Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
2014 Cervis, Inc. MRF450 User Manual U077.0.2-MRF450 ™ Module RF450 This document is the property of Cervis, Inc. and cannot be copied, modified, e-mailed, or reproduced without the express prior written consent of Cervis, Inc. Cervis, Inc. reserves the right to change this manual or edit, delete, or modify any information without prior notification. Operation of this module in Periodic Transmit mode requires a license. FCC Statements 15.19 – Two Part Warning This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. 15.21 – Unauthorized Modification NOTICE: The manufacturer is not responsible for any unauthorized modifications to this equipment made by the user. Such modifications could void the user’s authority to operate the equipment. 15.27 – Special Accessories This device is supplied with special accessories that include an RF adapter cable and antenna. These special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. 15.105(b) – Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Industry Canada Statements RSS-GEN 7.1.2 – Transmitter Antenna / Antenne de L'émetteur Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. This radio transmitter 7955A-MRF450 has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device. Le présent émetteur radio 7955A-MRF450 a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur. Approved Antenna List / Liste Antenne Approuvé Manufacturer Part Number Gain Impedance Nearson L324TR-440 0 dBi 50 Ohm RSS-GEN 7.1.3 – Notice / D élai This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. User Manual 2014 Cervis, Inc. i Table of Contents Table of Contents .......................................................................................................................... i List of Figures ............................................................................................................................... i List of Tables ................................................................................................................................. i Cervis Inc. Safety Precautions ................................................................................................... 1 1.0 Introduction .......................................................................................................................... 2 1.1 Features ............................................................................................................................. 2 1.2 Dimensions (mils)/Locations ........................................................................................... 3 1.3 Pinout ................................................................................................................................. 3 2.0 Installation ............................................................................................................................ 4 3.0 Tune-up Procedure .............................................................................................................. 4 4.0 Electric…
Text truncated - open the document above for the full version.
PHOTOGRAPHS - INTERNAL Cervis MRF450
Cervis LongRT™ Model: MRF450 FCC ID: LOBMRF450 IC: 7955A-MRF450
FCC / IC S Ɵ cker
LOBMRF450, Component Side, RF Shield Removed LOBMRF450, Component Side, RF Shield Installed LOBMRF450, Circuit Side
091213 Report Number: F2LQ5719-01E Rev. 1 Page 1 of 46 Issue Date: Mar. 9, 2014 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com CERTIFICATION TEST REPORT Manufacturer: Structured Mining Systems, Inc. d.b.a. Cervis Inc. 170 Thorn Hill Road Warrendale, Pennsylvania 15086 United States of America Applicant: Same As Above Product: Module Model: MRF450 FCC ID: LOBMRF450 Testing Commenced: Sept. 23, 2013 Testing Ended: Oct. 7, 2013 Summary of Test Results: Page 5 Standards: FEDERAL REGISTER CFR 47, PART 15 – RADIO FREQUENCY DEVICES • Part 15 Subpart C, Section 15.231 - Periodic operation in the band 40.66–40.70 MHz and above 70 MHz • Part 15 Subpart C, Section 15.209 - Radiated emissions limits; general requirements • Part 15 Subpart C, Section 15.35 - Measurement detector functions and bandwidths ANSI C63.4 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 2 of 46 Issue Date: Mar. 9, 2014 Evaluation Conducted by: Ken Littell, EMC