LNQT2200HWireless 11n VDSL2 Modem Gateway

1 Actiontec Electronics, Inc. 760 North Mary Ave., Sunnyvale, CA 94085 USA Wireless 11n VDSL2 Modem Gateway Model #: T2200H, T1200H Quick Start Guide Version: 2.0 (Draft to be review) 2 Connect the Gateway to a Computer 1. Get T2200H/T1200 router from the Quick Start Kit and take it out of the bag. 2. Get the Power Cord from your DSL Quick Start Kit. (Power: External, 12V DC, 1.8A; Model: STD‐12018U1) 3. Plug the smaller end of the Power Cord into the Black Port on the back of the Gateway. 4. Plug the larger end of the Power Cord into a Power Outlet. 5. Make sure the Power Light on the Gateway is SOLID Green. 7. Get the Yellow Cable 8. Plug one end of the Yellow Cable into any of the Yellow Ports on the back of the Wireless DSL Gateway. 9. Make sure that your computer is turned on. Then, plug the other end of the Yellow Cable into the Ethernet Port on the back of the computer. An Ethernet Port looks similar to a regular Phone Jack, but is slightly larger. 10. Make sure that 1 of the 4 Ethernet lights on the Gateway is Green. This may take a few moments. 11. Get the Black or Green DSL Cable from your DSL Quick Start Kit. (Note: two DSL cables if using T2200H) 12. Plug one end of the DSL Cable into the Grey Port located on the back of the Gateway. (Note: Plug two DSL cables to the Grey Ports on the back of the Gateway) 13. Plug the other end of the DSL Cable into the Phone Jack closest to your Computer. 14. Make sure All Devices with the same phone number as your DSL Line has Phone Filters. This includes telephones, fax machines, caller ID boxes, satellite TV receivers, TiVo devices, and answering machines. 15. Make sure that that Power and DSL Lights are solid Green. This may take up to 30 seconds. Note: If the DSL Light continues to blink, make sure you received notification from your DSL Internet Service Provider that your DSL service has been activated. 3 Configure the Gateway 1. Open a Web Browser (FireFox or Internet Explorer, for example). In the address bar, enter http://192.168.1.254 then press Enter on the keyboard. Note: When you open your web browser you may get a page cannot be displayed error. This is normal and will not effect the instructions in step 1. 2. The GUI login username and password values can be found on the bottom sticker. 3. The "Main Menu" screen appears. Note: If this screen does not appear, make sure our Ethernet port is configured for Dynamic IP. Configure Wireless Connection and Security 1. Click on Wireless Setup 2. Select a name for your wireless network and enter it in the "Network Name" field. Then click Apply. 3. Click on Wireless Security from the left column menu. 4. Select the type of wireless security that you want to use Actiontec recommends using WPA&WPA2. The following steps will show you how to enable WPA&WPA2 wireless security. Note: All of your other wireless devices will need to support that same type of wireless security chosen in order to connect to your wireless network. 5. Enter in a password or pre‐shared key. The key must be at least 8 characters long. Click Apply to continue. Congratulations you are now connected! 4 Specifications 1. Features • Supports Plug‐and‐Play installation. • Compliant with full‐rate ANSI T1.413 Issue 2 and ITU G.992.1 (G.dmt) standard. • ADSL2+ / VDSL2 Bonded / Single Line Compliant • DMT modulation and demodulation. • Supports RFC1483 (bridged Ethernet over ATM) for LAN mode. • Full‐rate adaptive modem: max. Downstream rate is 8 Mbps, max. upstream rate is 1 Mbps. • Compliant with IEEE 802.3 Ethernet standard. • Supports 10BaseT and 100BaseT and Gigabit. • 2.4 GHz IEEE 802.11n • Supports 20/40 MHz channels with optional SGI • Full IEEE 802.11 b/g/n legacy compatibility with enhanced performance Comprehensive wireless network security support that includes WPA, WPA2, and AES encryption/decryption coupled with TKIP and IEEE 802.1X support • Support 802.11b and Draft STD 802.11g Modulation. • 802.11b Data Rates: 11Mbit/s, 5.5Mbit/s, 2Mbit/s, 1Mbit/s (And 22Mbit/s with PBCC); • 802.11g Data Rates: 6Mbit/s, 9Mbit/s, 12Mbit/s, 18Mbit/s, 24Mbit/s, 36Mbit/s, 48Mbit/s, 54Mbit/s. • 802.11g Data Rates: 65Mbit/s, 130Mbit/s 2. Power requirements • Operating voltage: +12V +/‐ 5% @ 1.8A max • Power Dissipation Active: 12V DC @ xxx mA (typical) 3. Environmental Operating Range • Operating temperature: 0º C to 40º C (32º F to 104º F) • Humidity: 8‐95%, non‐condensing 4. Dimension and Weight • 9.9” (L) x 5.7” (W) x 1.4” (H) 1.35 lb. 5. Certifications • FCC Part 15 Class B, Class C and Part 68; Safety UL/cUL General Regulatory and Compliance Notices Important Safety Instructions If applicable, when using telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and personal injury, including the following: • Do not use this product near water –for example, near a bathtub, kitchen sink, laundry tub, or swimming pool, or in a wet basement; • Avoid using a telephone (other than a cordless type) during an electrical storm, as there may be a remote risk of electrical shock due to lightning; • Do not use the telephone to report a gas leak in the vicinity of the leak; • Use only the power cord and batteries indicated in this manual; • Do not dispose of batteries in fire, as they may explode –check with local codes for possible special disposal instructions. Telephone Line Cord Caution To reduce the risk of fire, use only No. 26 AWG or larger (e.g., 24 AWG) UL Listed or CSA Certified Telecommunication Line Cord. Coaxial Cable If applicable, the coaxial cable screen shield needs to be connected to the Earth at the building entrance per ANSI/NFPA 70, the National Electrical Code (NEC), in particular Section 820.93, “Grounding of Outer Conductive Shield of a Coaxial Cable,” or in accordance with local regulation. For Audio/Video Apparatus This reminder is provided to call the CATV system installer's attention to Section 820.93 of the National Electric Code (NEC), which provides g…

