the Gateway. Step 4Plug the larger end of the Power Cordinto a Power Outlet . Step 1Get the Wireless DSL Gateway from your DSL Quick Start Kit. Step 2Get the Power Cord from your DSL Quick Start Kit. Wireless DSL Gateway Power Cord Power Cord Black Port Step 11Get the Black orGray DSL Cable from your DSL Quick Start Kit. Step 12Plug one end of the DSL Cableinto the Gray Port on the back of the Gateway. Step 6Confirm the Power Light on the Gateway is SOLID Green. Power Light on Wireless DSL Gateway Step 5Make sure the Power Switch is ON. Power Switch Step 14Confirm that the Powerand DSL Lightsare solid Green. This may take up to 30 seconds. Power & DSL Lights on Wireless DSL Gateway Step 7Get the Yellow Cable. Step 8Plug one end of the Yellow Cableinto one of the Ye l l o w P o r t son the back of the Wireless DSL Gateway. Step 9Make sure that your computer is turned on. Then, plug the other end of the Yellow Cable in the Ethernet Porton the back of the computer. An Ethernet Portlooks similar to a regular Phone Jack, but is slightly larger. Note:If the Ethernet Light does NOTturn green, make sure the Yellow Cable is properly connected on both ends. Note:The DSL light may blink. Step 10Confirm that 1 of the 4 Ethernet lightson the Gateway is Green. This may take a few moments. Ethernet Lights on Wireless DSL Gateway Step 13Plug the other end of the DSL Cableinto the Phone Jack closest to your computer. Note:If the DSL Light continues to blink, make sure you received notification from your DSL Internet Service Provider that your DSL service is On. 2 Install the Phone Filters Step 1Unplug your Telephones (or other devices) from their current Phone Jacks. Step 2Open the Clear Bag and remove the Phone Filters from the bag. What are Phone Filters?Phone Filters separate the DSL signal from the voice signal, allowing you to talk on the telephone and be online at the same time. All Deviceswith the same phone number as your DSL Line require Phone Filters. This includes telephones, fax machines, caller ID boxes, satellite TV receivers and answering machines. Note:The number and type of Phone Filters included in this kit may vary. Power Outlet Power Cord Flip this Quick Start Guide over to continue  Yellow Port White Port Phone Port Yellow Cable Black Cable Black Cable Step 5Make sure you did NOT put a Phone Filter on the Black DSL Cable. Make sure your setup looks EXACTLY like the picture to the right. Step 3Plug a Phone Filterinto every Phone Jackin your house with the same phone number as your DSL Line, and a telephone(or other device) connected to it. If you need additional Phone Filters, contact your DSL Internet Service Provider. Step 4Plug one end of the Phone Cordinto the Phone Filter and keep the other end attached to the telephone (or other device). Power Cord DSL Cable Yellow Cable Phone Jack Phone Filter Phone Jack Phone Phone Filter Phone Cord 1 Connect the Gateway to a Computer Note: If you are a Macintosh® User, or other non- Windows User, please use this Quick Start Guide. This Quick Start Guide will walk you through the easy steps to set up your Wireless DSL Gateway. During this process, we’ll show you how to: • Wireless DSL Gateway • Black Power Cord • Black or Gray DSL Cable • Yellow Cable • Clear Bag NEXT Quick Start Guide Wireless DSL Gateway Model# GT704WG You will need the following items from your Actiontec Quick Start Kit: 2 Install the Phone Filters 3 Configure the Gateway 4 Turn the Wireless Signal ON Step 1Open a Web browser (Netscape Navigator or Internet Explorer, for example). In the address bar, enter http://192.168.0.1, then press Enteron the keyboard. Step 2The “Main Menu”screen appears. Select Setup/ Configuration. 