Tech. Mgr. Report Reviewed by: Wendy Fuster, President F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road Damascus, MD 20872 Middlefield, OH 44062 Ph 301.253.4500 Ph 440.632.5541 Fax 301.253.5179 Fax 440.632.5542 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 3 of 46 Issue Date: Mar. 9, 2014 TABLE OF CONTENTS Section Title Page 1 ADMINISTRATIVE INFORMATION 3 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 4 3 TABLE OF MEASURED RESULTS 5 4 ENGINEERING STATEMENT 6 5 EUT INFORMATION AND DATA 7 6 LIST OF MEASUREMENT INSTRUMENTATION 8 7 FCC Part 15.231(a)(1) 9 8 FCC Part 15.231(b) 16 9 FCC Part 15.231(b)(3)(c) 37 10 15.35( c) DUTY CYCLE 41 11 PHOTOGRAPHS 48 Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 4 of 46 Issue Date: Mar. 9, 2014 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to the 2003 version of ANSI C63.4 and recommended FCC procedure of measurement of DTS operating under Section 15.231. A list of the measurement equipment can be found in Section 6. 1.3 Uncertainty Budget: Radiated Emission • Combined Uncertainty (+ or -) 2.24 dB • Expanded Uncertainty (+ or -) 4.48 dB This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. 1.4 Document History Document Number Description Issue Date Approved By F2LQ5719-01E First Issue Dec. 3, 2013 W. Fuster F2LQ5719-01E Rev. 1 Retest of field strength emissions and replacement of test data, Section 8 Mar. 9, 2014 W. Fuster Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 5 of 46 Issue Date: Mar. 9, 2014 2 SUMMARY OF TEST RESULTS Standard(s) Results CFR 47 Part 15.231(a)(1) Complies CFR 47 Part 15.231(b) / Part 15.209 Complies CFR 47 Part 15.231(b)(3)(c) Complies CFR 47 Part 15.35 Complies Modifications Made to the Equipment None Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 6 of 46 Issue Date: Mar. 9, 2014 4 ENGINEERING STATEMENT This report has been prepared on behalf of Cervis Inc. to provide documentation for the testing described herein. This equipment has been tested and found to comply with Part 15.231 of the FCC Rules using ANSI C63.4 2009 standards. The test results found in this test report relate only to the items tested. Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 7 of 46 Issue Date: Mar. 9, 2014 5 EUT INFORMATION AND DATA 5.1 Equipment Under Test: Product: Module Model: MRF450 Serial No.: N/A FCC ID: LOBMRF450 5.2 Trade Name: Structured Mining Systems, Inc. d.b.a. Cervis Inc. 5.3 Power Supply: Battery Powered 5.4 Applicable Rules: CFR 47, Part 15.231, subpart C 5.5 Equipment Category: Module 5.6 Antenna: 0dBi Omni, Vertically polarized 5.7 Accessories: N/A 5.8 Test Item Condition: The equipment to be tested was received in good condition. 5.9 Testing Algorithm: The EUT was configured to permit frequency changes from low-mid-upper transmission channel. For all tests, in a semi-anechoic chamber and on the OATS, the EUT was equipped with a 0dBi Omni antenna. Order Number: F2LQ5719 Client: Cervis Inc. Model: MRF450 091213 Report Number: F2LQ5719-01E Rev. 1 Page 8 of 46 Issue Date: Mar. 9, 2014 6 LIST OF MEASUREMENT INSTRUMENTATION Equipment Type Asset Number Manufacturer Model Serial Number Calibration Due Date Shield Room 0175 Ray Proof N/A 11645 Oct. 28, 2014 Temp/Hum. Recorder CL137 Extech RH520 CH16992 Apr. 17, 2014 OATS-3m CL017 Compliance Labs N/A 001 Nov. 30, 2013 Spectrum Analyzer CL147 Agilent E7402A MY45101241 Oct. 24, 2014 Spectrum Analyzer CL138 Agilent Technologies E4407B US41192779 Oct. 29, 2014 Receiver CL151 Rohde & Schwarz ESU40 100319 Oct. 30, 2014 Antenna 1-Chamber 0142 ETS/EMCO 3142B 9811-1330 Verified Antenna 2-OATS 0105 Sunol Sciences JB1 A101101 May 7, 2015 Pre-Amplifier 0139 Hewlett Packard 83006A 3104A00500 Feb. 20, 2014 Active 18” Loop Antenna CL082 A.H. Systems, Inc. SAS-562B 241 Sept. 6, 2014 Antenna, Horn CL098 Emco 3115 9809-5580 Nov. 30, 2013 Cable: 0.3m Low Loss CL116 A.H. Systems, Inc. SAC-26G-0.3 206 Mar. 1, 2014 Cable: 0.3m Low Loss CL117 A.H. Systems, Inc. SAC-26G-3 207 Nov. 30, 2013 Coaxial Cable CL139 Thermax M17/128-RG400 JB (Brown) Feb. 2, 2014 C…
Text truncated - open the document above for the full version.
F2LQ5719 Page 1 of 1 Dec. 3, 2013 PHOTOGRAPHS: TEST SETUP Cervis, MRF450
170 Thorn Hill Road · Warrendale, Pennsylvania · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15.231 | 450 MHz - 470 MHz | - |
