LNQSBWD700AScreenBeam Enterprise Wireless Display Receiver

Mini Wireless Display Receiver Installation Guide This Installation Guide will walk you through the easy steps to set up your ScreenBeamEnterprise Wireless Display Receiver. During this process, we’ll show you how to : A Install the Receiver B 1 Connect Using Windows 8.1 or Higher B 2 Connect Using Intel WiDi App B 3 Connect Using WiFi Miracast-enabled Device C Switch Display Modes D Device Management Model# SBWD700A Part No: Meeting ScreenBeam Enterprise LED Indicator: indicates power supply status USB port: for configuring MGT connection data VGA In: reserved On/Off: the power switch VGA Out: connects to HDTV/projector with a VGA port for video output HDMI Out: connects to HDTV/projector with an HDMI port for video and audio output Ethernet: Connects to Ethernet for receiver management with ScreenBeam Central Management System Reset Button: resets system to defaults DC IN: for power supply Welcome! Step 2 Plug one end of the HDMI/VGA cable into the HDMI/ VGA Out port on the Receiver, and the other end into an available HDMI/VGA port on the HDTV/Projector. Step 3 Plug the connector of the power cord into the DC IN port of the Receiver, and the AC adapter into a power outlet. A Install the Receiver Thank you for your purchase of a ScreenBeam Enterprise Wire- less Display Receiver (hereinafter referred to as the Receiver). The Receiver connects to your Intel WiDi or Miracast-capable device wirelessly, and displays the device’s screen on your HDT V. Step 1 Get the Receiver, power adapter, and HDMI cable or VGA cable from the Receiver’s box. Step 4 Press the On/Off button to switch the power on. Note: You can switch the receiver off by pressing the On/Off button again. Step 5 Turn on your TV and switch the input source until you see the Ready To Connect screen. B 1 Connect Using Windows 8.1 or Higher Step 1 From the Windows desktop, navigate to the Charms menu and select Devices. You can also use the shortcut keys, + K. Step 2 From the Charms menu, click the Project icon. The Receiver is now connected to your HDTV. Proceed to one of the next three sections of this Guide (depending on the device you are using to connect to the Receiver) to finish the connection procedure. For Windows 8.1 devices, please proceed to section B1; For Windows 7/8 devices, please proceed to section B2; For Android devices, please proceed to section B3. Step 4 Select the ScreenBeam Receiver from the list. Step 5 Enter the PIN provided by your system administrator (or the one displayed on the television screen), then connect and display. Note: If you are running Windows 8.1 and the screens above do not appear, go to http://www.actiontec.com/widi81 for the latest software updates. Step 3 From the Project screen, select Add a wireless display. Note: The PIN for connection is “12345670” by default if no PIN is displayed. Step 2 The device scans for available receivers. Select your re- ceiver on the list and click Connect. (The Connect Automatically check- box is optional.) Step 3 Enter the PIN provided by your system administrator (or the one displayed on the TV screen) on the WiDi device, and then click Continue. Step 1Find the Intel Wireless Display application on the device and launch it. To find the application, go to Windows Search on your device and search for “Intel WiDi” in your apps. B 2 Connect Using Intel WiDi App Note: The default PIN is “12345670”. You can obtain the PIN from your system administrator if no PIN is dis- played on the HDTV. Step 4 The HDTV displays messages to show the status of the connection process. Step 5 A Connection Successful