3 Configure the Gateway 4 Turn the Wireless Signal ON Step 3Follow the instructions in the “Set Up/Configuration”screen, then click Begin Basic Setup. Step 7Click Save and Restart in the “Save and Restart”screen. Step 9Go to the “Main Menu” screen. Select Utilities. Step 8The “Congratulations” screen appears. The Power Light flashes rapidly while the Gateway restarts, then glows SOLID green when fully operational. The DSL Light will also glow SOLID green. Please go to Section 4 to complete the setup of this Gateway. If your DSL Light flashes, please go to Step 9. Step 12Click Save and Restart in the “Save and Restart”screen. Step 13The “Congratulations” screen appears. The Power Light flashes rapidly while the Gateway restarts, then glows SOLID green when fully operational. The DSL Light will also glow steadily green. Now go to Section 4. Step 4In the next window, follow the onscreen instructions, then click Next. Step 5In the next window, select the type of connection by clicking on the circle next to PPPoAor PPPoE. If unsure about the selection, contact your ISP. Then click Next. Step 6Enter the User Name and Password provided by the ISP in the ‘DSL Broadband Connection - PPP’screen. Click Next. Step 10Click on DSL Settings . Step 11Input VPI/VCI settings as provided by your ISP. Click Save and Restart. This will take you to the “Save and Restart”screen. If an error stating the Web browser was unable to connect to the Internet appears, check the configuration settings. Ensure all the information required by the ISP is entered correctly. Your Wireless DSL Gateway has the capability to transmit a wireless signal throughout your home. To turn the Wireless Signal ON, follow the instructions for steps 1-5 below. Note: If this screen does not appear, make sure your Ethernet port is configured for Dynamic IP. Congratulations!You have successfully installed your Wireless DSL Gateway. You can now access the Internet at high speed. Part No: 0530-0466-000QS663/1203 Step 3Click Begin Advanced Setup . Step 4Select Wireless Settings from the menu on the left. Step 1Go back to the “Main Menu”screen. Select Setup/ Configuration . Step 2Select Advanced Setu…

Text truncated - open the document above for the full version.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA RF MODULE DIAGRAM OF GT704-WG AND GT704-WR TO TI TNETD 7300/A NETWORK PROCESSOR ANTENNA 802.11 B/G MODULE VLYNK BUS TI TNETW1130 MAC AND BASEBAND PROCESSOR RC 2326 2.4-2.5 GHz RFFE CLOCK 62.5MHz RC 2422 IF Transceiver & Synthesizer OSC 40.000 MHz IF 374 MHz CLOCK 40.000MHz I/Q

55 44 33 22 11 D D C C B B A A TI NETWORK PROCESSORTNETD 7300 4MB FLASH DEVICE 16M SDRAM DEVICE EMIF BUS 802MTG 802.11 b/gWireless Adapter USB PORT GT704-WG DIAGRAM POWERSUPPLYSYSTEM VLYNQInterface WANPORTRJ11 ADSL PHY LANPORT2 MII LANPORT3 MARVELL 6-Port Switch LANPORT4 LANPORT1 http://www.actiontec.comACTIONTEC ELECTRONICS, INC Tuesday, December 09, 2003 A3760 N. MARY AVE.SUNNYVALE, CA94086 DW-07/24/2001 DIAGRAM SizeScale CAGE Code DWG NO Rev Sheet of Modified:

Actiontec Electronics, Inc. FCC ID: LNQGT704 EXHIBIT C - EUT PHOTOGRAPHS EUT – Chassis Top View EUT – Chassis Bottom View Actiontec Electronics, Inc. FCC ID: LNQGT704 EUT – Chassis Port View EUT – Antenna View Actiontec Electronics, Inc. FCC ID: LNQGT704 Power Adapter Top View Power Adapter Rear View

EXHIBIT A - FCC ID LABEL INFORMATION Proposed FCC ID Label Specifications : Text is black or white in color and is left justified. Labels are silk-screened and shall be “permanently affixed” at a conspicuous location on the EUT. Proposed Label Location on EUT Bottom Side of EUT/FCC ID Label FCC ID: I38-NA8300-001 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2.1875" 1.0" FCC ID: LNQGT704

Actiontec Electronics, Inc. FCC ID: LNQGT704 EUT – Chassis Cover Off View EUT – Main Board Component View Actiontec Electronics, Inc. FCC ID: LNQGT704 EUT – Main Board Solder View EUT – Antenna Connection View

APPROVAL SHEET CUSTOMER FILE NO . : ESCRIPTION :2.4GHZ Antenna ANTENNIQUES P/N : MCS-003-190-01 CUSTOMER P/N : DATE : 92 07 4 Customer Approval Antenniques Co.,Ltd 12265 TEL02-2668-5793 FAX02-2668-5795 5F,No.6,Laine 122, Sec 2,Ganyun St, Shulin Chulin City, Taipei Hsien,238 Taiwan R.O.C. [email protected] www.antenniques.com.tw TECHNICAL DATA Electrical Properties Frequency Range 2.42.5GHz Impedance 50 Ohm nominal VSWR 2.0 Gain 2dBi Radiation Omni Polarization Vertical Electrical Wave /4 Dipole Connector SMA Plug Reverse Mechanical Properties Antenna Cover PU Color Black Operation Temperature2060 Storage Temperature -3075 H-PLANE E-PLANE 90 270 0 180 0 270 90 180 H-PLANE2.40 PEAK1.823 AVER 0.8 , E-PLANE H-PLANE2.45 PEAK2.13 AVER1.0 E-PLAME H-PLANE2.50 PEAK1.72 AVER0.73 E-PLANE

