LNQSBWD60AScreenBeam Mini2 Wireless Display Receiver

Mini Wireless Display Receiver Installation Guide This Installation Guide will walk you through the easy steps to set up your ScreenBeam Mini 2 Wireless Display Receiver. During this process, we’ll show you how to : A Install the Receiver B 1 Connect Using Windows 8.1 or Higher B 2 Connect Using Intel WiDi App B 3 Connect Using WiFi Miracast-enabled Device C Switch Display Modes D Install ScreenBeam Configuration Utility Model# SBWD60A Part No: 0530-0734-000 Welcome! Step 2 Plug the small male connector of the USB cable to the Receiver’s micro USB port labeled “Power”. Step 3 Plug the Receiver into an available HDMI port on your HDTV. A Install the Receiver Thank you for your purchase of a ScreenBeam Mini 2 Wireless Display Receiver (hereinafter referred to as the Receiver). The Receiver connects to your Intel WiDi or Miracast-capable de- vice wirelessly, and displays the device’s screen on your HDTV. Step 1 Get the Receiver, power adapter, USB cable, and HDMI extension cable from the Receiver’s box. Step 4 Plug the large male connector of the USB cable to the power adapter, and plug the power adapter to a power outlet. Step 5 Turn on your TV and switch the input source until you see the Ready To Connect screen. Note: If you cannot plug the Receiver into an HDMI port on your TV (due to other components, or a poorly accessible port), use the included HDMI extension cable to connect the Receiver. B 1 Connect Using Windows 8.1 or Higher Step 1 From the Windows desktop, navigate to the Charms menu and select Devices. You can also use the shortcut keys, + K. Step 2 From the Charms menu, click the Project icon. The Receiver is now connected to your HDTV. Proceed to one of the next three sections of this Guide (depending on the device you are using to connect to the Receiver) to finish the connection procedure. For Windows 8.1 devices, please proceed to section B1; For Windows 7/8 devices, please proceed to section B2; For Android devices, please proceed to section B3. Step 4 Select the ScreenBeam Receiver from the list. Step 5 Enter the PIN as displayed on the television screen, then connect and display. Note: If you are running Windows 8.1 and the screens above do not appear, go to http://www.actiontec.com/widi81 for the latest software updates. Step 3 From the Project screen, select Add a wireless display. Step 2 The device scans for available receivers. Select the same receiver name as seen on the HDTV and click Connect. (The Connect Automatically checkbox is optional.) Step 3 Wait until the Receiver displays a PIN on the HDTV, and a PIN entry box on the screen of the WiDi device. Enter the PIN in the PIN entry box on the WiDi device, and then click Continue. Step 1Find the Intel Wireless Display application on the device and launch it. To find the application, go to Windows Search on your device and search for “Intel WiDi” in your apps. B 2 Connect Using Intel WiDi App Step 4 The HDTV displays messages to show the status of the connection process. Step 5 A Connection Successful screen appears on your device’s screen, as well as on the HDTV. Display Tip: If the edges of the device screen cannot be seen on the HDTV, adjust cropping. To do this, enter the WiDi application and click Settings. Navigate to the “Picture and Sound” section, click Adjust cropping..., and adjust the HDTV picture by clicking plus (+) or minus (-). Note: Make sure the device supports Intel Wireless Display (WiDi) software version 3.5 or higher. To find out what version of Intel WiDi your device has, enter the Intel WiDi application and click Help, and then navigate to the “About WiDi” section. To obtain the latest Intel WiDi software and drivers, go to: http://www.intel.com/go/wirelessdisplayupdate Step 2 The Wireless Display Application scans for available receivers. Select the ScreenBeam Receiver from the list. Step 3 Wait for the device to associate with the Receiver. When it does, the device’s screen will be displayed on the HDTV. Step 1 On a Miracast-enabled Android device, locate and open the Wireless Display Application. B 3 Connect Using Miracast-enabled Device You can connect to the Receiver from a Miracast-enabled Android device, such as a smartphone, tablet, or game console (find the wireless display feature in Settings). Also, the device should be running the latest software for best performance. Note: The name of the Wireless Display Application depends on the device type and model. Refer to the device’s carrier or manufacturer user manual for more details. The Receiver supports three display modes when connected with a compatible wireless display application (Intel WiDi or Windows 8.1 Project, for example). In Windows, press the Windows logo + P keys simultaneously ( + P) to launch the display options and select the desired display mode from the options. Windows 8.1 Windows 7 Switch Display Modes Go to http://international.actiontec.com/support for product support, updates, and more information including: • Firmware Updates • Troubleshooting • Registration • FAQs C Product Support & Additional Information Actiontec’s ScreenBeam Configuration Utility allows configuring and upgrading ScreenBeam series receivers wire- lessly. There are three versions available: Desktop, Metro, and Android. Access the following address to download ScreenBeam Configuration Utility for Desktop, Metro, or Android: http://www.actiontec.com/sbupdate For Windows 8.1 and Android devices, you can also install the Utility on Microsoft Store and Google Play Store, respectively. (tip: searching for “ScreenBeam”) Install ScreenBeam Configuration Utility • Increase the separation between the equipment and receiver; • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected; • Consult the dealer or an experience radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 _ Actiontec Electronics, Inc._ 2014/7/29 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ Actiontec Electronics, Inc._ __hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： ScreenBeam Mini2 Wireless Display Receiver Trade Name： Actiontec Model Name： SBWD60A Serial Model： N/A FCC ID： LNQSBWD60A Sincerely, Client’s name / title : Angela yao / Program Manager Contact information / address : 760 North Mary Ave., Sunnyvale, California 94085 United States SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 _ Actiontec Electronics, Inc._ 2014/7/29 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Product： ScreenBeam Mini2 Wireless Display Receiver Trade Name： Actiontec Model Name： SBWD60A Serial Model： N/A FCC ID： LNQSBWD60A Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ Actiontec Electronics, Inc._ ____hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): We affirm that between SIEMIC, Inc. and ____ Actiontec Electronics, Inc._ _, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s name / title : Angela yao / Program Manager Contact information / address : 760 North Mary Ave., Sunnyvale, California 94085 United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Actiontec Electronics, Inc. 2014/7/29 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: LNQSBWD60A We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s name / title : Angela yao / Program Manager Contact information / address : 760 North Mary Ave., Sunnyvale, California 94085 United States

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label ScreenBeam Mini2 Wireless Display Receiver Model NO.: SBWD60A Actiontec Input Rating: DC 5V/ 1000mA FCC ID: LNQSBWD60A Actiontec Electronics, Inc. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID: LNQSBWD60A FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: LNQSBWD60A Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density FCC ID: LNQSBWD60A MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS 2.4G: Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (AV) Maxim um output power (AV) Te s t Channe (MHz) ANT A ANT B ANT A ANT B dBm dBm mW TX 802.11b Mode CH01 2412 9.65 9.13 6.43 6.11 12.41 9.28 8.47 CH06 2437 9.76 9.42 6.55 6.18 12.55 9.32 8.55 CH11 2462 9.34 9.47 6.31 6.02 12.42 9.18 8.28 TX 802.11g Mode CH01 2412 8.85 8.32 5.82 5.26 11.60 8.56 7.18 CH06 2437 8.74 8.48 5.69 5.42 11.68 8.63 7.29 CH11 2462 8.72 8.50 5.65 5.33 11.62 8.50 7.08 TX 802.11n/20M Mode CH01 2412 7.94 7.79 5.07 4.89 10.88 7.99 6.30 CH06 2437 7.90 7.61 5.16 4.93 10.79 8.01 6.32 CH11 2462 7.98 7.75 5.25 4.99 10.88 8.13 6.50 TX 802.11n/40M Mode CH03 2422 6.83 6.69 4.33 3.68 9.77 7.03 5.05 CH06 2437 6.67 6.64 4.29 3.56 9.75 6.97 4.98 CH09 2452 6.74 6.49 4.17 3.55 9.63 6.88 4.88 Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11b 12.55 17.99 6.05 (4.03dBi)0.0144 1 Pass 802.11g 11.68 14.72 6.05 (4.03dBi)0.0118 1 Pass 802.11n-HT20 10.88 12.25 6.05 (4.03dBi)0.0098 1 Pass 802.11n-HT40 9.77 9.48 6.05 (4.03dBi)0.0076 1 Pass FCC ID: LNQSBWD60A 5.8G: Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (AV) Maxim um output power (AV) Te s t Channe (MHz) ANT A ANT B ANT A ANT B dBm dBm mW TX 802.11a Mode CH149 5745 10.16 9.63 7.25 6.85 12.91 10.06 10.14 CH157 5785 10.21 9.63 7.37 6.74 12.91 10.01 10.02 CH165 5825 10.09 9.59 7.28 6.72 12.86 10.02 10.05 TX 802.11 n20 Mode CH149 5745 9.12 8.65 6.38 5.42 11.90 8.94 7.83 CH157 5785 9.13 8.57 6.43 5.53 11.86 8.99 7.93 CH165 5825 9.17 8.42 6.29 5.44 11.82 8.90 7.76 TX 802.11 n40 Mode CH151 5755 8.16 7.77 5.27 4.23 10.98 7.79 6.01 CH159 5795 8.08 7.53 5.13 4.37 10.87 7.85 6.10 Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11a 12.91 19.54 6.05 (4.03dBi)0.0157 1 Pass 802.11n (20) 11.90 15.49 6.05 (4.03dBi)0.0124 1 Pass 802.11n(40) 10.98 12.53 6.05 (4.03dBi)0.0100 1 Pass FCC ID: LNQSBWD60A 5.2G Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (AV) Maxim um output power (AV) Te s t Channe (MHz) ANT A ANT B ANT A ANT B dBm dBm mW TX 802.11a Mode CH36 5180 9.69 8.87 6.38 5.63 12.31 9.03 8.00 CH40 5200 9.53 8.75 6.26 5.77 12.26 9.10 8.13 CH48 5240 9.72 8.71 6.11 5.56 12.25 8.85 7.67 TX 802.11 n20M Mode CH36 5180 8.52 7.86 5.54 4.35 11.21 8.00 6.31 CH40 5200 8.48 7.82 5.83 4.27 11.19 7.96 6.25 CH48 5240 8.61 7.79 5.35 4.39 11.23 7.91 6.18 TX 802.11 n40M Mode CH38 5190 7.52 6.88 4.11 3.72 10.22 6.93 4.93 CH46 5230 7.63 6.93 4.17 3.81 10.25 6.97 4.98 Mode Maximum peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11a 12.31 17.02 6.05 (4.03dBi)0.0136 1 Pass 802.11n (20) 11.23 13.27 6.05 (4.03dBi)0.0106 1 Pass 802.11n(40) 10.25 10.59 6.05 (4.03dBi)0.0085 1 Pass Note：This device 5GHz and 2.4GHz can not transmit simultaneously，don't have to assess exposure when transmit simultaneously.