screen appears on your device’s screen, as well as on the HDTV. Display Tip: If the edges of the device screen cannot be seen on the HDTV, adjust cropping. To do this, enter the WiDi application and click Settings. Navigate to the “Picture and Sound” section, click Adjust cropping..., and adjust the HDTV picture by clicking plus (+) or minus (-). Note: Make sure the device supports Intel Wireless Display (WiDi) software version 3.5 or higher. To find out what version of Intel WiDi your device has, enter the Intel WiDi application and click Help, and then navigate to the “About WiDi” section. To obtain the latest Intel WiDi software and drivers, go to: http://www.intel.com/go/wirelessdisplayupdate Step 2 The Wireless Display Application scans for available receivers. Select your receiver from the list. Step 3 Enter the PIN provided by your system administrator (or the onedisplayed on the TV screen) if required, and then connect. Step 1 On a Miracast-enabled Android device, locate and open the Wireless Display Application. B 3 Connect Using Miracast-enabled Device You can connect to the Receiver from a Miracast-enabled Android device, such as a smartphone, tablet, or game console (find the wireless display feature in Settings). Also, the device should be running the latest software for best performance. Note: The name of the Wireless Display Application depends on the device type and model. Refer to the device’s carrier or manufacturer user manual for more details. Note: The default PIN is “12345670”. You can obtain the PIN from your system administrator if no PIN is displayed on the HDT V. The Receiver supports three display modes when connected with a compatible wireless display application (Intel WiDi or Windows 8.1 Project, for example). In Windows, press the Windows logo + P keys simultaneously ( + P) to launch the display options and select the desired display mode from the options. Windows 8.1 Windows 7 Switch Display Modes The device management webpage provides the ability to manage the receiver’s settings. Device Management Log into the IT Management Console Step 1 Find the receiver’s SSID in the lower left corner of the Ready To Con- nect screen. Step 2 Right-click the WiFi network icon on the taskbar of your device and select Open Network and Sharing Center. Step 3 The Network and Sharing Cen- ter window appears. Click Set up a new connection or network.…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Actiontec Electronics, Inc. 2014/10/27 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____Actiontec Electronics, Inc.__ __hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： ScreenBeam Enterprise Wireless Display Receiver Trade Name： Actiontec Model Name： SBWD700A Serial Model： N/A FCC ID： LNQSBWD700A Sincerely, Client’s name / title : Angela yao / Program Manager Contact information / address : 760 North Mary Ave., Sunnyvale, California 94085 United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Actiontec Electronics, Inc. 2014/10/27 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: LNQSBWD700A We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s name / title : Angela yao / Program Manager Contact information / address : 760 North Mary Ave., Sunnyvale, California 94085 United States

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label ScreenBeam Enterprise Wireless Display Receiver Model NO.: SBWD700A Actiontec Input Rating: DC 5V/ 2000mA FCC ID: LNQSBWD700A Actiontec Electronics, Inc. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 BT ANT WIFI ANT1 WIFI ANT 2 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9