SPECIFICATIONS Of Wireless DSL Gateway GT704-WG Ver. 1.10 Date: 1/11/2004 Contents 1. Description of Wireless DSL Gateway 2. Features 3. Software Specifications 4. Physical Specifications 5. Environmental Operating Range 6. Power Requirements 7. Power Dissipation Appendix: GT704-WG Panel, LED and Connectors Definition 1. Description of Wireless DSL Gateway Actiontec Wireless DSL Gateway (GT704-WG) is designed for residential and small-office applications to link to the internet using ADSL. This device incorporates a built-in broadband ADSL interface, wireless LAN access and Four Fast Ethernet switch ports, all in one compact-sized box. The device includes TI’s TNETD7300 Broadband Communication Processor and Peripherals. The TNETD7300 is the most densely integrated system-on-a-chip ever offered to the ADSL CPE market by Texas Instruments. The TNETD7300 is an ADSL bridge/router solution, integrating a broadband communications processor and peripherals, ADSL physical layer, ADSL line driver, USB physical layer, and Ethernet physical layer. The device also includes TI’s TNETW1130 Medium-Access Controller(MAC) and Baseband Processor for Wireless-LAN(WLAN) application. The TNETW1130 supports IEEE Std 802.11b(2.4GHz-band) and IEEE Std 802.11g(2.4GHz-band) system. Wireless LAN speeds are up to 54Mbps. This device comes with four built-in 10/100Mbps switch ports, providing instant connection to Fast Ethernet servers and workstations. All switch ports support autosensing of network speeds, full/half duplex and MDI/MDI-X auto crossover. With a built-in IEEE 802.11b/g wireless LAN interface, the GT704-WG connects all wireless user together (with speeds up to 54Mbps) while providing them with the internet access. WEP 64/128/256 bit encryption, 802.1x, WPA and WPA-PSK wireless security are supported. The integrated ADSL modem is rate-adaptive and it supports downstream data rates up to 8Mbps and upstream data rates up to 1 Mbps. This hardware also supports ADSL2/2+ standard which will come in the future firmware upgrades. 2. Features • Supports Plug-and-Play installation for systems with Windows Operating Systems (98, 98SE, Me, 2000 and XP) • Support One ADSL WAN port (RJ11) • Compliant with full-rate ANSI T1.413 Issue 2, ITU G.992.1(G.dmt) and G.992.2(G.lite) standard • Auto-handshake for different ADSL flavors • Compliant with USB 1.1 device specification • Supports 12-Mbits/s USB data rate (Full Speed) • Bridged Ethernet over ATM, PPP over ATM, PPP over Ethernet • Precise ATM traffic shaping • IP packet routing and transparent bridge • Routing protocol supports RIP-1, RIP-2, Static Routing • Build-in NAT, DHCP server • DNS relay support • PAP/CHAP authentication, administrative passwords through Telnet • 64, 128 and 256-bit WEP and WPA wireless LAN security • Compliant with IEEE 802.3 Ethernet standard • Supports Four 10/100 Base-T Ethernet ports • Flow control support for Fast Ethernet • Web-based configuration setup • Default configuration backup restore • FTP firmware upgradeable • Support web download • Support 802.11b/g 3. Software Specifications Features Descriptions ADSL • ITU G.992.1 (G.dmt), G.992.2 (G.Lite), G.994.1 (G.hs), G.992.3 (G.dmt.bis)**,G.992.4(G.lite.bis)**, G.992.5 (ADSL2plus)** • ANSI T1.413 Issue2 ** available in future firmware upgrade ATM • ATM User-Network Interface, Version 3.1, Section 3. The ATM Forum, 1995. o The full VPI range (0 – 4095) and VCI range (1 – 65535) are supported. o Adaptation Layers AAL5, AAL2 and AAL0 are supported. o The traffic shaping function supports traffic classes CBR, VBR (real time and non-real time) and UBR (with PCR limiting). OAM • ITU-T Recommendation I.610 B-ISDN Operation and Maintenance Principles and Operations. o F5 segment and end-to-end loopback cells Ethernet • ISO/IEC 8802-3; ANSI/IEEE standard 802.3 part 3 o IEEE 802.3x – Full Duplex capable o IEEE 802.3u – Auto negotiation • RFC 1213 S K. McCloghrie, M. Rose, "Management Information Base for Network management of TCP/IP-based internets: MIB-II", 03/26/1991. • D-I-X, "The Ethernet - A Local Area Network: Data Link Layer and Physical Layer Specifications", Digital, Intel, and Xerox, November 1982. Wireless • IEEE 802.11B • IEEE 802.11G Wireless Security • WEP 64/128/256 bit encryption • WPA, WPA-PSK • 802.1x • SSID Broadcast enable/disable Bridge • Transparent MAC level bridge for