FCC RADIO TEST REPORT FCC ID: LNQSBWD60A Product： ScreenBeam Mini2 Wireless Display Receiver Trade Name： Actiontec Model Name： SBWD60A Serial Model： N/A Report No.： NTEK-2014NT07091105F3 Prepared for Actiontec Electronics, Inc. 760 North Mary Ave., Sunnyvale, California 94085 United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 96 Report No.: NTEK-2014NT07091105F3 TEST RESULT CERTIFICATION Applicant’s name........ Actiontec Electronics, Inc. Address ........................ 760 North Mary Ave., Sunnyvale, California 94085 United States Manufacture's Name... Actiontec Electronics, Inc. Address ........................ 760 North Mary Ave., Sunnyvale, California 94085 United States Product description Product name .................ScreenBeam Mini2 Wireless Display Receiver Model and/or type reference ..................... SBWD60A Serial Model .................... N/A Standards.................... FCC Part15.247 01 Oct. 2013 Test procedure ................ ANSI C63.4-2003 and KDB 558074 D01 DTS Meas Guidance v03r02 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 09 Jul. 2014 ~26 Jul. 2014 Date of Issue..................................... 26 Jul. 2014 Test Result......................................... Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 96 Report No.: NTEK-2014NT07091105F3 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 10 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 12 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3 . EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 DEVIATION FROM TEST STANDARD 15 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 15 3.1.6 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 20 3.2.1 RADIATED EMISSION LIMITS 20 3.2.2 TEST PROCEDURE 21 3.2.3 DEVIATION FROM TEST STANDARD 21 3.2.4 TEST SETUP 22 3.2.5 EUT OPERATING CONDITIONS 23 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 24 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 25 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 29 4 . POWER SPECTRAL DENSITY TEST 51 4.1 APPLIED PROCEDURES / LIMIT 51 4.1.1 TEST PROCEDURE 51 4.1.2 DEVIATION FROM STANDARD 51 4.1.3 TEST SETUP 51 4.1.4 EUT OPERATION CONDITIONS 51 4.1.5 TEST RESULTS 52 5 . BANDWIDTH TEST 66 5.1 APPLIED PROCEDURES / LIMIT 66 5.1.1 TEST PROCEDURE 66 Page 4 of 96 Report No.: NTEK-2014NT07091105F3 Table of Contents Page TEST SETUP 66 5.1.2 EUT OPERATION CONDITIONS 66 5.1.3 TEST RESULTS 67 6 . PEAK OUTPUT POWER TEST 81 6.1 APPLIED PROCEDURES / LIMIT 81 6.1.1 TEST PROCEDURE 81 6.1.2 DEVIATION FROM STANDARD 81 6.1.3 TEST SETUP 81 6.1.4 EUT OPERATION CONDITIONS 81 6.1.5 TEST RESULTS 82 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 84 7.1 DEVIATION FROM STANDARD 84 7.2 TEST SETUP 84 7.3 EUT OPERATION CONDITIONS 84 7.4 TEST RESULTS 85 8 . ANTENNA REQUIREMENT 94 8.1 STANDARD REQUIREMENT 94 8.2 EUT ANTENNA 94 9 . EUT TEST PHOTO 95 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 96 Report No.: NTEK-2014NT07091105F3 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 96 Report No.: NTEK-2014NT07091105F3 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 96 Report No.: NTEK-2014NT07091105F3 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment ScreenBeam Mini2 Wireless Display Receiver Trade Name Actiontec Model Name SBWD60A Product Description The EUT is a ScreenBeam Mini2 Wireless Display Receiver Operation Frequency: 802.11b/g/n(20MHz):2412~2462 MHz 802.11n(40MHz):2422~2452 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):150/144.44/130/117/ 115.56/104/86.67/78/52/6.5Mbps 802.11n(40MHz):300/270/240/180/150 /120/108/90/54 Mbps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Max.Output Power(Conducted): 12.55 dBm Operation Frequency: 5725 MHz ~ 5850 MHz Modulation Type: OFDM (BPSK / QPSK / 16QAM / 64QAM) Max.Output Power(Conducted): 12.91dBm Antenna Designation…