FCC ID:LNQSBWD700A RF Exposure FCC ID:LNQSBWD700A Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density FCC ID:LNQSBWD700A MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS 2.4G: Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (PK) (AV) LIMIT Te s t Channe (MHz) ANT A ANT B ANT A ANT B dBm dBm dBm TX 802.11b Mode CH01 2412 14.62 13.69 11.25 10.52 17.19 13.91 29.39 CH06 2437 14.74 13.84 11.31 10.11 17.26 13.73 29.39 CH11 2462 14.51 13.71 11.43 10.42 17.14 13.96 29.39 TX 802.11g Mode CH01 2412 11.73 10.35 8.24 7.22 14.10 10.77 29.39 CH06 2437 11.71 10.42 8.46 7.45 14.13 10.87 29.39 CH11 2462 11.75 10.47 8.31 7.36 14.17 10.87 29.39 TX 802.11n/20M Mode CH01 2412 9.92 8.73 6.76 5.31 12.38 9.11 29.39 CH06 2437 9.91 8.58 6.84 5.42 12.31 9.15 29.39 CH11 2462 9.92 8.72 6.61 5.72 12.37 9.20 29.39 TX 802.11n/40M Mode CH03 2422 9.23 8.24 6.21 5.61 11.77 8.93 29.39 CH06 2437 9.46 8.53 6.37 5.52 11.90 8.89 29.39 CH09 2452 9.52 8.65 6.32 5.44 12.12 8.91 29.39 Mode Maximum peak output power (dBm) Output power to antenna (mW) (Antenna Gain) numeric Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11b 17.26 53.21 2.29 (3.6dBi) 0.0242 1 Pass 802.11g 14.17 26.12 2.29 (3.6dBi) 0.0119 1 Pass 802.11n-HT20 12.38 17.30 2.29 (3.6dBi) 0.0079 1 Pass 802.11n-HT40 11.77 15.03 2.29 (3.6dBi) 0.0068 1 Pass FCC ID:LNQSBWD700A 5.8G: Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (PK) (AV) LIMIT Te s t Channe (MHz) ANT A ANT B ANT A ANT B dBm dBm dBm TX 802.11a Mode CH149 5745 9.76 9.21 7.02 6.71 12.50 9.88 29.79 CH157 5785 9.52 9.13 7.37 6.69 12.47 9.87 29.79 CH165 5825 9.67 9.02 7.24 6.72 12.37 10.00 29.79 TX 802.11 n20 Mode CH149 5745 9.31 8.56 6.42 5.42 11.96 8.96 29.79 CH157 5785 9.35 8.65 6.48 5.58 12.00 9.03 29.79 CH165 5825 9.16 8.35 6.22 5.47 11.78 8.87 29.79 TX 802.11 n40 Mode CH151 5755 8.52 7.76 5.26 4.55 11.17 7.93 29.79 CH159 5795 8.37 7.52 5.17 4.38 11.06 7.85 29.79 Mode Maximum peak output power (dBm) Output power to antenna (mW) (Antenna Gain) numeric Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11a 12.50 17.78 2.29 (3.6dBi) 0.0081 1 Pass 802.11n (20) 12.00 15.85 2.29 (3.6dBi) 0.0072 1 Pass 802.11n(40) 11.17 13.09 2.29 (3.6dBi) 0.0060 1 Pass BT: Frequency Maximum Conducted Output Power (PK) LIMIT Te s t Channe (MHz) (dBm) dBm CH00 2402 -3.57 30 CH19 2440 -3.76 30 CH39 2480 -4.29 30 Mode Maximum peak output power (dBm) Output power to antenna (mW) (Antenna Gain) numeric Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result CH00 -3.57 0.44 1.26 (1.0dBi) 0.0001 1 Pass CH19 -3.76 0.42 1.26 (1.0dBi) 0.0001 1 Pass CH39 -4.29 0.37 1.26 (1.0dBi) 0.0001 1 Pass FCC ID:LNQSBWD700A 5.2G Maximum output power. Antenna port Total Power Frequency (PK) (dBm) (AV) (dBm) (PK) (AV) LIMIT Te s t Channe (MHz) ANT A ANT B ANT A ANT B dBm dBm dBm TX 802.11a Mode CH36 5180 8.93 8.23 6.46 5.45 11.60 8.99 16.79 CH40 5200 8.64 8.21 6.37 5.32 11.60 8.94 16.79 CH48 5240 8.59 8.16 6.19 5.21 11.39 8.74 16.79 TX 802.11 n20M Mode CH36 5180 8.46 7.79 5.59 4.43 11.15 8.06 16.79 CH40 5200 8.33 7.62 5.44 4.34 11.07 8.02 16.79 CH48 5240 8.28 7.51 5.37 4.31 10.92 7.88 16.79 TX 802.11 n40M Mode CH38 5190 7.59 6.81 4.48 3.76 10.23 7.15 16.79 CH46 5230 7.53 6.72 4.57 3.71 10.19 7.12 16.79 Mode Maximum peak output power (dBm) Output power to antenna (mW) (Antenna Gain) numeric Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11a 11.60 14.45 2.09 (3.2dBi) 0.0060 1 Pass 802.11n (20) 11.15 13.03 2.09 (3.2dBi) 0.0054 1 Pass 802.11n(40) 10.23 10.54 2.09 (3.2dBi) 0.0044 1 Pass Note：1: This device 5GHz and 2.4GHz can not transmit simultaneously，don't have to assess exposure when transmit simultaneously. 2: BT and WIFI can't work at the same time .