Ethernet-like devices in conformance with the IEEE802.1d specification. • ISO/IEC 10038:1993 (E), Std 802.1D. • RFC1213 S K. McCloghrie, M. Rose, "Management Information Base for Network Management of TCP/IP-based internets: MIB-II", 03/26/1991. • RFC1493 Definitions of Managed Objects for Bridges. E. Decker, P. Langille, A. Rijsinghani, & K. McCloghrie. July 1993. IP • RFC 791, Internet Protocol. J. Postel. Sep-01-1981.RFC 950, Internet Standard Subnetting Procedure. J.C. Mogul, J. Postel. Aug-01- 1985. • RFC 1122, Requirements for Internet hosts – communication layers. R.T. Braden. Oct-01-1989. • RFC 1191, Path MTU discovery. J.C. Mogul, S.E. Deering. Nov-01-1990. • RFC 1213, Management Information Base for Network Management of TCP/IP-based internets:MIB-II. K. McCloghrie, M.T. Rose. Mar-01-1991. • RFC 894, Standard for the transmission of IP datagrams over Ethernet networks. C. Hornig. Apr-01-1984. ARP • RFC 826, Ethernet Address Resolution Protocol: Or converting network protocol addresses to 48.bit Ethernet address for transmission on Ethernet hardware. D.C. Plummer. Nov-01-1982. ICMP • RFC 792, Internet Control Message Protocol. J. Postel. Sep-01-1981. UDP • RFC 768, User Datagram Protocol. J. Postel. Aug-28-1980. TCP • RFC 793, Transmission Control Protocol. J. Postel. Sep-01-1981. IP Router • Support Static Route.. • Support unnumbered mode RIP • RFC 1058, Routing Information Protocol. C.L. Hedrick. Jun-01-1988. • RFC 1723, RIP Version 2 - Carrying Additional Information. G. Malkin. November 1994. • RFC 2453, RIP Version 2. G. Malkin. November 1998. • RFC 1812, Requirements for IP Version 4 Rout…

Text truncated - open the document above for the full version.

1 Operation Theory of Actiontec GT704-WG Here is the block diagram of GT704-WG. GT704-WG is a cost-effective full-rate ADSL Ethernet/USB Wireless Gateway. It provides four 10/100 Based Ethernet LAN port, one USB 1.1 device port, and an embedded 802.11G wireless Access Point. GT701-WG is based on TI’s TNETD7300 Broadband Communication Processor , TNETW1130 802.11 MAC ,Baseband Processor and Marvell 88E6060 6-port 10/100 Ethernet switch TNETD7300 RC2422 RC2326 H1164 TNETW1130 SDRAM FLASH 35.328MHZ 25MHZ T10120 4-port RJ45 USB DUAL RJ11 Micro Filter 88E6060 2 Broadband Communication Controller The Ethernet/USB Wireless Gateway uses TI’s TNETD7300 as main chip. The control system is comprised of TNETD7300, Flash and SDRAM . The TNETD7300 is the most densely integrated system-on-a-chip ever offered to the ADSL CPE market by Texas Instruments. The TNETD7300 provides a total ADSL bridge/router solution. It integrates a broadband communications processor with ADSL physical layer, ADSL line driver, USB physical layer, Ethernet physical layer, and power management modules. It is an ideal ADSL CPE device for residential and small-office applications. SDRAM: Store the program and data that run on CPU. Flash: Store firmware and parameter used in processing. Ethernet /USB and ADSL interfaces Ethernet interface uses Marvell 88E6060 6-port 10/100 Ethernet switch and H1164 Ethernet transformer. The transformer then connected to an 4-port RJ45 Ethernet connector. USB interface also uses TNETD’s physical layer and then connect to an USB connector. . ADSL also uses TNETD’s physical layer and T10120 ADSL transformer. The transformer is used for isolating and reducing common mode emissions. There is an on board micro filter, which allow a phone connect to the gateway directly. 802.11b/g Radio Path TNETW1130 is a 802.11 MAC and Baseband Processor. It is responsible for all 802.11b/g low layer process and interfaced with TNETD7300 and 802.11 radio chip set. RC2422 and RC2326 is a complete 802.11b/g dual band WLAN two-chip radio. RC2422 is IQ/IF transceiver with dual VCO synthesizers and is designed to perform the IQ conversion at 374 MHZ IF as well as provide an RFLO and control logic to RC2326 RFFE (radio frequency front end). It uses a common IF frequency for both bands, which eliminates the need for an additional IF filter in dual band applications. While RC2326 is dual band RFFE and is designed to perform RF up and down conversions in the unlicensed ISM band. It includes the LNA, PA, mixer, bias circuit, RX gain control, transmit coupler and T/R switches.