Text truncated - open the document above for the full version.

Actiontec Electronics, Inc. 760 North Mary Avenue • Sunnyvale • CA • 94085 • USA Phone (408) 752-7700 • Fax (408) 541-9003 • www.actiontec.com Solutions for the Digital Life™ FCC Authorization September 13, 2013 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Actiontec Electronics, Inc., the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Angela Yao / Sr. Program Manager 408-752-7700 760 North Mary Ave., Sunnyvale, CA 94085

Actiontec Electronics, Inc. 760 North Mary Avenue • Sunnyvale • CA • 94085 • USA Phone (408) 752-7700 • Fax (408) 541-9003 • www.actiontec.com Solutions for the Digital Life™ FCC Confidential Authorization September 13, 2013 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: LNQT2200H In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Actiontec Electronics, Inc., hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Angela Yao/Sr. Program Manager Phone: (408) 752-7700 Fax: (408) 541-9003 Email: [email protected]

Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 82 of 87 FCC Part 15C/IC RSS-210 Test Report 16 Exhibit C – EUT Photographs 16.1 EUT – Front View 16.2 EUT – Rear View Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 83 of 87 FCC Part 15C/IC RSS-210 Test Report 16.3 EUT – Top View 16.4 EUT – Bottom View Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 84 of 87 FCC Part 15C/IC RSS-210 Test Report 16.5 EUT – Left Side View 16.6 EUT – Right Side View

Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 85 of 87 FCC Part 15C/IC RSS-210 Test Report 16.7 EUT – Open View 16.8 EUT – Main PCB Top View Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 86 of 87 FCC Part 15C/IC RSS-210 Test Report 16.9 EUT – Main PCB Bottom View 16.10 EUT – AC/DC Adapter

Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 10 of 87 FCC Part 15C/IC RSS-210 Test Report 4 FCC §15.247 (i), §2.1091 & IC RSS-102 – RF Exposure 4.1 Applicable Standard According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 * (100) 30 1.34-30 824/f 2.19/f * (180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Before equipment certification is granted, the procedure of IC RSS-102 must be followed concerning the exposure of humans to RF fields. 4.2 MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 S = PG/4R² Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 4.3 MPE Results Maximum peak output power at antenna input terminal (dBm): 24.39 Maximum peak output power at antenna input terminal (mW): 274.7894 Prediction distance (cm): 20 Prediction frequency (MHz): 2437 Maximum Antenna Gain, typical (dBi): 5 Maximum Antenna Gain (numeric): 3.16 Power density of prediction frequency at 20 cm (mW/cm 2 ): 0.172874 MPE limit for uncontrolled exposure at prediction frequency (mW/m 2 ): 1.728742 The device is compliant with the requirement MPE limit for uncontrolled exposure. The maximum power density at the distance of 20 cm is 0.172874 mW/cm 2 , limit is 1.0 mW/cm 2 .

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 15, SUBPART C IC RSS-210, ISSUE 8, DECEMBER 2010 TEST AND MEASUREMENT REPORT For Actiontec Electronics, Inc. 760 North Mary Avenue, Sunnyvale, CA 94085, USA FCC ID: LNQT2200H IC: 2496A-T2200H Report Type: Original Report Product Type: 802.11 b/g/n Wireless Router Prepared By: Chaoran Chu Report Number: R1307232-247 Report Date: 2013-11-07 Reviewed By: Victor Zhang EMC/RF Lead Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732-9164 Actiontec Electronics, Inc. FCC ID: LNQT2200H, IC: 2496A-T2200H Report Number: R1307232-247 Page 2 of 87 FCC Part 15C/IC RSS-210 Test Report TABLE OF CONTENTS 1 General Description ..................................................................................................................................................... 5 1.1 Product Description for Equipment Under Test (EUT) ...................................................................................... 5 1.2 Mechanical Description of EUT ......................................................................................................................... 5 1.3 Objective ............................................................................................................................................................. 5 1.4 Related Submittal(s)/Grant(s) ............................................................................................................................. 5 1.5 Test Methodology ............................................................................................................................................... 5 1.6 Measurement Uncertainty ................................................................................................................................... 5 1.7 Test Facility ........................................................................................................................................................ 6 2 System Test Configuration.......................................................................................................................................... 7 2.1 Justification ......................................................................................................................................................... 7 2.2 EUT Exercise Software....................................................................................................................................... 7 2.3 Special Equipment .............................................................................................................................................. 7 2.4 Equipment Modifications.................................................................................................................................... 7 2.5 Local Support Equipment ................................................................................................................................... 7 2.6 EUT Internal Configuration Details .................................................................................................................... 7 2.7 Interface Ports and Cabling ................................................................................................................................. 7 2.8 Power Supply List and Details ............................................................................................................................ 8 3 Summary of Test Results ............................................................................................................................................ 9 4 FCC §15.247 (i), §2.1091 & IC RSS-102 – RF Exposure .......................................................................................... 10 4.1 Applicable Standard .......................................................................................................................................... 10 4.2 MPE Prediction ................................................................................................................................................. 10 4.3 MPE Results ..................................................................................................................................................... 10 5 FCC §15.203 & IC RSS-Gen §7.1.2 – Antenna Requirements ................................................................................ 11 5.1 Applicable Standard .......................................................................................................................................... 11 5.2 Antenna List ...................................................................................................................................................... 11 5.3 Result ................................................................................................................................................................ 11 6 FCC §15.207 & IC RSS-Gen §7.2.4 – AC Line Conducted Emissions .................................................................... 12 6.1 Applicable Standards ........................................................................................................................................ 12 6.2 Test Setup ......................................................................................................................................................... 12 6.3 Test Procedure .......................................................................…