FCC RADIO TEST REPORT-WIFI FCC ID:LNQSBWD700A Product： ScreenBeam Enterprise Wireless Display Receiver Trade Name： Actiontec Model Name： SBWD700A Serial Model： N/A Report No.： NTEK-2014NT09281643F3 Prepared for Actiontec Electronics, Inc. 760 North Mary Ave., Sunnyvale, CA 94085 USA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 76 Report No.: NTEK-2014NT09281643F3 TEST RESULT CERTIFICATION Applicant’s name........ Actiontec Electronics, Inc. Address ........................ 760 North Mary Ave., Sunnyvale, CA 94085 USA Manufacture's Name... Actiontec Electronics, Inc. Address ........................ 760 North Mary Ave., Sunnyvale, CA 94085 USA Product description Product name .................ScreenBeam Enterprise Wireless Display Receiver Model and/or type reference ..................... SBWD700A Serial Model .................... N/A Standards.................... FCC Part15.247: 01 Oct. 2013 Test procedure ................ ANSI C63.4-2003 and KDB 558074: June 5, 2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test...................................... Date (s) of performance of tests ....... 28 Sep. 2014 ~16 Oct. 2014 Date of Issue..................................... 16 Oct. 2014 Test Result......................................... Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 76 Report No.: NTEK-2014NT09281643F3 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 10 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 12 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3 . EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 DEVIATION FROM TEST STANDARD 15 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 15 3.1.6 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 20 3.2.1 RADIATED EMISSION LIMITS 20 3.2.2 TEST PROCEDURE 21 3.2.3 DEVIATION FROM TEST STANDARD 21 3.2.4 TEST SETUP 22 3.2.5 EUT OPERATING CONDITIONS 23 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 24 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 25 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 29 4 . POWER SPECTRAL DENSITY TEST 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . BANDWIDTH TEST 46 5.1 APPLIED PROCEDURES / LIMIT 46 5.1.1 TEST PROCEDURE 46 Page 4 of 76 Report No.: NTEK-2014NT09281643F3 Table of Contents Page TEST SETUP 46 5.1.2 EUT OPERATION CONDITIONS 46 5.1.3 TEST RESULTS 47 6 . PEAK OUTPUT POWER TEST 61 6.1 APPLIED PROCEDURES / LIMIT 61 6.1.1 TEST PROCEDURE 61 6.1.2 DEVIATION FROM STANDARD 61 6.1.3 TEST SETUP 61 6.1.4 EUT OPERATION CONDITIONS 61 6.1.5 TEST RESULTS 62 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 64 7.1 DEVIATION FROM STANDARD 64 7.2 TEST SETUP 64 7.3 EUT OPERATION CONDITIONS 64 7.4 TEST RESULTS 65 8 . ANTENNA REQUIREMENT 74 8.1 STANDARD REQUIREMENT 74 8.2 EUT ANTENNA 74 9 . EUT TEST PHOTO 75 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 76 Report No.: NTEK-2014NT09281643F3 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 76 Report No.: NTEK-2014NT09281643F3 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 76 Report No.: NTEK-2014NT09281643F3 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment ScreenBeam Enterprise Wireless Display Receiver Trade Name Actiontec Model Name SBWD700A Product Description The EUT is a ScreenBeam Enterprise Wireless Display Receiver Operation Frequency: 802.11b/g/n(20MHz):2412~2462 MHz 802.11n(40MHz):2422~2452 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):150/144.44/130/117/ 115.56/104/86.67/78/52/6.5Mbps 802.11n(40MHz):300/270/240/180/150 /120/108/90/54 Mbps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Max.Output Power(Conducted): 17.26 dBm Operation Frequency: 5725 MHz ~ 5850 MHz Modulation Type: OFDM (BPSK / QPSK / 16QAM / 64QAM) Max.Output Power(Conducted): 12.50 dBm Antenna Designation: Please see Note 3. Antenna Gain (dBi)…

Text truncated - open the document above for the full version.