Item Qty ReferencePartDescriptionPackage 10848 C806,C807,C808,C809,C810,10nFX7R, 10%,16V,0402, Ceramic Capacitor;402 C811,C812,C813,C820,C821, C822,C823,C824,C825,C826, C827,C828,C829,C830,C831, C832,C833,C834,C835,C836, C837,C839,C840,C841,C842, C843,C844,C851,C852,C855, C856,C860,C861,C866,C867, C871,C883,C888,C891,C906, C909,C914,C923 1091C814180pFNPO, 5%, 16V, 0402, Capacitor;402 1109C815,C816,C848,C850,C854,10uFY5V, 20%, 16V, 0805, Ceramic Capacitor;805 C857,C858,C859,C870 1111C8171000pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1123C818,C905,C90710pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1135C838,C862,C863,C864,C8681.0uFY5V, 20%, 16V, 0402, Ceramic Capacitor;402 1149C849,C853,C873,C880,C904,0.10uFX7R, 10%,16V,0402, Ceramic Capacitor;402 C908,C919,C921,C927 1151C865NLTBD402 1164C869,C881,C882,C88622nFX7R, 10%,16V,0402, Ceramic Capacitor;402 11711 C872,C877,C879,C884,C896,100pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 C897,C898,C910,C920,C922, C926 1181C87415pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1191C87522pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1201C87682pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1216C878,C885,C887,C890,C892,1.0nFX7R, 10%,16V,0402, Ceramic Capacitor;402 C893 1221C889680pFX7R, 10%,16V,0402, Ceramic Capacitor;402 1232C895,C8942pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1242C903,C9001pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1251C9016.8pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1261C9135.6nFX7R, 10%,16V,0402, Ceramic Capacitor;402 1271C9156.0pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1282C916,C924470pFX7R, 10%,16V,0402, Ceramic Capacitor;402 1291C91747pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1302C925,C91833pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1312C944,C9450.5pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1321D404SMV1255-79SMV1255-79SC-79 1339FB503,FB504,FB505,Bead-600mA0603, 600mA, Bead;603 FB506,FB507,FB508,FB509, FB510,FB511 1342FL1,FL2MDR741FQuasi Microwave Band Dieletric FilterMFE 1351FL3374MHz SAW374 Mhz Bandpass Filter;SMP-20 1361J404HEADER_NLFor antana Cable;HDR2 1371L409NL0805, Chip Inductor;805 1382L413,L41233nH33NH, 0402 Chip Inductor;402 1392L414,L41739nH39NH, 0402 Chip Inductor;402 1401L41520nH20NH, 0402 Chip Inductor;402 1411L41643nH43NH, 0402 Chip Inductor;402 1421Q409MMDT3904-7NPN Small Signal Transister;SOT-363 1432Q410,Q414MMBT2222ATNPN Small Signal Transister;SOT-523 1441Q412Si1305DLP-Channel, 1.8V MosfetSC70-3 GT704 is an USB/Ethernet DSL Gateway based on GT704-WG design that depopulated the following parts to remove wireless function from GT704-WG. Page 1 of 2 1451Q413MMDT3906-7PNP Small Signal Transister;SOT-363 1461R11311.10k0402, 1%, Chip Resister;402 1472R1132,R1157100402, 5%, Chip Resister;402 1481R11332.49k0402, 1%, Chip Resister;402 1491R11343.01k0402, 1%, Chip Resister;402 1501R11352.00k0402, 1%, Chip Resister;402 1513R1137,R1176,R11824.7k0402, 5%, Chip Resister;402 1523R1139,R1141,R11540_NL0402, 5%, Chip Resister;402 1531R114010k_NL0402, 5%, Chip Resister;402 1549R1143,R1144,R1150,R1151,10k0402, 5%, Chip Resister;402 R1152,R1155,R1160,R1161, R1183 1551R11452.7kPanasonic402 1561R1146200k0402, 5%, Chip Resister;402 1572R1147,R114856k0402, 5%, Chip Resister;402 1581R114920k0402, 1%, Chip Resister;402 1591R112600402, 5%, Chip Resister;402 1601R115622k0402, 5%, Chip Resister;402 1611R11581M0402, 5%, Chip Resister;402 1621R11598200402, 5%, Chip Resister;402 1631R11626800402, 5%, Chip Resister;402 1642R1163,R11642000402, 5%, Chip Resister;402 1651R11651300402, 5%, Chip Resister;402 1662R1166,R11681.0k0402, 5%, Chip Resister;402 1674R1167,R1173,R1174,R11801000402, 5%, Chip Resister;402 1681R11692100402, 5%, Chip Resister;402 1691R11706190402, 1%, Chip Resister;402 1702R1175,R1181200k0402, 1%, Chip Resister;402 1712R1177,R11792.15k0402, 1%, Chip Resister;402 1721R11781.54k0402, 1%, Chip Resister;402 1732R1219,R1220470402, 5%, Chip Resister;402 1747TP410,TP411,TP416,TP417,TP00TEST POINT;TP TP418,TP419,TP429 1751TP414TEST_TXTEST POINT;TP 1761TP415TEST_RXTEST POINT;TP 1771TP430TCKTEST POINT;TP 1781TP431TDITEST POINT;TP 1791TP432TDOTEST POINT;TP 1801TP433TMSTEST POINT;TP 1811U702AME8800LEEV1.5V/300mA, LDO, RF, Linear Regulator;SOT23-5 1821U704TNET1130-GHVMAC, Baseband Processor;BGA288 1831U705AME8800LEEV2.85V/300mA, LDO, RF, Linear Regulator;SOT23-5 1841U706AT24C08-10TC-2.5EEPROMTSSOP-8 1851U707AME8800MEEV1.8V/300mA, LDO, RF, Linear Regulator;SOT23-5 1861U708SN74LVC2GU04DCKR Dual Inverter Gate;SC70-6 1871U709RC2422RADIA RF CHIPSET SPC-001073-1121LPCC56_8X8 1881U710RC2326RADIA RF CHIPSET SPC-001073-1121LPCC32_5X5 1891U712LMV321IDCKROPSC70-5 1901X240MHz Parallel40Mhz, Parallel; SMT Crystal;XTAL 5X3.2 Page 2 of 2

4 Port Ethernet Router With ADSL Modem & 802.11B/G GT704-XX Revised: Friday, December 12, 2003 GT704-XX 00-0528 Revision: 1A+ ACTIONTEC ELECTRONICS, INC 760 N. MARY AVE. SUNNYVALE, CA94086 http://www.actiontec.com Bill O Page1 Item Qty ReferencePartDescriptionPackage 11 CC2091.0uFCAP_DUAL_0805_TH 21 C2120.033uF CAP_400_200D 31 CM200AQT04-40COMMON MODE CHOKEchoke04 48 C1,C3,C4,C13,C47,C62,C64,10UF/16V16V, 10 UF,M Series Aluminum Electrolytic CCAP_100 C82 520 C6,C11,C27,C28,C29,C30,0.1UF0.1UF; 10%; 16V; X7R; 603 C32,C33,C36,C37,C38,C39, C43,C44,C45,C49,C50,C55, C56,C61 63 C7,C424,C425100UF/16VM Series Aluminum Electrolytic Cap.CAP_100X250 71 C16270pF603 813 C31,C34,C40,C41,C46,C48,0.01UF0.1UF; 10%; 16V; X7R; 603 C51,C52,C53,C57,C58,C59, C60 95 C69,C70,C71,C72,C1501000PF/2KVCAP_200_CER 1047 C108,C117,C118,C119,C120, 0.1uF603 C121,C122,C123,C141,C142, C143,C144,C270,C402,C405, C415,C416,C417, C419,C420,C421,C422,C426, C430,C431,C433,C436,C438, C439,C440,C441,C442,C443, C444,C445,C447,C448,C449, C450,C451,C452,C453,C461, C462,C463,C464,R426 112 C127,C1427pF22PF; 10%; 16V; NPO; 603 123 C130,C67,C6833pF33PF; 10%; 16V; NPO; 603 1 C15615pF15PF; 10%; 16V; NPO; 603 132 C218,C203470pF CER MONO 470PF 50V J NPO 0805805 144 C204,C206,C215,C217180pF CER MONO 180PF 50V K NPO 0805805 152 C216,C205390pF CER MONO 390PF 50V J NPO 0805 (P805 164 C207,C208,C213,C214270pF 270PF 50V J NPO 0805805 172 C210,C211680pF CER MONO 680PF 50V J NPO 0805805 182 C400,C43247UF/16VM Series Aluminum Electrolytic Cap.CAP_100X250 198 C403,C404,C800,1000pF603 C801,C802,C803,C804,C805 201 C4061800uFCAP_M_700_300_200D 211 C4131000uFCAP_200_400D 222 C427,C42810UF/16VM Series Aluminum Electrolytic Cap.CAP_100X250 231 