FCC RADIO TEST REPORT-BT 4.0 FCC ID:LNQSBWD700A Product： ScreenBeam Enterprise Wireless Display Receiver Trade Name： Actiontec Model Name： SBWD700A Serial Model： N/A Report No.： NTEK-2014NT09281643F2 Prepared for Actiontec Electronics, Inc. 760 North Mary Ave., Sunnyvale, CA 94085 USA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 37 Report No.: NTEK-2014NT09281643F2 TEST RESULT CERTIFICATION Applicant’s name........ Actiontec Electronics, Inc. Address ........................ 760 North Mary Ave., Sunnyvale, CA 94085 USA Manufacture's Name... Actiontec Electronics, Inc. Address ........................ 760 North Mary Ave., Sunnyvale, CA 94085 USA Product description Product name .................ScreenBeam Enterprise Wireless Display Receiver Model and/or type reference ..................... SBWD700A Serial Model .................... N/A Standards.................... FCC Part15.247 01 Oct. 2013 Test procedure ................ ANSI C63.4-2003 and KDB 558074: June 5, 2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 28 Sep. 2014 ~16 Oct. 2014 Date of Issue...........................................: 16 Oct. 2014 Test Result...............................................: Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 37 Report No.: NTEK-2014NT09281643F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 18 3.2.5 EUT OPERATING CONDITIONS 19 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 20 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 21 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . POWER SPECTRAL DENSITY TEST 24 4.1 APPLIED PROCEDURES / LIMIT 24 4.1.1 TEST PROCEDURE 24 4.1.2 DEVIATION FROM STANDARD 24 4.1.3 TEST SETUP 24 4.1.4 EUT OPERATION CONDITIONS 24 4.1.5 TEST RESULTS 25 5 . BANDWIDTH TEST 27 5.1 APPLIED PROCEDURES / LIMIT 27 5.1.1 TEST PROCEDURE 27 Page 4 of 37 Report No.: NTEK-2014NT09281643F2 Table of Contents Page TEST SETUP 27 5.1.2 EUT OPERATION CONDITIONS 27 5.1.3 TEST RESULTS 28 6 . PEAK OUTPUT POWER TEST 30 6.1 APPLIED PROCEDURES / LIMIT 30 6.1.1 TEST PROCEDURE 30 6.1.2 DEVIATION FROM STANDARD 30 6.1.3 TEST SETUP 30 6.1.4 EUT OPERATION CONDITIONS 30 6.1.5 TEST RESULTS 31 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 32 7.1 DEVIATION FROM STANDARD 32 7.2 TEST SETUP 32 7.3 EUT OPERATION CONDITIONS 32 7.4 TEST RESULTS 33 8 . ANTENNA REQUIREMENT 35 8.1 STANDARD REQUIREMENT 35 8.2 EUT ANTENNA 35 9 . EUT TEST PHOTO 36 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 37 Report No.: NTEK-2014NT09281643F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 37 Report No.: NTEK-2014NT09281643F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 37 Report No.: NTEK-2014NT09281643F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment ScreenBeam Enterprise Wireless Display Receiver Trade Name Actiontec Model Name SBWD700A Serial Model N/A Model Difference N/A Product Description The EUT is a ScreenBeam Enterprise Wireless Display Receiver Operation Frequency: 2402~2480MHz Modulation Type: GFSK Number Of Channel 40CH Antenna Designation: Please see Note 3. Output Power(Conducted): -3.57dBm(MAX) Antenna Gain (dBi) 1.0dBi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Ratings DC 5.0V,2.0A Adapter Mode: WA-10P05FU Input: 100-240V~, 50/60Hz, 0.3A MAX Output: 5.0V , 2.0A Batter…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