C446470UF/6.3VM Series Aluminum Electrolytic Cap.CAP_100X350 242 D210,D211SMAJ11D214AA 252 D401,D403SMB5817D214AA 261 FB2FBEAD805 274 FB102,FB103,FB104,FB105FBEAD603 282 FB400,L4FBEAD 100 OHM@100MHZ 3A 1206(CHILISIN1206 291 GD200GDTGDT_DUAL_TH_NL 301 JP1HEADER 10X2_NLEXTENTION PORT;HDR2X10 311 JP212PINHDR_RA_NLHDR_RA2X6HDR2X6 322 JP3,JP603HEADER_1X6H6 331 J6AMP-1470113-1RJ45X4 341 J100USB PORTCON_AMP787780 351 J400 POWER JACKDIA-1.28MM RA,44-1600-1245DCPWR_DTD_017 362 LED1,LED3Power L-3VEGW KINGBRIGHT RED/GREENLED 3mm 377 LED2,LED4,LED5,LED6SYNC 3mm GREEN (HIGHT LIGHT)LED 3mm LED7,LED8,LED9 381 L401100uH IRON POWER CHOKE 100UH@100KHTIR_DUAL 391 L40210uH 10UH 2A M(DELTA:SI104-100/CHILISSI104_TOROID 401 L4052.2uH 2.2UH 500MA M(DELTASI54-2R2/CHSI54 412 L406,L407100uH 100UH 400MA(DELTA SIQ74-101)SIQ74_DUAL 423 Q2,Q401,Q1FCX1149ASOT89 431 Q32N3906SOT23_NPN_PNP 441 Q100BSS138SOT23_MOSFET 452 Q408,Q403IRLML2402SOT23_MOSFET 461 Q405IRLML6401SOT23_MOSFET 471 Q4062N3904SOT23_NPN_PNP 4823 R11,R14,R15,R16,R29,R31,0 5%;SMT CHIP RES;603 R34,R36,R53,R86,R102, R118,R138,R140,R223, R413,R421,R430,R431,R432, R447,R63,R406 502 L2,L30 5%;SMT CHIP RES;1206 511 R2261K603 5216 R17,R18,R19,R37,R38,R39,49.9R_1%1%;SMT CHIP RES;603 R40,R44,R46,R47,R49,R57, R59,R61,R67,R70 5325 R22,R27,R33,R35,R48,R54,4.7K5%;SMT CHIP RES;603 R91,R96,R101,R105,R106, R107,R108,R110,R112,R114, R115,R130,R133,R134,R232, R270,R274,R449,R450 543 R30,R403,R441100 5%;SMT CHIP RES;603 551 R322K5%;SMT CHIP RES;603 5619 R52,R55,R56,R58,R60,R62,33 5%;SMT CHIP RES;603 R65,R66,R68,R69,R78,R83, R92,R93,R117,R125, R128,R135,R136 5711 R1,R64,R71,R72,R73,R74,120 1/16W;5%;SMT CHIP RES;603 R76,R79,R81,R84,R85 582 R104,R10320K5%;SMT CHIP RES;603 591 R10947K5%;SMT CHIP RES;603 601 R1111K5%;SMT CHIP RES;603 612 R116,R14249.9 1%;SMT CHIP RES;603 624 R119,R410,R412,R44410.0K1%;SMT CHIP RES;603 632 R121,R12027 1%;SMT CHIP RES;603 641 R12215.0K1%;SMT CHIP RES;603 652 R123,R4461.50K1%;SMT CHIP RES;603 666 R429,R436,R437,L7,R4330 5%;SMT CHIP RES;805 R434 672 R144,R1450.22 5%;SMT CHIP RES;805 681 R146100 RES;5%;1/8W;0603603 692 R148,R1491M1%;SMT CHIP RES;603 7048 R150,R151,R152,R153,R154,33 RES;5%;0402402 R155,R156,R157,R158,R159, R160,R161,R162,R163,R164, R165,R166,R167,R168,R169, R170,R171,R172,R173,R174, R175,R176,R177,R178,R179, R180,R183,R184,R185,R186, R187,R188,R189,R190,R191, R192,R193,R194,R195,R196, R197,R198,R199 712 R200,R22112.4 12.4 OHM 1% 0805805 722 R218,R2038.06K 8.06K OHM 1% 0603603 732 R204,R217665 665 OHM 1% 0603603 742 R216,R2055.23K 5.23K OHM 1% 0603603 752 R206,R215604 604 OHM 1% 0603603 762 R214,R2077.32K 7.32K OHM 1% 0603603 772 R213,R208887 887 OHM 1% 0603603 782 R211,R210499 499 OHM 1% 0603603 7926 R235,R236,R238,R239,R240, 4.7K5%;SMT CHIP RES;402 R241,R242,R243,R244,R245, R247,R248,R249,R250,R251, R252,R254,R255,R256,R257, R258,R259,R260,R262,R233 R1127 802 R295,R2960 5%;SMT CHIP RES;1206 8112 R301,R302,R305,R308,R309,75 1%;SMT CHIP RES;603 R312,R315,R316,R319,R321, R322,R325 821 R303348 5%;SMT CHIP RES;603 831 R40016.5K1%;SMT CHIP RES;603 841 R40110K1%;SMT CHIP RES;603 851 R404100 5%;SMT CHIP RES;2512 861 R41120K1%;SMT CHIP RES;603 871 R425100K5%;SMT CHIP RES;603 881 R4271.0M5%;SMT CHIP RES;603 891 R44351K1%;SMT CHIP RES;603 901 R44530 5%;SMT CHIP RES;1206 911 R61310K_E1%;SMT CHIP RES;603 922 R614,R6150_E_NL603 931 R112512.4K1%;SMT CHIP RES;603 941 SW1SW SLIDESW, SLIDE,2 POS,R ANGL1101M2S3AV2QE2 951 SW270ESWITCH_TL1105RF250QSW_MOM_VERT_PC 961 T1H11644 Port Switch TransformerSMT-40 971 U3 MC34063AD SOP-8 981 T2001.5mH 2:1XFORMER_50217_10P_D 991 U674AHC08SO_14P 1001 U1288E6060PQFP128 1011 U100TNETD7300BGA_324_1MM 1021 U104AM29LV320DTSOP48 1031 U105MT48LC8M16A2TSOP54 1041 U402TL331IDBVPSOP_5P_DBV 1051 Y10035.328MHzTH_HC49US 1062 Y103,Y125MHzTH_HC49US Wireless 10848 C806,C807,C808,C809,C810, 10nFX7R, 10%,16V,0402, Ceramic Capacitor;402 C811,C812,C813,C820,C821, C822,C823,C824,C825,C826, C827,C828,C829,C830,C831, C832,C833,C834,C835,C836, C837,C839,C840,C841,C842, C843,C844,C851,C852,C855, C856,C860,C861,C866,C867, C871,C883,C888,C891,C906, C909,C914,C923 1091 C814180pFNPO, 5%, 16V, 0402, Capacitor;402 1109 C815,C816,C848,C850,C854, 10uFY5V, 20%, 16V, 0805, Ceramic Capacitor;805 C857,C858,C859,C870 1111 C8171000pFNPO, 5%, 16V, 0402, Ceramic Capacitor;402 1123 C818,C905,…

Text truncated - open the document above for the full version.

Item Qty ReferencePartDescriptionPackage 11CC2091.0uFCAP_DUAL_0805_TH 22CC212,C2120.033uF CAP_400_200D 31CM200AQT04-40COMMON MODE CHOKEchoke04 42C218,C203470pF805 54C204,C206,C215,C217180pF805 62C216,C205390pF805 74C207,C208,C213,C214270pF805 82C210,C211680pF805 92D210,D211SMAJ11D214AA 101GD200GDTGDT_DUAL_TH_NL 111J200RJ11_E5364_30A0F2RJ11_E5364_30A0F2_N6 122R200,R22112.40603, 1%, Chip Resister;805 132R218,R2038.06K0603, 1%, Chip Resister;603 142R204,R2176650603, 1%, Chip Resister;603 152R216,R2055.23K0603, 1%, Chip Resister;603 162R206,R2156040603, 1%, Chip Resister;603 172R214,R2077.32K0603, 1%, Chip Resister;603 182R213,R2088870603, 1%, Chip Resister;603 192R211,R2104990603, 1%, Chip Resister;603 202R295,R29601206, 5%, Chip Resister;1206 211T2001.5mH 2:1ADSL transformerXFORMER_50217_10P_DUAL 221R44351K0603, 1%, Chip Resister;603 231R44410K0603, 1%, Chip Resister;603 242R449,R4504.7K0603, 5%, Chip Resister; 251U402TL331IDBVPSOP_5P_DBV 265C452,C453,C431,C433,C4300.1uF0.1UF; 10%; 16V; X7R; 272R413,R44700603, 5%, Chip Resister; 282Q408,Q403IRLML2402SOT23_MOSFET 291D403SMB5817D214AA 301L4052.2uH2.2UH 500MA MSI54 311L407100uH100UH 400MA(DELTA SIQ74-101)SIQ74_DUAL 321R3033485%;SMT CHIP RES;603 331R4461.50K1%;SMT CHIP RES;603 341R445305%;SMT CHIP RES;1206 352C400,C43247UF/16VM Series Aluminum Electrolytic Cap.CAP_100X250 361SW1SW SLIDESW, SLIDE,2 POS,R ANGL1101M2S3AV2QE2 371J100USB PORTCON_AMP787780 381FB2FBEAD805 392R121,R120271%;SMT CHIP RES;603 401R1241.50K1%;SMT CHIP RES;603 GT704-WR adding parts list based on GT704-WG BOM 411R43500805, 5%, Chip Resister;805 424R42,R43,R45,R34649.949.9 OHM 1% 0603603 431C80.1uF603 446R290,R294,R280,R281,R28200603, 5%, Chip Resister;603 45R283 461R362100603, 5%, Chip Resister;603 471C1022nFCER MONO 0.022UF 50V K X7R 603 481FB106FERRITE BEAD600 OHM@100MHZ 300MA 0603603 491T2PX-5111S SOP-16 (MAGDOTCOMM) 508R276-R279.R285-R288JUMPER WIRE 517R291,R113,R292,R141,R1817575 OHM 1% 0603603 522R75,R289603 531C83CER 1000PF 2KV 541J200ARJ45 LP SIDE ENTRY BLACK GT704-WR is a 54Mbps Wireless Cable/DSL Ro…

Text truncated - open the document above for the full version.
